The ATLAS Experiment the ultimate Emc2

1
The ATLAS Experiment the ultimate Emc2
Chris Oram
2
Outline

• Einstein Emc2 , the ether
• Using Emc2 Making and annihilating particles
• Making very massive particles the LHC
• The ATLAS experiment
• Watching particles collide
• Why watch particles collide ?
• High School Physics Books 1905-2005
• What we do not understand
• What to expect how to think!

Some technical how to slides
3
Einstein

• Emc2 is the famous equation BUT what Einstein
  really did, was to say
• The speed of light is a constant
• A trivial but far reaching statement !

Vgalaxy 2.2 x 105 m/s Vsun 5 x 103 m/s
4
Einstein continued

• It meant there was NO ether
• What was this ether ???
• Well it was a theoretical postulate

5
The Ether
Einstein on Ether http//www.tu-harburg.de/rzt/rz
t/it/Ether.html

• Light is a wave waves move in a medium
• How come we see action at a distance?
• (gravity magnets)
• ?
• Postulate Ether

Theory
Postulated Measurable Speed of light variation
? Result of measurement NO variation
Experiment
6
Einstien

• Destroyed the Ether Theory
• Stated the speed of light is a constant
• Many many more things and
• Emc2

The ATLAS experiment 100 years later uses
Emc2 BUT seeks to explain mass (the m) by the
vacuum. The Vacuum and The Ether are rather
similar!
7
More on Emc2

• Two Light beams (photons) strike each other head
  on
• Each has energy E (and no mass)

8
More on Emc2

• Form 2 particles. If each has no momentum then
• m E / c 2

9
More on E m c 2

• Energy can be switched into Mass
• AND
• Mass switched into Energy

Physicists do both routinely
m
Time Reversal Invariance
m
10
More on Emc2

• If you want to make a BIG mass you need a BIG
  energy
• Ebig mbig c 2

11
BIG Energies

• ATLAS has two proton beams each with
• 7 TeV T1012

12
Getting 7 x 1012 Volts
28 Kilometre Circumference tunnel
One 600,000 Volt Kick on each rotation 1.2 x 107
Rotations (600,000 V x 1.2 x 107 7 x 10 12
V) Moving at c 3 x 108 m/sec 28,000 m
takes 9 x 10-5 sec 1.2 x 107 rotations take 103
sec 20 mins
13
Stored Energy

• 0.6 amps at 7 TeV Aircraft Carrier at 30 Knots

14
Keeping 7 TeV particles going in a circle

• Requires VERY powerful magnets 28 km worth!
• CERN engineers had to increase the maximum field
  of a mass production super-conducting magnets

15
The 28Km LHC Tunnel
16
Inside the 28Km LHC Tunnel
17
LHC two counter rotating beams collide at 4
locations!
18
The ATLAS Experiment
19
The ATLAS Experiment big by any measure

• 7000 Tonnes
• 1800 Scientists
• 15 years to build
• 35 Countries
• 500M in materials

What does it do?
20
Observes collisions

• But this collision is so small you cannot see
  it so you measure all the particles that come out

21
Observes collisions
Measure Direction, Momentum, Energy Of every
particle
22
Measure Direction

• Pixel detector has nearly 80 million channels!
• Each Pixel wafer measures 16x60mm and has 46,000
  pixels 50x400 microns

23
Measure Momentum

• Inner detector in 2 Tesla magnetic field 20000
  Gauss

100 Gauss
24
Measure Energy
3 metres of Metal
25
Observes collisions

• Summing the energies of sets of tracks you
  measure the masses of particles that exploded
  and look for new particles

26
Actual Collisions can be very complicated

• Need lots of computing power
• 8 Pbytes data per year. (G-109, T-1012, P-1015)
  8 km stack of CDs without jewel cases!

27
The GRID a world wide web of computers

• The World Wide Web was invented by particle
  physicists in order to share data more easily and
  it ended up changing the way the world uses and
  exchanges information.
• The Grid is the next step and promises to change
  the way we process information and create new
  knowledge.

28
Why do this ???

• We believe we are on the breaking point of our
  present theories we await a new Einstein
• Meanwhile we make measurements to try and find
  differences between our present theories
  predictions and reality!
• Going to the highest energies and directly
  observing new particles has historically been a
  good approach (upcoming slides).

