Title: Rapid Assessment Process Project Strategic Plan City of La Joya Wastewater Treatment Plant and Collection System Improvements Hidalgo County, Texas Presented to: Project Sponsor and BECC Staff Transition Meeting January 9, 2003


1
Rapid Assessment ProcessProject Strategic
PlanCity of La JoyaWastewater Treatment Plant
and Collection System Improvements Hidalgo
County, TexasPresented to Project Sponsor and
BECC StaffTransition Meeting January 9, 2003
2
Agenda
  • General Aspects
  • Environmental and Human Health Indicators
  • Technical Approach, Objectives and Funding Plan
  • Public Participation
  • Sustainable Development
  • Immediate Action Items
  • Project Development Schedule

3
General Aspects
  • Project Location
  • City of La Joya is located in Hidalgo County,
    Texas west of McAllen. The community is 5 miles
    north of the U.S./Mexican Border.

4
General Aspects
  • State of Existing WWTP and Collection System
  • Originally constructed in 1982, the WWTP is a
    no-discharge pond facility.
  • The system includes a WWTP with a capacity of
    0.175 MGD and consists of two lagoons, two
    stabilization ponds, one holding pond, one
    submersible pump and wet well for irrigation and
    re-circulation purposes and one 5.24-acre
    irrigation field.
  • The WWTP includes five storage ponds with total
    capacity of 27.8 acre-feet for storage of treated
    effluent prior to evaporation and irrigation.
  • It should be noted that the renewal permit
    requires 28.9 acre grassland drainage area.
  • Currently in poor condition, the WWTP operates
    well-above its designated capacity.
  • The Citys wastewater collection system consists
    of 8-inch gravity sewer pipe, 4-inch to 6-inch
    force main, and 9 lift stations, with most of the
    gravity sewer mains flowing at full capacity and
    not able to accept additional flow.
  • Concerns Currently violating renewal permit
    requirements with only 5.2 acres of grassland
    available for disposal. Additional expansion is
    required to address capacity demands.

5
General Aspects
  • Proposed Wastewater Treatment System Improvement
    Project
  • Continued use of the existing WWTP requires
    acquisition or lease of additional disposal land
    under the current TCEQ no-discharge permit is
    still needed.
  • Expansion/Replacement of existing WWTP in order
    to comply with TCEQs permit, which requires the
    City to commence construction of additional
    treatment facilities after reaching 90 percent of
    capacity.
  • The WWTP will be constructed to accommodate
    additional flow from the expanding school
    district and from the planned extension of
    wastewater services to outlying colonias of
    Tierra Blanca, Havana and Penitas.
  • The City agrees with the existing technical
    studies recommendation to construct a new
    conventional WWTP rather than expanding the
    existing WWTP because of land requirements of
    that technology. The proposed alternative for the
    ww treatment will implement an activated sludge
    process consisting of oxidation ditches,
    clarifiers, chlorine disinfections, and sludge
    processing facilities, requiring approximately
    9-acres and treat 1.57 MGD.
  • Improvements to the existing wastewater
    collection system, including the rehabilitation
    of some existing lift stations, collection lines,
    manholes, laterals, extension of new service to
    the outlying colonias and household connections.

6
General Aspects
  • Total Estimated Cost 8.7 Million
  • (Based on STEP I Application)

7
General Aspects
Project Sponsor Profile
Prior Agency Support and Existing Studies
  • Population 3,303 (5,027 with colonias)
  • Colonias Population
  • Penitas 958
  • Tierra Blanca 380
  • Havana 386
  • Growth rate (90-00) 26.8
  • MHI 22,820.00
  • Unemployment rate 19.6
  • Legal utility provider
  • 985 water accounts
  • 1,073 sewer accounts
  • 10 employees (4 certified operators)
  • Billing efficiency 96
  • USDA City applied for funding for construction
    of lift stations in 2001 (currently awaiting
    completion of review by USDA).
  • CDBG grant funding provided in 2001 to prepare
    plans, specs and estimates to re-certify
    pond-lining and repair areas of erosion of the
    WWTP stabilization and holding ponds.
  • TWDB the City has applied for funding for the
    proposed project.
  • No prior BECC or NADB assistance.
  • 2001 Environmental Information Document.
  • Drafted Category A, B and C planning documents
    per TWDB.

