Caching and Data Consistency in P2P

1
Caching and Data Consistency in P2P

• Dai Bing Tian
• Zeng Yiming

2
Caching and Data Consistency

• Why Caching
• Caching helps use bandwidth more efficiently
• The data consistency in this topic is different
  from the consistency in distributed database
• It refers to the consistency between cached copy
  and data on servers.

3
Introduction

• Caching is built based on current P2P
  architectures like CAN, BestPeer, Pastry, etc.
• Caching layer is between application layer and
  P2P layer.
• Every peer has its cache control unit and its
  local cache, and publish the cache contents

4
Presentation Order

• We will present four papers, they are
• Squirrel
• PeerOLAP
• Caching for Range Queries
• With CAN
• With DAG

5
Overview
Paper Based on Caching Consistency
Squirrel Pastry Yes Yes
PeerOLAP BestPeer Yes No
RQ with CAN CAN Yes Yes
RQ with DAG Not Specified Yes Yes
6
Squirrel

• Enables web browsers on desktop machines to share
  their local caches
• Uses a self-organizing, peer-to-peer network
  Pastry as its object location service
• Pastry is fault resilient, so is Squirrel

7
Web Caching

• Web browser generate HTTP GET requests
• If the object is in the local cache, return it if
  fresh enough
• freshness can be checked by submitting cGET
  request
• If no such object, issue GET request to the
  server
• For simplicity, we assume objects are cacheable

8
Home Node

• As described in Pastry, every peer (node) has its
  nodeID
• objectID SHA-1 (obj URL)
• This object is assigned to the node whose ID is
  numerically nearest to the objectID
• The node who owns this object is called the home
  node of this object

9
Two approaches

• There are two approaches of Squirrel
• Home-store
• Directory
• Home-store stores the object directly in the
  cache of the home node
• Directory stores the pointer to the nodes who
  have this object in its cache, these nodes are
  called delegates

10
Home-store
WAN
Origin Server
Requester
LAN
Send A over
Send A over
Yes, it is fresh
Request for A
Yes, it is fresh
Request for A
Is my copy of A fresh?
Is my copy of A fresh?
Home Node
Request Routed Through Pastry
11
Directory
Origin Server
Send A over
Request for A
Send A over
Yes, it is fresh
Request for A
Requester
Is my copy of A fresh?
Send A over
WAN
Request for A
Delegate
LAN
Requester and I are your delegates
Get it from D
Update Meta-info Keep the directory
Request for A
Get it from Server
No directory
Request Routed Through Pastry
Home Node
Im your delegate
12
Conclusion

• The home-store approach is less complicated, but
  it does not have any collaboration
• The directory approach is more collaborative, it
  has the ability to store more objects in those
  peers with larger cache capacity, by setting the
  pointers to these peers in the directory

13
PeerOLAP

• OnLine Analytical Processing (OLAP) query
  typically involves large amounts of data
• Each peer has a cache containing some results
• An OLAP query can be answered by combining
  partial results from many peers
• PeerOLAP acts as a large distributed cache

14
Data Warehouse Chunk

• A data warehouse is based on a multidimensional
  data model which views data in the form of a data
  cube.
• Han Kamber

http//www.cs.sfu.ca/han/dmbook
15
PeerOLAP network

• LIGLO servers provide global name lookup and
  maintain a list of active peers

• Except for LIGLO servers, the network is fully
  distributed without any centralized
  administration point

16
Query Processing

• Assumption 1 Only chunks at the same aggregation
  level as the query are considered
• Assumption 2 The selecting predicates is a
  subset of grouping-by predicates

17
Cost Model

• Every chunk is associated with a cost value,
  indicating how long it spends to get this chunk

18
Eager Query Processing (EQP)

• Peer P sends requests for the missing chunks to
  all its neighbors, Q1, Q2, .... Qk
• Each Qi provides the desired chunks as many as
  possible, return to P with a cost associated with
  each chunk
• Qi then propagates the requests to all its
  neighbors recursively
• In order to avoid flooding, hmax is set to limit
  the depth of the search

19
EQP (Contd.)

• P collects (chunk, cost) pairs from all its
  neighbors
• Random select one chunk ci, and find the peer who
  can provide it with lowest cost, Qi
• For the subsequent chunks, it evaluates the
  minimum of two cases the peer with lowest cost
  is not connected yet, or some existing peer who
  can also provide this chunk
• Ask for chunks from these peers and the rest
  missing chunks from the warehouse.

