An Update on the Wellsite Information Transfer Standard Markup Language WITSML

1
An Update on the Wellsite Information Transfer
Standard Markup Language (WITSML)

• Alan Doniger, POSC April 2005

2
WITSML WWW.WITSML.ORG Wellsite Information
Transfer Standard Markup Language The
right-time seamless flow of well-site data
between operators and service companies to speed
and enhance decision-making A New Open
Information Transfer Standard for the Oilfield
3

• WITSML started as a collaborative effort to
  update the widely used WITS standard for moving
  drilling data between rig and office based
  computer systems
• WITSML is designed for the standards of today's
  always on Internet environment while still
  accommodating those rigs not yet Wired
• WITSML is published and available to all to
  implement
• Real world use of WITSML is happening NOW
• The scope of practical usage is being extended
  based on practical experience and pragmatic needs

4
The Drilling Environment
Drilling Data Providers
Rig Instrumentation
Fluids Systems
Surface Logging
Coring
Surveying
Directional Horizontal Drilling Systems
Logging While Drilling
Source BakerHughes
5
Integration Value Hierarchy
Higher
Higher
Integration Automation
Work Practices
Data Practices
Data Practices
Value
Value
Data Entry, Q.C., Retrieval Tools
Data Model
Applications
Hardware
Lower
Lower
Higher
Low
Higher
Higher
Low
Complexity
Complexity
Based on ExxonMobil slide, June 04
6
BP Vision

• Automation of many manual processes in current
  Drilling Data workflows
• Contractors (Service and Drilling) automatically
  push data into our corporate data stores
• Partners can automatically pull data (Not images)
  for morning reports into their data stores
• Operators can push statutory reporting data for
  statutory reports
• Contractors can share data with one another at
  the rigsite
• A single standard to make the vision possible,
  reducing industry costs

Based on BP slide, June 04
7
Drilling Issues

• Maximize well productivity
• Minimise formation damage
• Avoid pressure problems
• Steer the drill bit
• Find and stay within hydrocarbon zone
• Requires a combination of different measurements
  from different companies and collaboration
  between different disciplines (Drilling, Geology,
  Reservoir)

Based on BakerHughes slide, June 04
8
The POSC WITSML Special Interest Group (SIG)

• The WITSML SIG is the formal user community for
  the WITSML standards.
• Membership is open to all (POSC members and
  non-member alike)
• Membership grew in 04 from 17 to 31 now 35
• The SIG recognizes requirements and needs
• The SIG is the first line of review of new and
  updated specifications
• The SIG helps promote vendor take-up and operator
  deployment

9
WITSML SIG

• Area of Interest
• the definition, movement, and storage of drilling
  data, information, and knowledge,
• especially the right time seamless flow of well
  site data between operators and service companies
  to speed and enhance decision-making.
• This group is essentially a cross-vendor,
  cross-product line user community for drilling
  applications and data storage products and
  services.
• Players
• operators, service and software providers,
  government agencies, consultancies, and POSC.

10
(No Transcript)
11
Sample WITSML Data Flow
API server(InterACT)
Source Schlumberger
12
Special Interest Group Participants

• Operators
• Statoil
• BP
• Shell
• ExxonMobil
• ChevronTexaco
• Pioneer Nat. Res.
• Hydro
• ONGC
• Total
• Regulators
• UK DTI
• US DOI

Service/Software Suppliers Baker Hughes
Landmark/Halliburton/Sperry Schlumberger Sense
Technology SDC Geologix Petrolink INT Paradigm UPE
G Pason WeatherfordOpenSpirit

• Service/Software Suppliers
• HRH Geological Services
• Smith Technologies
• IFP
• Interaction
• US Synthetic
• Knowledge Systems
• AspenTech
• Roxar
• Key Energy ServicesSeismic Micro Technology
• M/D Totco
• Geoservices

POSC special interest groups are open to all
interested parties.
13
Right-time Data
Alarms
RIG or OFFICE
Filter
Transform
WITSML
Technical Database Environment
Real-time drilling
Raw Data Archive
Service company
Technical Application Environment
Source Landmark
14
Benefits

