California Energy Commission

1
California Energy Commission T-24 Standards
2009 Effective January 1, 2010
Presented by Caecilia Gotama P.E., LEED A.P.,
Principal Gotama Building Engineers, Inc.
2
Sustainable development is development which
meets the needs of the present without
compromising the ability of future generations to
meet their own needs. - Gro Harlem
Brundtland, World Commission on Environment and
Development, 1987
3
Introduction to the CEC
Introduction to the CEC

• Established in 1978 to reduce Californias
  Energy Consumption.
• The 2008 Standards are the 13th official
  revision since the code inception.
• Has saved 53 billion in electricity and
  natural gas costs since 1978.
• Estimated savings of an additional 23 billion
  by 2013.

Source www.energy.ca.gov/title24/
4
Components of T24
5
Architectural

• Walls
• Wraps
• Fenestration
• Roofing

6
Envelope Highlights
Source 2008 Building Energy Efficiency Standards
- Table 151-B
7
Basics to Electrical Title 24

• Three basic methods to calculating lighting
  requirements
• - Complete Building Method
• - Area Category Method
• - Tailored Method
• Added allowances for controls, emergency lighting
  or specific lighting usages.
• Further requirements for day lit areas and
  certain room sizes.

8
How Electrical T24 Works!
Total Wattage Installed 59W x 3 fixtures
177 W Total Room Square Footage 130 sq.
ft. Lighting Power Density (LPD) 177W/130sqft
1.36 W/sq. ft. Allowable LPD for office
1.1 W/sq. ft. Allowable LPD for conference
room 1.4 W/sq. ft.
Source 2008 Building Energy Efficiency Standards
- Table 146
9
Electrical Indoor Lighting Density

• Offices
• Parking Areas
• Retail
• Track Lighting

10
List of Allowed Lighting Changes
Source 2008 Building Energy Efficiency Standards
- Table 146
11
Electrical Residential Lighting

• LED Lighting
• Kitchen Lighting
• Permanent Night Light
• Cabinet Lighting

12
Lighting Control Highlights

• Astronomical time clock features must maintain
  its time parameters for 7 days after power
  failure.
• Occupancy sensors shall not have override
  switches.
• Dimmers must reduce power consumption by minimum
  65.
• Photo sensor calibration must be remote from
  actual sensor to avoid calibration influence.
• Multi-level occupancy sensors shall be capable of
  turning all lights off by the occupant. First
  stage shall operate 30-70 of the lights.

Source 2008 Building Energy Efficiency Standards
Section 119
13
Electrical Residential Lighting Controls

• High and Low Efficacy Lighting
• Exhaust Fan and Lighting
• Outdoor Lighting

14
Exterior Lighting Highlights

• Expanded on allowable usage LPDs for specific
  applications.
• Provided tradeoffs between exterior LPDs.
• Calculations will be determined by combined
  total of hardscape areas, specific applications,
  and local ordinances.
• Removed Signage from exceptions list.

Source 2008 Building Energy Efficiency Standards
Section 147
15
Mechanical System Highlights

• HVAC system Efficiencies 1/1/10
• Domestic hot water re-circulating loop
• Setback Thermostats
• Demand Control Ventilation
• DDC Controls must have load shedding capabilities

6
CO2
3
16
Mechanical

• Residential Thermostat
• Outside Air Supply
• Energy Limitation for Central Air System

17
Plumbing Water Heating

• Automatic Air Release Valve
• Check Valve
• Hose Bibb for Bleeding Air from Pump
• Isolation Valve at Each Side of Pump

18
Questions and Answers
