Cornerstone Valve USA, LP
  • Valves that WORK!

Founded 1 October 1990
2
Cornerstone Valve USA, LP
  • Manufacturer of Severe Service
  • Ball Valves
  • Check Valves
  • Rotary Control Valves

3
Cornerstone Valve USA, LP
  • Applications in
  • Oil and gas production -Refining
  • Petrochemical
  • Ore Slurries - Iron ore reduction
  • Pulp Paper
  • Aerospace
  • Power Steam Condensate
  • Subsea Offshore platforms
  • High pressure gas
  • Gas liquid Pipelines
  • Cryogenic liquid gas
  • United States Navy

4
Cornerstone Objectives
  • Provide a superior valve solution.
  • Customer/End User satisfaction.
  • Teach others how to specify valves that
  • will perform to their expectations.
  • 4. Have Fun!

5
Cornerstone Features
  • Trunnion-mounted
  • Soft or Metal seated
  • Sizes 1/2" to 48"
  • Full or Reduced Port
  • ANSI 150 - 4500
  • API 2000 - 15000
  • -320º F to 1,875º F, -251ºC to 1023ºC
  • Any Metallurgy
  • End Connections to customer specification
  • Leakage Class to customer specification
  • Actuation to customer specification

6
Cornerstone QA Programs
  • API 6D-0164 monogram (Ball Check)
  • API 6A-0321 monogram PSL 1-4, valves
    chokes
  • API Q1-0165
  • ISO 9001 2000-0450

7
CORNERSTONE TECHNOLOGIES
1. High pressure design experience - to
15,000 psig liquid or gas - onshore,
offshore subsea 2. Abrasive services - solids
proof 3. High temperature design experience
- to 1850F 4. Low temperature design
experience - to -320F 5. Power valves 6.
Rotary Ball Control technology - patented
D-ball trim
8
Typical high pressure gas
One-Piece Ball/Stem
Standard Design Trunnion Mounted

Top Entry
Spring pre-loaded Pressure assisted
9
18 x 16 1500METAL SEATEDHIGH PRESSURE GAS
10
16-600/900IN-LINE SERVICEABLE
PetronasMalaysiadomestic gas distribution system
11
4"-10000SonatrachAlgeria Natural Gas at 10,000
psig
12
10"-2500Chevron VZ420F4000 psig
13
Amine _at_ 5,000 psig8000 F (352 Kg/cm24270
C) NATREF Refinery, So. Africa
14
14-1500 full duplex Check ValveMarathon Alba
field
15
10"-4500Gas _at_ -160 F6,200 psig
Still bubble tight !!!! Algeria - SONARCO
Cornerstone valve passes 120 km/h drop-shock test
16
2"-1500 RTJOne Piece Bodyfull SS
17
Hydrogen at 6,600 psig 465 Kg/cm2 NASA, White
Sands, NM quick opening space station thruster
nozzle developmentIn-line serviceable.
18
and Easy to Service !
19
ESD Block Features
1. One-piece ball /trunnions / stem assembly -
strong and reliable! 2. Ball axis of
rotation remains fixed due to bearing support 3.
Upstream sealing seats for bi-directional
shutoff - Permits testing of seats without
cycling valve - Uses live-loaded seals and fire
seals to allow for expansion and
contraction 4. Permits downstream seat and
upstream seat to seal in same direction (a
specification option) 5. Compatible with any
automation system 6. Takes a minimum of space,
½ the wt. of gate valves! 7. May be serviced
in-line (specification option)
Examples Boarding valves, battery limits,
etc.
20
Quick Opening (or Closing) Valve - Features
  • 6-1500 full bore, 3000 psig
  • One-piece ball / trunnions / stem assembly
  • 2. Special soft seat design - stays in one
    piece after stroking!
  • -and is bubble tight !
  • 3. Actuator, mounting bracket, bonnet and valve
    body are
  • dowel pinned together to maintain
    alignment
  • 4. Specially designed actuator to handle end
    load impacts
  • 5. Hydrogen atmosphere rated electrical
    accessories
  • 6. Proven in service with many valves going
    through hundreds
  • of cycles - still bubble tight !
  • 7. Installed at Cape Canaveral Vandenberg AFB
  • 8. No available "equal" to date 14 years!

21
  • Additional Considerations for
  • Lock hopper or Pigging Service
  • Ball lip detail - must accommodate solids
  • Ball seat coatings must be metallurgically
    bonded
  • Seats to ball loading continuous to prevent
    particles from getting between sealing
    surfaces
  • Sealing systems must accommodate rapid
    temperature
  • changes
  • Robust design - to assure high cycle life
  • Note The valve cost is small compared to the
    cost of process downtime !

