Software Independent Verification and Validation (IV

1
Software Independent Verification and Validation
(IVV) An Agency Overview

• Kenneth A Costello
• IVV Program Lead Engineer

GSFC Systems Engineering Seminar Series 12 Sep
2006
2
Agenda

• A Quick IVV Facility/Program History
• The Software Crisis
• IVV/NASA IVV
• Forming an IVV Project
• IVV Relationships
• Closing

3
Setting the stage A History
05/03 NASA Executive Council makes IVV an Agency
OSMA Program
1996 Facility Omnibus contract Enabled IVV
across all NASA Projects
06/99 Senior Management Council IVV mandate
for all NASA software
04/94 Space Station Program Implements IVV
through Facility
05/88 Space Shuttle Program Implements IVV
10/03 IVV Funding changed to Corporate GA
1991
2004
1996
1993
1999
1988
focusresearch
08/01 NPD 8730.4 Software IVV Policy
08/05 NPD 2820.1 Software Policy
focusIVV
04/96 Facility transitioned to AMES Research
Center
07/00 Facility transitioned to Goddard Space
Flight Center
42
36
37
00
96
91

26

24
20
15
12
IVV, IA Projects
1
2-3
4
Setting the Stage An Agency Requirement

• NPD 8730.4 SW IVV Policy
• Cancelled on 08/30/05
• Current Requirements
• NPD 2820.1C Software Policy
• NPR 7150.2 Software Engineering Requirements
• NASA-STD-8739.8 Software Assurance

5
NPD 2820.1C Software Policy

• NASA policy regarding software activities for
  each project is to accomplish the following
• (5) Projects shall ensure software providers
  allow access to software and associated artifacts
  to enable insight/oversight by software
  engineering and software assurance which includes
  Independent Verification and Validation (IVV)
  and NASA's Safety and Mission Assurance
  organizations.
• c. Use the NASA IVV Facility as the sole
  provider of IVV services when software created
  by or for NASA is selected for IVV by the NASA
  Chief Safety and Mission Assurance Officer.
• Responsibilities
• c. The NASA Chief Safety and Mission Assurance
  Officer shall
• (1)
• (6) Oversee the functional management of the
  NASA IVV Program and assure the performance of
  all of IVV processes, services, and
  activities.
• (7) Establish and manage processes for the
  selection of software to which to apply IVV.
• (8) Charter the IVV Board of Directors
  (IBD) which makes prioritized recommendations for
  allocating IVV services to projects based on
  the annual Software Inventory (maintained by the
  Chief Engineer) and the Office of Safety and
  Mission Assurance(OSMA) defined process.
• (9) Select and maintain the list of software
  projects to which IVV is to be applied.
• (10)
• d. The IVV Program Manager shall 1) establish
  and manage the Agency's software IVV services
  and procedures 2) establish, maintain, and
  report on the results of IVV services and
  findings and 3) support NASA's program for
  improving software assurance and other trusted
  verifications (e.g., independent assessments,
  peer reviews, and research). The IVV Facility
  shall determine and document the services
  provided by the Facility on projects selected for
  IVV by the NASA Chief Safety and Mission
  Assurance Officer.

6
NPR 7150.2 Software Engineering Requirements

• Section 5.1.1.1 states required content for SW
  Development Plans.
• The Software Development or Mgmt Plan shall
  contain SWE-102
• a. Project organizational structure showing
  authority and responsibility of each
  organizational unit, including external
  organizations (i.e., Safety and Mission
  Assurance, Independent Verification and
  Validation (IVV), Independent Technical
  Authority (ITA), NASA Engineering and Safety
  Center (NESC))".
• Additionally, within section 5.1.5 which
  addresses SW Assurance, it states "The SW
  Assurance Plan details the procedures, reviews,
  and audits required to accomplish software
  assurance. The project office should coordinate,
  document, and gain concurrence with the Office of
  Safety and Mission Assurance as to the extent and
  responsibilities of the assurance and safety of
  the project. This will be documented into the
  project plans and reflected in the assurance
  process.
• Section 5.1.5.1 states The SW Assurance Plan(s)
  shall be written per NASA-STD-8739.8, NASA SW
  Assurance Standard. SWE-106".