8
Environmental and Human Health Indicators
  • Human Health Indicators
  • The limitations of the WWTP pose a direct threat
    to the health and safety of the residents of La
    Joya, given the potential health risks that can
    be derived from groundwater contamination due to
    higher application rates.
  • The residents of Tierra Blanca, Havana and
    Penitas currently utilize septic tanks and drain
    fields. Failure of these systems represents a
    public risk.
  • Most of these on-site systems do not meet TCEQ
    On-Site Sewage Facilities design requirements,
    with most residential lot sizes with less than
    0.5 acres or multiple homes on a single lot.

9
Environmental and Human Health Indicators
  • Human Health Indicators
  • The expansion of the Citys WWTP and the
    rehabilitation of the existing collection system
    will address several human health and
    environmental concerns of the residents of City
    of La Joya and outlying colonias of Tierra
    Blanca, Havana and Penitas, which currently
    utilize septic tanks and drain fields.
  • Although existing statistics are not specific to
    the City of La Joya, the Texas DOH has indicated
    that cases of Cryptosporidiosis and Amebiasis
    have been reported in Hidalgo County. The number
    of cases per 100,000 people are as follow

10
Environmental and Human Health Indicators
  • Environmental Indicators
  • The poor conditions and under sizing of the
    existing WWTP may have a significant
    environmental impact on the groundwater and air
    quality of the area.
  • Overflow conditions and exposed wastewater
    accumulated at the surface of land disposal areas
    due to higher application rates can create a pest
    and odor nuisance for the community of La Joya.
  • Groundwater contamination may occur due to
    improper lining of the stabilization ponds and
    higher land application rates on designated
    disposal areas.
  • The proposed project will bring positive
    improvements to the general environment of the
    City of La Joya are by eliminating the
    environmental impacts that can be caused by the
    current wastewater disposal practices and
    systems deficiencies.

11
Environmental and Human Health Indicators
  • Compliance with Environmental Norms Regulations
    Including Violations
  • The City received a notice of violation on
    January 5, 2000, by TCEQ, regarding the Citys
    failure to commence additional construction
    planning of the WWTP after reaching 90 percent of
    capacity for three consecutive months.
  • Previous TCEQ violations included the need to
    repair stabilization and holding pond
    embankments, failure to provide an audio-visual
    alarm system for all lift stations and failure to
    submit a permit application within the
    appropriate time before the expiration date of
    the effective permit.
  • The City needs to improve the existing wastewater
    distribution system to resolve the overflow
    conditions in pipelines due to the increase in
    flow by rainfall events, causing significant
    increase to influent at the WWTP.

12
Technical Approach,Objectives and Funding Plan
  • Project Objectives
  • Improvements to the wastewater treatment,
    rehabilitation of existing wastewater collection
    system and expansion of new collection services
    to meet the demands of the existing population of
    the City, and to comply with TCEQs permit
    requirements.
  • The expansion will allow the City to provide
    wastewater services to the outlying colonias of
    Tierra Blanca, Havana and Penitas.
  • Technical Approach
  • Technical Assistance needed to develop the
    following documents
  • Facility Plan and EID for WWTP improvements (In
    progress and funded by CDBG).
  • Preliminary Engineering Report and Environmental
    per USDA
  • Financial Analysis.
  • Rate Study.
  • Public Participation Program.
  • Engineering Design for the proposed wastewater
    systems improvements.

