SIMULATIONBASED ACQUISITION OF SOFTWARE FOR THE DISMOUNTED LAND WARRIOR SOLDIER

1
SIMULATION-BASED ACQUISITION OF SOFTWARE FOR
THE DISMOUNTED LAND WARRIOR SOLDIER

• By
• Major James Illingworth

2
Agenda

• Introduction Background
• Focus of Project
• Evaluation Procedures
• User Jury Findings
• Key Points Recommendations

3
Introduction Background

• Land Warrior (LW) Combat System
• Dismounted Simulation Acquisition System (DSAS)
• Simulation using modified COTS software
• Combination of two applications.
• Provided an acquisition opportunity
• Hardware still being developed
• Test software interface and functionality.

4
Focus of Project

• Provide platform to evaluate LW interface
• Must replicate the functionality of LW system
• Rapid replacement of interface upon modification
  (Plug and Play)

5
Evaluation Procedures

• Utilize Subject Matter Experts (SMEs) in a User
  Jury
• Create Testing Agenda
• Look and Feel
• Ease of Use
• Functionality
• Evaluation of Feedback
• Recode interface
• Retest

6
User Jury Goals

• The goals of the User Jury was to provide
  feedback on
• New Land Warrior screen development
• Use of simulations as a training tool and
• Gather general ideas for future Land Warrior
  development.

7
Survey Sample Group Statistics

• Three main groups
• Rangers
• National Guard and
• Small Group Instructors.
• General range of Army experience.
• PV2 to SFC CPT-MAJ
• General range of computer experience.
• Novice to Advanced User

8
Survey Sample Group Statistics
9
User Jury Findings Examples

• On the Maps Screen
• Include grid reference
• Declination diagram
• Datum and contour interval
• On the Messages
• Data included that is not needed below PLT level
• Must have its own window at the Main menu level

10
User Jury Additional Findings

• Click and Drag functions common to Windows
  applications should be used in creating overlays.
• The software used in the simulation should be the
  same as the operational equipment (if possible).
  If not, then it must react/look the same.
• Input devices (cost of original equipment versus
  surrogate equipment).

11
Key Points Recommendations

• Key Points of Presentation
• Utilize SBA when presented with opportunity
• Focus the Testing Agenda on all aspects
• Utilize the SMEs from all fields.
• Recommendations
• Ensure SBA saves the time/cost/resources
• Document changes made in evaluation cycle.

12
Questions?
13
What is Land Warrior?
14
Land Warrior Delta Force Applications
LW App
DF App
15
Look and Feel
Visual Queueing
Mode Manipulation
16
Ease of Use
Click or Tab to bring up desired menu.
17
Functionality
Example Sent messages that are undeliverable
What happens?
Functionality of software Behind the Interface
results
