Title: ABAP Performance Tuning


1
ABAP Performance Tuning
2
??? ??
?? 10
System Tuning 20 (OS,I/O,???,DBMS..)
Application Tuning 70 (SQL,???,?,JOIN,Array,??
??)
3
Array Mode and Workarea Mode
4
Database architecture
5
Rules of Efficient Database Programming (I)
  • 1. Keep the hit set small
  • specify everything you know in the WHERE clause
  • 2. Keep data to be transferred small
  • projection views and field lists
  • no workarea update
  • aggregate functions and group by
  • 3. Keep the number of transfers small
  • use array changes
  • avoid nested selects(possible alternatives
    joins, subselects, explicit cursors)
  • 4. Keep the area to be searched small
  • let the database use the indexes in an optimal
    way
  • create good indexes

6
Rules of Efficient Database Programming (II)
  • 5. Take load off the database where possible
  • Table buffering
  • Avoid repeated reading of data (e.g. use global
    reading module for master data)
  • Avoid SELECT before changes
  • Avoid restart logic for mass data processing
  • Better use open cursor with hold
  • Use SORT instead of ORDER BY where possible
  • Use DELETE ADJACENT instead of DISTINCT where
    possible
  • Use logical databases only if design is
    appropriate
  • Avoid dynamic SQL because it is not using
    buffering mechanisms

7
ABAP/4 Performance Tuning(Technique 1)
  • Bad statement
  • SELECT FROM table
  • Ex) SELECT FROM VBAK ..
  • WRITE / VBAK-VBELN, ..
  • ENDSELECT.
  • Good statement
  • SELECT col1,col2 into(col1,col2) FROM table
  • Ex) SELECT VBELN, AUART, BNAME, KUNNR
  • INTO (VBAK-VBELN, VBAK-AUART, .)
  • FROM VBAK ..
  • WRITE / VBAK-VBELN, VBAK-AUART,.

?? 1000 ??? ??? SELECT FROM table
? 2,910,000 ms(micro seconds)
SELECT col1,col2.. ? 239,000 ms
DB SVR?AP SVR? ??? ?? ??? ??,??? ???? I/O??? ??.
??? ??? ???? AP SVR? ??? loading??? ?? ??? ????
?? ? ??
8
ABAP/4 Performance Tuning(Technique 2)
  • Bad statement
  • SELECT FROM table ... EXIT
  • Ex) SELECT VBELN BNAME INTO (VBAK-VBELN,.)
  • FROM VBAK.
  • IF SY-DBCNT gt 1000. EXIT. ENDIF.
  • WRITE / VBAK-VBELN,
    VBAK-BNAME,.
  • ENDSELECT.
  • Good statement
  • SELECT col1,col2 into(col1,col2) FROM table UPTO
    n ROWS
  • Ex) SELECT VBELN, AUART, BNAME, KUNNR
  • INTO (VBAK-VBELN, VBAK-AUART, .)
  • FROM VBAK .. UPTO 1 ROWS.
  • WRITE / VBAK-VBELN, VBAK-AUART,.

?? 1000 ??? ??? SELECT ... EXIT. ENDSELECT.
? 410,000 ms SELECT .. UPTO 1 ROWS
? 368,000 ms
9
ABAP/4 Performance Tuning(Technique 3)
  • Bad statement
  • SELECT FROM table ... CHECK
  • Ex) SELECT VBELN INTO ( VBAK-VBELN, .)
  • FROM VBAK.
  • CHECK
    VBAK-VBELN7(1) 9.
  • WRITE /
    VBAK-VBELN,
  • ENDSELECT.
  • Good statement
  • SELECT col1,col2 into(col1,col2) FROM table
    WHERE Clause
  • Ex) SELECT VBELN, AUART, BNAME, KUNNR
  • INTO (VBAK-VBELN, VBAK-AUART, .)
  • FROM VBAK
  • WHERE VBAK-VBELN LIKE -------9---.
  • WRITE / VBAK-VBELN, VBAK-AUART,.

?? 57,000 ??? ??? SELECT ... CHECK.
? 27,958,000 ms SELECT WHERE clause. ?
3,065,000 ms
10
ABAP/4 Performance Tuning(Technique 4)
  • Bad statement
  • DBMS sort ??
  • Ex) SELECT VBELN.. INTO (VBAK-VBELN,..)
  • FROM VBAK
  • WHERE BNAME IN S_BNAME
  • ORDER BY BNAME
  • Good statement
  • AP?? internal table sort ??
  • Ex) SELECT VBELN, AUART, BNAME, KUNNR
  • INTO TABLE IVBAK FROM VBAK
  • WHERE BNAME IN
    S_BNAME.
  • SORT IVBAK BY BNAME.

11
ABAP/4 Performance Tuning(Technique 5)
  • Bad statement
  • SELECT APPEND
  • Ex) SELECT VBELN . INTO (IVBAK-VBELN, )
  • FROM VBAK
  • WHERE BNAME IN S_BNAME
  • APPEND IVBAK
  • ENDSELECT.
  • Good statement
  • SELECT INTO TABLE
  • Ex) SELECT VBELN, AUART, BNAME, KUNNR
  • INTO TABLE IVBAK FROM VBAK
  • WHERE BNAME IN S_BNAME.