22
6-1500 full bore ball valves. 3,000 psig N2.
Launch Pads Open in 0.016 seconds ! limit
switch to limit switch

36 installed! They WORK
23
Boiler recirculationtight shutoff block valve4
- ANSI 2500
Isolates the control valve 4,000psig _at_ 4100 F
24
24-900 24-300
GAS
CRUDE OIL
25
Subsea Valve Installations
  • Cameron Marine 2 1/16 -10000.
  • Launcher Manifolds to 3000 ft depth
  • ELF (Coflexip Stenna) 25 Cr duplex, 380
    meters,
  • 3 6- 1500s (off wellheads)
  • Oceaneering Gulf of Mexico, 800 ft depth avg
  • 2 3 -10000s
  • Devils Tower Gulf of Mexico, 5600 ft,
  • dual stem 4-1500s Technip
  • Oilstates Hydrotech Piston Checks, 8600 ft
    4-5000s

26
Cornerstone Subsea Valve Assembly
TACTILE POSTION INDICATOR

LIMIT SWITCH HOUSING
Alternate Location
SPRING CAVITY PRESSURE COMPENSATOR
API 17D, CLASS 4 ROV INTERVENTION
SUBSEA SPRING RETURN HYDRAULIC ACTUATOR-DANTORQUE
TOP ENTRY FULL BORE METAL SEATED BALL VALVE YCV
CORNERSTONE
Optional ends Flanged, Hub, Weld end integral
to body, as shown, etc.
Water depth 8600 ft. Testing to 11500 ft.
WELD OR GRAYLOC CONNECTION - or ONE - PIECE
WITH BODY
Max installed depth to date is 11400 feet

11-MAR-2000
27
DUAL STEM SUBSEA VALVES
SKID USED ON DEVILS TOWER
28
ROV POSITION INDICATOR
29
OPERATION FROM EITHER SIDE
30
COMPLETED SUBSEA SKID
31
Atlantis Project
  • Principal Specifications
  • All valves were API 10000 except the two main
    export valves
  • Were 26 18 1500s .
  • Top entry in-line serviceable with Grayloc ends
  • NACE MR01-75
  • Inconel 625 on all sealing surfaces
  • Sealant injection on seats and stems for both
    soft metal seated versions
  • Fully tested and documented to 6A PSL 3
  • Seals both EDR resistant to wellhead fluids
  • Note Of (6) bidders we were the only ones that
  • can routinely pass the PSL 3 testing.
  • (other bidders were from UK, France Italy)
  • Can the valves you are specifying open at full
    differential pressure and re-close to bubble
    tight ??

32
Atlantis/Mustang Gulf of Mexico
API 10,000 w/Dantorque Hydraulic SR Actuators
33
Atlantis/Mustang 12 10000 with Bettis SR
hydraulic
34

Atlantis/Mustang Project
35
Atlantis/Mustang 26-1500 main oil export valve
In-line Serviceable Special forged pipe pups
36
Atlantis/Mustang/Taylor Forge
37
8 -10000s - Mustang - Mad Dog Project - Texas
Systems
38
3 1/16 -10000s - Mustang - Mad Dog - Texas
Systems
39
Special Valve in Solid Inconel 625
Nuclear Reactor - natural recirculation - control
40
ABRASIVE SERVICE VALVES
  • APPLICATIONS
  • 1. Delayed coking - two way and 4-way valves, OH
    vapor
  • 2. Heavy sulfur and iron sulfite deposits (very
    sour gas)
  • 3. Catalyst switching at high temperature with
    fine abrasive
  • catalyst particles
  • - FCC catalyst
  • - CCR catalyst switching
  • - Iron ore reduction
  • - LC Fining, H-Oil
  • - Silica reactors
  • Ore and other slurries
  • Oil/gas with entrained sand
  • Hydrates
  • Polymers

