Title: Difficult Airway Management


1
Difficult Airway Management
  • Anesthesia Assistant Course
  • Algonquin College
  • Joel Berube
  • 19 SEP 09

2
Objectives
  • Airway management is our specialty!
  • Significant MM associated with mismanaged
    airways
  • Avoidance
  • Anticipate
  • Airway exam, predictors of difficulties
  • Preparation
  • Know your equipment
  • Back-up plan
  • Methods, adjuncts for intubation/ventilation/oxyge
    nation

3
Outline
  • The Difficult Airway
  • Definitions
  • Assessment
  • The Algorithm
  • Anticipated DA
  • Unanticipated DA
  • Devices
  • Fibreoptic Bronch
  • Glidescope
  • Bullard Scope
  • Jet Ventilator
  • Surgical Airways
  • Percutaneous Trach
  • Cricothyroidotomy
  • Trans-tracheal Jet

4
The Difficult Airway Definitions
  • Difficult Airway
  • Difficult Laryngoscopy
  • Difficult Mask Ventilation
  • Difficult Endotracheal Intubation

5
Difficult Airway
  • Situation where a conventionally trained
    anesthesiologist experiences difficulty with
    mask ventilation, endotracheal intubation or both

6
Difficult Mask Ventilation
  • 1 person unable to keep SpO2 gt92
  • Significant gas leak around face mask
  • No chest movement
  • Two-handed mask ventilation needed
  • Change of operator required
  • Use of fresh gas flow button gt2X (flush)

7
Predictors of Difficult Ventilation
  • Beard
  • Hiding? Bad seal
  • Obesity
  • BMI gt 26
  • Age
  • gt55
  • Teeth
  • Lack of
  • Snoring
  • On history or dx OSA

BOATS
8
Difficult Laryngoscopy
  • Not possible to view any part of the vocal cords
    during direct laryngoscopy
  • Cormac-Lehane Grades III/IV

9
Difficult Endotracheal Intubation
  • Insertion of ETT with direct laryngoscopy
    requires gt3 attempts or gt10 minutes
  • Or when an experienced laryngoscopist using
    direct laryngoscopy requires
  • More than 2 attempts with same blade
  • Change in blade or use of adjunct
  • Use of alternative device/technique following
    failed intubation with direct laryngoscope

10
Predictors of Difficult Laryngoscopy/Intubation
  • aka your airway assessment (last class)
  • Mallampati
  • What can you see when they open their mouth?
  • Mouth Opening, teeth
  • Can you fit your blade tube in the opening?
  • Thyromental Distance
  • Predicts an anterior larynx
  • C-Spine Range of Motion
  • Can they get in a sniffing position?

11
Tough Airways?
12
General Approach to Airways
  • Is Airway Control Required?
  • ie is there a different anesthetic technique?
  • Predict Difficult Laryngoscopy?
  • Is Supralaryngeal Ventilation (LMA, mask) ok to
    use if needed?
  • ie can you get away without intubation?
  • Full Stomach?
  • Will the patient tolerate an apneic period?

13
Difficult Airway Algorithm
  • A model for the approach to the difficult airway
  • Considers
  • Patient factors
  • Clinical setting
  • Skills of the practitioner
  • If you need to intubate the patient for the case
    and run into trouble at any step

14
(No Transcript)
15
Airway assessment
  • Non-Reassuring
  • Laryngoscopy
  • Ventilation technique
  • Aspiration Risk
  • Intolerance of apnea
  • Anticipated DA
  • Awake Technique
  • Box A
  • NB - Invasive knife or needle in the neck
    (see surgical airway)
  • Reassuring
  • Put the patient to sleep, now having difficulty
  • Unanticipated DA
  • Attempts after induction
  • Box B

16
Difficult Airway Algorithm - Anticipated DA
17
DA anticipated, intubate Awake
  • Patient will maintain their own patent airway
  • Can abandon or try another approach
  • No bridges burned
  • Concept freeze the airway, put the tube in, /-
    sedation (usually !)

18
Awake Intubation Advantages
  • Maintain spontaneous ventilation
  • Wide open pharynx and palate space
  • Forward tongue
  • Maintain esophageal tone (?aspiration)
  • Able to protect if reflux occurs
  • Risk of neurologic injury able to monitor
    sensory-motor function
  • Some spines awake intubation positioning!