20
Lazy Query Processing (LQP)

• Instead of propagating the requests from each Qi
  to all its neighbors, each Qi selects its most
  beneficial neighbor, and forward the request.
• Given the expected number of neighbors a peer has
  is k, EQP will visit O(khmax) nodes, LQP only
  visit O(khmax)

21
Chunk Replacement

• Least Benefit First (LBF)

• Similar to LRU, every chunk has a weight
• Once the chunk is used by P, its weight is set
  back to the original benefit value
• Every time there is a new chunk come in, the
  weight of old chunks will reduce

22
Collaboration

• LBF gives local chunk replacement algorithm
• 3 variations of global behavior
• Isolated Caching Policy non-collaborative
• Hit Aware Caching Policy collaborative
• Voluntary Caching highly collaborative

23
Network Reorganization

• Optimization can be done by creating virtual
  neighborhoods of peers with similar query
  patterns
• So that there is a high probability for P to get
  missing chunks directly from neighbors
• Each connection is assigned a benefit value and
  the most beneficial connections are selected to
  be the peers neighbors

24
Conclusion

• PeerOLAP is a distributed caching system for OLAP
  results
• By sharing the contents of individual caches,
  PeerOLAP constructs a large virtual cache which
  can benefit all peers
• PeerOLAP is fully distributed and highly scalable

25
Caching For Range Queries

• Range Query
• E.g.
• SELECT Student.name
• WHERE 20ltStudent.agelt30
• Why Cache?
• Data source too far away from the requesting node
• Data source overloaded with queries
• Data source is a single point of failure
• What to cache?
• All tuples falling in the range
• Who cache?
• Peers responsible for the range

26
Problem Definition

• Given a relation R, and a range attribute A, we
  assume that the results of prior range-selection
  queries of the form R.A(LOW, HIGH) are stored at
  the peers. When a query is issued at a peer which
  requires the retrieval of tuples from R in the
  range R.A(low, high), we want to locate a peer in
  the system which already stores tuples that can
  be accessed to compute the answer.

27
A P2P Framework for Caching Range Queries

• Based on CAN.
• Map data into 2d virtual space, where d is
  dimensions of the relation.
• For every dimension/attribute, say its domain is
  a, b, it is mapped to a square virtual hash
  space whose corner coordinates are (a,a), (b,a),
  (b,b) and (a,b).
• The virtual hash space is further partitioned
  into rectangular areas, each of which is called a
  zone.

28
Example

• Virtual hash space for an attribute whose domain
  is 10,70
• zone-1 lt(10,56),(15,70)gt
• zone-5 lt(10,48),(25,56)gt
• zone-8 lt(47,10),(70,54)gt

29
Terminology

• Each zone is assigned to a peer.
• Active Peer
• Owns a zone
• Passive Peer
• Not participate in the partitioning, register
  itself with an active peer
• Target Point
• A range low,high is hashed to a point with
  coordinates (low,high)
• Target Zone
• Where the target point resides
• Target Node
• The peer that owns the target zone
• Stores the tuples falling into the range which
  is mapped to the its zone
• Caches the tuples in the local cache OR
• Stores a pointer to the peer who caches the tuples

30
Zone Maintenance

• Initially, only the data source is the active
  node and the entire virtual hash space is its
  zone
• A zone split happens under two conditions
• Heavy Answering Load
• Heavy Routing Load

31
Example of Zone Splits

• If a zone has too many queries to answer
• It finds the x-median and y-median of the stored
  results. Determine if a split at x-median or
  y-median results in even distribution of stored
  answers and the space.
• If a zone is overloaded because of routing
  queries
• It splits the zone from the midpoint of the
  longer side.

32
Answering A Range Query

• If an active node poses the query, the query is
  initiated from the corresponding zone if a
  passive node poses the query, it contacts any
  active node from where the query starts routing.
• 2 steps involved
• Query Routing
• Query Forwarding

33
Query Routing

• If the target point falls in this zone
• Return this zone
• Else
• Route the query to the neighbor who is closest
  to the target point

(26,30)
34
Query Routing

• If the target point falls in this zone
• Return this zone
• Else
• Route the query to the neighbor who is closest
  to the target point

(26,30)
35
Query Routing

• If the target point falls in this zone
• Return this zone
• Else
• Route the query to the neighbor who is closest
  to the target point

(26,30)
36
Forwarding

• If the results are stored in the target node,
  then the results are sent back to the querying
  node
• Else, it is still possible that zones lie in the
  upper left area of the target point store the
  results. So we need to forward the query to these
  zones too.

37
Example

• If no results are found in zone-7, the shaded
  region may still contains the results.
• Reason Any prior range query q whose range
  subsumes (x,y) must be hashed into the shaded
  region.

38
Forwarding (Cont.)

• How far should it go?
• For a range (low,high), we want to restrict to
  results falling in (low-offset,highoffset),
  where offset AcceptableFit x domain.
• AcceptabelFit 0,1
• The shaded square defined by the target point and
  offset is called the Acceptable Region

offset
39
Forwarding (Cont.)

• Flood Forwarding
• A naïve approach. Forward to the left and top
  neighbors if they fall in the acceptable region
• Directed Forwarding
• Forward to the neighbor that maximally overlaps
  with the acceptable region
• Can bound the number of forwards by specifying a
  limit d, which is decremented for every forward.