12
ABAP/4 Performance Tuning(Technique 6)
  • Bad statement
  • NESTED SELECTS
  • Ex) SELECT VBELN AUART VTWEG VKORG SPART
  • INTO IVBAK FROM VBAK
  • WHERE VBELN BETWEEN ..... AND
    ......
  • SELECT POSNR MATNR ZMENG MEINS
  • INTO IVBAP FROM VBAP
  • WHERE VBELN
    IVBAK-VBELN.
  • WRITE /IVBAK-VBELN,
    .......
  • ENDSELECT.
  • ENDSELECT.
  • Good statement
  • ??? ??? VIEWS ??
  • Ex) SELECT FROM ZV_VBAK
  • WHERE VBELN BETWEEN
    .... AND ....
  • WRITE ZV_VBAK-VBELN, .....
  • ENDSELECT.
  • ??? ??? view? tables join, columns projection,
  • rows selection? ?? logical table?.

Join ??? ?? ? ? ?? SAP R3 3.1?? ABAP SQL?? JOIN
???.
13
ABAP/4 Performance Tuning(Technique 7)
  • Bad statement
  • ABAP CALCULATIONS(Collect)
  • Ex) SELECT MATNR KWMENG MEINS INTO VBQTY
  • FROM VBAP WHERE ..
  • COLLECT VBQTY.
  • ENDSELECT.
  • Good statement
  • DBMS SUM, AVG, MIN, MAX ?? ??
  • Ex) SELECT MATNR SUM(KWMENG) MEINS
  • INTO TABLE VBQTY FROM VBAP
  • WHERE .. GROUPBY ..

??,??,???,??? ? ?? ??? ? DBMS? ??? ???? ?? ??.???
logic?? ?? ?? ???.
14
ABAP/4 Performance Tuning(Technique 8)
  • Bad statement
  • READ TABLE ..WITH KEY.
  • Ex) SELECT VBELN KUNNR .... INTO TABLE IVBAK
  • WHERE ..........
  • READ TABLE IVBAK WITH KEY VBELN
    00900000090.
  • Good statement
  • READ TABLE ..WITH KEY. BINARY SEARCH (
    TRANSPORTING NO FIELDS)
  • Ex) SELECT VBELN KUNNR .... INTO TABLE IVBAK
  • WHERE .......
  • READ TABLE IVBAK WITH KEY VBELN
    00900000090.
  • BINARY SEARCH ( TRANSPORTING NO FIELDS)

Large internal table? ??? ? binary search
transport no fields? ?? ??.
15
ABAP/4 Performance Tuning(Technique 9)
  • Good statement
  • Itab2 itab1 .
  • Bad statement
  • LOOP AT ITAB1.
  • MOVE ITAB1 TO ITAB2.
  • APPEND ITAB2.
  • ENDLOOP.

?? ?? internal table? ??? ??? ??? ?.
16
ABAP/4 Performance Tuning(Technique 10)
  • Bad statement
  • LOOP AT ITAB1.
  • MOVE ITAB1 TO ITAB2.
  • APPEND ITAB2.
  • ENDLOOP.
  • Good statement
  • APPEND LINES OF ITAB1 TO ITAB2.

Internal table? data append??
17
ABAP/4 Performance Tuning(Technique 11)
  • Bad statement
  • LOOP AT IVBAK WHERE BNAME SMITH.
  • DELETE BNAME.
  • ENDLOOP.
  • Good statement
  • DELETE IVBAK WHERE BNAME SMITH.

Internal table? data ????.
18
ABAP/4 Performance Tuning(Technique 12)
  • Good statement
  • select from vbap where vblen vbak-
  • vblen and pstyv ZRE3 and
    werks0100.
  • Bad statement
  • select from vbap where vblen vbak-vblen.
  • check vbap-pstyv ZRE3.
  • check vbap-werks 0100.

Transparent table ? select ? ?? ??? ?? key field?
where?? ?? ??. Bad statement? Application server?
?? memory? ?? ??.
19
ABAP/4 Performance Tuning(Technique 13)
  • Bad statement
  • select from bseg where bukrs bsik-bukrs
  • and rebzgbsik-belnr
  • and lifnrbsik-lifnr
  • and shkzgS
  • and koartK.
  • Good statement
  • select from bseg where bukrsbsik-bukrs
  • and rebzgbsik-belnr.
  • check lifnrbsik-lifnr.
  • check shkzgS.
  • check koartK.

Pool,cluster table? data? ?? statement? parse?? ?
data ??? unpack ??? ? ??. ??? ?? logical table?
key field? where?? ????, ???? check??? ????.
20
ABAP Performance Tuning(? ?)
  • Native SQL ??
  • ??? DB link???
  • SQL join?? ???
  • SELECT SINGLE? ?? ??
  • key? ? ???(index)
  • Index full scan??? table full scan? ??? ??.
  • R3??? mandt field? ?? index full scan?
    ???.
  • Index? single block read??,table? multi
    block read?.
  • Select option? client specified? ??
    mandt field? ABAP???? ?? ???.
  • Read only table? buffering? ????.
  • Full buffering(?? table),Generic
    buffering(? table)? ??? ? ??.
  • SQL Trace? ABAP trace? ??? ????.
  • Index????,full scan,DB ? AP?? ?? ?? ??
    ???? ??POINT??
