Motion in One Dimension (Position vs. Time) Chapter 5.1

1
Motion in One Dimension (Position vs.
Time)Chapter 5.1
2
Distance, Position and Displacement

• Distance The total distance that an object has
  moved.
• Ex. You walk 3 meters north and then walk 3
  meters south. What distance have you traveled?
• 6 meters

3
Distance, Position and Displacement

• Position Where you are relative to a starting
  point.
• Ex. You walk 3 meters north.
• Your position is 3 meters from your starting
  point.

4
Distance, Position and Displacement

• Displacement A measure in distance relative to a
  starting point that includes direction.
• Ex. You walk 3 meters north and then 3 meters
  south. What is your displacement?
• 0 meters.
• Ex. Your walk 3 meters north and 4 meters east.
  What is your distance traveled? What is your
  displacement?
• Distance 7 meters.
• Displacement 5 meters.

5
Motion of Objects

• To describe the motion of an object, what other
  information will we need other than position,
  distance or displacement?
• Time
• If I have the objects position and time, what
  can be determined about the objects motion?
• Speed or Velocity

6
1. Collect Data
7
2. Choose appropriate axes and plot the data.
8
3. Draw a curve that provides a best fit to the
points.
9
What information does the shape of the curve
provide?

• Straight line constant velocity.
• Changing curve changing velocity(i.e.
  acceleration).

10
What information does the shape of the curve
provide?
Negative Acceleration
Positive Acceleration
Decreasing Velocity
Increasing Velocity
11
Characterize the motion of the object from A to E.

1. Constant velocity in the positive direction.
2. Decreasing velocity.
3. Stationary.
4. Increasing velocity.
5. Constant velocity in the positive direction.

12
What information does the slope of the curve
provide?

• Positively sloped curve movement in the
  positive direction.
• Negatively sloped curve movement in the
  negative direction.

13
What else does the slope tell us?

• What is the motion described by each curve?
• How does the velocity of each curve compare to
  one another?
• A is stationary
• B is moving at the same
• speed as C, but their starting
• position is different.
• D is moving slower than
• B or C.

14
Analyzing motion of more than one object.

• Two vehicles travel through a speed trap
  traveling at two different velocities.

15
Determining the slope of the curve.
1997 World Championships - Athens, Greece
Maurice Green
100
90
80
70
60
Distance (m)
50
40
30
20
10
0
0
2
4
6
8
10
Time (s)
16
Velocity determined from the slope of the curve.
rise run df di tf
ti 85m-50m 8.4s-5.4s m 11.7m/s Since
m v v 11.7 m/s
17
Key Ideas

• Although space exists in 3 dimensions, analysis
  of objects in motion can be limited to one
  dimension to simplify problems.
• When graphing position vs. time, use the x-axis
  for time and the y-axis for position.
• By analyzing the shape of a position vs. time
  graph, the relative motion of the object can be
  determined, i.e. constant velocity, acceleration,
  stationary.
• The slope of the position vs. time graph provides
  the average velocity over the time interval.

18
What can be inferred from the following graph?