• Improved plug and play for moving data between
  systems
• Operators reduce cost, improve vendor
  competitiveness
• Contractors reduce need to support different
  systems for different operators
• (Near) real-time, sequential data, but also
  contextual data

15
A WITSML Time Line 1980s WITS used by Amoco,
Chevron and Mobil, point-to-point serial
transfers, binary and ASCII formats, became
obsolete by late 90s 2000 Statoil and BP agree
to begin WITSML for Drilling bring in three
major service companies evolved from Statoil
DART (Java, CORBA) 2001 Funded project Version
1.0 specifications and first public seminar 2002
Early deployment Version 1.1 specifications
First commercial products Agreement to transfer
standard to POSC 2003 Version 1.2
specifications Transfer to POSC Special
Interest Group from 6 to 17 Version 1.1
commercial products SPE paper 2004 POSC
commitment to expanding WITSML to Production
Operations, Regulatory, and All Data Transfer
Uses US ePermit Collaboration evolves Stage One
begins Special Interest Group from 17 to 31
Version 1.2 commercial products 2005 - Version
1.3 release
16
RigLink WITSML

• Wellsite data to RigLink/WITSML Server
• Real time via subscription
• Batch via file transfer etc.
• WITSML API calls from 3rd Party systems

Source Baker Hughes
17
Data Objects Original, New, Updated, Draft

• Bottom Hole Assembly Run
• Capabilities
• Cement Job
• Conventional Core
• Fluids Report
• Formation Marker
• Log, Well Log (transition)
• Message
• Mud Log (updated)
• Operations Report
• Real Time (updated)
• Rig / Rig Equipment
• Server Capabilities

Sidewall Core Subscription Survey Program Target
Trajectory Trajectory Station
(updated) Tubular / Bit Record / Open
Hole Well Wellbore (update) Wellbore
Geometry Risk (new) Completion / Well Mechanical
(draft) Regulatory Permitting and Reporting
(draft) Production Volumes (draft)
18
WITSML Server API

• SOAP Interfaces defined in WSDL
• Store Interface
• GetFromStore()
• AddToStore()
• UpdateInStore()
• DeleteFromStore()
• Publish/Subscribe Interface
• Subscribe()
• Both Interfaces
• GetVersion()
• GetCapability()

19
SiteCom Overview
To next level, corporate data mgmt System OpenWir
e
Source Sense Intellifield
20
Technologies

• Internet standards driven / Hardware software
  platform independent
• XML (eXtensible Markup Language) xsd, (XML
  schema definition)
• WITSML Server Application Programming Interface
  (API)
• XML Specification of data objects
• A formal and validated Dictionary and Grammar
• World Wide Web-compatible / Web services
• HTTP, SOAP WSDL, XML
• Broad coverage of mainly drilling related data
• Well, trajectory, drill string, wellbore,
  reports, logs, real time data
• Designed to support drilling workflows, with or
  without network links
• WITSML Server Behavior Profiles
• Data Transfer, Data Management, Data Archive

21
Web Services

• Using XML to communicate between computer systems

Web Server
Client
HTTP POST an XML File
Receive XML File
ltSOAP-ENVBodygt ltmGetTradePricegt
ltsymbolgtBHIlt/symbolgt lt/mGetTradePricegt lt/SOAP
_ENVBodygt
ltSOAP-ENVBodygt ltmGetTradePriceResponsegt
ltpricegt36.13lt/pricegt lt/mGetTradePriceRes
ponsegt lt/SOAP_ENVBodygt
Source Baker Hughes
22
A Service Companys View

• Open development environment
• industry co-operation at its best
• Operators driving internal work process
  improvements with take-up of WITSML
• Enhanced vendor independence
• Technology being implemented to improve internal
  service company technology and processes

23
Whats Happening and Whats Next?

• CURRENT RELEASES
• Version 1.2 Released in early 2003
• Version 1.3 Released in March 2005
• FUTURE PLANS
• Version 1.3 Clarifications (published as
  identified)
• Version 1.3.1 (release late 2005)SIG Meetings
  and Public Seminar, Houston, May 10-12
• EXPANSION AND INTEGRATION
• During 2004, existing and new POSC data transfer
  standards were adapted as part of a broader based
  family of standards based on WITSMLs technical
  architecture and characteristics
• WellPathML ? well, wellbore, trajectory and
  trajectoryStation, WellLogML ? wellLog,
  WellSchematicML ? completion,
• ProductionML ? production

24
May 10-12 Meetings

• Technical Teams
• Address feedback and deferred issues
• Use Case and Requirements Team
• Address possible future areas of focus drilling
  reports, completions, environmental, well
  services, well stimulation, service rig
  reporting.
• Implementation Support Team
• First meeting. Intended for those supporting
  WITSML-enabled environments to share lessons
  learned and current issues and challenges.
• Public Seminar
• Current reports from actual experiences and plans
  from oil companies, service companies, and
  software companies.

