Text in Oracle The Search Platform and Ultra Search

1
Text in OracleThe Search Platform and Ultra
Search
Omar Alonso, Senior Product Manager, Oracle
Corp. Stefan Buchta, Principal Product Manager,
Oracle Corp. NoCOUG May 16th 2001
2
Agenda

• What is Oracle Text?
• Introducing Oracle Text
• Text in the database Why Integration is Key
• Performance and scalability
• Ease of Use
• Global Solutions
• Search Quality
• Specialized Indexes
• XML
• Document Services
• Ultra Search
• Summary

3
What is Oracle Text?

• Formerly know as interMedia Text
• Oracle Text adds powerful text search and
  intelligent text management capabilities to the
  Oracle database.
• Oracle Text
• Fully integrated with the database
• Offers premier text search quality
• Provides several advances features for text
  management, document services, XML, etc.
• Has the best internationalization set of features
  for multilingual text search applications.

4
Introducing Oracle Text An example

• create index description_idx on
• PRODUCT_INFORMATION(PRODUCT_DESCRIPTION)
• indextype is ctxsys.context
• select score(1), product_id, product_name
• from product_information
• where contains (product_description, 'monitor
  NEAR "high resolution"', 1)gt0
• order by score(1) desc
• SCORE(1) PRODUCT_ID PRODUCT_NAME
• -------- ---------- -------------------------
  -----
• 29 3331 Monitor 21/HR
• 27 3060 Monitor 17/HR
• 14 1726 LCD Monitor 11/PM
• 14 3054 Plasma Monitor 10/XGA
• 14 2252 Monitor 21/HR/M
• 14 2243 Monitor 17/HR/F

5
Integration with the database

• The attempt to separate text and normal business
  (structured) data fails
• Cost
• Complexity
• High latency of development and deployment
• Performance

6
No Integration - Separate Everything
File System
Inverted
C API
Oracle Database
B-Tree
SQL
Repository
Index
Search Engine (API)
7
Full Integration text, index, API, optimizer
SQL
Oracle Database
B-Tree
Repository
Index
Search Engine (API)
8
Integration Benefits

• Low cost
• Low complexity
• High performance
• High integrity
• Manageability
• Leveraging existing skills

9
Oracle Uses Oracle Text

• Oracle internet File System
• Oracle Portal
• Oracle CRM
• Oracle E-Business Suite
• Oracle eXchange
• Ultra Search
• Oracle.com
• OTN

10
Oracle Internet File System
11
Oracle E-Business Suite
12
Performance illustration

• Large doc set 100Gig (20million web pages)
• Hardware Enterprise Sparc
• Task web query
• Web-style query syntax
• 2-3 words
• Return first 100 hits
• 40 queries/second
• 90 of requests take lt 0.5 second
• 7 hours to create index

13
Performance Query throughput

• Oracle Text vs one of the best-known specialist
  Text search engines

14
Ease of Use, Ease of Development

• Simple SQL and PL/SQL interface
• Can be used by any developer that knows SQL
• Can be called by any tool that knows SQL
• Using any language Java, JSP, PL/SQL, C, etc.
• Choice of datastores
• Stored in the database
• Stored in the file system
• Stored on the web (URL)
• User-defined datastore

15
Global Solutions

• Basic indexing/search works in any NLS language
• Special support for Japanese, Chinese, Korean
• Theme search and services available in any
  single-byte, white space-delimited language
• Can mix languages, character sets in a single
  column
• Can query across languages

16
Chinese, Japanese, Korean Text

• Character sets
• Japanese JA16SJIS, JA16EUC
• Simplified Chinese GBK, GB2312-80
• Traditional Chinese BIG5, EUC, TRIS
• Korean KO16KSC5601
• Unicode UTF8
• Lexing
• Lexical segmentation for Japanese, Chinese
• Morphological segmentation for Korean

17
Multilingual Search
18
Cross-language queries

• Can mix languages, character sets within a
  document collection (e.g. Chinese and English
  documents)
• Can use English to query e.g. Chinese terms or
  vice versa.
• Query a term which is expressed differently in
  simplified and traditional Chinese.
• select score(1), product_id, product_name
• from product_information
• where contains (product_description,
  'TRSYN(monitor, Chinese)', 1)gt0
• order by score(1) desc
• Find products whose description contains
  monitor' or its Chinese equivalents.