41
Trunnion-mounted split-body solids proof !
One-piece ball Trunnion mtd Upstream Sealing
Valve body cavity is isolated when full open or
full closed.
Basic Design Elements (Split body style)
42
Features
1. Live loading of seats and ball (sealing
arrangement) 2. Isolation of the valve body
cavity from solids (double seated-trunnion) 3.
Ball design that permits rotation within its own
geometry Trunnion Mounted - and permits
true double block bleed. 4. Designs that
accommodates radical temperature swings (up
down) 5. Smooth flow passages 6. Material
selections - both of coatings and substrates. 7.
Purges - if required for a particular
application 9. Solids Proofing to exclude
solids/particulates from critical areas these
may include sealant, solids barriers, purges and
bearing isolation.
43
Examples of Solids handling Valves
  • Coal gasification 12-900 valves, handle coal,
    ash, silica particles in a slurry. Installed in
    1983. Cycle every 30 minutes. Still operating !
  • 2. Lockhopper valves handling catalyst
  • Example Temperature 1150 F (621 C), delta P of
    800 psig (56.25 kg/cm2). Char, ash, caustic
    catalyst. Cycle rate of 12 x per hour. Operated
    over 362000 cycles with zero failures! (next
    best valve design lasted 2 ½ days)
  • 18 throttling valves in Alumina Slurry

44
The result KHI process for iron ore reduction
Iron Carbide - 12000F H2

45
TiO216500 F1100 psig 8990 C, 77.5 Kg/cm2
46
Digester Blow Valve 4 300,
on Kamyr Digester Throttling
in pulp stock, sand, stones, etc.
Best valve we have ever had in this service.
.. like new after 16 months
47
Fully Stellite 21 Lined
12-900, NOX reduction system, 8000 F coke
particles
Drop tight on water, bubble tight on Nitrogen gas
zero bubbles at Full vacuum ! both directions
48
Polypropylene Reactor Letdown
Cycle 7 xs Per minute
! 4500 F 480 psig
3 years Still Stroking !
49
QUICK DELIVERY
18-600 Alumina Slurry 8 weeks ARO to first
(3) pieces. Including design pattern,
casting, machining testing
50
SYNGAS COAL GASIFICATION
18-900 Coke Particles
51
POWER VALVE APPLICATIONS
  • STEAM TURBINE DRAINS
  • CONDENSATE BLOCK CONTROL
  • BLOWDOWN
  • ATTEMPERATING
  • FEEDWATER ISOLATION
  • FEEDWATER BYPASS
  • NOISE CONTROL
  • STEAM DRUM VENT
  • SOOT BLOWER
  • SUPERHEATED STEAM
  • BOILER RECIRCULATION

52
POWER VALVE MODEL TEP-1
First in-line serviceable ball valve offered in
the power market ! Straight through flow
bore. Upstream sealing seat. Continuous seat
loading. One piece ball stems. Valves that Work!
53
POWER VALVE MODEL TEP-1
POWER
54
Completed assembly (bare stem) Lever removed
55
Remove - stem key
Stem key
Upstream
Downstream
56
Remove packing set packing follower
Packing follower
Packing set
57
Remove upper lower bonnets
Upper Bonnet
Lower Bonnet
This Unloads ball seat/seal assembly
58
Remove one-piece ball (stem-trunnions-ball)
Ball
59
Seat seat seal removed through bonnet
Inlet
Outlet
Seat
60
The Solution for Power Plants In-Line
Serviceability !
Standard Tools !
Weld end top entry body (shown
sliced along flow bore)
61
POWER VALVE MODEL TEP-1
Them suckers is ugly, but they sure do work
62
POWER VALVE MODEL TEP-1
Power valve with vane actuator, SV limit
switches
63
POWER VALVES MODEL TEP-1
POWER
  • FULLY IN-LINE SERVICEABLE
  • NO CUTTING
  • NO WELD PREP
  • NO WELDING
  • NO STRESS RELIEF
  • NO RADIOGRAPHY
  • NO NDE
  • NO MESS!!

64
Cornerstone Valve USA, LP
Boiler Vent Valves
65
Cornerstone Valve USA, LP
POWER
DEAERATOR HEATER BLOCK VALVES gt
lt DUAL BOILER TUBE DRAIN VALVES
66
Attemperator Valves - 2-1500
67
Special Valve in Solid Inconel 625
Nuclear Reactor - natural recirculation - control
68
Rotary Control Valves
  • Advantages
  • High rangeability - max Cv / min Cv
  • Space typically smaller space than globe
  • Simple packing arrangements
  • Durability with the right design features
  • - one piece ball/stem no joint no hysterisis
  • - ease of automation
  • - tight shutoff (typically ANSI/FCI Cl V or VI
  • - bi-directional shutoff (if so specified)
  • - In-line serviceable

69
Case History in Steam Letdown Service ( Gulf
Coast Fractionators - Conoco ) Valve
Size 3"-600 P1 750 psig (51.6 barg) T1 750
F P2 35 psig (2.4 barg) Flow Rate 2200 to
44000 lbs per hour. (Avg 20000) Installed 1991
(June) As of - Jul 03 3 billion lbs of
steam !! still going!! And It is quiet. -
reference available on request!
Cage guided Stellited trim globe lasts 9 months

