Madagascar Installation

1
MadagascarInstallation

• Sergey Fomel
• University of Texas at Austin
• August 30, 2006
• Vancouver, BC

2
This Presentation

• Introductory remarks
• History
• Goals
• Design principles
• Installation and compilation
• Downloading
• Software construction with SCons
• File structure

3
Madagascar Story

• Started in 2003
• Publicly open in June 2006
• Open-source http//rsf.sourceforge.net
• Standing on SEPlib/SU shoulders
• RSF (regularly sampled format)

4
Cumulative Downloads
Registered at freshmeat.net
Vancouver School announced
5
(No Transcript)
6
Source Referral (August 2006)
7
Goal

• To make our research productive
• To make technology transfer efficient

computational experiments
8
One Week Technology Transfer
Monday Get an idea
Tuesday Implement it
Wednesday Test it
Thursday Communicate it
Friday Commercialize it
a b c
9
Madagascar Design Principles

• Document computational experiments
• Old experiments are regression tests
• New experiments become unit tests

Test Driven Development
10
This Presentation

• Introductory remarks
• History
• Goal
• Design principles
• Installation and compilation
• Downloading
• Compiling with SCons
• File structure

11
Downloading Madagascar

• Stable version
• madagascar-0.9.3
• SourceForge
• Unstable (development) version
• svn co https//svn.sourceforge.net/svnroot/rsf/tru
  nk rsf
• Update with svn update
• Commit with svn commit (developers)
• Browse at http//svn.sourceforge.net/viewvc/rsf/
• Subversion facilitates collaboration and version
  control

12
Cumulative Subversion Access
13
SCons (Software Construction)

• make replacement
• Built-in autoconf/automake functionality
• Written in
• Open-source http//www.scons.org
• Used for compiling Madagascar
• Used for managing processing flows

SCons is an easier, more reliable and faster way
to build software.
14
From Tim OReillys blog OReilly Radar
15
Installing from Source

• Unpack
• tar xvzf madagascar-0.9.3.tgz
• Prerequisites
• Install Python and SCons if necessary
• Set environmental variables
• Build
• scons config (generates config.py)
• scons install
• http//rsf.sf.net/wiki/index.php/Installation

RSFROOT root of installation PYTHONPATH add
RSFROOT/lib DATAPATH home for binary files
16
Open Source
created by scons install

• madagascar-0.9.3/
• Sconstruct
• config.py
• api/
• book/
• filt/
• user/
• pens/
• plot/
• python/ convenience Python scripts
• scons/ SCons sources

• RSFROOT/
• bin/
• lib/
• include/
• doc/
• figs/

17
Look Inside I

• madagascar-0.9.3/
• Sconstruct top software construction
• config.py created by scons config

ENV 'PATH' '/usr/local/bin/bin/usr/bin' AR
'ar' JPEG 'jpeg' PPM None CC
'gcc' CCFLAGS '-O2 -stdgnu99 -Wall -pedantic
-DNO_COMPLEX' CPPPATH LIBPATH LIBS
'm', 'rpc' XLIBPATH '/usr/X11R6/lib' XLIBS
'Xaw', 'Xt', 'X11' XINC '/usr/X11R6/include
' CXX 'g'
18
Look Inside II

• api/ API tests C/Fortran/MATLAB
• book/ reproducible research tests
• gee/ book
• ajt/ chapter/paper
• SConstruct
• paper.tex (LaTeX)
• causint/ project
• SConstruct
• conv/
• hlx/
• bei/
• geo391/

from rsfproj import Flow('data1',None,'spike
n130 k115 label1') Flow('data2','data1','causin
t') Flow('data3','data1','causint
adjy') Flow('data4',None, 'spike n130
nsp2 k110,15 mag1,-1 label1
') Flow('data5','data4','causint') Flow('data6','d
ata4','causint adjy') Flow('data7','data5','causi
nt')
19
Look Inside III

• filt/ program sources arranged by subject
• lib/ sources for rsf.h, librsf.a and API
  bindings
• SConstruct
• alloc.c
• main/ most common data manipulation programs
• SConstruct
• add.c
• proc/ processing
• imag/ imaging
• user/ program sources arranged by author
• fomels/
• slim/
• easily extensible

20
Look Inside IV

• plot/ sources for Vplot generation
• lib/ sources for rsfplot.h, librsfplot.a
• SConstruct
• axis.c
• main/ RSF to Vplot
• SConstruct
• contour.c
• test/ Vplot from source
• pens/ sources for Vplot manipulation
• main/
• SConstruct
• pspen.c Vplot to PostScript

21
Lessons

• Madagascar goal
• To make our research productive
• To make technology transfer efficient
• Multiple levels
• (Tuesday) implement main modules, C
• (Wednesday) test projects, SCons/Python
• (Thursday) communicate papers, LaTeX
• If you dont like it, please voice your concerns.
• Wiki Blog Mailing list Forums Bug
  tracking Feature requests
