Protozoa

1
??? ???? ?????? ??????
2
Protozoa Intestinal Amoeba
3
(No Transcript)
4

• Causal Agent
• Several protozoan species in the genus Entamoeba
  infect humans, but not all of them are associated
  with disease.
• Entamoeba histolytica is well recognized as a
  pathogenic ameba, associated with intestinal and
  extra-intestinal infections.
• The other species are important because they may
  be confused with
• E. histolytica in diagnostic investigations.

5

• Introduction
• Entamoeba histolytica
• 1. The only pathogenic amoeba
• among all of the intestinal
• amoebae.2. Infecting perhaps 10 of the
• world's population.3. Lead to invasive
  amoebiasis.

6

• Entamoeba histolytica
• Worldwide, with higher incidence of amoebiasis in
  developing countries.
• risk groups include male homosexuals, travelers
  and recent immigrants, and institutional
• populations.

7
morphology
8
(No Transcript)
9
(No Transcript)
10

• Life cycle
• Infection by Entamoeba histolytica occurs by
  ingestion of mature cysts in fecally contaminated
  food, water, or hands.
•   Excystation occurs in the small intestine and
  trophozoites are released, which migrate to the
  large intestine.
• The trophozoites multiply by binary fission and
  produce cysts.
• Cysts and trophozoites are passed in feces Cysts
  are found in formed stool, whereas trophozoites
  are found in diarrheal stool.

11
(No Transcript)
12
(No Transcript)
13
E.dispar has similar live cycle but non invasive
,not pathogenic.
Via polluted water infected food handler, flies
contaminating food, soil cultivation, direct
contact
Viability -Moist ,cool condtion Up to 12days
-In water 9-30 day
14

• transmission.
• the cysts can survive days to weeks in the
  external environment (protection by cyst walls)
  and are responsible for transmission.
• Trophozoites in the stool are rapidly destroyed
  outside ,and if ingested not survive in the
  gastric juice.
• In many cases, the trophozoites remain confined
  to the intestinal lumen of individuals who are
  known as (non-invasive infection) cyst passer.

15
1- the primary ulcer invasion of mucosa via
crypts repair may occur. 2- extension in mucosa
muscularis mucosa relatively resistant.
3-formation of sinus accumulation of amoebae
superficial to muscularis mucosa with lateral
extension of lytic necrosis abscesses may
coalesce under intact mucosa , mucosa may slough
with widespread ulceration 4-deep extension
muscularis mucosa eventually pierced (direct or
via blood) deep necrosis of sub-mucosa even
muscle and sub-serosa
1
2
3
4
16
Complications and squeals
-Perforation hemorrhage (rare)
-Pretonitis haemorrhag
-Surronging inflammatory reaction
-Secondary infection
-A mass under oedemotous mucosa Amoeboma
clinically simulates neoplasm
Amoeboma Obestraction intusssception
-Invasion of blood vessels. -Direct extension
outside bowel
-Extraintestinal lesion
17

• -Ulcer with peritonitis
• - hemorrhage
• - surrounding inflammatory reaction
• and fibroplastic proliferation a
• mass formed under edematous
• mucosa amoeboma (simulate carcinoma)

18
Extra intestinal extension
19
Extra intestinal extension
Liver involvement - Secondary to - Concomitant
with - Independent of
20
.
A
B
21

• the pathogenic E. histolytica is not
  morphologically differs from the nonpathogenic E.
  dispar!
• Each trophozoite has a single nucleus, which has
  a centrally karyosome and uniformly distributed
  peripheral chromatin.
• The cytoplasm has a granular or "ground-glass"
  appearance.
• Entamoeba histolytica / E. dispar trophozoites
  measure usually 15 to 20 µm (range 10 to 60 µm),
  tending to be more elongated in diarrheal stool.

22
C D
23
erythro-phagocytosis,
e
f
Trophozoites of Entamoeba histolytica with
ingested erythrocytes .The ingested erythrocytes
appear as dark inclusions.
24

• Erythro-phagocytosis
• is the only morphologic characteristic that can
  be used to differentiate E. histolytica from the
  non-pathogenic
• E. dispar

25

• The nuclei of Entamoeba histolytica have
  characteristically centrally located karyosomes,
  and fine, uniformly distributed peripheral
  chromatin.
• The cysts contain chromatoid
• bodies , with typically blunted
• ends.
• Entamoeba histolytica cysts usually measure 12 to
  15 µm.

