Agenda

• About Altronix
• Fuses Vs. PTCs
• Determining Power Wiring Requirements
• Challenges Solution
• Product Overview
• System Examples

3
About Altronix

• Founded 1983
• US owned and operated. HQ in Bklyn, NY
• Leading Designer Manufacturer of Commercial
  Industrial Grade Power Supply Solutions
• Products for Security, Automation Fire
  Access Control
• Lifetime Warranty
• ISO 9001 2000 Registered Firm
• TOA now US distributor for select CCTV products

4
Why Use Altronix?

• Centralized power distribution offers neater
  installation
• Easier maintenance
• More robust/stable power hub
• More secure (key-lock entry)
• Individually fused outputs. Master
  breaker/switch
• UL/CE Listed
• Durable metal housing
• No wall-warts
• More reliable and professional installation

5
Power Supply Design Check List

• Does the system require AC, DC or both?
• What is the manufacturers recommended operating
  voltage range (tolerance) of the equipment?
• What is the total current draw (load) of the
  system and/or each zone being powered in both
  stand-by and alarm?
• How many outputs does the system require?
• Is battery back-up necessary?
• Where is your power source to be located?

6
Output Power Protection - Fuses
Fuses protect electrical devices and components
from over-currents and short circuits that occur
in improperly operating circuits. When
current reaches a predetermined magnitude for a
fixed period of time, current flow is interrupted
through the melting of an internal element.
7
Output Power Protection - Fuses

• Pros
• Fast acting and accurate.
• A one (1) amp fuse will blow at 1.25 amp - 1.5
  amp, in approximately 1 second.
• Cons
• They are designed for one time use and must be
  replaced.

8
Output Power Protection - PTCs
A Positive Temperature Coefficient Resistor
(PTC), acts as a type of circuit
breaker. As the PTCs current rating is
exceeded it slowly heats up until the temperature
threshold is reached causing a dramatic increase
in resistance, which in effect opens the circuit.
It will reset itself after overload is removed
and the device cools down.
9
Output Power Protection - PTCs

• Pros
• Provides Class 2 Rated Power Limited Outputs.
• Device is reusable.
• Cons
• Temperature sensitive.
• Not an accurate device.
• In some cases the slow and inaccurate response
  could
• jeopardize delicate electronic equipment.
• Note When used where ambient temperatures are
  too high PTCs will trip prematurely. When used
  where ambient temperatures are too low the PTCs
  trip will be delayed.

10
TOA CCTV Power Requirements
11
Calculating Maximum Wire Runs
Common Wire Gauges The common U.S. wire gauges
(called AWG gauges) refer to size of copper wire.
12
Calculating System Power Demands

• Formula
• Power (Watts / VA) Voltage (Volts) Current
  (Amps)
• Example
• 100VA 24VAC 4.17 amp
• VA is power in Watts described for AC systems.
• 100VA 100 Watts
• Formula
• Voltage (Volts) Resistance (Ohms) Current
  (Amps)
• Example
• 12 Volts 300? .04 Ampa (40mA)
• Note 1,000 Milliamps (mA) 1 Amp

13
Calculating Maximum Wire Runs

• A circuit with a total current draw of 3 Amps
  and an allowable Voltage drop of 2 Volts on
  a 14 gauge wire.
• Allowable Voltage Drop ? Total Current Draw
  Device Resistance
• Resistance ? Wire Resistance Total Resistance
• Total Resistance x 1000 ft. Maximum Wire Run
• 2 Volt Drop ? 3 amp .66 ? (device resistance)
• .66? (device resistance) ? (5.05? (wire
  resistance) .1306? (total resistance)
• (2.525? x 2 5.05 ?)
• .1306? (total resistance) x 1000 ft. 130.6 ft.
  (maximum wire run).

14
Calculator Tool
Calculate
2.5
2.4
15
150
Calculate
30
24
19.2
1.25
Calculator tool is located on the Altronix
website and product CD.
15
Indoor AC Camera Installation

• Challenge
• Selecting power for indoor fixed and PTZ
  cameras.
• Camera/PTZ Specifications
• Input voltage 24VAC/28VAC.
• Total load range 500mA 5 amp.

16
Indoor AC Camera Installation

• Altronix Solutions
• Centralized power supply unit
• for multiple cameras.
• Benefits
• Wall mount design.
• Flexible.
• Reliable.
• Cost effective.
• Agency approvals.

Wall Mount
AC
AC
AC
AC
17
Outdoor AC Camera Installation

• Challenge
• Selecting power for outdoor domes.
• Camera, PTZ, Heater/Blower Specifications
• Input voltage 24VAC/28VAC.
• Total load range 2 amp 7 amp.

18
Outdoor AC Camera Installation

• Altronix Solutions
• Power supply unit installed at each dome.
• Decentralized power supply unit for several
  domes.
• Benefits
• Reduces labor by eliminating long wire runs.
• NEMA 4 / IP 65 rated.
• Simple to install.
• Provides power for IR
• illuminators.
• Cost effective.
• Agency approvals.