7
NASA-STD-8739.8 Software Assurance

• Std states the following
• Section 6.1.4 When IVV has been selected for a
  project, the provider shall coordinate with IVV
  personnel to share data and information.
• Section 7.5.3 When the IVV function is required,
  the provider shall provide all required
  information to NASA IVV Facility personnel.
  (This requirement includes specifying on the
  contracts and subcontracts, IVVs access to
  system and software products and personnel.)

8
A Software Crisis
Independent Verification and Validation The NASA
Approach
9
Growing Software Importance

• Fundamental Concern
• First NASA robotic mission with actual software
  launched in 1969 (Mariner 6)
• Software size has grown over time
• 128 words of assembly equivalent 30 lines of C
  code
• MER has about 600,000 lines of equivalent C code
• More functionality is being placed within
  software and software constructed devices
  (Programmable Logic Devices)
• With increased processing power and memory, more
  tasks are running concurrently
• Control software increasing in complexity and
  size
• Software used to monitor and react to hardware
  faults

10
Software is still hard to get right

• The Carnegie Mellon Software Engineering
  Institute reports(1) that at least 42-50 percent
  of software defects originate in the requirements
  phase.
• The Defense Acquisition University Program
  Manager Magazine(2) reports in a Department of
  Defense study that over 50 percent of all
  software errors originate in the requirements
  phase.

1 Carnegie Mellon Software Engineering
Institute, The Business Case for Requirements
Engineering, RE 2003, 12 September 2003 2 -
Defense Acquisition University Program Manager
Magazine, Nov-Dec 1999, Curing the Software
Requirements and Cost Estimating Blues
11
Fixing errors early can conserve resources

• Early error detection and correction are vital to
  development success
• The cost to correct software errors multiplies
  during the software development lifecycle
• Early error detection and correction reduces cost
  and saves time
• IVV assurance vital to mission success
• Independent evaluation of critical software is
  value-needed
• Agency goal

Average relative costs for finding errors late
"Software Engineering Economics" by Barry Boehm
12
Overview of Defects found by IVV Teams
13
Independent Verification and Validation
Independent Verification and Validation The NASA
Approach
14
What is Verification and Validation?

• Simply put, assuring that a software system meets
  the users needs
• Verifying that the software is accurate and
  representative of its specification
• Validating that the software will do what the
  user really wants it to do

15
What is up with that I?

• I Independent
• Financially Funded from Corporate GA for Agency
  identified high priority Projects
• Customer Project may also fund the effort
• Technical IVV program defines scope and tasks,
  tailored by an IVV criticality assessment
• Uses a predefined work breakdown structure
• Managerial Functional management supplied by
  OSMA
• Project management supplied from the IVV program

16
So what is IVV?

• An engineering discipline employing rigorous
  methods for evaluating the correctness and
  quality of the software product throughout the
  software life cycle from a system level
  viewpoint.
• The NASA Software IVV approach covers not only
  expected operating conditions but the full
  spectrum of the system and its interfaces in the
  face of unexpected operating conditions or
  inputs.

17
So what else is IVV?

• Testing at the end of the life cycle?
• No
• IVV is testing, but it is whole life cycle
  testing
• The IVV team tests artifacts ranging from
  system and software requirements to source code
  and test results
• Each task in the IVV WBS is designed to test a
  development artifact or process

18
What are the objectives of IVV?

• Find defects within the system with a focus on
  software and its interactions with the system
• Make an assessment of whether or not the system
  is usable in an operational environment, again
  with a focus on the software within the system
• Identify any latent risks associated with the
  software

19
What is the goal of IVV?
Establish confidence that the software is fit for
its purpose within the context of the system

• Note that the software may not be free from
  defects
• Rarely the case and difficult to prove
• The software must be good enough for its intended
  use
• As described by the requirements
• Correct requirements
• The type of use will determine the level of
  confidence that is needed
• Consequence of software defect/failure

20
Are there any other benefits to IVV?

• Primary purpose to provide confidence to OSMA,
  however...
• Development projects receive all findings
• The good, the bad, the ugly
• Allows PM to have unbiased view of software
  development effort
• Provides knowledge resource for software
  developers
• In phase IVV work provides early error detection
  and may save the project money in error correction

