Title: Predictable Scheduling for a Soft Modem


1
Predictable Scheduling for a Soft Modem
  • Michael B. Jones Microsoft Research
  • Stefan Saroiu University of Washington

2
Consumer Real-Time
  • General-purpose Operating Systems,such as
    Windows 2000
  • maximize aggregate throughput
  • approximate fair sharing of the resources
  • Increasing use of time-dependent tasks
  • signal processing, audio, video
  • Need support for
  • predictable scheduling for independently
    developed applications
  • low latency responses
  • explicit resource allocation mechanisms

3
Why Study Soft Modems ?
  • Signal Processing done on host CPU
  • requires predictable scheduling
  • requires low latency responses
  • While coexisting with other system activities
  • Soft Modem is a background real-time task
  • Successful in home computer market
  • Low cost
  • Easy to update software upgrade

4
Methodology
  • Instrumented Windows 2000 performance kernel
  • Logs predefined and custom events
  • Writes them to a memory buffer
  • Dumps buffers to disk at end of trace
  • Driver Software
  • No source for signal processing code
  • Measurement Environment
  • All experiments run with normal-priority spinning
    competitor thread
  • System
  • Windows 2000 Professional
  • Pentium II 450 MHz (uniprocessor)
  • 384 MB ECC SDRAM - 100 MB allocated to logging

5
Vendor Driver - Signal Processing in Interrupt
(INT)
  • Operation of the modem
  • 1. DMA transfers between A/D and D/A and physical
    memory
  • 2. When enough data samples, the modem raises an
    interrupt
  • 3. Inside ISR, process incoming data and provide
    outgoing samples, before buffers exhausted
  • Uses input and output data buffers holding 512
    16-bit samples (1024 bytes/buffer)

6
Three Additional Versions
  • DPC Version (DPC)
  • The ISR queues a DPC
  • DPC performs signal processing
  • Thread Version (THR)
  • The ISR queues a DPC that signals a thread via a
    semaphore
  • Thread performs signal processing
  • Experimented with several different priorities
  • Rialto/NT Version (RES)
  • Same as THR, but thread scheduled using Rialto/NT
    real-time periodic CPU Reservation

7
Interrupt Rate
3 different phases, interrupts very regular
Falls within PC 99 recommended interrupt rates of
3-16ms
8
Elapsed Times in ISR (INT)
1.8 ms with repeatable worst case of 3.3 ms
  • PC 99 recommends maximum time during which a
    driver-based modem disables interrupts should not
    exceed 100 µs

9
CPU Utilization
14.7 sustained load on 450MHz Pentium II
10
Elapsed Times in ISR (DPC)
ISR times now small, typically lt 6µs
11
Elapsed Times in Queued DPC
But now long DPC times 1.8ms avg., 3.3 max
(same as elapsed times in ISR for INT)
  • PC 99 recommends that the total execution time
    required for all queued DPCs should not exceed
    500 µs

12
Samples Pending to be Processed(INT THR 24)
Small relative to 512 sample buffer size
13
Samples Pending to be Processed (THR 8)
Unsurprisingly, contention kills modem
14
Latency Results
  • Set the multimedia timers to fire once every
    millisecond
  • Register a routine to be called every millisecond
  • Routine does very little work
  • Stores cycle counter value and sleeps again
  • Histograms show differences between recorded
    times and ideal times

15
Coexisting Thread Latencies (Control Case - No
Modem)
Maximum 1978µs between wakeups
16
Coexisting Thread Latencies (INT)
Maximum 5313µs between wakeups
17
Coexisting Thread Latencies (DPC)
Maximum 4396µs between wakeups
18
Coexisting Thread Latencies (THR 24)
Maximum 2239µs between wakeups
19
What Have We Learned So Far?
  • Signal processing in the context of the interrupt
    handler is
  • unnecessary
  • detrimental to the latencies and predictability
    of coexisting activities
  • Vendor choice understandable
  • For any priority there is a potentially unbounded
    delay between the interrupt and the thread
    running
  • In practice
  • Delays are reasonable for well-configured systems
    Intel OSDI 99
  • Using interrupts extreme form of priority
    inflation

20
Two Possible Solutions
  • Rate Monotonic Analysis determine the right
    priority assignments among all threads. Two
    problems
  • Assumes cooperative priority assignment among all
    threads - unrealistic
  • Working priority assignment dependent upon timing
    requirements of all threads
  • Changes in application mix may require changes in
    priority assignments
  • Use a time-based real-time scheduler
  • Such as Rialto/NT

21
Rialto/NT Abstractions
  • Two real-time software abstractions
  • CPU Reservations ongoing reservation for at
    least X time units out of every Y units for a
    thread
  • Time Constraints one-shot time reservation for
    specified amount of work between start time and
    deadline
  • The Soft Modem work only uses CPU Reservations

22
Rialto/NT Implementation
  • Rialto/NT developed on top of Windows 2000
    priority scheduler
  • Limitations
  • CPU Reservations must be integer multiples of
    milliseconds
  • Frequency of reservations must be power-of-two
    multiple of 1ms

23
Samples Pending to be Processed (RES 2ms/8ms
25)
Fits well within 512-sample buffer size
24
Coexisting Thread Latencies (RES 2ms/8ms 25)
Maximum 1971µs between wakeups
25
File Transfer Times
Results for 10 copies of 200,000 bytes each
For 1/8, 2/15, 3/17, 4/17, 7/20 no test passed
26
Modem Reservation Ranges
Sensitivity to both percentage and gaps
If period lt 12.5ms, must get 14.7 to work If
period gt 12.5ms, (period amount) gt 12.5ms must
also hold
27
Conclusions
  • Signal Processing in interrupt context is
  • Unnecessary
  • Detrimental to the predictability and latencies
    of the coexisting activities
  • The DPC version has similar problems
  • Threads help alleviate these problems
  • Modem runs well with real-time priorities and
    non-real-time competition
  • However modem threads may interfere with other
    threads
  • Real-time scheduler allows
  • Control over modems degree of interference with
    other time-sensitive activities
  • Performance isolation for threads using
    reservations

28
Industry Perspective
  • Vendor did build their own THR version
  • Worked fine during normal load
  • However, modem was starved when
  • copying data between two IDE devices
  • using USB scanner (Intel 440BX chipset) that
    turned off interrupts for 30-50 ms
  • Therefore they shipped the INT version
  • Vendor is willing to be a good citizen
  • if ensured that others would be as well
  • Systematic latency timing verification of
    components is needed to enforce good behavior

29
Soft DSL is Coming
  • More demanding than soft modems
  • 4ms processing period
  • G.lite
  • 1.531Mbps downstream and 512Kbps upstream
  • 25 of a 600 MHz Pentium III
  • Full rate DSL
  • 3.062Mbps downstream and 512Kbps upstream
  • Nearly 50 of a 600 MHz Pentium III
  • Soft Bluetooth period 312.5µs

30
Further Research Possibilities
  • Soft DSL studies
  • Multiple soft devices within the same machine
  • Similar studies on multiprocessors

31
For More Information
  • See the authors
  • Mike Jones
  • mbj_at_microsoft.com
  • http//research.microsoft.com/mbj/
  • Stefan Saroiu
  • tzoompy_at_cs.washington.edu
  • http//www.cs.washington.edu/homes/tzoompy/
  • See related papers at Mikes web site