Power Supplies by Altronix
19
Indoor DC Camera Installation

• Challenge
• Selecting power for indoor fixed and PTZ
  cameras.
• Camera/PTZ Specifications
• Input voltage 12VDC.
• Total load range 500mA 1.5 amp.

20
Indoor DC Camera Installation

• Altronix Solutions
• Centralized power supply unit
• for multiple cameras.
• Benefits
• Wall mount design.
• Flexible.
• Reliable.
• Cost effective.
• Agency approvals.

Wall Mount
DC
DC
DC
DC
21
Outdoor DC Camera Installation

• Challenge
• Powering an outdoor housing with a 24VAC
  heater/blower along with a 12VDC camera
  from a single 24VAC input.
• Outdoor Housing Specifications
• Input voltage
• Camera 12VDC.
• Heater/blower 24VAC.
• Total load range
• Camera 250mA 1 amp.
• Heater/blower 750mA 3 amp.

22
Outdoor DC Camera Installation

• Altronix Solutions
• Local 24VAC power supply unit with a 12VDC
  voltage
• regulator at each housing.
• Decentralized 24VAC power supply unit for
  several housing with a 12VDC voltage regulator
  in each housing.
• Benefits
• Separate DC power supply not needed.
• No additional wiring required.
• Simple to install.
• Flexible.
• Reliable.
• Cost effective.

23
A Look at the Panel

• Camera Power Outputs

• Independent Line Fuses

• Power Mains Input

24
CCTV 4 Out AC Wall Mount

• ALTV244UL
• 24VAC _at_ 3.5 amp (85VA) or
• 28VAC _at_ 3 amp (85VA) supply current.
• Power ON/OFF switch.
• ALTV244175UL
• 24VAC _at_ 7 amp (170VA) or
• 28VAC _at_ 6.25 amp (175VA) supply current.
• Illuminated power disconnect circuit breaker
• with manual reset.
• Features
• Input 115VAC.
• Four (4) individually fuse protected outputs.
• Surge suppression.
• AC power LED.
• Enclosure and transformer.

ATV244UL

• Add suffix CB to model number for Class 2
  Rated PTC protected outputs.
• Add suffix 3 to model number for factory
  Installed 3-wire line cord.

25
CCTV 8 Out AC Wall Mount

• ALTV248UL
• 24VAC _at_ 3.5 amp (85VA) or
• 28VAC _at_ 3 amp (85VA) supply current.
• Power ON/OFF switch.
• ALTV248175UL
• 24VAC _at_ 7 amp (175VA) or
• 28VAC _at_ 6.25 amp (175VA) supply current.
• Illuminated power disconnect circuit breaker
• with manual reset.
• Features
• Input 115VAC.
• Eight (8) individually fuse protected outputs.
• Surge suppression.
• AC power LED.
• Enclosure and transformer.

ATV248UL

• Add suffix CB to model number for Class 2
  Rated PTC protected outputs.
• Add suffix 3 to model number for factory
  installed 3-wire line cord.

26
CCTV 8 Out AC Wall Mount
ALTV248600UL

• ALTV248300UL
• 24VAC _at_ 12.5 amp (300VA) or
• 28VAC _at_ 10 amp (280VA) supply current.
• Illuminated power disconnect circuit breaker
• with manual reset.
• ALTV248600UL
• 24VAC _at_ 25 amp (600VA) or
• 28VAC _at_ 20 amp (560VA) supply current.
• Illuminated power disconnect circuit breaker
• with manual reset.
• Features
• Input 115VAC.
• Eight (8) individually fuse protected outputs.
• Surge suppression.
• AC power LED.
• Enclosure and transformer.

• Add suffix CB to model number for Class 2
  Rated PTC protected outputs.
• Add suffix 3 to model number for factory
  installed 3-wire line cord.

27
CCTV 16 Out AC Wall Mount

• ALTV2416ULX
• 24VAC _at_ 7 amp (170VA) or
• 28VAC _at_ 6 amp (170VA) supply current.
• Power ON/OFF switch.
• ALTV2416300UL
• 24VAC _at_ 12.5 amp (300VA) or
• 28VAC _at_ 10 amp (280VA) supply current.
• Illuminated power disconnect circuit breaker
  with manual reset.
• ALTV2416600UL
• 24VAC _at_ 25 amp (3600VA) or
• 28VAC _at_ 20 amp (580VA) supply current.
• Illuminated power disconnect circuit breaker
• with manual reset.
• Features
• Input 115VAC.
• Surge suppression.
• Sixteen (16) individually fuse protected
  outputs.
• AC power LEDs.
• Enclosure and transformer.

ATV2416ULX

• Add suffix CB to model number for Class 2
  Rated PTC protected outputs.
• Add suffix 3 to model number for factory
  installed 3-wire line cord.