26
MatureEntamoeba histolytica cysts usually measure
12 to 15 µm. cysts have 4 nuclei.
h
I
27

• Entamoeba coli

28
Trophozoites of Entamoeba coli
B
C
A
29

• Entamoeba coli
• -Trophozoites each have one nucleus with a large,
  eccentric karyosome and coarse, irregular
  peripheral chromatin.
• -The cytoplasm is coarse , vacuolated
• (dirty cytoplasm).
• - Cytoplasm contains ingested bacteria , yeasts
  or other materials.
• - The trophozoites of E. coli measure usually 20
  to 25 µm, but it can reach up to 50 µm.

30

• Mature cysts typically have
• 8 nuclei, and measure about
• 20-25 µm (range 10 to 35 µm).
•   Chromatoid bodies are seen less frequently than
  in E.histolytica.  they are splinter like with
  pointed ends.
• N.B. chromatoid bodies of E.histolytica have
  rounded ends.

31
Entamoeba coli cyst
E
D
F
32
(No Transcript)
33

• Clinical FeaturesA wide spectrum, from
  asymptomatic infection ("luminal amebiasis"), to
  invasive intestinal amebiasis (dysentery,
  colitis, appendicitis, toxic megacolon,
  amebomas), to invasive extra-intestinal amebiasis
• (liver abscess, peritonitis, pleuropulmonary
  abscess, cutaneous and genital amebic lesions).

34
pinpoint lesion on mucous membrane
35
(No Transcript)
36
flask-shaped (Ulcers)
37
Amoebic abscess in liver
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41

• Pathogenesis
• Clinical classification
• Intestinal
• Asymptomatic infection
• (carrier)  85-95 of cases.
• Sympomatic cases 5-15
• a. Intestinal amoebiasis
• - a. dysentery
• (blood and mucus in stool)
• - b. non-dysenteric colitis
• - c. amoeboma
•

42

• b.Extra-intestinal amoebiasis
• a. Hepatic
• (1) acute non suppurative
• hepatitis
• (2) liver abscess
• b. Pulmonary
• c. Brain, Skin, Other extra-
• intestinal amoebiasis.

43

• Hepatic amoebiasis
• sing symptoms
• Local discomfort.
• Malaise, fluctuant temperature
• Toxemia.
• Pain in right shoulder.

44
Diagnosis intestinal Direct _
Microscopic identification of cysts and
trophozoites in the stool _ trophozoites can
also be identified in aspirates or biopsy
samples obtained during colonoscopy or
surgery. Indirect by immunodiagnosis (elisa)

45

• Diagnosis of Amoebic liver abscess
• X-ray or ct scan show raised
• diaphragm
• Blood picture leucoytosis.
• Serological test (elisa).
• Examination of aspirate if indicated as treatment.

46

• Treatment-For asymptomatic infections,
  (furamide) is the drugs of choice.
• -For symptomatic intestinal disease,
• or extra intestinal, infections
• (e.g. hepatic abscess), the drugs of choice are
  metronidazole or tinidazole, immediately followed
  by treatment with diloxanide furoate.

47

• Prevention
• human feces should not be used as fertilizer
• food and drinks must be protected from flies.
• (mechanical transmission)
• personal hygiene.
• wash hands after defecation and before meals.
  (autoinfection)

48

• in summary
• pinpoint lesion on mucous membrane
• flask-shaped Ulcers
• Amoebic liver abscess
• anchovy sauce sputum (lung)
• brain , spleen , genito-urinary tract
• amoeboma simulate carcinoma.
• - Cyst carrier is a healthy persons
  (trophozoite only in intestinal lumen -Lumenal
  form).
• - Pre-employments Stool analysis was done for
  food handler.

49
????? ???
50
(No Transcript)
51
FREE-LIVING PROTOZOA

• Ameba Diseases
• Naegleria fowleri
• PAM
• Acanthamoeba spp.
• GAE,
• skin or lung lesions,
• amebic keratitis.

