Portable Filtering System

1
Portable Filtering System

• Adam Tanbouz
• Jie Gu
• Shivam Mathur
• Vaibhav Mal

2
Agenda

• Aquaquick Team
• Motivation
• - Need for product
• - Product Overview
• Market and Competition
• Inner Workings
• - Energy Generation
• - Filtration Process
• Product Testing

• Project Specifics
• - Team Dynamics
• - Finances and Timeline
• Looking Back and Thinking Ahead
• What we learnt from this experience
• Future improvements
• Conclusion
• Acknowledgements References
• Questions Demo

www.aquaquick.ueuo.com
3
AquaQuick Team
Vaibhav Mal President and Chief Executive
Officer Concept and team dynamics Shivam
Mathur Chief Technical Officer RD UV
Technology and Implantation Jie Gu Chief
Financial Officer RD Finances and Mechanical
building Adam Tanabouz Mechanical Lead RD
Mechanical and Electrical Building
www.aquaquick.ueuo.com
4
Motivation

• Need for the product
• What problem is it addressing
• Earth Two third water
• Human Body Approx 70 water
• 1.5 billion people without regular access to
  water
• 4 Million deaths annually
• People walk an Average of 3.7 miles and spend 16
  hours a week (2 hours a day)
• Product Overview

www.aquaquick.ueuo.com
5
Market and Competition

• Filtering Products
• Many available
• None reusable, self sustaining and durable
• Other Methods
• Iodine tablets
• Battery powered filters
• Charcoal filters
• Hand crank
• Cannot be used on the go

www.aquaquick.ueuo.com
6
Energy Generation
Txt

• DC voltage generator to charge a battery.
• Ultraviolet bulbs that work at 12 V DC and have
  the required specification to kill bacteria.

www.aquaquick.ueuo.com
7
Current range Calculation

• RPM of the carts speed
• 47 cm diameter wheel and a stop watch, it was
  found equal to 40 RPM
• 47 RPM 50 to 80 Watt for one hour
• Maximum current rating 70 Watt /12 V 5.8 A
• Nominal operating current 40 Watt /12 V 3.3 A
• 40 RPM x wheels circumference 59.2 meter per
  minutes. So, 3.55 KM in one hour.

8
The generator

• RPM generator- Current higher than the calculated
  currents.
• Permanent magnet DC motor from used car or
  appliance is powerful and cheap
• Wiper Motor from used vista eagle car 1992 model
• 80 watt 12 VDC 6.7 A
• The generation of 13 VDC to 14 VDC was easy at
  low RPM that was calculated using stop watch. It
  was found Equal to 50 RPM

9
Gear Module

• Generator rotates in one direction, so gear
  module rotates in one direction.
• The gear ratio needed The generators RPM/ The
  wheels
• RPM 50/40 1.25.
• Rotation are transferred by chain

10
The circuit
The Circuit

• The battery and the generator are connected in
  parallel
• Current flows from generator to the battery when
  the generated voltage is larger than the voltage
  of the battery.

11
Filtering Process

• Our Objective
• Get same results as boiling
• Micro-organisms
• Chemicals
• Particles
• Filtering techniques we used
• Mesh Filtering
• UV Filtering
• Sun Filtering

www.aquaquick.ueuo.com
12
Filtering Process

• Mesh Filtering
• 20 micron Sediment Filter
• Reduces amount of sand,
• silt, dirt, and other particles.
• Two Layers

www.aquaquick.ueuo.com
13
Filtering Process

• UV filtering
• UV-C Short wave- 100-280 nm
• UV Lamps
• Alter DNA of viruses, bacteria
• molds and parasites
• No chemicals added
• Class A and B

www.aquaquick.ueuo.com
14
Filtering Process

• Sun Filtering
• UV-A Long wave- 315-400 nm
• (PET) Polyethylene terephthalate
• Deactivates diarrhea-causing
• organisms in polluted drinking water2
• Cumulative solar energy
• Aluminum 75 UV Reflectivity1

www.aquaquick.ueuo.com
15
Combined System

• Working together
• Simultaneous charging and lighting
• Water movement
• Other components
• UV Lamps case
• Battery/Generator Cabinet
• Water Tap
• Reversible movement
• UV lamp switch and generator switch
• Mesh filter container

www.aquaquick.ueuo.com
16
Lifetime

• UV Lamps
• - 8000 burning hours7 (2hrs/day 730hrs)
• - Recommended replacement - Annual
• - Contact retailers
• Battery
• Generator
• Mesh Filter
• - 6 months life8
• Four replacement papers provided
• Other parts
• - Contact retailers