13
Technical Approach,Objectives and Funding Plan
  • Identified Potential Funding Sources
  • Texas Water Development Board (TWDB)
  • Funds may be available through TWDB Dfund II,
    EDAP and CWTAP
  • United States Department of Agriculture (USDA)
  • Funds tailored for rural areas with populations
    of less than 10,000
  • North American Development Bank (NADB)
  • BEIF and IDP
  • Border Environment Cooperation Commission (BECC)
  • PDAP program
  • US Army Corps of Engineers

14
Technical Approach,Objectives and Funding Plan
  • Project Sponsor Financial Potential
  • Revenues and Expenditures Summary (millions)
  • 1999 2000 2001
  • Revenues 1.1 0.5 0.5
  • Expenses 1.4 0.03 0.2
  • Net Available
  • from Operations (0.3) 0.5 0.3
  • Existing Debt 0 Annual Debt Service 0
  • Water WW
  • Average Monthly Bill 23.50 22.50
  • (City approved rate increase in July 2002.)

15
Technical Approach,Objectives and Funding Plan
  • PDAP Eligibility Criteria
  • 1) Financial strategy for the entire
    project Yes
  • 2) Project sponsor awareness of technical aspects
    of project Yes
  • 3) Project sponsor has provided demonstration of
    documentation Yes
  • support for the project
  • 4) BEIF financing eligible Yes
  • 5) C.N.A. and/or state/local gov. support, for
    projects in Mexico NA
  • 6) Funds allocated on a per task basis Yes
  • 7) Project coordination with all government
    agencies involved Yes
  • 8) Value engineering as required under BEIF
    program Yes

16
Technical Approach,Objectives and Funding Plan
  • BEIF Eligibility Criteria
  • 1) Project located within 100 km of the
    border Yes
  • 2) Project addresses a human health and/or
    ecological issue Yes
  • 3) Project provides U.S. side benefits Yes
  • 4) Project scope entails community infrastructure
    in W/WW Yes
  • 5) Project sponsor to pursue Certification of
    Project Yes
  • 6) Drinking water projects quality of water
    only, not raw water supply NA
  • 7) Projects have a funding strategy with funding
    sources identified Yes
  • 8) Projects that discharge into U.S. side waters
    to target US norms Yes
  • 9) Payment and benefit to public entity only not
    private sector Yes
  • 10) For final design must meet eligibility
    requirements Yes
  • 11) Colonias projects, after 06-01-01,
    eligibility based on established Yes
  • enforceable ordinances preventing
    exacerbation or new colonias

17
Technical Approach,Objectives and Funding Plan
  • Agency Perspectives - NADB
  • An initial analysis of the proposed project in
    regards to BEIF eligibility criteria provides a
    sense that the project will be eligible for this
    program.
  • An affordability analysis will be completed to
    determine any participation with BEIF grants
    including construction, hook-up and transition
    support.
  • Loan assistance can be available for construction
    and potential support may be provided by the IDP
    for completion of a rate study and other
    institutional capacity building needs.

18
Technical Approach,Objectives and Funding Plan
  • Agency Perspectives - TWDB
  • Because the project will address nearby colonias,
    this project will be eligible for EDAP funding
    through TWDB, a process already initiated by the
    community.
  • Project will meet criteria for application to SRF
    and Dfund II. Application to be included on
    priority list (IUP) needs to be submitted in Feb.
    2003.
  • The community will include a line-item request
    for project management assistance.
  • Upsizing collection lines of the existing system
    will not be eligible for EDAP.

19
Technical Approach,Objectives and Funding Plan
  • Technical Assistance Tasks
  • Task Source
  • Facility Plan and EID CDBG
  • Revisions to Planning Docs to meet USDA BECC
  • Financial Analysis BECC
  • Public Participation Program BECC
  • Project Certification Document BECC
  • Final Design BECC/Other

20
Technical Approach,Objectives and Funding Plan
  • Institutional Capacity Building
  • The project sponsor identified such needs as a
    capital improvement plan, rate study, project
    management assistance and the development of
    public participation programs.
  • The Frank M. Tejeda Center has conducted an
    Institutional Capacity Needs Assessment with the
    City of La Joya.