70
Superior Solutions for Rotary Control
In addition to a variable impedance trim which
rotates with the ball, inlet / outlet trims
behave as a series / parallel combination of
chokes
Ball trim
Top view through center
Applications Blowdown, recylce/surge control,
slug catcher, cavitation control, gas/steam
control.
71
Control Valve for ROM desalination unit US Navy
Simple Components
72
Control Trim into Ball
73
  • Valves - Suggested Specification Highlights
  • Specify temperature range pressures.
  • Specify ANSI B16.34, API, or Special Class
    rating.
  • 3. Material choicescorrosion, high/low
    temperature, special trim materials expected,
    piping material, acceptable seat materials,
    coatings, weld overlays on sealing areas,
    specifications for plating, etc.
  • 4. List suggested types and grades of seals as
    well as installation
  • highlights, such as limiting cross-section
    sizes, backups, fire-
  • seal requirements (live loaded for
    example.)
  • 5. Testing In high pressure service, require
    the manufacturer to cycle the valve and prove
    operability. Suggested is testing to API 6A
    PSL 3 . Use water if in liquid service and
    nitrogen
  • if in gas service - with the minimum
    holding periods and
  • cycling requirements as outlined is this
    standard.
  • Require material certificates for all components
    in the valve.
  • Identify pipe schedules and end connections
    required.
  • 9. Specify any additional options such as
    sealant injection,
  • special painting, in-line serviceability,
    etc.

74
Cornerstone Valve Customers (Partial List)
  • PETRONAS
  • VICO
  • Millenium Chem.
  • QGPC
  • Total.Fina.Elf
  • Kvaerner
  • Chevron
  • Statoil
  • Albemarle
  • Burlington Resources
  • BP Chemical
  • BP Refinery
  • Atochem
  • Unocal
  • Texaco
  • Electric Boat
  • Bechtel Bettis
  • PDO (Oman)
  • Jacobs Sverdrup
  • BP Shell Egypt
  • Amoco
  • Mobil
  • GCF
  • CP
  • Anadarko
  • Europipe
  • Texas Utilities
  • HL P
  • Great Northern Paper
  • Sonatrach
  • SONARCO
  • Formosa
  • Mitsubishi
  • Enron
  • Newport News
  • Shell Offshore
  • NREL
  • Edison Mission
  • ARCO
  • AMOCO
  • Corpoven
  • Maraven
  • PDVSA
  • Shell
  • PEMEX
  • Conoco
  • Arnold AFB
  • Cape Canaveral
  • Vandenberg AFB
  • Stennis Space Ctr
  • Marshall Space Ctr.
  • KHI
  • Wilpro
  • Williams
  • Finch Pruyn
  • Production Operators
  • Dow (Terre Haute) PFBC

75
Applications by Country

USA Alaska Oil Gas, pulp paper,
power, Synfuels, Subsea, petrochemical,
refining, cryogenic, Military, NASA and
classified. PFBC, slug- catchers,
gas-to-flare, brine. Nuclear valves Mexico
FCC catalyst fines - 3rd stage
cleanup Venezuela High pressure gas
compression injection Colombia High
pressure gas compression injection, and
high pressure produced water injection
Compressor recycle / surge control Ecuador
High pressure oil production
76
Applications by Country
Chile Copper ore slurry, copper
smelters Finland Synfuel (PFBC) Siberia Ethyle
ne storage - salt domes Norway North Sea -High
pressure gas offshore oil pipeline blowdown
and produced water
Statoil Europipe, BP platform Holland Offshore
Subsea block valves Elf Algeria High pressure
gas injection flare block
(SONARCO, Sonatrach and Anadarko)
77
Applications by Country
South Africa Synfuels
Refining Egypt Produced water
(sour)-- injection Canada Delayed
Coking, steam crude oil China
Offshore ESD block Singapore Power
Refining Malaysia Offshore
production platform, pipeline Indonesia
High pressure oil gas production
78
Applications by Country
India Ammonia compressor valves Uzbekistan H
igh pressure gas to flare Bangladesh Domestic
gas pipeline Syria Domestic gas pipeline,
ESD Qatar Offshore high pressure gas/oil
and injection and produced water Oman
Low pressure gas lift
79
How may we assist you ?
View by Category
About This Presentation
Title:

Cornerstone Valve USA, LP

Description:

