Ocean Energy
Kim Cobb with slides from Dr. Alam, MIT
2
Overview of Ocean Energy

• ocean energy is replenished by the sun and
  through tidal influences of the
• moons and suns gravitational forces
• near-surface winds induce wave action and cause
  wind-blown currents at
• about 3 of the wind speed
• tides cause strong currents into and out of
  coastal basins and rivers
• ocean surface heating by some 70 of the incoming
  sunlight adds to the
• surface water thermal energy, causing expansion
  and flow
• wind energy is stronger over the ocean due to
  less drag, although
• technically, only seabreezes are from ocean
  energy

3
How much energy and what types?

• 250 Billion barrels of oil worth of energy coming
  into ocean every day
• 80 million barrels of oil per day produced

kinetic
potential
4
How much energy and what types?

• 250 Billion barrels of oil worth of energy coming
  into ocean every day
• 80 million barrels of oil per day produced

Theoretical global resource of ocean
energy 8,000-80,000 TWh/yr for wave energy 800
TWh/yr for tidal current energy 2,000 TWh/yr for
salinity gradient energy 10,000 TWh/yr for ocean
thermal energy
Worlds electricity consumption 17,000 TWh/yr
5
Source of Ocean Wave Energy
6
(No Transcript)
7
Wave Energy Extraction Technologies
Oscillating Water Column (Energetech/Oceanlinx)

• Point
• Absorber
• (OPT,
• Finavera)

Overtopping, Wave Dragon
Attenuator, Pelamis WP
8
Power From Ocean Waves
kW/m crest length
9
Power From Ocean Waves

• Wave energy is strongest on the west coasts and
  increases toward the poles.
• At approx. 30 kW/mcl in the Northwest (yearly
  avg.), a single meter (3.3 feet) of wave has the
  raw energy to power about 23 homes.

10
Point absorber buoys most common
11
(No Transcript)
12
Oscillating Water Column Installations LAND
NOTE Plant Bowen (Georgia Power) operates at
3,200,000 kW
13
Oscillating Water Column Installations OCEAN
14
Overtopping Wave Energy
15
Sea Snake Wave Energy
121m long, 3.5m tall!
16
(No Transcript)
17
Tidal Energy Conversion
18
Ocean Thermal Energy Conversion
19
210 kW OTEC test plant, 1993-1998, Hawaii
20
Future OTEC plant grow food and fuel?
21
Ocean Energy Where are we today?

• Wave Energy (grid-connected)
• 0.4MW and 0.5MW OWC off the coast of Pico and
  Islay by 2008
• 2.25MW Pelamis off Portugal by 2008
• 0.5MW section of Wave Star Energy off Denmark by
  2009
• 7MW Wave Dragon off Wales by 2010
• Tidal
• barriers 240MW France in 1966 and 20MW in
  Canada
• Current 1.2MW off Ireland by 2009, 1MW France
• Thermal
• 0.2MW Hawaii 1993-1998

22
Ocean Energy PROS and CONS?