25
Version 1.3 Highlights
26
WITSML Version 1.3 Highlights

• General
• Data object (schema) and Server (API)
  specifications are now independent and will
  evolve separately
• Server behavior profiles defined Data Transfer,
  Data Management, and Data Archive
• Many small corrections and enhancements based on
  usage feedback

27
WITSML Version 1.3 Highlights

• Improvements
• Consistency realtime and log objects
• Tighter constraints on individual values
• Mud log upgrades to handle time logs
• Log enhanced to handle array data and multiple
  passes
• wellLog
• will replace WellLogML

28
WITSML Version 1.3 Highlights

• Additions
• Composite object schema
• New measure types with enumerated Unit of Measure
  values
• Well datum capability
• New risk object
• Well Path (planned, measured, calculated)

29
Extending WITSML

• WITSMLs original mandate for wellsite to
  operator (contextual and real-time) data
  transfers can be reused for many EP data
  exchange work flows
• to partners, to labs, and more
• All using a common architecture, common
  terminology, maximal commercial product and
  service incentive, etc.

30
Extended WITSML and the POSC Special Interest
Groups WITSML Special Interest Group (1)
Drilling uses (2) Overall architecture IntOPS
Special Interest Group (1) Production
Operations uses eRegulatory Special Interest
Group - (1) Regulatory (Permitting and
Reporting) data transfer uses Practical Well Log
Standards Special Interest Group (1) Well Log
data transfer uses wireline and LWD Data Store
Solutions Special Interest Group (1) Reference,
Geoscience, Engineering, Partner, and other data
transfer uses
31
Why has the WITSML initiative been
successful?Some lessons learned / best practices

• The Right Initial Players - clear focus
• BP Statoil with Baker, Halliburton,
  Schlumberger, and NPSi
• Strong Commitment
• Initial funding by oil companies Oil service
  companies remain engaged after initial delivery
• Effective Processes
• Practical, incremental approach
• Clear focus on target outcomes - through
  implementation
• Frequent communications - steering technical
  teams
• Choice of Technologies
• XML, SOAP
• Comprehensive Output and Documentation
• XML Schemas Server API sample implementation
• Openness / Evolution
• Public seminars and presentations
• Transfer to POSC in early 03 -- commercially
  neutral custody, publication, promotion and
  evolution

32
What we must do in the future?

• Maintain enthusiasm for the vision
• Continue to involve interested and committed,
  knowledgeable people
• Address use cases that add real (quantifiable to
  management) value
• Keep the spirit of trust and cooperation between
  competitors
• Have oil companies supply chain management
  provide contractual re-enforcement
• Increase cooperation among different domains to
  minimize duplication working with similar types
  of data and to maximize re-use of work already
  done

Based on BP slide, June 04
33
Alan Doniger, POSC Chief Technology
OfficerEmail Doniger_at_POSC.orgPhone 1 713
267-5124Fax [phone]http//www.posc.org
and http//www.witsml.org
34
History
35

• History
• 1980s WITS real-time binary formats defined
• 1990s as Internet and related technologies
  became available, new solutions emerged but
  separately
• Statoil developed Drilling Automation Real Time
  (DART)
• 2001 DART evolved into the multi-company WITSML
  effort by BP and Statoil with BakerHughes,
  Halliburton, and Schlumberger
• 2002
• Version 1.1 completed
• Public Seminar and SIG Meetings in Stavanger

36

• History
• 2003
• Version 1.2 completed
• WITSML transfer for custody and evolution to POSC
• Public seminar and SIG meetings in Aberdeen and
  Houston
• 2004
• Version 1.3 completed
• POSC announced extension of the WITSML
  architecture to support all POSC data exchange
  standards.
• Public seminar and SIG meetings in Calgary and
  Paris
• Regional SIG meetings in Stavanger and Houston

