Discover the Microbes Within: Impacts of DNA-based technologies and PCR basics

1
Discover the Microbes WithinImpacts of
DNA-based technologies and PCR basics

• Bill Reznikoff
• Marine Biological Laboratory
• Woods Hole, MA

2
The Old WayClassical microbiology phenotypic
approach
Gram stain
Culture
Shapes
3
The old, old way Darwin and the first tree
4
Genes to Cells (Cells to Organisms)

• DNA is the genetic material
• DNA encodes RNA
• RNA (mRNA) encodes proteins
• Proteins (and some RNAs) compose cells
• Cells compose organisms

5
(No Transcript)
6
The New way The Evolutionary Tree of Life

• Evolution
• The process of genetic change in a line of
  descent over time that results in new varieties
  and species of organisms
• Phylogeny
• Evolutionary relationships between organisms
• Relationships can be deduced by comparing genetic
  information (nucleic acid or amino acid
  sequences) in the different specimens
• Ribosomal RNA (rRNA) are excellent molecules for
  determining phylogeny Carl Woese 1st person to
  use it
• Can visualize relationships on a phylogenetic
  tree

7
16S rRNA (ribosomal RNA)

• Small ribosomal subunit involved in mRNA
  translation process
• Ancient molecule, conserved function,
  universally distributed
• Helps identify unknown bacterium to genus or
  species levels
• Present in bacteria eukaryote has very
  divergent copy that is named 18S rRNA present in
  all cells
• Plays a catalytic and structural role in the
  ribosome

8
16S rRNA conservation (red)
9
Ribosomal RNA (rRNA) Gene Sequencing and Phylogeny
Universal PCR primers for 16S rRNA
Figure 2.16
10
Microbial Systematics genetic approach

• Gene sequences are identifiers of organisms
• More accurate, objective, and reproducible
  results
• Identifies unculturable bacteria (99)
• Eliminates special growth requirements
• DNA sequence data are more easily shared and
  databased
• Rapid diagnosis
• Resolves evolutionary relationships through trees
  metaphors for evolutionary diversification

11
The Evolutionary Tree of Life

• Comparative rRNA sequencing has defined three
  distinct lineages of cells called domains.
• Bacteria (prokaryotic)
• Archaea (prokaryotic)
• Eukarya (eukaryotic)
• Archaea and Bacteria are NOT closely related.
• Archaea are more closely related to Eukarya than
  Bacteria.

12
Evolutionary Tree of Life Based on 16S and 18S
rRNA
ARCHAEA
BACTERIA
EUKARYA
Carl Woese, 1977
13
Bacteria Fun Facts

• Most microbes do not cause disease!
• 1 gram of soil 1 billion bacteria
• More bacteria in your mouth than there are people
  in the world
• beneficial bacteria in human intestine of
  cells in human body
• Your colon has the highest density of microbes
  recorded for any microbial habitat
• Oldest forms of life on earth are bacteria (3.8
  billion years ago)
• Bacteria make up most of the biomass on earth,
  but only 1 have been cultured

14
Genes and Genomes fun facts

• Bacteria have small genomes (1-7 million base
  pairs vs. 3 billion base pairs in human)
• 1995 First bacterial genome sequence, of
  Haemophilus influenzae
• Two years later 12 genomes sequenced
• April, 2010 4900 prokaryotic genomes sequenced
  or in progress. Wow!

15
Prokaryotic Genomes Sizes and Gene Contents

• Rule of thumb A prokaryotic gene 1,000 bp long
• As genome size increases gene content
  proportionally increases
• Prokaryotic genomes range in size from those of
  large viruses to those of eukaryotic microbes
• Unlike eukaryotes, prokaryotic genomes do not
  contain a large fraction of non-coding DNA

16
Correlation Between Genome Size and ORF Content
Figure 13.1
17
Bacterial Lifestyle Correlates with Genome Size
Variation
18
Mutational process in bacterial genes is biased
towards deletions
19
Intracellular lifestyle alters genome size
DNA Inflow
DNA Outflow
Diagram modified from Mira, A., Ochman, H.
Moran, N.A. 2001. Trends Genet 17, 589-96.
20
Genome Reduction

• The process by which a genome decreases in size
  relative to its ancestor
• Usually coupled with symbiotic, intracellular
  lifestyle
• Organelles and endosymbionts

21
Endosymbionts have the smallest bacterial genomes
known

Bordenstein, unpublished
22
How do we go from here..?
Crustaceans (35)
Insects (20-75!)
Filarial nematodes (90)
Chelicerates
2-6 million insect species are infected with
Wolbachia!!
Arthropods
Nematodes
23
To studying the Wolbachia within?
Credit Mark Taylor
24
(No Transcript)
25
PCR (Polymerase Chain Reaction)

• 1- Amplifies defined DNA sequences
• 2- Uses basic properties of the DNA replicating
  enzyme (DNA Polymerase)
• 3- DNA polymerization using defined DNA template,
  two defined primers, 4 dNTPs

26
DNA Polymerase Action
27
Basics of PCR

• Template DNA - the starting DNA of interest.

• High temperature denatures template DNA into
  single strands and synthetic sequences of ssDNA
  (20-30 nucleotides) serve as primers

• Two different primers are used to bracket the
  target gene to be amplified

• DNA polymerase copies the complimentary strand
  starting at the primer. In one cycle, two
  identical strands are made.

28
PCR - Ready Beads

• Small quantity of DNA
• Primers
• Buffered solution containing DNA polymerase
• Four base pairs of DNA
• Cofactor MgCl2

All in test tube

• Small quantity of DNA
• Primers

• Buffered solution containing DNA polymerase
• Four base pairs of DNA
• Cofactor MgCl2

29
Temperature drives the reaction
30
Target gene 16S rDNA of Wolbachia
31
PCR Animation
http//highered.mcgraw-hill.com/olc/dl/120078/micr
o15.swf
32
Two Key Innovations for Success of PCR

• Heat-stable DNA polymerase isolated from
  bacterium Thermus aquaticus which inhabits hot
  springs
• Polymerase remains active despite being heated
  many times
• DNA thermal cyclers a computer that controls
  repetitive temperature changes required for PCR

70C hot springs in Yellowstone National Park
Example of a thermal cycler from MJ Research
33
PCR and Pop Culture

• Jurassic Park and CSI
• Some fun PCR facts to share with your students
  PCR has been used to amplify DNA from
• a preserved quagga (a zebra relative that became
  extinct 100 years ago)
• crime scenes (e.g., O.J.)
• Abducted children to find parents
• Prisoners leading to exonerations
• Mummies to determine gender, bacterial infections

34
Our goal Determine which of your insects harbor
Wolbachia?

• DNA extraction

PCR
Gel electrophoresis
35