52
Acanthamoeba spp 7 species
53

• Acanthameoba
• Have only 2 stage cyst And
• trophozoite.
• Trophozoite and cyst are infective form.
• portal of entry unknown, possibly respiratory
  tract, eyes, skin.
• presumed hematogenous dissemination to the CNS.

54

• Acanthamoeba Encephalitis
• infection associated with debilitation or
  immunosuppression. opportunistic parasitic inf.
• chronic GAE (granulomatous amebic
  encephalitis). the organisms cause a
  granulomatous encephalitis that leads to death.
• occurred in wearers of contact lenses.

55

• Amebic Keratitis
• Predisposing factors
• ocular trauma, contact lens
• (contaminated cleaning solutions).
• Symptoms ocular pain, corneal lesions
  (refractory to usual treatments).
• Diagnosis
• demonstration of amebas in corneal scrapings.
• Treatment
• difficult, limited success
• corneal grafts often required.

56
(No Transcript)
57
Niglaria fowleri
58
Naegleria fowleri

• found in fresh water.
• ameba with loblose
• Pseudopodia.
• motile bi-flagellated form.
• PAM first recognized by
• Fowler (1965).

59

• Primary Amebic Meningoencephalitis
• (PAM)
• Symptoms usually within a few days after
  swimming in warm still waters.
• Infection believed to be
• introduced through nasal cavity and olfactory
  bulbs.
• Symptoms include headache, disorientation,
  coma.

60
Giardia lamblia
61
(No Transcript)
62
(No Transcript)
63

• Clinical picture
• A-Asymptomatic infection majority ,
• about 80
• B-Symptomatic infection
• 1 typical picture most of symptomatic
• cases incubation period 1-2 weeks
• followed by diarrhea for bout 6 weeks.
• 2 atypical picture
• - malabsorption in children
• - fatty diahrrea
• - Sever diarrhoea.

64
Laboratory diagnosis -Stool examination daily
for three days. -Examination of duodenal
aspirate, or by string (enterotest)
65
(No Transcript)
66
Trichomonas vaginalis
67
No cyst form
68
(No Transcript)
69

• Trichomonas vaginalis
• Transmission sexual intercourse or contact with
  contaminated objects.
• Pathology
• Female vaginitis ,profuse thin yellowish
  discharge with bad smell.
• Male invasion of urethra ,prostate and seminal
  vesicles ,causing urethritis but mostly
  asymptomatic.

70

• Diagnosis
• identification of parasites by microscopy of
  discharge.
• (Examination of vaginal or uretheral discharge
  for T.vaginalis).
• N.B. No cyst stage Imp

71
(No Transcript)
72

• Cryptosporidium parvum

Cryptosporidium pravum
73

• Cryptosporidiosis zoonosis,cosmopolitan,most
  human and animals infected by Cryptosporidium .
• Life cycle
• Infective stage oocyst with4sporozoites passed
  in feces.
• Upon ingestion sporozoites are released.
• Sporozoite penetrate intestinal epithelial cells
  and undergo two cycle
• 1-schizogony 2-gametogony.
• Sporulated oocyst ,4-5M (with 4 sporozoites) are
  passed in feces.

74
(No Transcript)
75
duodenal biopsy sample from a patient with AIDS
and cryptosporidiosis
76
(No Transcript)
77

• Pathology clinical picture
• Immunocopetent persons asymptomatic or mild
  enterocolitis ,last about 2 weeks.
• Immunodeficient persons sever diarrhoea with
  malabsorption.
• Diagnosis morphology
• duodinal biopsy gametes or schizont (4-8
  merozoites) in epithelial cells.
• Stools oocyst 4-5 m with 4 sporozoites (without
  sporocyst).

78

• Treatment
• - Self limited in immunocomptant persons ,no
  effective drugs in cases of AIDS.
• - Management of fluid and electrolytes loss.
• Prevention and control
• -person-to person or animal to person
  transmission controlled by sanitation.
• -Identify common sources e.g.
• contaminated water

79
????? ???
