Computer Organization and Logic design COS3602

1
Computer Organization and Logic designCOS3602
2
Architecture Organization 1

• Architecture is those attributes visible to the
  programmer
• Instruction set, number of bits used for data
  representation, I/O mechanisms, addressing
  techniques.
• e.g. Is there a multiply instruction?
• Organization is how features are implemented
• Control signals, interfaces, memory technology.
• e.g. Is there a hardware multiply unit or is it
  done by repeated addition?

3
Structure Function

• Structure is the way in which components relate
  to each other
• Function is the operation of individual
  components as part of the structure

4
Function

• All computer functions are
• Data processing
• Data storage
• Data movement
• Control

5
Functional view

• Functional view of a computer

6
Operations (1)

• Data movement
• e.g. keyboard to screen

7
Operations (2)

• Storage
• e.g. Internet download to disk

8
Operation (3)

• Processing from/to storage
• e.g. updating bank statement

9
Operation (4)

• Processing from storage to I/O
• e.g. printing a bank statement

10
Structure - Top Level
Computer
Peripherals
Central Processing Unit
Main Memory
Computer
Systems Interconnection
Input Output
Communication lines
11
Structure - The CPU
CPU
Arithmetic and Login Unit
Computer
Registers
I/O
CPU
System Bus
Internal CPU Interconnection
Memory
Control Unit
12
Structure - The Control Unit
Control Unit
CPU
Sequencing Login
ALU
Control Unit
Internal Bus
Control Unit Registers and Decoders
Registers
Control Memory
13

• Computer Architecture is the design of computer ,
  including their instruction sets, hardware
  components, and system organization. The
  computer architecture consists of two parts
• Instruction set architecture (ISA)
• Hardware system architecture (HAS)

14

• The instruction set architecture
  ????????????????????? Software/Hardware
  ??????????????????????????????????????????????????
  ???????????????????? ??????
• The instruction set
• The instruction formats
• The available addressing techniques
• The format of the available data types
• The Operational register set and usage

15

• The hardware system architecture
  ????????????????????????????????????????
  ??????????????????????????????????????????????
  CPU , Memory , ??? I/O devices ??????? Hardware
  system architecture ??????? logical design ???
  data flow organization ???????????????????????????
  ??????????????????????????????????????
  ??????????????????
• ?????????
• ????????
• ???? ???

16
Computational Models

• Two primary computational models
• Von Neumann Model
• System Bus Model
• The Von Neumann Model consists of five major
  subsystems (input, output, control, arithmetic,
  memory)
• The System Bus Model streamlines this into three
  subsystems (CPU, memory, IO)

17
Von Neumann Model
Memory Unit
Control Path
Data Path
Arithmetic and Logic Unit (ALU)
Input Unit
Output Unit
Control Unit
18
System Bus Model
CPU (ALU, Registers, and Control)
Memory
Input and Output
Data Bus
Address Bus
Control Bus
19
Computational Models

• Consider the implications of these alternative
  designs
• Design 1 Central processor with special cabling
  to specialized devices
• Design 2 Multi-bus with common parsing of data
  and control packets for device-ids

20
Introduction to Computer Architecture

• History
• Computational Models
• gtgt Levels of the Machine
• Computer System Metaphor

21
Levels of the Machine

• 1. Individual electrical components
• Transistors
• Resisters
• Capacitors
• 2. Circuit boards
• 3. Specialized devices
• Power supply
• Cooling fan

22
Levels of the Machine

• 4. Specialized components
• Graphics accelerator
• Memory banks
• 5. Mother board
• CPU
• Battery
• Plug-in expansion card slots
• Specialized components
• Connector for power supply

23
Levels of the Machine

• 6. Operating system and device drivers
• 7. Machine language
• 8. Compilers and interpreters
• 9. High-level languages
• Java
• C
• Visual Basic
• Microsoft Excel (?)