Cornerstone Valve USA, LP – PowerPoint PPT presentation

Number of Views:705
Avg rating:3.0/5.0
Slides: 80
Provided by: rgdave
Category:
Tags: usa | auy | cornerstone | valve

less

Write a Comment
User Comments (0)
Transcript and Presenter's Notes

Title: Cornerstone Valve USA, LP


1
Cornerstone Valve USA, LP
  • Valves that WORK!

Founded 1 October 1990
2
Cornerstone Valve USA, LP
  • Manufacturer of Severe Service
  • Ball Valves
  • Check Valves
  • Rotary Control Valves

3
Cornerstone Valve USA, LP
  • Applications in
  • Oil and gas production -Refining
  • Petrochemical
  • Ore Slurries - Iron ore reduction
  • Pulp Paper
  • Aerospace
  • Power Steam Condensate
  • Subsea Offshore platforms
  • High pressure gas
  • Gas liquid Pipelines
  • Cryogenic liquid gas
  • United States Navy

4
Cornerstone Objectives
  • Provide a superior valve solution.
  • Customer/End User satisfaction.
  • Teach others how to specify valves that
  • will perform to their expectations.
  • 4. Have Fun!

5
Cornerstone Features
  • Trunnion-mounted
  • Soft or Metal seated
  • Sizes 1/2" to 48"
  • Full or Reduced Port
  • ANSI 150 - 4500
  • API 2000 - 15000
  • -320º F to 1,875º F, -251ºC to 1023ºC
  • Any Metallurgy
  • End Connections to customer specification
  • Leakage Class to customer specification
  • Actuation to customer specification

6
Cornerstone QA Programs
  • API 6D-0164 monogram (Ball Check)
  • API 6A-0321 monogram PSL 1-4, valves
    chokes
  • API Q1-0165
  • ISO 9001 2000-0450

7
CORNERSTONE TECHNOLOGIES
1. High pressure design experience - to
15,000 psig liquid or gas - onshore,
offshore subsea 2. Abrasive services - solids
proof 3. High temperature design experience
- to 1850F 4. Low temperature design
experience - to -320F 5. Power valves 6.
Rotary Ball Control technology - patented
D-ball trim
8
Typical high pressure gas
One-Piece Ball/Stem
Standard Design Trunnion Mounted

Top Entry
Spring pre-loaded Pressure assisted
9
18 x 16 1500METAL SEATEDHIGH PRESSURE GAS
10
16-600/900IN-LINE SERVICEABLE
PetronasMalaysiadomestic gas distribution system
11
4"-10000SonatrachAlgeria Natural Gas at 10,000
psig
12
10"-2500Chevron VZ420F4000 psig
13
Amine _at_ 5,000 psig8000 F (352 Kg/cm24270
C) NATREF Refinery, So. Africa
14
14-1500 full duplex Check ValveMarathon Alba
field
15
10"-4500Gas _at_ -160 F6,200 psig
Still bubble tight !!!! Algeria - SONARCO
Cornerstone valve passes 120 km/h drop-shock test
16
2"-1500 RTJOne Piece Bodyfull SS
17
Hydrogen at 6,600 psig 465 Kg/cm2 NASA, White
Sands, NM quick opening space station thruster
nozzle developmentIn-line serviceable.
18
and Easy to Service !
19
ESD Block Features
1. One-piece ball /trunnions / stem assembly -
strong and reliable! 2. Ball axis of
rotation remains fixed due to bearing support 3.
Upstream sealing seats for bi-directional
shutoff - Permits testing of seats without
cycling valve - Uses live-loaded seals and fire
seals to allow for expansion and
contraction 4. Permits downstream seat and
upstream seat to seal in same direction (a
specification option) 5. Compatible with any
automation system 6. Takes a minimum of space,
½ the wt. of gate valves! 7. May be serviced
in-line (specification option)
Examples Boarding valves, battery limits,
etc.
20
Quick Opening (or Closing) Valve - Features
  • 6-1500 full bore, 3000 psig
  • One-piece ball / trunnions / stem assembly
  • 2. Special soft seat design - stays in one
    piece after stroking!
  • -and is bubble tight !
  • 3. Actuator, mounting bracket, bonnet and valve
    body are
  • dowel pinned together to maintain
    alignment
  • 4. Specially designed actuator to handle end
    load impacts
  • 5. Hydrogen atmosphere rated electrical
    accessories
  • 6. Proven in service with many valves going
    through hundreds
  • of cycles - still bubble tight !
  • 7. Installed at Cape Canaveral Vandenberg AFB
  • 8. No available "equal" to date 14 years!