29
Breaking Point WHY?

• The present theory has 20 free parameters, and
  is rather complicated
• Rather like the periodic table of the elements
  before we knew elements were made of a nucleus of
  Neutrons and Protons with electrons orbiting
• Rather like when Einstein gave us Emc2 100
  years ago

30
The development from large to small
Neutron Stars and nuclei are (105)3 more dense
than water. Chemistry is all about electrons!
To see small things you need high energies !
(Quantum Mechanics)
31
ATLAS
TRIUMF
The Sun
32
100 Years AGO Canadian High School Text
33
100 Years AGO Canadian High School Text (
Published 1902)

• Much on the Last page was WRONG (However
  Maxwells Theory remains accepted today.)
• Published before Einstein wrote his papers in
  1905!
• Einstein was taught this at high school!

34
Your 2005 High School Text which page is wrong?
The last page is interesting like in 1902 it
deals with the important issues of the day! I
suspect it is in these important issues (and
assumptions) the key to the new theory lies.
35
What did they not understand in 1902 ?

• Action at a distance
• Why the speed of light always measured the same
  independent of the speed of the source relative
  to the observer
• The black body spectrum
• The stability of the atom
• and a few other problems
• Out of explaining the above came
• Quantum Mechanics
• Relativity
• Modern Physics
• It changed the way we view the world !

36
What do we not understand ?

• Mass
• Quantum Mechanics and Gravity
• Dark Matter (gravity at large distances)
• Dark Energy (expanding universe)
• Why do some particles have charge 1 and others
  charge 1/3rd 2/3rds
• Why are our theories so complicated?
• Matter Anti-Matter asymmetry in universe
• Understanding this will change the way we view
  the world

37
The Standard Model of Particle Physics

• 6 Quarks (and 6 Anti-Quarks) 6 Leptons (and 6
  Anti-Leptons)
• 3 Connecting Particles the quark glue
• Photon, W, Z gluons in 3 colours
• Gravity
• Gravitino
• The Higgs

38
20 Parameters (minimum)

• 6 Quark Masses (6)
• 6 Lepton Masses (12)
• Z W Masses (14)
• Gluon Coupling (15)
• W Z Coupling (16)
• Photon Coupling (17)
• Inter-Generation Coupling (Cabibbo) (18)
• Gravity Coupling (19)
• Higgs Mass (not yet measured) (20)

39
The Higgs

• To understand the Higgs mechanism, imagine that a
  room full of politicians chattering quietly is
  like space filled with the Higgs field ...

A quasi-political Explanation of the Higgs Boson
for Mr Waldegrave, UK Science Minister 1993. When
CERN was trying to get funding for the LHC
40
The Higgs

• A well-known politician walks in, creating a
  disturbance as she moves across the room and
  attracting a cluster of admirers with each step

41
The Higgs

• This increases her resistance to movement, in
  other words, she acquires mass, just like a
  particle moving through the Higgs field...

42
The Higgs

• If a rumor crosses the room, ...

43
The Higgs

• It creates the same kind of clustering, but this
  time among the politicians themselves. In this
  analogy, these clusters are the Higgs particles.

Today on the ATLAS web page http//atlasexperimen
t.org the politician is replaced by a physicist !
44
1905 to 2005

• The combination of measurements of the very big
  and the very small is the challenge to our
  theories
• Very Big radius of the universe
• 10 billion light years 1025 metres
• Very Small wavelength of highest energy
  particle
• 1TeV 2 10-19 metres
• In my opinion the study of astronomy and particle
  physics are the studies of the frontiers of
  knowledge and thus particularly worth studying

1044
45
Conclusion

• I think we live in interesting times
• I think you will see a revolution in Science in
  your lifetime the effects will reach far beyond
  science
• I believe that measurements of the very big
  (astronomy), and the very small (particle
  physics) are essential to speeding the start of
  this revolution
• It is likely the revolution in Science will be
  in a very unexpected area, where the dogma is
  strongest today !

46
Think outside the box !
Look out for Scientific Dogma Einstein was
taught incorrect physics at School !