21
IVV is process as well as product oriented
22
IVV Increases Project Awareness
23
IVV Interfaces and Reporting

• Formal and informal interface with developers
• The formal interface with an IVV Program project
  manager
• Informal interface between the IVV analysts and
  the developers
• Helps to get identified problems and issues into
  the appropriate hands quickly
• Results of the effort thoroughly documented
• Issues identified to the developers in a timely
  manner
• Status reports to the Project Management
• Monthly/Quarterly reviews to GPMCs/Directorates/HQ
  s
• Project close out report
• All inputs and outputs archived
• Final report delivered to project for its own
  internal records
• Lessons learned documented throughout

24
NASA IVV
25
Agency Generic IVV Scoping and Costing Flow
26
The IVV Life Cycle

• An IVV Project follows a life cycle similar to
  most Projects
• Formulation
• Execution
• Close-out

27
Formulation Phase

• The Formulation phase is used to plan and scope
  the work to be performed
• Starts usually prior to System Requirements
  Review (SRR) with initial planning and contact
  with the Project
• Generally between SRR and Preliminary Design
  Review (PDR) planning and scoping process is
  executed
• Criticality analysis developed as foundation for
  the IVV effort on the project
• The effort addresses all of the software on a
  Project
• The process generates a tailored approach based
  on the results of the assessment

28
Execution Phase

• Majority of the IVV effort is performed
• Documented in an IVV Plan (IVVP) that is an
  output of the Formulation work
• The IVVP is provided to the Project for review
  and applicable concurrence
• Approach taken from the WBS and tailored based on
  the results of the Formulation work
• The Execution phase generally ends somewhere
  around or shortly after launch
• In some cases, work may extend beyond launch when
  software is still being developed (MER)

29
IVV WBS for NASA Missions

• The purposes of the IVV Work Breakdown Structure
  are to
• Provide a consistent approach to IVV across the
  Agency
• Provide a consistent and comprehensive basis for
  collection and reporting of metrics
• Help Projects anticipate and understand what IVV
  will do
• The IVV WBS was developed using industry
  standards and IVV history on NASA missions as
  reference
• IEEE Std. 1012-2004 IEEE Standard for Software
  Verification and Validation
• IEEE/EIA 12207.0-1996 Standard for Information
  Technology-Software life cycle processes
• WBS Tasks for NASA Missions
• Task selection is based on an algorithm using
  software development risk
• Risk is generated based various on Project
  characteristics (size, complexity, reuse, risk,
  etc.) as part of IVV planning and criticality
  analysis tasks
• The full WBS can be found at http//ims.ivv.nasa.g
  ov/isodocs/IVV_09-1.pdf

30
IVV Activities Fit within the Project Schedule
System Requirements Review
Preliminary Design Review
System Test
Mission Readiness Review
System Retirement
Critical Design Review
S/W FQT
Launch
Initial IVVP Signed
Baseline IVVP Signed

• - IVV provides support and reports for Project
  milestones
• Technical Analysis Reports document major phases
• IVVP is updated to match changes in Project

IVV Provides CoFR
IVV Final Report
Concept Phase 2.0
Requirements Phase 3.0
Design Phase 4.0
Implementation Phase 5.0
Test Phase 6.0
Operations Maintenance Phase 7.0
IVV Phase Independent Support 1.0
Note numbers correspond to IVV WBS

• Designed to mesh with the Project schedule and
  provide timely inputs to mitigate risk
• Dialog between the IVV Facility and the Project
  begins before SRR

31
Close Out Phase

• The Close Out phase concludes the IVV effort
• All of the work performed is summarized in a
  final technical report
• Additionally, Lessons Learned are captured and
  either documented separately or incorporated into
  the final technical report
• In some cases, the IVV Team is retained to
  provide mission support during critical phases of
  the Project which may occur after Close Out of
  the primary effort

32
The IVV Life Cycle Flow
Concept Phase
Focused activity at the earliest point System
requirements and software role important Issues
are introduced at lowest level
Verification
Covers all levels of testing. Ensures that system
meets the needs of the mission
System Requirements
Software Planning
Verification
Verification
IVV in phase with development
Validation Testing
Software Requirements
Verification
Design
Verification
Simulator/ Environment/ Hardware
Implementation
Verification
Maintenance
Later life cycle activity also important Issues
are still introduced at lowest level Focused more
on individual components
IVV support continues over initial operational
phase and beyond based on mission profile
33
IVV Testing Philosophy
Component Based Testing
Integration