19
Search Quality

• Exact word
• Boolean expression
• Phrase
• Proximity
• Fuzzy
• Stemming
• Wildcards
• Prefix, substring index

• Thesaurus, multiple Thesauri
• ABOUT search
• Theme (concept-based) search
• Accumulate scores
• Term weighting
• Advanced XML search
• XPath support
• Query Feedback

20
ABOUT themes and theme queries

• "We ordered a bottle of chardonnay to go with the
  fish, and cabernet sauvignon for the steak "
• select id from docswhere contains(text,
  ABOUT(wine)')gt0
• The knowledge base allows Oracle Text to
  associate words and concepts.
• Knowledge base contains over 400,000 concepts.
• You can extend the knowledgebase to include
• Words and concepts from your specialist field
  e.g. medicine
• Associations of words and spellings to guide
  novice/internet users

21
Catalog Index

• Optimized for response time on small text fields
• True transactional DML
• Supports structured query, including range query
• Subset of CONTEXT query language
• No fuzzy, stemming, about
• User-friendly web-like query syntax

22
Classification

• CTXRULE is an index type designed
  classification/routing applications
• Efficiently take a document and find matching
  queries

Classification Application
Perform Action
Incoming documents
Matched Documents
Compares against rules
9i
23
Prefix, substring index

• Prefix and Substring are flavors of the CONTEXT
  index
• Prefix will add more tokens to the CONTEXT index
  to efficiently process prefix searches (e.g.
  'ora')
• Substring will add an index on substrings of each
  token, to efficiently process substring searches
  (e.g. 'oxy')

24
Storing XML in Oracle

• Decomposition
• decompose documents into atomic elements
• store elements in columns/rows
• compose XML documents using SQL
• xmltype
• store XML as xmltype, use xmltype methods
• Store as LOB or varchar
• Store XML as-is, in a LOB or VARCHAR
• Search using Oracle Text section searching or
  XPath

25
Content search and XML

• Create index
• create index BOOKINDEX on BOOKS(text) indextype
  is ctxsys.context
• Query by content
• select PRICE from BOOKS
• where contains(text, Harry Potter')gt0 order by
  price desc
• Create index to include section info create
  index BOOKINDEX on BOOKS(text) indextype is
  ctxsys.context parameters ('section group
  my_auto_section_group' )
• Limit content search to a section of text
• select price from books
• where contains(text, Harry Potter within
  title)gt0 order by price desc

26
Advanced XML searches

• Nested section search
• ltmoviegtlttitlegtThe Matrixlt/titlegtlt/moviegt
• ltbookgtlttitlegtIntroduction to Matrix
  Algebralt/titlegtlt/bookgt
• select price from media
• where contains(desc, matrix within title within
  movie)gt0
• Search inside attribute values
• ltbook authorBarry HughartgtBridge of
  Birdslt/bookgt
• select title from books
• where contains(text, Hughart within
  book_at_author)gt0

27
More advanced XML searches

• map multiple tags to same name
• ltH1gtThe Diamond Agelt/H1gt
• ltH2gtor, A Young Ladys Illustrated Primerlt/H2gt
• (map H1 and H2 to section name of headline)
• select author from articles
• where contains(text, Diamond within headline)gt0
• doctype limiters to handle tag collisions
• lt!DOCTYPE foogt ltaddressgtking_at_world.com
• lt!DOCTYPE bargt ltaddressgt123 Meheula Pkwy
• map (foo)address to email, (bar)address to
  address

28
Document Services

• Extract Themes (major concepts)
• Extract hierarchical structure
• Extract Gist
• Generic or Point-of-View
• Sentence- or Paragraph- level
• View a document as HTML
• Highlight search terms, highlight navigation
• Return results in a table or a PL/SQL table
• Basis for Clustering, More Like This,

29
Summary

• Fully integrated with the database
• Premier text search quality
• Advanced features for text management, document
  services, and XML.
• Best multilingual features in the market.

30
Introducing Oracle Ultra Search
31
Issues in Corporate Search

• Information Management Crisis
• Explosive Growth of Information flowing over
  corporate Intranets.
• Knowledge scattered across IT repositories,
  billions of documents, and data fragments.
• Non-Uniform Information
• Structured in databases.
• Unstructured - Word processing doc.,
  presentations.

32
Impacts of Bad Search

• Customers - Turn to competitors Website.
• Employees - Waste time and money on useless
  searches.
• Oracle Ultra Search
• Solves problem of finding relevant information.
• Across your companys many disparate information
  repositories.

