Title: Design Patterns A Case Study: Designing a Document Editor


1
Design Patterns A Case Study Designing a
Document Editor
2
Attributions
  • This material is based on the 2nd Chapter of
  • Design Patterns, by Gamma, Helm, Johnson,
    Vlissides.
  • The chapter, in turn, is based on
  • Paul R. Calder Mark A. Linton. The
    object-oriented implementation of a document
    editor. In Object-Oriented Programming Systems,
    Languages, Applications Conference Proceedings,
    p. 154-165, Vancouver, Oct. 1992. ACM Press.

3
Introduction
  • OOD of a WYSIWYG document editor
  • The editor
  • can mix text graphics
  • has a GUI (see next slide)

4
Lexi
File Edit Style Symbol
WYSIWYG Editor
Fig. 4 A gratuitous graphic
Here is some gratuitous text to indicate the
text formatting capabilities
-

1
2
3
4
5
Design Problems
  • Document Representation
  • Formatting
  • Embellishing the UI
  • Support multiple look--feel standards
  • Support multiple window systems
  • User operations
  • Spelling checking hyphenation

6
Design Problems
  • Document Representation
  • The documents representation affects
  • editing, formatting, displaying, analysis
  • e.g., hyphenation
  • Physical vs. logical representation
  • Formatting
  • How to arrange boxes into lines, columns, pages?
  • What objects implement formatting policies?
  • How do these interact with representation?

7
Design Problems ...
  • Embellishing the UI
  • GUI changes are likely.
  • Add/remove/modify GUI elements should be easy.
  • Support multiple look--feel standards
  • Implement with Swing (what if no swing?)
  • Support multiple window systems
  • Implement with Swing (what if no swing?)

8
Design Problems ...
  • User operations
  • Users control model via GUI.
  • Functions are distributed among many objects.
  • Access these functions in a uniform way
  • undo.
  • Spelling checking hyphenation
  • How does Lexi support analytical operations?
  • Minimize of classes affected by such operations
  • Reduce cost of enhancements

9
Design Problems
  • Document Representation
  • Formatting
  • Embellishing the UI
  • Support multiple look--feel standards
  • Support multiple window systems
  • User operations
  • Spelling checking hyphenation

10
Document Representation
  • Outline
  • Goals
  • Constraints
  • Recursive Composition
  • Glyphs
  • Composite Pattern

11
Document Representation Goals
  • User views document as a
  • logical structure
  • physical structure.
  • User composes interacts with substructures
  • E.g., sections, tables, lines, figures
  • Representation matches physical structure.
  • Could have representation reflect logical
    structure.

12
Document Representation Goals
  • Representation helps
  • Maintain documents physical structure
  • lines, columns, tables, etc.
  • Generating a view
  • Map pixel positions to internal elements
  • So Lexi can track mouse clicks, etc.

13
Document Representation
  • Outline
  • Goals
  • Constraints
  • Recursive Composition
  • Glyphs
  • Composite Pattern

14
Document Representation Constraints
  • Treat text graphics uniformly
  • graphics within text
  • text within graphics
  • format elements an abstraction of both
  • Anywhere 1 element may go, so may a group go.
  • Allows arbitrarily complex documents
  • Support operations that violate these constraints
  • spelling , hyphenation

15
Document Representation
  • Outline
  • Goals
  • Constraints
  • Recursive Composition
  • Glyphs
  • Composite Pattern

16
Recursive Composition
  • Recursive composition construct complex objects
    from simpler ones of the same abstract type.
  • For example, consider streams
  • streams of characters are broken into lines
  • streams of lines are broken into columns
  • streams of columns are broken into pages.
  • Graphics are boxes similar to characters.

17
Composite (column)
Composite (row)
characters
space
G
g
18
Object Structure for Recursive Composition of
Text Graphics
Composite (column)
Composite (row)
Composite (row)
G
g
space
19
Recursive Composition ...
  • An object for each character graphic promotes
  • flexibility
  • uniformity
  • displaying, formatting, embedding
  • ease of adding new character sets
  • Object structure reflects physical structure
  • Objects classes extend abstract class
    inheritance.

20
Document Representation
  • Outline
  • Goals
  • Constraints
  • Recursive Composition
  • Glyphs
  • Composite Pattern

21
Glyphs
  • Glyph the name of the abstract class for
    document objects.
  • A glyph is responsible to know
  • how to draw itself
  • what space it occupies
  • who its children parent are

22
Glyphs Responsibility Methods
  • Appearance
  • void draw(Window w)
  • Rectangle bounds()
  • Hit Detection
  • boolean intersection(Point p)
  • Structure
  • void insert(Glyph g, int i) // why is i used?
  • void remove(Glyph g) // why an argument?
  • Glyph child(int i) // return child at i
  • Glyph parent() // return parent glyph

23
Partial Glyph Class Hierarchy
Glyph
draw(Window)
intersects(Point)
children
insert(Glyph, int)
. . .
Character
Rectangle
Polygon
Row
draw(Window)
draw(...)
draw(...)
draw(...)
intersects(Point)
intersects(...)
intersects(...)
intersects(...)
insert(Glyph, int)
char c
24
Glyphs ...
  • Extensions of Glyph implement its methods
  • Rectangle implements draw
  • void draw(Window w)
  • w.drawRect(x, y, width, height)
  • where
  • x, y, width, height are Rectangle data members
    indicating its position
  • Window extends Graphic

25
Document Representation
  • Outline
  • Goals
  • Constraints
  • Recursive Composition
  • Glyphs
  • Composite Pattern

26
Composite Pattern
  • Intent
  • Compose objects into hierarchies child part-of
    parent
  • Motivation
  • Clients treat objects their compositions
    uniformly
  • Uses abstract class to represent both
  • primitive object
  • container object
  • Declares common methods (e.g., draw)

27
Composite Pattern Structure
Component
Client
operation()
children
add(Component)
remove(Component)
getChild(int)
Leaf
Composite
operation()
operation()
add(Component)
remove(Component)
getChild(int)
28
Composite Pattern Participants
  • Component
  • declares interface for
  • objects
  • accessing managing children
  • accessing parent
  • implements default behavior
  • Leaf
  • represents primitive objects
  • has 0 children

29
Composite Pattern Participants ...
  • Composite
  • defines behavior for containers
  • contains children
  • implements child-related operations of Component
    interface
  • Client
  • manipulates objects polymorphically via Component
    interface.

30
Composite Pattern Collaborations
  • Client accesses objects via Component interface
  • If
  • object is primitive, handle requests directly
  • else
  • recursively request operation of its children

31
Composite Pattern Consequences
  • Enables client to access objects polymorphically
  • primitive
  • composite
  • Facilitates adding new concrete classes
  • primitive
  • container
  • Disadvantage
  • If a container class can contain only certain
    types of components, it cannot be restricted by
    type system.
  • Partition Composite class?

32
Composite Pattern Implementation
  • There are many implementation issues
  • Explicit parent references
  • simplify traversal
  • Maximizing the Component interface
  • Where are child management operations declared?
  • Caching to improve performance
  • See Design Patterns to get a feel for them.

33
When Use a Composite Pattern?
  • Good candidate for any structure that is
  • recursive
  • hierarchical

34
Design Problems
  • Document Representation
  • Formatting
  • Embellishing the UI
  • Support multiple look--feel standards
  • Support multiple window systems
  • User operations
  • Spelling checking hyphenation

35
Formatting
  • Outline
  • Encapsulating the Formatting Algorithm
  • Compositor Composition
  • Strategy Pattern