System Testing
Acceptance Testing
Unit Test (CSC, CSCI)
S/W Integration
S/W Functional Qualification Testing
Acceptance Testing
System Integration and Test

• Most testing is designed to show the software
  works within the envelope of the mission (Test
  what you fly, fly what you test)
• The IVV approach is to focus more on off-nominal
  and unexpected situations in the software
• The higher the level of confidence needed the
  deeper the analysis
• The guiding goal is not necessarily to perform
  additional testing
• The goal is to improve the Project's test
  planning and execution
• In some cases, IVV may independently test highly
  critical software

34
Forming an IVV Project
Independent Verification and Validation The NASA
Approach
35
IVV Project Requirements Background

• Critical first steps is to develop the
  requirements for the IVV project
• A set of engineering/management tasks that are
  determined through a criticality analysis process

• Previously accomplished individually by different
  NASA contractors using different processes
• This sometimes led to confusion with the NASA
  development projects as there was little
  consistency
• There was also a mixture of terminology used that
  was sometimes in conflict with other NASA
  terminology and industry standard terminology
• There was also a perception among some parts of
  NASA that the IVV contractors were determining
  their own work

36
Software Integrity Level Assessment Process

• To help mitigate or eliminate some of these
  issues the IVV Program undertook an initiative
  to develop a new process
• Examined the best of current criticality analysis
  processes from industry and academia
• The primary objective of the process is to
  develop the requirements for an IVV project

37
SILAP Goals
Scalable Reasonably applicable from a mission-level, down to a function level
Risk-based Ranking A combination of Consequence (impact if the software component fails) and Error Potential (likelihood an error exists)
Minimal Complexity Relatively simple such that it can be executed across a broad range of experience levels
Minimal Impact Minimize the level of participation from the project we are assessing
Objective Criteria Minimize the use of engineering judgment and maximize the use of measurable criteria
Disjoint Tasking Produce tasking that is different for each software integrity level
Applicable Applicable throughout the life cycle
Understandable The process and reasons for the results can be completely described and should make sense to a general engineer/project manager
38
Software Integrity Level (SIL)

• Software Integrity Levels
• Want to define, for a software component, the
  required level of integrity in terms of its role
  in the system
• Understand how the component fits within the
  system
• Understand what is required of that component to
  be able to maintain the functionality of the
  system

39
Software Integrity Level Definition

• Definition of Software Integrity Level
• A range of values that represent software
  complexity, criticality, risk, safety level,
  security level, desired performance, reliability,
  or other project-unique characteristics that
  define the importance of the software to the user
  and acquirer
• The characteristics used to determine software
  integrity level vary depending on the intended
  application and use of the system.
• A software component can be associated with risk
  because
• a failure (or defect) can lead to a threat, or
• its functionality includes mitigation of
  consequences of initiating events in the systems
  environment that can lead to a threat
• Developed using not only software but also system
  level integrity as a basis (ISO/IEC 15026, 6)

40
Risk A Common Denominator

• Previously development projects (IVV
  stakeholders) could not easily link risk with the
  scoring that was performed
• Prime requirement for this new process is that it
  clearly defined the system risk and is linked to
  the software
• Process was built around two project factors the
  combination of which would define some level of
  system risk linked to the software
• The factors are Consequence and Error Potential

41
Consequence vs. Error Potential

• Consequence is a measure of the system level
  impact of an error in a software component
• Generally, take the worse case error (at the
  software component level) that has a reasonable
  or credible fault/failure scenario
• Then consider the system architecture and try to
  understand how that software fault/failure
  scenario may affect the system
• Error Potential is a measure of the probability
  that the developer may insert an error into the
  software component
• An error is a defect in the human thought process
• A fault is a concrete manifestation of errors
  within the software
• A failure is a departure of the system behavior
  from the requirements
• With these definitions in mind, the approach is
  not to assess faults or failures, but to assess
  errors
• Scoring

42
Consequence

• Consequence consists of the following items
• Human Safety This is a measure of the impact
  that a failure of this component would have on
  human life
• Asset Safety This is a measure of the impact
  that a failure would have on hardware
• Performance This is a measure of the impact
  that a failure would have on a mission being able
  to meet its goals

