Bored Piles

1
Bored Piles
2
Bored pile developement

• Why was bored pile system invented?
• There are many type of bored piles
• Have you seen them?
• ..

3
Type of Bore piles

• There are two types(Equipment)
• Rotary, Non rotary
• There are two types(Size)
• Small, Large Diameter bored pile
• There are two types(Process)
• Dry Process, Wet Process

4
Small bored pile (Dry Process)Ø35,40,50,60
(tripod)N/A (Auger) Discuss Adv.Disadv.
5
Casing surcharge
6
Casing checking connecting
7
Vertical Checking
8
Equipment (tripod) Cylinder hammerTackleAir
winch
9
ReinforcementSpacer
10
Material Quality (general)

• Concrete
• fcgt240 ksc. (cube)
• Cement content gt 300 kg/concrete m3
• Steel
• Main SD-30, As gt 0.5 of total area
• Stirrup SR-24 (single or spiral)gt 6 mm. _at_
  0.30m(Max.)

11
Process for Tripod

• Pre bore depth 1.00-1.50 m. by boring tackle
• Checking position, vertical line
• Casing..Length 1.00-1.20 m. .gtgt Stable stratum
  (BKK clay 20.00-23.00 m.)
• Boring ..casing and boring until required depth
• Cleaning bored holeNo slump concrete and compact
• Reinforcing steel install..
• Pouring concrete.
• Removing casing(details in class)
• Checking..

12
Wet Process

• From limitation of Dry process
• Discuss Adv. Disadv.
• Shape Circular, Rectangular (Barrette)
• Thailand (BKK)
• Up to 1500 T. in capacity
• More than 60 m. in depth
• Up to Ø 2.00 m.

13
(No Transcript)
14
Method statement (Drilling Rig)

• Insert steel casing by hydraulic vibrator
• Start drilling by auger until digged to sand
  layer
• Add Bentonite slurry into the bore hole to
  protect collapse of side of bore hole
• Continue drilling by using Bucket under bentonite
  slurry till reach to the require depth
• Pull drill and insert rebar cage
• Add Tremie and pouring concrete (details in
  class) replaced sullry to Betonite plants
• During place concrete and pull casing Complete

15
Bucket Auger
16
Hydraulic Vibrator.Steel case
17
Check vertical line
18
Bored pile diagram
19
Expanded pile tip
20
Rebar cage Checking depth
21
Tremie pipe
3-5 m.
22
Tremie Plug
23
Bentonite Slurry

• Why..use it?
• EX. General Characteristic (change under Eng.)
• PH gt7
• Density 1.02-1.15 T/m3 Quantity 2-6by weight
• Viscosity 30-90 sec. (Marchs Cone Test)
• Maximum sand content lt 6
• Level of Bentonite 2.00 m. from top of casing

24
Bentonite(2)
25
Desander Desilter
26
Checking Report

• Checking Quantity of poured concrete and
  calculated volume continuously
• Avoid/Do not disturb bored piles those concrete
  not setting

27
Tangential piles as retaining wall
