Vector Quantization

1
Vector Quantization

• CAP5015
• Fall 2005

2
Voronoi Region

• Blocks
• A sequence of audio.
• A block of image pixels.
• Formally vector example (0.2, 0.3, 0.5, 0.1)
• A vector quantizer maps k-dimensional vectors in
  the vector space Rk into a finite set of vectors
  Y yi i 1, 2, ..., N.  Each vector yi is
  called a code vector or a codeword. and the set
  of all the codewords is called a codebook.
  Associated with each codeword, yi, is a nearest
  neighbor region called Voronoi region, and it is
  defined by
• The set of Voronoi regions partition the entire
  space Rk .

3
Two Dimensional Voronoi Diagram
Codewords in 2-dimensional space.  Input vectors
are marked with an x, codewords are marked with
red circles, and the Voronoi regions are
separated with boundary lines.
4
The Schematic of a Vector Quantizer
5
Compression Formula

• Amount of compression
• Codebook size is K, input vector of dimension L
• In order to inform the decoder of which code
  vector is selected, we need to use
  bits.
• E.g. need 8 bits to represent 256 code vectors.
• Rate each code vector contains the
  reconstruction value of L source output samples,
  the number of bits per sample would be
  .
• Sample a scalar value in vector.
• K level of vector quantizer.

6
VQ vs SQ

• Advantage of VQ over SQ
• For a given rate, VQ results in a lower
  distortion than SQ.
• If the source output is correlate, vectors of
  source output values will tend to fall in
  clusters.
• E.g. Sayoods book Exp 9.3.1
• Even if no dependency greater flexibility.
• E.g. Sayoods book Exp 9.3.2

7
Algorithms

• Lloyd algorithm pdf-optimized quantizer, assume
  that distribution is known
• LBG (VQ)
• Continuous (require integral ooperation)
• Modified with training set.

8
LBG Algorithm

1. Determine the number of codewords, N,  or the
   size of the codebook.
2. Select N codewords at random, and let that be the
   initial codebook.  The initial codewords can be
   randomly chosen from the set of input vectors.
3. Using the Euclidean distance measure clusterize
   the vectors around each codeword.  This is done
   by taking each input vector and finding the
   Euclidean distance between it and each codeword.
   The input vector belongs to the cluster of the
   codeword that yields the minimum distance.

9
LBG Algorithm (contd.)

• 4. Compute the new set of codewords.  This is
  done by obtaining the average of each cluster.
  Add the component of each vector and divide by
  the number of vectors in the cluster.
• where i is the component of each vector (x, y,
  z, ... directions), m is the number of vectors in
  the cluster.
• 5. Repeat steps 2 and 3 until the either the
  codewords don't change or the change in the
  codewords is small.

10
Other Algorithms

• Problems LBG is a greedy algorithm, may fall
  into Local minimum.
• Four methods selecting initial vectors
• Random
• Splitting ( with perturbation vector) Animation
• Train with different subset
• PNN (pairwise nearest neighbor)
• Empty cell problem
• No input correspond to a output vector
• Solution give to other clusters, e.g. most
  populate cluster.

11
LBG for image compression

• Taking blocks of images as vector LNM.
• If K vectors in code book
• need to use bits.
• Rate
• The higher the value K, the better quality, but
  lower compression ratio.
• Overhead to transmit code book
• Train with a set of images.

12
Rate_Dimension Product

• Rate-dimension product
• The size of the codebook increase exponentially
  with the rate.
• Suppose we want to encode a source using R
  bits/sample. If we use an L-d quantizer, we would
  group L samples together into vectors. This means
  that we would have RL bits available to represent
  wach vector.
• With RL bits, we can represent 2(RL) output
  vectors.

13
Tree structured VQ

• Set vectors in different quadrant. Only signs of
  vectors need to be compared. Thus reduce the
  number of comparisons by 2L for L-d vector
  problem.
• It works well for symmetric distribution. But not
  when we lose more and more symmetry.

14
Tree Structured Vector Quantizer

• Extend to non-symmetric case
• Divide the set of output points into two groups,
  g0 and g1, and assign to each group a test vector
  s.t. output points in each group are closer to
  test vector assigned to that group than to the
  test vector assigned to the other group.
• Label the two test vectors 0 and 1.
• When we got an input vector, compare it against
  the test vectors. Depending on the outcome, the
  input is compared to the output points associated
  with the test vector closest to the input.
• After these two comparisons, we can discard half
  of the output points.
• Comparison with the test vectors takes the place
  of looking at the signs of the components to
  decide which set of output points to discard from
  contention.
• If the total number of output points is K, we
  make( K/2)2 comparisons instead of K
  comparisons.
• Can continue to expand the number of groups.
  Finally 2logK comparisons instead of K.( 2
  comparisons with the test vectors and a total of
  logK stages

15
Tree Structured VQ (continued)

• Since the test vectors are assigned to groups 0,
  1, 00,01,10,11,000,001,010,011,100,101,110,111
  etc. which are the nodes of a binary tree, the VQ
  has the name Tree Structured VQ.
• Penalty
• Possible increase in distortion it is possible
  that at some stage the input is closer to one
  test vector while at the same time being closest
  to an output belonging to the rejected group.
• Increase storage output points from VQ codebook
  plus the test vectors.

16
Additional Links

• Slides are adapted from
• http//www.data-compression.com
• and
• http//www.geocities.com/mohamedqasem/vectorquant
  ization/vq.html