28
CCTV 32 Out AC Wall Mount

• ALTV2432300UL
• 24VAC _at_ 12.5 amp (300VA) or
• 28VAC _at_ 10 amp (280VA) supply current.
• Illuminated power disconnect circuit breaker
• with manual reset.
• ALTV2432600UL
• 24VAC _at_ 25 amp (600VA) or
• 28VAC _at_ 20 amp (560VA) supply current.
• Illuminated power disconnect circuit breaker
• with manual reset.
• Features
• Input 115VAC.
• Thirty-two (32) individually fuse protected
  outputs.
• Surge suppression.
• AC power LEDs.
• Enclosure and transformer.

ATV2432600UL

• Add suffix CB to model number for Class 2
  Rated PTC protected outputs.
• Add suffix 3 to model number for factory
  installed 3-wire line cord.

29
CCTV 4 Out DC Wall Mount

• ALTV615DC4UL
• 6VDC to 15VDC field adjustable.
• 2.5 amp supply current.
• Four (4) Class 2 Rated fuse protected power
  limited outputs.
• Power ON/OFF switch.
• Filtered and electronically regulated outputs.
• AC input and DC output power LEDs.
• Operates from plug-in transformer, which
  eliminate expensive licensed electrician.

ATV615DC4UL
30
CCTV 8 Out DC Wall Mount
ATV615DC8UL

• ALTV615DC8UL
• Input 115VAC.
• 6VDC to 15VDC field adjustable.
• 4 amp supply current.
• Eight (8) Class 2 Rated fuse protected power
  limited outputs.
• Power ON/OFF switch.
• Filtered and electronically regulated outputs.
• AC input and DC output power LEDs.
• Enclosure and transformer.

• Add suffix CB to model number for Class 2
  Rated PTC protected outputs.
• Add suffix 3 to model number for factory
  installed 3-wire line cord.

31
CCTV 16 Out DC Wall Mount

• ALTV615DC416UL
• 4 amp supply current.
• Sixteen (16) individually fuse protected
  outputs.
• ALTV615DC616UL
• 6 amp supply current.
• Sixteen (16) individually fuse protected
  outputs.
• Features
• Input 115VAC.
• 6VDC to 15VDC field adjustable.
• Illuminated power disconnect circuit breaker
  with manual reset.
• Filtered and electronically regulated outputs.
• AC and DC output power LEDs.
• Enclosure and transformer.

ALTV615DC416UL

• Add suffix CB to model number for Class 2
  Rated PTC protected outputs.
• Add suffix 3 to model number for factory
  installed 3-wire line cord.

32
CCTV 8 Out AC Outdoor Units

• WPTV248UL
• 24VAC output rated _at_ 3.5 amp (85VA)
• or 28VAC output rated _at_ 3 amp (85VA).
• Eight (8) fuse protected non-power limited
  outputs
• WPTV248175UL
• 24VAC output rated _at_ 7 amp (175VA)
• or 28VAC output rated _at_ 6.25 amp (175VA).
• Eight (8) fuse protected non-power limited
  outputs
• WPTV248300UL
• 24VAC output rated _at_ 12.5 amp (300VA)
• or 28VAC output rated _at_ 10 amp (280VA).
• Eight (8) fuse protected non-power limited
  outputs
• Features
• Input 115VAC.
• Illuminated power disconnect circuit breaker
  with manual reset.
• Surge suppression.
• NEMA 4 rated enclosure for outdoor use.

WPTV248300UL
33
Plug-in Transformer

• TP2450
• UL Listed
• 24VAC/50VA (2.1 amp) supply current.

34
System Example 1

• 4- Indoor PTZ Domes . Max cable run is 300ft
• PTZ 1A x44A max run (16ga)300ft

ALTV244175UL
35
System Example 2

• 8 Cameras 4- Outdoor PTZ Domes 4 fixed VP
  Domes. PS mounted indoors. Max cable run is 300ft
• PTZ 2.8A x411.2A max run (12ga)300ft
• VP domes 300mA x41.2A max run (20ga) 400ft

ALTV248300UL
36
System Example 3

• 12 Cameras 4- Outdoor PTZ Domes 4 fixed
  Outdoor VP Domes w/heaters. 4 fixed Indoor VP
  Domes. PS is mounted indoors. Max cable run is
  400ft
• PTZ 2.8A x411.2A max run (10ga)400ft
• VP domes 300mA x 41.2A max run (20ga) 400ft
• VP domes w/heater above plus .93A x 43.75A
  Max run (16ga)400ft
• Total current 16A

ALTV2416600UL
37
System Example 4

• 12 Cameras 4- Outdoor PTZ Domes 8 fixed
  Outdoor VP 4 fixed Indoor 12V Mini Domes. PS is
  mounted indoors. Max cable run is 300ft
• PTZ 2.8A x411.2A max run (12ga)300ft
• VP domes 300mA x 82.4A max run (20ga) 300ft
• 12V Mini domes .12A x 4.5A Max run
  (22ga)300ft
• Total current 14A
• Add 4 VR-12T to mini domes

ALTV2416600UL
VR1
VR1
VR1
VR1
38
Contact Info [phone] www.altronix.com
E-mail info_at_altronix.com TOA Product
Support [phone]
39
Thank You
