15.6 Intel Chief River Platform Specification
QAL50(UMA) QAL51(DIS)
2
15.6 Intel Chief River Platform Specification
2011 15.6 Features 2012 15.6 Features
Processor Cache Huron River, Sandy Bridge Processor Dual Core i3i7, Quad Core i7 Chief River, Ivy Bridge processor Dual Core i3i7, Quad Core i7
Chipset Intel Cougar Point PCH (HM65) Intel Panther Point PCH (HM75 or HM76)
Main Memory 2 x SODIMM Sockets for Expansion Up to 8GBDual Channel DDR3 1066/1333 DRAM support 2 x SODIMM Sockets for Expansion Up to 16GBDual Channel DDR3 1066/1333 DRAM support
Display 15.6 HD/FHD 169 LED Backlight, Dual Channel LVDS Cable 15.6 HD/FHD 169 LED Backlight, Dual Channel LVDS Cable
Graphics Video Module nVIDIA N12P-GV2 max to 1G VRAM nVIDIA /N12P-GS/N12P-GT max to 2G VRAM nVIDIA N3P-GS max to 2G VRAM nVIDIA N13P-GT max to 2G VRAM
Card Reader Non Push-Push Type, SDMMCMS Non Push-Push Type, SDMMCMS
Hard Disk Drive 2.5 9.5mm SATA HDD Supported 2.5 9.5mm SATA HDD Supported, SSD Design Ready
ODD 12.7mm slim SATA ODD, S-Multi ODD, BD Combo 12.7mm slim SATA ODD, S-Multi ODD, BD Combo
Network Connectivity WLAN 802.11b/g/n, Combo card 802.11bgnBT3.0On board Giga LAN WLAN 802.11b/g/n, Combo card 802.11bgnBT3.0On board Giga LAN , Intel WiDi
Video Camera Fixed 1.3M / 2.0 Mb Pixels Video Camera Fixed 1.3M / 2.0 Mb Pixels Video Camera
Keyboard General Keyboard Isolated Keyboard
Interface 1x D-Sub, 3x USB 2.0 (1 Co-lay with USB 2.0), 2 Audio jack, 1x LAN RJ-45 jack, 1x HDMI , Card Reader, TPM, Smart Card Reader 1x D-Sub, 1x USB 3.0, 2 x USB 2.0, 1x USB 3.0 e-SATA Combo, 2 Audio jack, 1x LAN RJ-45 jack, 1x HDMI , TPM (Option), Card Reader, Smart Card Reader, Express Card (TBD), Fingerprint (Option, TBD)
Audio HD Audio, Speakers (22W), Microphone-in and Headphone-out HD Audio, Speakers (22W), Microphone-in and Headphone-out
Battery Pack 6 cell , 4400/5200 mAh 6/9 cell , 4400/5200 mAh
AC adapter 65W/90W/120W, 3 pin 65W/120W, 3 pin
Support OS Windows7 Windows7
ID IMR Paint
Dimension / Weight 373.3 249 34.9mm 2.5 Kg TBD