43
Error Potential

• Error Potential consists of the following items
• Developer Characteristics
• Experience This is a measure of the system
  developers experience in developing similar
  systems
• Organization This is a measure of the
  complexity of the organization developing the
  system (distance and number of organizations
  involved tend to increase the probability of
  errors being introduced into the system)
• Software/System Characteristics
• Complexity This is a measure of the complexity
  of the software being developed
• Degree of Innovation This is a measure of the
  level of innovation needed in order to develop
  this system/software
• System Size This is a measurement of the size
  of the system in terms of the software (i.e.,
  Source Lines of Code)

44
Error Potential (2)

• Development Process Characteristics
• Formality of the Process This is a measure of
  how maturity of the developers processes
• Re-use Approach This is a measure of the level
  of re-use for the system/software
• Artifact Maturity This is a measure of the
  current state of the development documentation in
  relation to the state of the overall development
  project (i.e., the is past critical design review
  but the requirements documents are still full of
  TBDs and incompletes)

45
Determining the Scores

• Using the criteria, each software component is
  assessed and a score generated
• The scores are then processed through an
  algorithm to create a final score for Consequence
  and Error Potential
• The algorithm takes into account a weight for
  each of the characteristics

Consequence Factors  Weight
Human Safety 0.0
Asset Safety 35.0
Performance 65.0
Error Potential Factors Sub-Factor Weight  Factor Weight
Developer 57.9
Experience 82.8
Development Organization 17.2
Development Process 24.9
Formality of Process 53.2
Re-use Approach 22.6
Artifact Maturity 24.2
System/Software Characteristic 17.2
Complexity 54.7
Degree of Innovation 35.1
Size of System 10.2
Note that the Human Safety score carries no
weight. Rather it is treated in a special manner
as shown on the next slide
46
Calculating Consequence

• The following algorithm is used to determine the
  final Consequence score

If a component has no human safety impact then
Human Safety 0 else score the Human Safety
(hs) 1-5 using the criteria Score the Asset
Safety (as) 1-5 using the criteria Score the
Performance (pf) 1-5 using the criteria If hs gt
(.35as .65pf) then Final score
hs else Final score (.35as .65pf)
This step defines the Human Safety score (hs)

This last step is important as it places emphasis
human safety by using it as an overriding score
if it is larger than the sum of the weighted
asset safety and performance score
47
Calculating Error Potential

• The algorithm for the Error Potential calculation
  has no special provisions
• It is simply a sum of the weighted scores

The first three terms represent the high level
weights

• These attributes have
• Values (vi)
• generated during the assessment
• Weights (wi)
• pre-defined

Error Potential
Note that all scores are rounded to the next
whole integer
48
Developing Tasking

• A tasking set based on each individual score
• Tasking associated with a given Consequence score
• Tasking associated with a given Error Potential
  score
• One set of tasks per component
• The tasks are not exclusive to a given score
• This results in a matrix of software components
  and scores that provides the starting set of
  requirements for IVV on that project
• The current matrix of score and tasks is provided
  on the next slide