40
Discussion

• Improvements
• Lookup During Routing
• Warm up queries
• Peer soft-departure Failure event
• Updatecache consistency
• Say a tuple t with range attribut ak is updated
  in the data source, then the target zone of point
  (k,k) and all zones lie in the upper left region
  have to update their cache.

41
Range Addressable Network A P2P Cache
Architecture for Data Ranges

• Assumption
• Tuples stored in the system are labeled 1,2,,N
  according to the range attribute
• A range a,b is a contiguous subset of
  1,2,,N, where 1ltaltbltN
• Objective
• Given a query range a,b, peers cooperatively
  find results falling in the shortest superset of
  a,b, if they are cached somewhere.

42
Overview

• Based on Range Addressable DAG (Directed Acyclic
  Graph)
• Map every active node in the P2P system to a
  group of nodes in the DAG
• A node is responsible for storing results and
  answering queries falling into a specific range

43
Range Addressable DAG

• The entire universe 1,N is mapped to the root.
• Recursively divide one node into 3 overlapping
  intervals of equal length.

44
Range Lookup
7,13

• Input a query range qa,b,
• a node v in DAG
• Output the shortest range in
• DAG that contains q
• boolean downtrue
• search (q, v)
• if q i(v)
• search (q, parent(v))
• if q i(child(v)) down
• search (q, child(v))
• else
• if some range stored at v is a superset of q
• return the shortest range containing q that is
  stored at v or parent(v) ()
• else
• downfalse
• search(q,parent(v))

5,12
Q 7,10
45
Peer Protocol

• Maps the logical DAG structure to physical peers
• Two components
• Peer Management
• Handles peer joining, leaving, failure
• Range Management
• Deals with query routing and updates

46
Peer Management

• It ensures that at any time,
• every node in the DAG is assigned to some peer
• the nodes belonging to one peer, called a zone,
  is a connected component of the DAG
• This is done by handling Join Request, Leave
  Request, Failure Event properly.

47
Join Request

• The first peer joining the system takes over the
  entire DAG
• A new peer joining the system contacts one of the
  peers in the system to take over one of its child
  zones. Default strategy left child, then mid
  child, then right child.

48
Join Request

• The first peer joining the system takes over the
  entire DAG
• A new peer joining the system contacts one of the
  peers in the system to take over one of its child
  zones. Default strategy left child, then mid
  child, then right child.

49
Join Request

• The first peer joining the system takes over the
  entire DAG
• A new peer joining the system contacts one of the
  peers in the system to take over one of its child
  zones. Default strategy left child, then mid
  child, then right child.

50
Join Request

• The first peer joining the system takes over the
  entire DAG
• A new peer joining the system contacts one of the
  peers in the system to take over one of its child
  zones. Default strategy left child, then mid
  child, then right child.

51
Leave Request

• When a peer wants to leave (soft departure), it
  hands over its zone to the smallest neighboring
  zone.
• Neighboring zones there is a parent-child
  relationship among any nodes in the zones

52
Leave Request

• When a peer wants to leave (soft departure), it
  hands over its zone to the smallest neighboring
  zone.
• Neighboring zones there is a parent-child
  relationship among any nodes in the zones

53
Failure Event

• A zone maintains info on all its ancestors. So in
  case it finds out one of its parents failed, it
  contacts the nearest alive ancestor for zone
  takeover.

54
Range Management

• Range Lookup
• Range Update
• When a tuple is updated in the data source, we
  locate the peer with the shortest range
  containing that tuple, then update this peer and
  all its ancestors.

55
Improvement

• Cross Pointers
• For a node v, if its the left child of its
  parent, then it keeps cross pointers to all the
  left children of nodes that are in its parents
  level.
• Similarly for mid child.

56
Improvement (Cont.)
P1

• Load Balancing by Peer Sampling
• Collapsed DAG collapse each peers zone to a
  single node.
• The system is balanced if the collapsed DAG is
  balanced.
• Lookup time is O(h) where h is the height of the
  collapsed DAG. Hence a balanced system leads to
  optimal performance.
• When a new peer joins, it polls k peers randomly,
  and send join request to the one whose zone is
  rooted nearest to the root.

P2
P3
57
Improvement (Cont.)

• Load Balancing by Peer Sampling
• Collapsed DAG collapse each peers zone to a
  single node.
• The system is balanced if the collapsed DAG is
  balanced.
• Lookup time is O(h) where h is the height of the
  collapsed DAG. Hence a balanced system leads to
  optimal performance.
• When a new peer joins, it polls k peers randomly,
  and send join request to the one whose zone roots
  nearest to the root.

Collapsed DAG
58
Conclusion

• Caching Range Queries based on CAN
• Maps every attribute into a 2D space
• The space is divided into zones
• Peers manage their respective zones
• A range low,high is mapped to a point
  (low,high) in the 2D space
• Query Routing Query Forwarding

59
Conclusion (Cont.)

• Range Addressable Network
• Model ranges as DAG
• Every peer takes responsibility of a group of
  nodes in DAG
• Querying involves traversal of the DAG