19
Contraindications to Awake
  • Emergency no ABSOLUTE, but caution
  • Cardiac ischemia, bronchospasm, increased ICP or
    ocular pressure
  • Elective
  • Refusal or inability to cooperate
  • Child, mental retardation, dementia, intox
  • Allergy to local anesthetics

20
Technique
  • Generally Awake Intubation implies use of
    Fibreoptic Bronchoscope
  • Any other method to intubate is possible, but
    likely more difficult or tough to tolerate
  • Used to do awake blind nasal intubations in
    trauma patients (some still do)

21
The Fibreoptic Bronchoscope
  • fragile device with optical and non-optical
    elements
  • Glass-fibre bundle (10k-30k fibres)
  • Objective - Insertion Cord - Eyepiece
  • 60cm, graduated q10cm
  • Flexible, rotate, bend, control
  • Working Channel (2mm diam)
  • Suction, O2, fluids, drugs
  • Peds intubating scopes no channel (lt2mm ext
    diam)
  • Light Source

22
Bronch
23
FOB intubation
  • Local Anesthetic
  • 3 areas to freeze
  • Nasopharynx
  • Base of tongue
  • Larynx/trachea
  • Topical
  • Swish/swallow
  • Pledgets
  • Viscous
  • Nebulized
  • 4 Lido, 10-15min pre
  • Nerve Blocks
  • Bronch
  • Correct size
  • Light Source
  • monitor/eyepiece
  • Suction
  • O2 for patient
  • Tube/Lube
  • Oral Airways/Bite block

24
FOB intubation
  • Topicalize the airway
  • Supplemental O2
  • Appropriate sedation
  • For the patient!
  • Insert Oral Airway
  • Appropriate size it will help guide scope and
    protect it
  • Tube loaded on scope
  • Holder/tape
  • suction
  • Visualize cords with scope
  • Some more local via working channel?
  • Advance ETT
  • Confirm placement
  • ETCO2
  • Induce the anesthetic
  • Very uncomfortable

Patient needs coaching/reassurance throughout!!!
25
Troubleshooting
  • Tube not advancing through cords
  • Too large tube and too small scope the extra
    room causes the tube to catch on arytenoids
  • Softer ETT
  • Deep breath
  • Scope in centre of cords, bevel forward, rotate
    ETT clockwise
  • FOB not good if pt. bleeding in A/W or
    secretions
  • Suction not adequate
  • Try O2 to clear lens
  • Desaturations
  • Keep O2 on!
  • Breaks for patient
  • Sedation level
  • Fogging up
  • Defogger
  • Warm scope prior to starting
  • Suction/insuffl/flush
  • Adjust picture?

26
Pearls
27
DA Algorithm
  • Ok, so if youre not reassured by the airway,
    intubate awake
  • If not successful (box A)
  • Cancel/wake vs. invasive airway!!
  • What if the airway doesnt look bad and you bang
    the patient off to sleep only to see this

Obviously you cant just stick the tube in! What
now?
28
(No Transcript)
29
From this point on, consider
  • Call for Help
  • Absolutely!
  • Return to Spontaneous Ventilation
  • If you can
  • Awakening the patient
  • If you can

30
Cannot Intubate Scenario
  • Optimize position/scope etc
  • DO NOT persist with repeated attempts at direct
    laryngoscopy
  • Evidence that this approach leads to
    complications (including death)
  • Return to Mask Ventilation, get SpO2 back up and
    try another technique
  • Glidescope, Bullard, Bougie, Trachlite,
    Intubating LMA, McCoy Blade

31
(No Transcript)
32
Alternate Techniques
  • Your first attempt at laryngoscopy should always
    be set up to be the best
  • Early transition from one technique to another
    without persistent and multiple failed attempts
  • On subsequent attempts, use adjuncts to enhance
    whatevers missing the last time
  • Need to remain fluid/flexible and adapt the plan
    as you progress through the algorithm
  • Often means going through lots of equipment
  • Having backups and backups for the backups

33
Other devices
  • Reviewed last week?
  • Different laryngoscope blades
  • MAC, Miller, McCoy
  • Different introducers
  • Stylet, Bougie, Trachlite
  • Supraglottic Devices
  • LMA, Proseal, Fastrach (ILMA)
  • Combitube, King Airway, Cobra Airway

34
Glidescope
  • Video-assisted laryngoscopy
  • Video chip set at the end of a conventional-like
    blade
  • Steeper angle (60º)

Canadian Invention!
35
Glidescope Advantages
  • Setup minimal/easy!
  • Handled with similar skills for direct
    laryngoscopy
  • But in midline
  • No need to elevate tongue
  • Point of sight is near blade tip
  • Can see around the corner
  • Image on screen
  • Supervisor, assistant can see too
  • Less stress on airway
  • Dont need external light source
  • Lightweight, compact

36
Glidescope Negatives
  • As with FOB, image can be obscured by
    blood/secretion
  • Less a problem with color vs. B/W monitor
  • Sometimes view is better than you can get a tube
    into
  • Variations on stylet bends
  • Re-usable glidescope stylet
  • Limited number of handles/blades
  • Need to be sterilized between uses
  • Cap in correct place before cleaning!!!

37
Bullard Scope
  • Fixed fibreoptic cable on posterior part of blade
  • Same setup as FOB
  • Eyepiece
  • Working Channel
  • Detachable Stylet
  • Blade has natural curve
  • Good if C-spine ROM ?