24
Levels of the Machine

• 10. Single-user applications
• 11. Network components and software
• 12. Multi-user centralized applications
• 13. Internet connection devices and s/w
• 14. Internet utilities (global / specific)
• 15. Web connection devices and s/w
• 16. Web utilities (global / general)

25
Introduction to Computer Architecture

• History
• Computational Models
• Levels of the Machine
• gtgt Computer System

26
Typical Computer System

• Hard Disk
• Floppy Disk
• Tape Backup
• Random Access Memory
• Central Processing Unit
• Graphics Accelerator Card
• Keyboard
• Monitor
• Printer

27
Computer System

• The intent of the following slides is to remind
  us to ask, when studying any computer component,
• What problem is this intended to solve?

28
Digital Computers

• Computer Structure
• Figure 1-2 Block Diagram of a Digital
  Computer

29
Digital Computers

• Basic Structure
• memory unit stores programs, input, output, data
• processor unit performs arithmetic and other
  data-processing operations, as
  specified by the program
• control unit supervises the flow of information
  between units
• (CPU control unit data path)
• input device key board
• output device CRT, LCD
• More
• FPU (floating-point unit)
• MMU (memory management unit)
• (Memory MMU internal cache external cache
  RAM)

30
Classification of Computer Architectures
31
Von Neumann Machine
??????????????????????????????????????????????????
????? John von nuemenn ???????????????????????????
IAS ( Institute for Advanced Studies)
??????????? ??? Princeton University in the
1940s
32
Von Neumann Machine

• ?????????????? Von nuemann ?????????????????
• ?????????????????????? 3 ???????
• CPU
• Main memory
• I/O system
• ?????????????????????????????????????????

33

• ?????????????????????????????????????????
  ??????????????????????????????????????????????????
  ????????????????????
• ??????????????????????????????????????????????
  ????????????????????????
• ?????????????????????????????????????????????????
  ??????????? CPU ?????????????????????????????????
  Bottleneck

34

• The major subsystems within the CPU are
• The control unit (CU)
• The arithmetic and logic unit (ALU)
• A register set

35
Von Neumann Model
Memory Unit

• Input Unit
• Provides instructions and data to system

Arithemtic and Logical Unit (ALU)
Input Unit
Output Unit
Control Unit
36
Von Neumann Model
Memory Unit

• Output Unit
• Returns data from system

Arithemtic and Logical Unit (ALU)
Input Unit
Output Unit
Control Unit
37
Von Neumann Model
Memory Unit

• Memory
• Storage for instructions and data

Arithemtic and Logical Unit (ALU)
Input Unit
Output Unit
Control Unit
38
Von Neumann Model
Memory Unit

• ALU
• Processes data

Arithemtic and Logical Unit (ALU)
Input Unit
Output Unit
Control Unit
39
Von Neumann Model
Memory Unit

• Control Unit
• Directs processing

Arithemtic and Logical Unit (ALU)
Input Unit
Output Unit
Control Unit
40
Von Neumann Model
Memory Unit

• CPU
• ALU and Control Unit combined

CPU
Arithemtic and Logical Unit (ALU)
Input Unit
Output Unit
Control Unit
41
System Bus Model
CPU (ALU, Registers, Control)
Memory
Input Output (I/O)
Data Bus
Address Bus
System Bus
Control Bus

• Streamlined version of von Nuemann model
• Data Bus
• Address Bus
• Control Bus
• Power Bus (optional)

42
System Bus Model
CPU (ALU, Registers, Control)
Memory
Input Output (I/O)
Data Bus
Address Bus
System Bus
Control Bus

• Data Bus
• Carries the information being transmitted
• Sometimes implemented as data-in and data-out
  buses

43
System Bus Model
CPU (ALU, Registers, Control)
Memory
Input Output (I/O)
Data Bus
Address Bus
System Bus
Control Bus

• Address Bus
• Identifies where the information is being sent
• Memory address identifies read/write location

44
System Bus Model
CPU (ALU, Registers, Control)
Memory
Input Output (I/O)
Data Bus
Address Bus
System Bus
Control Bus

• Control Bus
• Describes aspects of how the information is being
  sent, in what manner
