MRI of Brain/Head and Neck

1
MRI of Brain/Head and Neck

• labeling by Amanda Butcher, MD
• JCE SOM Class of 2008

2
White Matter
Grey Matter
3
Parietal Lobe
White Matter Occipital Lobe
Frontal Lobe Lateral Sulcus
Temporal Lobe
Grey Matter
Cerebellum
4
Gyri of cerebral cortex
Sulci of cerebral Cortex
Frontal Lobe
Temporal Lobe
Cerebellum
5
Parietal Lobe
Frontal Lobe
Occipital Lobe
Temporal Lobe
Cerebellum
6
Parietal Lobe Occipital Lobe Transverse
Sinus Cerebellar Hemisphere
Frontal Lobe Eye Ball
7
Precentral Sulcus
Lateral Ventricle
Occipital Lobe
Optic Nerve Maxillary Sinus
8
Corpus callosum
Thalamus Tentorium Cerebelli Pons
Caudate Nucleus Tongue
9
Thalamus
Genu of Corpus Callosum
Splenium of Corpus callosum
Hypophysis
Mesencephalon
Ethmoid air Cells Inferior nasal Concha
Fourth Ventricle
Pons
10
Body of corpus callosum
Thalamus
Splenium of Corpus callosum
Genu of corpus callosum
Superior Colliculus
Inferior Colliculus
Nasal
Nasal Septuml
Pons
Medulla
11
Cingulate Gyrus
Splenium of Corpus callosum
Genu of corpus callosum
Ethmoid air cells
Fourth Ventricle
Oral cavity
12
Thalamus
Corpus Callosum
Parietal Lobe Occipital Lobe
Frontal Lobe Maxillary Sinus
Cerebellum
13
Parietal Lobe Lateral Ventricle Occipital
Lobe Cerebellum
Frontal Lobe Temporal Lobe
14
Parietal Lobe Occipital Lobe Cerebellum
Frontal Lobe Temporal Lobe
15
Parietal Lobe Middle Temporal Gyrus External
Auditory Meatus
Frontal Lobe Lateral Sulcus Superior
Temporal Gyrus Inferior Temporal Gyrus
16
Eye Ball
Lateral Sulcus (Sylvian)
Cerebral Peduncle
Temporal Horn Lateral Ventricle
Inferior Colliculus
Occipital Lobe
17
Third Ventricle
Putamen
Globus Pallidus
Thalamus
18
Frontal Horn Lateral Ventricle
Anterior Limb Internal Capsule
Head of the Caudate Nucleus
Posterior Limb Internal Capsule
Thalamus
19
Frontal Lobe
Genu of Corpus Callosum
Anterior Limb Internal Capsule
Lentiform Nucleus
Head of the Caudate Nucleus
Posterior Limb Internal Capsule
Thalamus
Splenium of Corpus Callosum
Lateral Ventricle
20
Longitudinal Fissure
Frontal Horn Lateral Ventricle
Caudate Nucleus
Occipital Horn Lateral Ventricle
21
Corpus Callosum
Lateral Ventricle
22
Corona Radiata
Cingulate Gyrus
23
Gyri
Sulci
Falx cerebri
24
Calvarium
25
Superior Sagittal Sinus Straight Sinus
26
Superior Sagittal Sinus Straight Sinus
Transverse Sinus
27
Superior Sagittal Sinus
Cerebellum
28
Occipital Lobe
Cerebellum
29
Longitudinal Fissure Sigmoid Sinus
Straight Sinus Vermis of Cerebellum
30
Lateral Ventricle, Occipital Horn
Straight Sinus Cerebellum
31
Arachnoid Villi Great Cerebral Vein Tentor
ium Cerebelli
Falx Cerebri Lateral Ventricle Vermis
of Cerebellum Cerebellum
32
Splenium of Corpus callosum Posterior
Cerebral Artery Superior Cerebellar Artery Fo
ramen Magnum
Lateral Ventricle Internal Cerebral Vein Tentor
ium Cerebelli Fourth Ventricle
33
Corpus Callosum Thalamus Pineal
Gland Vertebral Artery
Cingulate Gyrus Choroid Plexus Superior
Colliculus Cerebral Aqueduct
34
Insula Lateral
Sulcus Cerebral Peduncle Olive
Crus of Fornix Middle Cerebellar Peduncle
35
Corpus Callosum Thalamus Cerebral Peduncle Para
hippocampal gyrus
Caudate Nucleus Third Ventricle
Hippocampus Pons
36
Lateral Ventricle Uncus Of
Temporal Lobe Lateral Ventricle, Temporal Horn
Body of Fornix Third Ventricle Hippocampus
37
Internal Capsule Insula
Optic Tract
Caudate Nucleus Lentiform Nucleus Hypothalamus
Amygdala Parotid Gland
38
Cingulate Gyrus Caudate Nucleus Lentiform
Nucleus Internal Carotid Artery
Internal Capsule Optic Nerve Nasal part
of Pharynx
39
Superior Sagittal Sinus Genu of
Corpus Callosum Temporal Lobe
Longitudinal Fissure Lateral
Sulcus Parotid Gland
40
Frontal Lobe Nasal Turbinate Masseter
Muscle
Ethmoid Sinus Nasal Septum Nasal Cavity Tongue
41
Frontal Lobe Rectus Superior Rectus
Inferior Maxillary Sinus Tooth
Rectus Medialis Rectus Lateralis Inferior
Turbinate
42
Superior Sagittal Sinus White Matter Eye
Ball Maxillary Sinus Tongue
Grey Matter
43
Superior Sagittal Sinus Nasal
Septum Tooth
44
Frontal Lobe Oral Cavity
Eye Ball
45
(No Transcript)
46
Nasal Turbinate Medulla Oblongata Vermis
of Cerebellum
External Auditory Meatus Auricle
47
Maxillary Sinus
Rhombencephalon (Hindbrain) Inferior
Cerebellar Peduncle
Trigeminal Nerve Fourth Ventricle Cerebellum
48
Maxillary Sinus Middle Cerebellar Peduncle
Temporal Lobe Pons Fourth Ventricle
49
Ethmoid sinus
Pituitary Gland
Temporal Lobe Pons Fourth Ventricle
Cerebellar Hemisphere
50
Lens
Eye Ball Optic Nerve Optic Chiasm Pons Ce
rebellum
Lateral Rectus muscle
Temporal lobe
Cerebral aqueduct
51
Nasal Septum
Eye Ball Cerebellum
Cerebral Peduncle Inferior colliculus
52
Eye Ball Third Ventricle Cerebral
Peduncle Vermis of Cerebellum Cerebellum
Hypothalamus Inferior Colliculus
53
Third Ventricle Superior
colliculus Cerebellum
Lateral Sulcus (Sylvian) Lateral Ventricle
54
Genu, Corpus Callosum Anterior Limb, Internal
Capsule Thalamus Lateral Ventricle
Head of Caudate Nucleus Posterior
Limb, Internal Capsule
55
Lateral Ventricle
Head of Caudate Nucleus Third
Ventricle Lateral Ventricle
Anterior Limb, Internal Capsule
Thalamus
Choroid Plexus
56
Longitudinal Fissure
Lateral ventricle, Frontal horn
Genu of corpus callosum
Head of Caudate Nucleus
Lateral Ventricle, Occipital horn
Internal capsule
Falx cerebri
57
Cingulate gyrus
Corona radiata
58
Falx cerebri
Calvarium
59
Grey Matter White Matter
Falx cerebri
60
Gyri
Sulcus