49
IVV Tasking Matrix
Factors Factors Consequences Consequences Consequences Consequences Consequences Error Potential Error Potential Error Potential Error Potential Error Potential
Factor Scores Factor Scores 1 2 3 4 5 1 2 3 4 5
1.0 Phase Independent Support
1.1 Management and Planning of Independent Verification and Validation X X X X X X X X X X
1.2 Issue and Risk Tracking X X X X X X X X
1.3 Final Report Generation X X X X X X X X
1.4 IVV Tool Support X X X X X X X X
1.5 Management and Technical Review Support X X X X X X X X X X
1.6 Criticality Analysis X X X X X X X X X X
1.7 Identify Process Improvement Opportunities in the Conduct of IVV X X X X X X X X
Items with a carat () next to them are only
invoked when human safety is involved
50
IVV Tasking Matrix (2)
Factors Factors Consequences Consequences Consequences Consequences Consequences Error Potential Error Potential Error Potential Error Potential Error Potential
Factor Scores Factor Scores 1 2 3 4 5 1 2 3 4 5
2.0 Concept Phase
2.1 Reuse Analysis X X X
2.2 Software Architecture Assessment X X X
2.3 System Requirements Review X X X X X
2.4 Concept Document Evaluation X X X
2.5 Software/User Requirements Allocation Analysis X X X
2.6 Traceability Analysis X X X
3.0 Requirements Phase
3.1 Traceability Analysis Requirements X X X  X X X
3.2 Software Requirements Evaluation X X X X X
3.3 Interface Analysis Requirements X X X X X
3.4 System Test Plan Analysis X X X
3.5 Acceptance Test Plan Analysis X
3.6 Timing and Sizing Analysis   X X
51
IVV Tasking Matrix (3)
Factors Factors Consequences Consequences Consequences Consequences Consequences Error Potential Error Potential Error Potential Error Potential Error Potential
Factor Scores Factor Scores 1 2 3 4 5 1 2 3 4 5
4.0 Design Phase
4.1 Traceability Analysis Design   X X X X
4.2 Software Design Evaluation X X X X
4.3 Interface Analysis Design X X X
4.4 Software FQT Plan Analysis X X X X
4.5 Software Integration Test Plan Analysis   X X
4.6 Database Analysis   X X X
4.7 Component Test Plan Analysis   X
52
IVV Tasking Matrix (4)
Factors Factors Consequences Consequences Consequences Consequences Consequences Error Potential Error Potential Error Potential Error Potential Error Potential
Factor Scores Factor Scores 1 2 3 4 5 1 2 3 4 5
5.0 Implementation Phase
5.1 Traceability Analysis - Code X X X X X
5.2 Source Code and Documentation Evaluation X X X X X
5.3 Interface Analysis - Code X X X X X
5.4 System Test Case Analysis X X
5.5 Software FQT Case Analysis X X
5.6 Software Integration Test Case Analysis   X
5.7 Acceptance Test Case Analysis X
5.8 Software Integration Test Procedure Analysis   X
5.9 Software Integration Test Results Analysis   X X
5.10 Component Test Case Analysis   X
5.11 System Test Procedure Analysis X
5.12 Software FQT Procedure Analysis X
53
IVV Tasking Matrix (5)
Factors Factors Consequences Consequences Consequences Consequences Consequences Error Potential Error Potential Error Potential Error Potential Error Potential
Factor Scores Factor Scores 1 2 3 4 5 1 2 3 4 5
6.0 Test Phase
6.1 Traceability Analysis - Test X X X X X
6.2 Regression Test Analysis   X X
6.3 Simulation Analysis X
6.4 System Test Results Analysis X X
6.5 Software FQT Results Analysis X X
7.0 Operations and Maintenance Phase
7.1 Operating Procedure Evaluation X
7.2 Anomaly Evaluation X
7.3 Migration Assessment X
7.4 Retirement Assessment X
54
IVV Relationships
55
IVV Facility Relationship to HQ

• IVV reports annual performance and receives
  approved budget from IBD (Chaired by OSMA)
• AA/OSMA delegates Program to GSFC Center Director
• IVV Facility Director is Program Manager
• Facility works with OSMA IVV Liaison to
  coordinate IBD budget inputs and performance
  reporting
• OSMA works with IBD to identify and prioritize
  Projects annually

56
IVV/Center/Project Relationships

• IVV-Project Relationship
• IVV still reports issues to Project first and
  treats Project as primary customer for
  technical findings and risks
• As a Code Q Program, IVV will keep Center SMA
  personnel informed of IVV technical issues so
  that SMA has a complete mission assurance
• IVV-Center Relationship
• Center Liaison facilitates the startup of IVV on
  new Projects
• Center Liaison and IVV Facility Leads facilitate
  technical issue resolution
• Center Liaison promotes consistent approaches to
  IVV on Projects, and promotes awareness of IVV
  Center-wide
• SMA, Projects, and IVV provide technical status
  and issues to the GPMC
• IVV reports to GSFC PMC as a Program Office

57
Closing
Independent Verification and Validation The NASA
Approach

• Software IVV, as practiced by the NASA Software
  IVV Facility, is a well-defined, proven, systems
  engineering discipline designed to reduce the
  risk in major software developments

58
Points of Contact

• Bill Jackson
• Acting Director
• 304-367-8202
• Bill.L.Jackson_at_nasa.gov
• Ken Costello
• Lead Engineer
• 304-367-8343
• Kenneth.A.Costello_at_nasa.gov

59
(No Transcript)