33
Oracle Ultra Search

• Out-of-the-Box solution that
• Searches text across multiple repositories
• Databases, HTML Pages, Files, Mail Servers.
• Provides the best relevance ranking and
  globalization in the industry.
• Provides value added Portal functionality.
• Presents Web style interface.
• Built onto Oracles proven, reliable Text
  Retrieval software and Oracle9i server.

34
Oracle Ultra Search
Docum. Title
Relevance
35
Ultra Search Applications

• Portal Search
• Most powerful search for Oracle9iAS Portal.
• Build your own portal.
• Special Portlet crawls inside and outside of
  Portal Repository.
• Canned Web Search for Oracle Text
• Library or Archive Search
• Content Management Platform Searc

36
Search Multiple Repositories
37
Value Added Portal Functionality

• Canned Web-Style Search
• Aggregates Information For Indexing
• Documents stay in their own repositories.
• Search returns normalized results, uniformly
  ranked by relevance.
• Organize Categorize Content From Multiple
  Repositories
• Extract valuable metadata.
• Improve search by narrowing through fielded
  search.

38
Out-of-the-Box Web-Style Search

• Oracle Text Application
• Uses public Text interfaces.
• Enhanced with expertise about gathering and
  indexing information for best quality search.
• No coding against low level APIs.
• Oracle Text Retrieval Engine
• Highly integrated with Oracle9i server.
• Best interoperability with dynamic data.
• Scalability and Reliability of Oracle platform.

39
Aggregates Information

• Gather
• Crawls Web, corporate repositories
• Analyze
• Create index required for querying, filter
• Make Queryable
• Embedd through API
• Maintain
• Schedule crawling
• Easy Administration

Gather
Analyze
Maintain
MakeQueryable
40
Powerful Fielded Search

• Narrow search to parts of document - title, body,
  name of author.
• Extract and use repository metadata
• Word processing documents Author, Title.
• Databases Identify Columns.
• Email Header/Body/Attachment.
• Unify repositories in common, logical terms.
• Uniform set of results, ranked by overall
  relevance.

41
Flexible Metadata Mapping
Search Term
Metadata Fields
Repositories
42
Ultra Search Architecture
43
Architecture

• Simple, Robust Architecture Built on
• Oracle9i Server Platform
• Oracles Text Retrieval Engine
• Flexible Deployment
• Server-Tier
• Mid-Tier

44
Ultra Search Components

• Crawler
• Server Component
• Query API Application
• Administration Tool
• Mail API

45
Ultra Search Crawler

• Multi-Threaded JAVA process.
• Gathers documents from repositories you specify
  on a set schedule.
• Maps and analyzes link relationships.
• Filters (150) Non-HTML Documents, extracts
  valuable metadata.
• Indexes documents and data fragments.
• Flexible Configuration
• Run on one or more machines Remote crawling

46
Ultra Search Crawler

• Set Inclusion/Exclusion Domains
• Limit crawling to corporate net or specific
  sections of it.
• Maintain Fresh Search Results
• Set crawling schedules for each Web site or
  repository.

47
Crawling Abilities

• Web Sites (HTTP Protocol)
• Database Tables
• Oracle and any ODBC compliant database.
• Local (Ultra Search instance) or remote database
• Crawls both fulltext and fielded columns.
• Files (file// Protocol)
• Ultra Search filters, extracts text and metadata.
• Emails (IMAP Protocol)
• Crawl and index mailing lists through IMAP.

48
Ultra Search Query API

• Embed Ultra Search in your Portal or
  Application.
• Customize look-and-feel to your requirements.
• Easy integration with your application.
• API for JAVA (JSP) and PL/SQL (PSP).
• Returns data with or without HTML markup.
• Build Basic Search Form, Search Result Form...
• Includes Highly Functional Query Application.

49
Java Query API Illustration
3
1
2
50
PL/SQL Query API Illustration
1
2
3
4
51
Administration Environment

• Browser-based, Self-Service Web Application.
• Define Ultra Search Instances.
• Configure and Schedule Crawler.
• Set Query Options To Narrow Searches.
• Document Attributes (e.g. TITLE, AUTHOR).
• Define Data Source Groups.
• Manage Administrative Users.

52
Administration Environment
53
Summary

• Eliminate the Chaos Inside Your Firewalls !
• Oracle Ultra Search
• Crawls, Indexes, and makes searchable your
  Intranet.
• Provides Web-style search without the need for
  coding.
• Organizes, categorizes, and unifies content from
  multiple repositories.
• Leverages Oracle9i platform - reliable, scalable,
  always available.

54
A
55
(No Transcript)