21
  • Additional Considerations for
  • Lock hopper or Pigging Service
  • Ball lip detail - must accommodate solids
  • Ball seat coatings must be metallurgically
    bonded
  • Seats to ball loading continuous to prevent
    particles from getting between sealing
    surfaces
  • Sealing systems must accommodate rapid
    temperature
  • changes
  • Robust design - to assure high cycle life
  • Note The valve cost is small compared to the
    cost of process downtime !

22
6-1500 full bore ball valves. 3,000 psig N2.
Launch Pads Open in 0.016 seconds ! limit
switch to limit switch

36 installed! They WORK
23
Boiler recirculationtight shutoff block valve4
- ANSI 2500
Isolates the control valve 4,000psig _at_ 4100 F
24
24-900 24-300
GAS
CRUDE OIL
25
Subsea Valve Installations
  • Cameron Marine 2 1/16 -10000.
  • Launcher Manifolds to 3000 ft depth
  • ELF (Coflexip Stenna) 25 Cr duplex, 380
    meters,
  • 3 6- 1500s (off wellheads)
  • Oceaneering Gulf of Mexico, 800 ft depth avg
  • 2 3 -10000s
  • Devils Tower Gulf of Mexico, 5600 ft,
  • dual stem 4-1500s Technip
  • Oilstates Hydrotech Piston Checks, 8600 ft
    4-5000s

26
Cornerstone Subsea Valve Assembly
TACTILE POSTION INDICATOR

LIMIT SWITCH HOUSING
Alternate Location
SPRING CAVITY PRESSURE COMPENSATOR
API 17D, CLASS 4 ROV INTERVENTION
SUBSEA SPRING RETURN HYDRAULIC ACTUATOR-DANTORQUE
TOP ENTRY FULL BORE METAL SEATED BALL VALVE YCV
CORNERSTONE
Optional ends Flanged, Hub, Weld end integral
to body, as shown, etc.
Water depth 8600 ft. Testing to 11500 ft.
WELD OR GRAYLOC CONNECTION - or ONE - PIECE
WITH BODY
Max installed depth to date is 11400 feet

11-MAR-2000
27
DUAL STEM SUBSEA VALVES
SKID USED ON DEVILS TOWER
28
ROV POSITION INDICATOR
29
OPERATION FROM EITHER SIDE
30
COMPLETED SUBSEA SKID
31
Atlantis Project
  • Principal Specifications
  • All valves were API 10000 except the two main
    export valves
  • Were 26 18 1500s .
  • Top entry in-line serviceable with Grayloc ends
  • NACE MR01-75
  • Inconel 625 on all sealing surfaces
  • Sealant injection on seats and stems for both
    soft metal seated versions
  • Fully tested and documented to 6A PSL 3
  • Seals both EDR resistant to wellhead fluids
  • Note Of (6) bidders we were the only ones that
  • can routinely pass the PSL 3 testing.
  • (other bidders were from UK, France Italy)
  • Can the valves you are specifying open at full
    differential pressure and re-close to bubble
    tight ??

32
Atlantis/Mustang Gulf of Mexico
API 10,000 w/Dantorque Hydraulic SR Actuators
33
Atlantis/Mustang 12 10000 with Bettis SR
hydraulic
34

Atlantis/Mustang Project
35
Atlantis/Mustang 26-1500 main oil export valve
In-line Serviceable Special forged pipe pups
36
Atlantis/Mustang/Taylor Forge
37
8 -10000s - Mustang - Mad Dog Project - Texas
Systems
38
3 1/16 -10000s - Mustang - Mad Dog - Texas
Systems
39
Special Valve in Solid Inconel 625
Nuclear Reactor - natural recirculation - control
40
ABRASIVE SERVICE VALVES
  • APPLICATIONS
  • 1. Delayed coking - two way and 4-way valves, OH
    vapor
  • 2. Heavy sulfur and iron sulfite deposits (very
    sour gas)
  • 3. Catalyst switching at high temperature with
    fine abrasive
  • catalyst particles
  • - FCC catalyst
  • - CCR catalyst switching
  • - Iron ore reduction
  • - LC Fining, H-Oil
  • - Silica reactors
  • Ore and other slurries
  • Oil/gas with entrained sand
  • Hydrates
  • Polymers

