Title: Colloidal and Surface Phenomena of Liquid Laundry Detergent


1
Colloidal and Surface Phenomena of Liquid Laundry
Detergent





Dan Boek Erika Indivino Katie Marso Karey
Smollar April 18th, 2002



















What type of pet(s) do you have in your home?









Featured Product






Make the most of Tide.com



Become a registered member and















- it's easy and free.
- it's easy and free.






2
History
  • Clothes first cleaned by mechanical means
  • Production of soaps
  • First produced in the 15th century
  • Combine fats and sodium hydroxide
  • Renewable, biodegradable resources
  • Negative affects of hard water

3
History
  • Synthetic detergents
  • First produced in 1916 in Germany
  • Introduction of margarine
  • Large bodies of water covered in foam
  • Production took off in the U.S. after WWII
  • Mainly used for dishwashing and fine fabrics

4
History
  • 1946, first all-purpose laundry detergent
  • Included surfactants and builders
  • Combinations became more complex
  • Sodium triphosphate (STP)
  • Very effective builder
  • Use restricted in 1960s because it caused
    eutrification in rivers
  • New additives are continually being introduced

5
History
  • Liquid laundry detergent
  • 1970s, became popular in the U.S.
  • More convenient for consumers
  • Easier to handle
  • Do not contain bleaching agents
  • Remove stains better at lower temperatures
  • Sales have soared above powders in last decade
  • Have reached 50/50 market split in the U.S.

6
Design Considerations
  • Excellent soil removal
  • Low sensitivity to hard water
  • Builders prevent calcium and magnesium deposits
  • Good dispersion properties
  • Liquid detergents spread easily
  • Soil antiredeposition capability
  • Surfactants keep soils in suspension

7
Design Considerations
  • High solubility in water
  • Liquid detergents dissolve faster than powders
  • Foaming
  • Psychological affect, foam means detergent is
    working
  • Odor
  • Perfumes and fragrances
  • Color

8
Design Considerations
  • Toxicity
  • Exposure through skin, ingestion, inhalation
  • Environmental affect
  • Use of phosphates
  • Convenience
  • Easier to pour, direct application on stains
  • Cost

9
Types of Fabrics
  • Fabrics require specialized soil removal
  • Textile versus synthetic fabrics
  • Different calcium content
  • Wettability due to hydrophobic and hydrophilic
    nature
  • Complexing agents react differently with each
    type of soil

10
Types of Fabrics
  • Sodiumtriphosphate
  • Effectiveness dependent on hydrophilic/hydrophobic
    nature of the fiber
  • Efficient removal of soils from synthetic or
    cotton garments, which are hydrophilic
  • Minimal affect on hydrophobic textile fibers
  • Different fabric and soil types are dealt with by
    using a mixture of compounds in detergents

11
History
  • Tablets
  • Directed to elderly and students
  • New and expensive
  • Hold 25 of market in some European countries
  • Pouches
  • Introduced in April 2001
  • Liquid detergent in polyvinyl alcohol skin
  • Dissolves in seconds, leave behind no residue

12
Main Components
13
Anionic Surfactants
  • Tetrapropylenbenzene (TPS)
  • -used in earlier stage production of detergents
    to first replace soap
  • -branching increases the wetting ability but
    limits effective detergency

14
  • Linear Alkylsulfonate (LAS)
  • -demonstates good detergency ability and is not
    very sensitive to water hardness

Sodium linear alkylsulfonate (LAS)
15
  • Secondary Alkanesulfonates (SAS)
  • -highly soluable surfactant demonstrating fast
    wetting properties and chemical stability of
    alkali and acids

Secondary Alkanesulfonates (SAS).
16
Olefinsulfonates (AOS)
  • produced using alkaline hydrolysis process
  • shows less sensitivity to water only under
    certain conditions such as chain length and type
    of chemical bonding



17
Nonioinic Surfactants
  • An essential ingredient found in smaller
    quantities which are used for stabilizing the
    micelle formations and prevent redeposition

18
Advantages of Builders
  • Enhances effects of surfactants
  • Used to reduce water hardness, Mg2 and Ca2
  • Enables the production of cheaper detergent while
    retaining the cleaning properties

19
Types of Builders
  • Trisodium phosphate is the most common type of
    builder
  • Zeolites Molecular formula Na2OAl2O34.5H2O.
  • -water insoluble builder
  • -10 micrometer diameter
  • -reduces soil redeposition by replacing calcium
    and magnesium ions with sodium

Figure 3 Trisodium Citrate (NaCit)
20
Enzymes
  • Help with the removal dried in stain from milk,
    cocoa, blood, egg yolks and grass
  • Enzymes commonly used are proteolytic, amylolytic
    and lipolytic
  • Enzymes cause hydrolysis of peptide, glucosidic,
    or ester linkages