Predecessor to Glidescope?
38
Bullard s
  • Low profile
  • Gets into mouth when opening limited
  • High Flow O2 via channel blows secretions away
    and may reduce fogging
  • Attached stylet helps direct tube to glottis
  • Can use standard scope handle instead of light
    source

39
Bullard -s
  • Finnicky sometimes very difficult to get a good
    view, even in an easy airway
  • Plastic extension on blade sometimes dislodges.
    Dont forget it in the patient!!!

40
Back to the Difficult Airway
  • Still unable to intubate despite help, various
    adjuncts, adjustments, alternate devices
  • Now youre having trouble ventilating!!!
  • Now try 2 and 3 handed mask ventilation, LMA (if
    feasible)
  • If this works, get the SpO2 back up, breathe
    yourself Try again, abort, discuss

41
(No Transcript)
42
Cannot Intubate-Cannot Ventilate
  • THIS IS AN EMERGENCY
  • If you havent yet CALL FOR HELP
  • People die if you cant ventilate them
  • You NEED to secure an airway or have the patient
    awake and breathing on their own!
  • Securing the airway likely now Invasive Airway
  • Salvage techniques while getting the surgical
    airway?

43
The Surgical Airway
  • aka the invasive airway
  • If access to the airway through the mouth or nose
    is unavailable, need to access the airway via the
    trachea
  • Needle cricothyroidotomy and jet ventilation
  • Percutaneous cricothyroidotomy set
  • Emergency/Awake Tracheostomy

44
Cricothyroidotomy
  • Landmarks thyroid cartilage, cricoid cartilage
    cricothyroid membrane
  • Local to skin (if time) and entry via membrane
    with large needle attached to partially-filled
    syringe
  • Aspiration of air into airway!
  • Proceed to ventilate, retrograde wire intubation,
    percutaneous cric set

45
Transtracheal Ventilation
  • Connect the needle/angiocath to an oxygen source,
    jet ventilator, ambubag and deliver air/oxygen
    into the trachea
  • Not a protected or definitive airway
  • Life-saving, temporizing measure

46
Sanders Jet Ventilation
  • O2 from hi-pressure source (50psi) thru valve and
    switch to a needle and into the airway
  • Used in shared airway surgeries
  • Rigid bronch

Surgeon working in airway, cant use normal
ventilation/ETT
47
Sanders Jet Ventilator
  • Continuous Ventilation is possible
  • Can minimize apneic period, shorten surgery
  • Can deliver O2, N2O, Volatile Anesthetic
  • Jet entrains room air, so variable and
    unpredictable FiO2 at end of scope
  • Inadequate ventilation of lungs if poor
    compliance
  • Difficult to assess adequacy of ventilation
  • Can be used for transtracheal oxygenation
  • Next section

48
Percutaneous Cric Set
  • Once cricothyroid membrane punctured with needle,
    can use Seldinger technique to dilate tissues and
    insert a large bore cannula to secure the airway
  • Not a trach, but allows ventilation and
    oxygenation with low-pressure systems (std 15mm
    connector)
  • Ambubag, conventional ventilator
  • Some are cuffed, so would protect airway

49
Emergency Tracheostomy
  • Rather than needling the neck, once its
    established that the patient needs a surgical
    airway, the surgeon performs a surgical
    tracheostomy
  • Awake or asleep, depending on where on the
    algorithm the scenario happens to be

50
Awake Tracheostomy
  • Some airways are so non-reassuring and patients
    so high risk that Plan A is to perform a
    tracheostomy under local anesthetic (/- minimal
    sedation) PRIOR to any other airway management or
    anesthesia
  • Ex certain head/neck tumors/malformations,
  • Any attempt at awake intubation may create an A/W
    obstruction and loss of airway
  • Cant intubate, cant ventilate scenario is
    avoided!
  • Awake patient prepped and draped, surgery
    started once airway access secured, induction of
    anesthesia can occur

51
(No Transcript)
52
Recap
  • Difficult Airway Definitions
  • Predictors
  • Difficult Airway Algorithm
  • Fibreoptic Bronchoscope
  • Awake intubation
  • Alternate Devices
  • Glide, Bullard, Sanders
  • Emergency Airway
  • Surgical Airway

53
Take-Home messages
  • Not all airways are routine
  • Theres more to a difficult airway than difficult
    laryngoscopy
  • Need skills with various airway tools and
    adjuncts and must transition between them easily
    and quickly
  • Familiarity with the difficult airway algorithm
    should give you a sense of which direction a
    given scenario is taking
  • When faced with cannot intubate, cannot ventilate
    scenario, decision to secure surgical airway is
    life-saving and hesitation can be costly

54
Questions? Discussion?
  • Thank you.
About PowerShow.com