41
Trunnion-mounted split-body solids proof !
One-piece ball Trunnion mtd Upstream Sealing
Valve body cavity is isolated when full open or
full closed.
Basic Design Elements (Split body style)
42
Features
1. Live loading of seats and ball (sealing
arrangement) 2. Isolation of the valve body
cavity from solids (double seated-trunnion) 3.
Ball design that permits rotation within its own
geometry Trunnion Mounted - and permits
true double block bleed. 4. Designs that
accommodates radical temperature swings (up
down) 5. Smooth flow passages 6. Material
selections - both of coatings and substrates. 7.
Purges - if required for a particular
application 9. Solids Proofing to exclude
solids/particulates from critical areas these
may include sealant, solids barriers, purges and
bearing isolation.
43
Examples of Solids handling Valves
  • Coal gasification 12-900 valves, handle coal,
    ash, silica particles in a slurry. Installed in
    1983. Cycle every 30 minutes. Still operating !
  • 2. Lockhopper valves handling catalyst
  • Example Temperature 1150 F (621 C), delta P of
    800 psig (56.25 kg/cm2). Char, ash, caustic
    catalyst. Cycle rate of 12 x per hour. Operated
    over 362000 cycles with zero failures! (next
    best valve design lasted 2 ½ days)
  • 18 throttling valves in Alumina Slurry

44
The result KHI process for iron ore reduction
Iron Carbide - 12000F H2

45
TiO216500 F1100 psig 8990 C, 77.5 Kg/cm2
46
Digester Blow Valve 4 300,
on Kamyr Digester Throttling
in pulp stock, sand, stones, etc.
Best valve we have ever had in this service.
.. like new after 16 months
47
Fully Stellite 21 Lined
12-900, NOX reduction system, 8000 F coke
particles
Drop tight on water, bubble tight on Nitrogen gas
zero bubbles at Full vacuum ! both directions
48
Polypropylene Reactor Letdown
Cycle 7 xs Per minute
! 4500 F 480 psig
3 years Still Stroking !
49
QUICK DELIVERY
18-600 Alumina Slurry 8 weeks ARO to first
(3) pieces. Including design pattern,
casting, machining testing
50
SYNGAS COAL GASIFICATION
18-900 Coke Particles
51
POWER VALVE APPLICATIONS
  • STEAM TURBINE DRAINS
  • CONDENSATE BLOCK CONTROL
  • BLOWDOWN
  • ATTEMPERATING
  • FEEDWATER ISOLATION
  • FEEDWATER BYPASS
  • NOISE CONTROL
  • STEAM DRUM VENT
  • SOOT BLOWER
  • SUPERHEATED STEAM
  • BOILER RECIRCULATION

52
POWER VALVE MODEL TEP-1
First in-line serviceable ball valve offered in
the power market ! Straight through flow
bore. Upstream sealing seat. Continuous seat
loading. One piece ball stems. Valves that Work!
53
POWER VALVE MODEL TEP-1
POWER
54
Completed assembly (bare stem) Lever removed
55
Remove - stem key
Stem key
Upstream
Downstream
56
Remove packing set packing follower
Packing follower
Packing set
57
Remove upper lower bonnets
Upper Bonnet
Lower Bonnet
This Unloads ball seat/seal assembly
58
Remove one-piece ball (stem-trunnions-ball)
Ball
59
Seat seat seal removed through bonnet
Inlet
Outlet
Seat
60
The Solution for Power Plants In-Line
Serviceability !
Standard Tools !
Weld end top entry body (shown
sliced along flow bore)
61
POWER VALVE MODEL TEP-1
Them suckers is ugly, but they sure do work
62
POWER VALVE MODEL TEP-1
Power valve with vane actuator, SV limit
switches
63
POWER VALVES MODEL TEP-1
POWER
  • FULLY IN-LINE SERVICEABLE
  • NO CUTTING
  • NO WELD PREP
  • NO WELDING
  • NO STRESS RELIEF
  • NO RADIOGRAPHY
  • NO NDE
  • NO MESS!!

64
Cornerstone Valve USA, LP
Boiler Vent Valves
65
Cornerstone Valve USA, LP
POWER
DEAERATOR HEATER BLOCK VALVES gt
lt DUAL BOILER TUBE DRAIN VALVES
66
Attemperator Valves - 2-1500
67
Special Valve in Solid Inconel 625
Nuclear Reactor - natural recirculation - control
68
Rotary Control Valves
  • Advantages
  • High rangeability - max Cv / min Cv
  • Space typically smaller space than globe
  • Simple packing arrangements
  • Durability with the right design features
  • - one piece ball/stem no joint no hysterisis
  • - ease of automation
  • - tight shutoff (typically ANSI/FCI Cl V or VI
  • - bi-directional shutoff (if so specified)
  • - In-line serviceable