37
Special Interest Group
38

• SIG Organization
• Steering Committee
• Technical Teams
• Drilling data transfer content
• Overall architecture / infrastructure
• Use Case and Requirements Team
• Future planning and requirements determination
• Implementation Support Team
• New in 05

39
WITSML SIG

• Whats Next?
• Promote use
• Continued support and evolution
• Create new Implementation Support group
• Expand scope
• Completions
• Production Operations
• Fluid Properties
• Well Services (Workover Rigs)

40
Recent News
41
5th Public Seminar and SIG Working Meetings Held
in Europe

• Venue IFP, Paris, France
• Dates Seminar, Nov. 4 Working Meetings Nov. 2-3
• Oil Co. Presenters BP, ChevronTexaco, Statoil,
  ExxonMobil
• Regulator UK
• Service Co. Schlumberger, Baker Hughes, Sense
  Intellifield, Paradigm, Geologix, Smith, US
  Synthetic, KSI, and Aspentech
• SIG updates on current and future work efforts.
• Next May 10-12, Houston, Texas USA hosted by
  ChevronTexaco

42
WITSML SIG Membership Tops 30 Organizations

• The number of service and operator organizations
  making use of the WITSML Standards continue to
  grow. More have joined as SIG members.
• The SIG began 04 with 17 members and ends 05
  with 31 members.
• Recent additions to the SIG include Total, US
  Department of the Interior, HRH Geological
  Services, Smith Technologies, IFP, Interaction,
  US Synthetic, Knowledge Systems, Aspentech.
• And Roxar, Key Energy Services, and M/D Totco

43
Mud Log Sub-Teams Work Evolves Into Formal
Change Requests

• In Sep. 03, it was agreed to review and enhance
  the mud log data specifications of WITSML.
• A sub-team, led by ExxonMobil, worked throughout
  04 leading to a set of change requests
  integrated into WITSML Version 1.3.
• ExxonMobil is leading a pilot project to test the
  mud logging work flow. Other organizations are
  invited to joint his pilot test or to organize
  tests of their own.

44
Version 1.3 On-Track for Year-End Release

• The previous release of the WITSML Standards was
  made in early 03 as Version 1.2. In the fall of
  03, we set a target to release an enhancement
  version by year-end 04.
• A list of issues was managed throughout the year.
  Individual issues were resolved as
  clarifications, minor fixes, or larger issues. By
  the fall WITSML meetings in Nov. 04, almost all
  pending issues were resolved.
• The final review period for the SIG and the
  public will close at the end of Jan. 05.
• After post-review issue resolution, Version 1.3
  was finalized and published in mid-March 05.

45
Well Path and Well Log Data Transfer Standards

• In early 04, POSC stated the policy of
  integrating all data exchange standards in an
  extended family of WITSML Standards.
• One area of enhancement provides support for
  wellbore paths and trajectories planned and
  actual measurements and calculated results.
• A second area of enhancement extends support for
  well log data to include wireline as well as LWD.

46
Use Case and Requirements Team Looks to the Future

• At the WITSML meetings in Paris in Nov. 04, the
  following were identified as candidate future
  subjects.
• Daily Drilling Reporting (BP, ChevronTexaco, and
  Hydro expressed interest)
• Completions and Well Mechanical (ChevronTexaco
  has used a draft version of this Statoil,
  ExxonMobil, and Hydro are interested)
• HSE Reporting
• Operational Data Reporting to ERP Systems
• Distributed Temperature Surveys (underway as an
  IntOPS SIG effort)
• Well Services has been proposed and approved for
  consideration in 05

47
Product Certification Program Will Start in
Early 05

• A Certification Program for POSC Standards is
  being beta-tested for WITSML enabled products.
  This is a self-certifying program, in which
  product vendors fill out a form indicating the
  nature of their products use of WITSML.
• Products in the program may use a special logo
  and the phrase, POSC WITSML Certified Product
  in literature and on packaging.
• A related program allows oil companies to be
  designated as Registered Users of the WITSML
  Standard.
