Overview

1
New features in TRNSYS 16

• Overview

2
Presentation Outline

• This presentation (Michaël)
• TRNSYS package
• Solver, utility routines (KERNEL)
• Components (TYPES)
• Creating distributable applications (TRNSED)
• More details on
• The new DLL architecture (Dave)
• IISiBat 4 (Werner)
• Multizone Building PREBID / Type 56
  (Torsten)
• Add-ons
• TRNFLOW, SimCad, TRNSYSLite, TESS Libraries

3
We are listening to you!

• User Survey in May 2002
• Results presented at the 2002 Belgian users day
• Watch for the user request icon!

4
Enhanced TRNSYS Package

• Improved usability, better integration
• IISiBat ? Simulation studio, central point
• Improved documentation (How Tos)
• Project templates
• New applications in IISiBat (e.g. interactive
  data input)
• Up-to-date documentation
• Latest version always available on the TRNSYS web
  site
• You will still get the printed manuals
• Improved error handling
• More flexibility in the TRNSYS Kernel
• IISiBat will tell you about warnings / errors

5
TRNSYS 16 Kernel

• Improved numerical solver
• New solver with numerical relaxation
• Improved numerical precision
• Double precision variables
• Small time steps (1 sec)
• Clean coding practices
• Implicit none
• Data modules instead of common blocks
• New error message handling
• Separate routine
• Types send Error number OR string

6
TRNSYS 16 Kernel (2)

• DLL architecture
• Add a new component drop a DLL in a folder
• Types written in any language!
• Call to external programs
• Call to EES
• More than one component
• Call to Matlab

7
Standard Component Library

• Combined Data Reader/Solar Radiation Processor
• Very frequent error cause
• Hydrogen Systems Components
• HYDROGEMS Library included in standard package
• Improvements to HYDROGEMS
• New SOFC model
• Improved thermal modeling
• Improved control library
• PID controller
• 5-stage thermostat

8
Standard Component Library

• New HVAC components
• Proportional Furnace
• Variable Speed Pump
• New Absorption Chiller Model
• Etc.
• Enhancements to existing components
• More flexibility for data reading
• More robust Storage Tank model (Type 60)

9
TRNSED

• Improved navigation inside the TRNSED file
• Multiple windows or HTML-like anchors
• Clickable areas in pictures
• Improved usability for developers
• Menus to insert TRNSED features (e.g. check box)
• Recallable default values
• Interaction between TRNSED variables
• E.g. selecting a line in a pull-down menu will
  change another displayed variable

10
DLL Architecture
TRNSYS 15
TRNSYS 16
11
DLL Architecture what is the advantage ?

• Memory issue trnlib.dll is getting too big.
• Only load the Types that are needed.
• Many non-standard libraries.
• Transsolar no-standard types, TESS Libraries,
  Hydrogems, User Components.
• Allows for easier updates.
• Non Fortran Language Types may be used.
• Shorter recompilation time.

12
DLL Architecture how does it work ?

• After reading the deck, TRNSYS calls subroutine
  LoadLibrary.
• LoadLibrary searches the UserLib directory for
  DLLs and loads any that are found.
• LoadLibrary searches each DLL for exported
  subroutines that have Type in their name.
• LoadLibrary compiles a list of pointers to each
  exported subroutine.
• Instead of calling Types, TRNSYS calls each
  pointer in the list.

13
DLL Architecture what do I need to do ?

• One new line of code must be added to each Type

!DECATTRIBUTES DLLEXPORT TYPExxx
14
DLL Architecture what are the disadvantages ?

• Setting up a Compaq Visual Fortran workspace is
  more complicated.
• TRNSYS now comes with a ready made workspace.
• Debugging in the Developer Studio is more
  complex.
• Be careful of which project is active when you
  recompile.
• You can only set breakpoints in the active
  project.

15
IISiBat 4Plans for TRNSYS 16

• New, DLL-based software architecture optimized
  for Windows XP/ME (but still supporting Windows
  95, NT, 2000)
• New equipment-oriented features
• Better integration of the building model (better
  connection with PREBID / TYPE 56)
• New connection editor
• New wizards
• New developer in the team
  Paul SETTE

16
IISiBat 4 New equipment-oriented features
IISiBat 3
IISiBat 4
Information and real flow engineers point
of view
Information flow computer scientists view
f(i)
f(i)
Input-Output logic
Network logic
17
SimSol New wizards (1)

• Integration of tools from the SimSol project(cf.
  article by Dominique Caccavelli)

18
SimSol New wizards (2)

• Interactive mask editor for type 68

19
SimSol New wizards (3)

• New profile editor for type 14

20
SimSol New wizards (4)

• Others ?

21
SimSol New wizards (5)
22
IISiBat 4Divers

• Possibility to define UNIT numbers
• Automatic assignment of Logical Units
• Allow to customize deck style
• And ?

__________________________________________________
________________________________________________
__________________________________________________
____________ ____________________________________
____________________________________________ ____
__________________________________________________
__________________________ ______________________
__________________________________________________
________ ________________________________________
________________________________________
23
cooled ceilingNew Features of TYPE 56

• Integration of a cooled ceiling model in TYPE56
• according to norm for cooled ceiling tests (DIN
  4715-1)

24
cooled ceiling New Features of TYPE 56

• advantages
• integrated in TYP56
• heat exchange with zone is taken into account
• heat transfer to the fluid is taken into account

• Library of cooled ceilings tested and available
  on the market

25
Two band model for windows New Features of TYPE
56

• currently one band model for windows

26
Two band model for windows New Features of TYPE
56

• New Two band model for windows

27
cooled ceiling New Features of TYPE 56

• automatic segmentation (internal Loop input
  /output for TYPE56)

• minimum specific mass flow needed for linear
  approximation of e-function
• gt several serial segments are needed. Now these
  segments are connected
• automatically (Tout1Tin2, Tout2Tin3,
  mflow1mflow2mflow3)

28
cooled ceiling New Features of TYPE 56

• Demands from the user survey
• Include balance checks for outputs
• improve Libraries (for schedules, gains)
• rename or delete a type that has been created
• .......
• ......
• ......