21
Technical Approach,Objectives and Funding Plan
  • Institutional Capacity Building
  • In specific, observations were made pertaining
    to
  • Current Operating Violations WWTP capacity,
    berm wall leaks.
  • Planning Under development per TWDB guidelines,
    may need modification to meet USDA requirements.
  • Project Development and Funds Management City
    requires assistance.
  • Outsourcing City provides all operation
    services.
  • Operational Capacity Additional certified
    operators will be needed, specifically with B
    and C certifications. Operator training
    recommended.
  • Management Capabilities working with the Tejeda
    Center for continued assistance.
  • Governance Recommend elected official training
    and development of manuals.

22
Technical Approach,Objectives and Funding Plan
  • Potential Obstacles
  • Inter-local agreement are complete with the City
    of Penitas to allow the City to provide
    wastewater treatment within the Penitas
    wastewater CCN (No. 20794), further obstacles for
    this community are not anticipated to meet the
    proposed project objectives.
  • La Joya WSC has agreed to decertify a portion of
    CCN to provide an opportunity for the City to
    certify this area. Further obstacles are not
    anticipated on this issue.
  • USDA has not participated in RAP and is a
    potential funding source for the project.
    Efforts must continue to be made to bring this
    agency to the table. Modifications to planning
    documents be required.
  • Potential obstacles may exist because of the
    public perception problems encountered during the
    recently certified project with La Joya WSC.
  • The final WWTP site selection process should take
    into account significant public outreach. A site
    is recommended in the existing planning
    documents, public outreach must be extensive to
    comfort the response of the community.

23
Public Participation
  • Identification of Main Stakeholders
  • City of La Joya and its residents
  • Texas Water Development Board
  • Texas Commission on Environmental Quality
  • North American Development Bank
  • Frank M. Tejeda Center
  • Border Environment Cooperation Commission
  • United States Department of Agriculture
  • Secretary of State
  • US Army Corps of Engineers
  • Local Politics
  • The Citys government structure is composed of a
    City Mayor and two commissioners. Current counsel
    members have a two-year term. The Mayor has a
    long history of public service with this
    community.

24
Sustainable Development
  • Minimum Criteria Requirements
  • The City of La Joya made a commitment to comply
    to all applicable minimum requirements for the
    project in compliance with the BECCs sustainable
    development criteria. Based on the status of
    existing planning and capacity assessment
    conducted by the Tejeda Center, a strategy to
    meet the applicable requirements has been
    included in Attachment H of the Strategic Plan.

25
Sustainable Development
  • Service Indicators
  • Water service indicators all available water
    service indicators were recorded.
  • Sewer service indicators all available sewer
    service indicators were recorded. The indicators
    describe 99 coverage of the existing service
    area with 1073 connections. Other flagged
    indicators such as OM problems,
    infiltration/inflow problems will be addressed
    with the proposed project
  • .
  • Wastewater service indicators all available
    wastewater service indicators were recorded.
    Indicators were not provided to describe actual
    flow into the existing WWTP or sludge quality.
    OM problems and non-compliance notifications
    will be addressed with the proposed project.

26
Immediate Action Items
  • City of La Joya
  • Provide procurement documentation for consultant
    selection.
  • Determine financial needs to complete the
    development of technical documents to meet TWDB
    requirements. Is the existing CDBG funding
    adequate?
  • Provide letter accepting Strategic Plan.
  • Formation of Steering Committee.
  • Provide additional information to complete
    Baseline Conditions report and TBD indicators.
  • BECC
  • Develop SOW. SOW to include a determination of
    modifications required to meet USDA requirements.

27
Project Development Schedule
Task Name Duration Start Finish
Application Process 10 days 08/02/02 08/15/02
Rapid Assessment Process 94 days 08/19/02 01/09/03
Technical Assistance Process 38 days 01/10/03 03/04/03
Project Development Process (TA, Public Participation, NEPA) 494 days 12/16/02 11/18/04
Project Design Process 322 days 06/26/03 09/17/04
TWDB Funding 66 days 07/03/03 10/02/03
NADB Rate Study 67 days 02/03/04 05/05/04
BECC Certification Process 39 days 07/26/04 09/16/04
Write a Comment
User Comments (0)
About PowerShow.com