www.aquaquick.ueuo.com
17
Testing
www.aquaquick.ueuo.com
18
Testing Steps

• Pour the water getting from SFU pond on the mesh
  filter and exposure it under UV for 10 minutes
• Prepare 2 water samples (one is from SFU pond ,
  one is after treated)
• Culture Bacteria
• Mix the agar and pour it into the dish to cover
  the bottom
• Pour 1 ml sample water on the agar
• Set the dish in a warm dark cupboard for two to
  three days
• Observe the bacteria colonies through the top of
  the dish

www.aquaquick.ueuo.com
19
Testing Result (Untreated)
www.aquaquick.ueuo.com
20
Testing Result (Dilute Untreated Water)
Sample No. Colonies
1 37
2 45
3 40
4 26
5 50
Average 40
Total Colonies 40 1000 40,000 per 1ML
www.aquaquick.ueuo.com
21
Testing Result (Treated)
After treatment from aquaQuick, there are only 5
colonies! 99.9875 bacteria have been killed
www.aquaquick.ueuo.com
22
Testing Result (Compare)
SteriPEN Kills over 99.9 of bacteria and
viruses, and it gets WQA approved.
4
www.aquaquick.ueuo.com
23
Team Dynamics (Teamwork)
Work Together
Share Ideas Democratic Process
www.aquaquick.ueuo.com
24
Team Dynamics(Individual Work)

www.aquaquick.ueuo.com
25
Finances
Item Proposed Actual
Wheel Mechanism 105 50
Chain Gears 0 10
Pulley Belts 25 0
Wheels 50 10
Support 30 30
UV Components 100 117
UV Lamp 40 25
Plexi Glass 10 12
UV Circuit 50 80
Boiling Components 200 0
Magnets 50 0
Coil 150 0
Power Generation 225 147
Generator 200 50
Battery 25 67
Diode 0 4
Other Parts 150 209
Cart 0 32
Container 50 10
Mesh Case 0 30
Cabinet 70 0
Screws, Nuts Washer 30 27
Water Proof Seal Tape 0 20
Paint 0 12
Tap 0 10
Tools Renting 0 72
Aluminum 0 6
Greese Oil 0 5
Total 680 520
www.aquaquick.ueuo.com
26
Timeline
Item Proposed Implemented
Order Parts Drafts Oct-10 Ongoing
Generator Power Circuits Oct-30 Oct-20
Transmission(Gears, Wheels Chain) Nov-15 Nov-26
UV Circuit Containers Functions Nov-30 Dec-02
Mesh Case Dec-03 Dec-03
Integration Dec-05 Dec-07
Testing Debugging Dec-10 Dec-10
www.aquaquick.ueuo.com
27
Future Improvements

• Add Quartz around the UV tube
• Integrating Active Carbon Filtration
• Aluminum Mirror (200nm-10µm)3
• Replaceable UV Tubes
• Stronger Parts of Cart
• Indicator for Bulb Replacement
• Indicator for Water Quality
• Automatically Switch

6
5
www.aquaquick.ueuo.com
28
Conclusion

• What do we take away from an experience like
  this?
• Mechanical skill and respect for tradesmen
• A lot of knowledge about Microbiology
• Great friendships and memories

www.aquaquick.ueuo.com
29
Acknowledgements

• Engineering Student Society Endowment Fund for
  their financial contribution
• Linda Pinto for her help with water testing
• Professors for their feedback and validation of
  our ideas and progress

www.aquaquick.ueuo.com
30
References
1 Ultraviolet Germicidal Irradiation Handbook
by Wladyslaw Kowalski. Pg 153. UV Reflective
Materials 2 (2010). Solar Water Disinfection.
Retrieved December 16th, 2010, from Wikipedia Web
Site http//en.wikipedia.org/wiki/Solar_water_dis
infection 3 (2010). Protected Aluminum
Broadband Front Surface Mirrors. Retrieved
December 16th, 2010 from PGO Online Web Site
http//www.pgo-online.com/intl/katalog/sea-uv.html
4 (2010). See Water in a whole New Light.
Retrieved December 12th, 2010, from SteriPen Web
Site http//www.steripen.com/ 5
http//www.youtube.com/watch?v1KZ-Ebp3Ct0 6
(2009). Retrieved December 20th, 2010 from
ChineseMol Web Site http//www.chinesemol.com/pro
ducts/p19289.html 7 (1995). UV Waterworks 2.0.
Retrieved December 19th, 2010, from Berkley Lab
Web site http//www.lbl.gov/Education/ELSI/Frames
/Sustain21-f.html 8 (2010). Liquatec 20 Micron
Sediment 2 ½ x 9 7/8 Cartridge Filter.
Retrieved December 18th, 2010 from Aquapura Web
Site http//www.aquapurawater.ca/liquatec-20-micr
on-sediment-2-12-x-9-78-cartridge-filter-p-383.htm
l?zenid20034cf5cb124824e24e2a80b9cb569b
www.aquaquick.ueuo.com