69
Case History in Steam Letdown Service ( Gulf
Coast Fractionators - Conoco ) Valve
Size 3"-600 P1 750 psig (51.6 barg) T1 750
F P2 35 psig (2.4 barg) Flow Rate 2200 to
44000 lbs per hour. (Avg 20000) Installed 1991
(June) As of - Jul 03 3 billion lbs of
steam !! still going!! And It is quiet. -
reference available on request!
Cage guided Stellited trim globe lasts 9 months

70
Superior Solutions for Rotary Control
In addition to a variable impedance trim which
rotates with the ball, inlet / outlet trims
behave as a series / parallel combination of
chokes
Ball trim
Top view through center
Applications Blowdown, recylce/surge control,
slug catcher, cavitation control, gas/steam
control.
71
Control Valve for ROM desalination unit US Navy
Simple Components
72
Control Trim into Ball
73
  • Valves - Suggested Specification Highlights
  • Specify temperature range pressures.
  • Specify ANSI B16.34, API, or Special Class
    rating.
  • 3. Material choicescorrosion, high/low
    temperature, special trim materials expected,
    piping material, acceptable seat materials,
    coatings, weld overlays on sealing areas,
    specifications for plating, etc.
  • 4. List suggested types and grades of seals as
    well as installation
  • highlights, such as limiting cross-section
    sizes, backups, fire-
  • seal requirements (live loaded for
    example.)
  • 5. Testing In high pressure service, require
    the manufacturer to cycle the valve and prove
    operability. Suggested is testing to API 6A
    PSL 3 . Use water if in liquid service and
    nitrogen
  • if in gas service - with the minimum
    holding periods and
  • cycling requirements as outlined is this
    standard.
  • Require material certificates for all components
    in the valve.
  • Identify pipe schedules and end connections
    required.
  • 9. Specify any additional options such as
    sealant injection,
  • special painting, in-line serviceability,
    etc.

74
Cornerstone Valve Customers (Partial List)
  • PETRONAS
  • VICO
  • Millenium Chem.
  • QGPC
  • Total.Fina.Elf
  • Kvaerner
  • Chevron
  • Statoil
  • Albemarle
  • Burlington Resources
  • BP Chemical
  • BP Refinery
  • Atochem
  • Unocal
  • Texaco
  • Electric Boat
  • Bechtel Bettis
  • PDO (Oman)
  • Jacobs Sverdrup
  • BP Shell Egypt
  • Amoco
  • Mobil
  • GCF
  • CP
  • Anadarko
  • Europipe
  • Texas Utilities
  • HL P
  • Great Northern Paper
  • Sonatrach
  • SONARCO
  • Formosa
  • Mitsubishi
  • Enron
  • Newport News
  • Shell Offshore
  • NREL
  • Edison Mission
  • ARCO
  • AMOCO
  • Corpoven
  • Maraven
  • PDVSA
  • Shell
  • PEMEX
  • Conoco
  • Arnold AFB
  • Cape Canaveral
  • Vandenberg AFB
  • Stennis Space Ctr
  • Marshall Space Ctr.
  • KHI
  • Wilpro
  • Williams
  • Finch Pruyn
  • Production Operators
  • Dow (Terre Haute) PFBC

75
Applications by Country

USA Alaska Oil Gas, pulp paper,
power, Synfuels, Subsea, petrochemical,
refining, cryogenic, Military, NASA and
classified. PFBC, slug- catchers,
gas-to-flare, brine. Nuclear valves Mexico
FCC catalyst fines - 3rd stage
cleanup Venezuela High pressure gas
compression injection Colombia High
pressure gas compression injection, and
high pressure produced water injection
Compressor recycle / surge control Ecuador
High pressure oil production
76
Applications by Country
Chile Copper ore slurry, copper
smelters Finland Synfuel (PFBC) Siberia Ethyle
ne storage - salt domes Norway North Sea -High
pressure gas offshore oil pipeline blowdown
and produced water
Statoil Europipe, BP platform Holland Offshore
Subsea block valves Elf Algeria High pressure
gas injection flare block
(SONARCO, Sonatrach and Anadarko)
77
Applications by Country
South Africa Synfuels
Refining Egypt Produced water
(sour)-- injection Canada Delayed
Coking, steam crude oil China
Offshore ESD block Singapore Power
Refining Malaysia Offshore
production platform, pipeline Indonesia
High pressure oil gas production
78
Applications by Country
India Ammonia compressor valves Uzbekistan H
igh pressure gas to flare Bangladesh Domestic
gas pipeline Syria Domestic gas pipeline,
ESD Qatar Offshore high pressure gas/oil
and injection and produced water Oman
Low pressure gas lift
79
How may we assist you ?
About PowerShow.com