21
Stabilizers
  • Prevent redeposition of negatively charged
    particles back on the neutral fabric surfaces
  • Sodium carbomethyl cellulose (SCMC)
  • Molecular weight is between 20,000 and 500,000
  • -Attaches itself to the fibers adding to the
    negative

22
Other Additives
  • Optical Brighteners
  • -Used to brighten fabric appearance by converting
    ultra violet light into longer wavelengths of
    visible blue light
  • Fragrances
  • Alcohols
  • Water

23
Contact Angle
soil-water interface
Soil
?
Water
fabric-water interface
fabric-soil interface
Fabric
24
Young Equation
  • After surfactants are added ?FW ?SW 0
  • Interfacial tension between soil and fabric
    remains constant, so ?FS gt ?FW
  • Tgt90 degrees
  • Contact area between soil and fabric 0


25
Roll-Up
  • As Tgt90 degrees, the roll-up mechanism takes place

26
Without Surfacant
  • Without surfactant, surface tensions remain
    constant, T lt 90 degrees
  • The soil is partially removed by mechanical
    agitation

27
Packing Parameter
  • Packing parameter
  • pv/aolc
  • aosurface area of headgroups
  • V volume of hydrocarbon chains
  • lo maximum length of chains

28
Packing Geometry
29
Multilamellar Structure
  • Headgroup area diminishes in the presence of salt
    ions, NaCit
  • ½ gt p gt 1 so structure is bi-layer
  • Continuous lamellar crystalline structure

30
Multilamellar Vesicles
  • Bilayers form multalamellar vesicles to minimize
    hydrocarbon chain and solvent interactions
  • Unilamellar vesicle

31
Multilamellar Vesicles
32
Flocculation
  • Water is a poor solvent with salt ions present
  • Chain length decreases due to poor solvency
  • Van der Waals forces
  • Flocculation and phase separation result

33
Decoupling Polymer
  • Decoupling polymer
  • Hydrophylic backbone and hydrophobic side chains
  • Side chains dissolve in oil
  • Backbone dissolves in water
  • Steric repulsion causes the lamellar droplets to
    repel, hindering flocculation

34
Steric Repulsion
Poor solvent without decoupling polymers
Poor solvent with decoupling polymers
35
Particulate Soil
  • METHODS OF REMOVAL
  • Mechanical Energy is the primary type of removal
    and used to enhance anti-redeposition
  • Potential Energy barriers is greatest near the
    surface, DLVO Theory
  • Using Anioinc surfactant to create electrical
    Charge on the surfactant and fiber causing
    repulsion

Diagram, PE vs. distance
36
Potential Energy vs. pH Diagram
  • Potential of various fibers as a function of pH
    a) Wool b) Nylon c) Silk d) Cotton e) Viscose

37
Calcium Containing Soil
  • Found on textile fabric surfaces
  • Effective detergency is dependent on type of
    washing solvent used
  • Increases water hardness which decreases the
    solubility
  • Slight solubility can cause calcium deposit
    break-up

38
Types of Fabrics
  • Cotton, Synthetic, textile
  • Different hydrophobic/hydrophilic nature
  • Effective detergency is dependent of
    wettability of the cloth and the type of
    complexing agent used
  • Cleaning mixed soils on blending fabrics cause
    complementing effects

39
Manufacturing
  • Liquid detergents are produced either in a batch
    reactor or a continuous blending process.
  • Surfactants
  • STPP/Zeolite
  • Sodium Sulphate
  • Sodium Perborate
  • Sodium Carbonate
  • Sodium Silicate
  • Minors

Mixing and Homogenizing
Liquid Detergent
40
Packaging
  • 3 Main Purposes
  • Maintain quality of detergent
  • Supply detergent information
  • Make handling easy

41
Packaging
  • Company Considerations
  • Compatibility
  • Cost
  • Safety
  • Waste
  • Convenience

42
Packaging
  • Typical bottles are recyclable plastic
  • Gradually, companies are adding a percentage of
    recycled plastic to their bottles.
  • Generally 25 recycled material
  • Concentrated detergents
  • Refillable bottles
  • Refill bottles 65-90 smaller than original
    container

43
Environmental Concerns
  • Adjust to environmentally-friendly washing
    machines
  • Reduced
  • Water
  • Energy
  • Temperature
  • Water consumption
  • Minimize amount required for detergent to
    function
  • Adapt formula to wash in poor conditions

44
Liquid Detergent Sales Continue to Grow
45
Market Sales
  • Liquid detergent sales top powders in 1998
  • 3 billion sold in liquid
  • 1.8 billion sold in powder
  • Liquids more popular due to convenience and
    better performance

46
Market Breakdown
47
(No Transcript)
