Photosynthesis

1
Photosynthesis

• Chapter 10

2
Photosynthesis

• Fundamentals
• Autotrophs vs Phototrophs
• Anatomy
• Development of Formula
• Nature of sunlight
• Photosystems
• Overview
• Light Reactions
• Calvin Cycle

3
IA.Autotrophs vs Phototrophs

• Autotrophs? make organic molecules from raw
  material
• Photoautotroph? use energy of sun to produce
  food, explants algae, cyanobacteria euglena
• Chemoautotrophs? reduces inorganic compounds for
  energy,ex sulfur bacteria
• Heterotrophs? live and use organic materials made
  by other organisms, ex us,fungi

4
IB. Anatomy

• Carried out by green parts of a plant
• Stomata regulates flow of CO2 H2O
• Mesophyll layer of leaf site of photosynthesis,
  contains chloroplasts(endosybiotic bacteria)

5
The Leaf Chloroplasts

• Chloroplast? 3 functional compartments
• Intermembrane space
• Thylakoid space
• stroma

• The leaf

6
Pigments and Chromatography

• Paper chromatography is a technique used to
  separate a mixture into its component molecules.
  The molecules migrate, or move up the paper, at
  different rates because of differences in
  solubility, molecular mass, and hydrogen bonding
  with the paper
• In paper chromatography the pigments are
  dissolved in a solvent that carries them up the
  paper. To separate the pigments of the
  chloroplasts, you must use an organic solvent

7
Chromatography
8
Retention Factor

• Rf distance traveled by spot/ distance
  traveled by solvent
• If the for an unknown is close to or same as that
  for a known compound, the two are most likely
  similar or identical

Solvent Front
Solute front
Sample origin
9
IC. Development of Formula

• Using glucose as our target product, the equation
  describing the net process of photosynthesis is
• 6CO2 6H2O light energy ?C6H12O6 6O2
• In reality, photosynthesis adds one CO2 at a
  time
• CO2 H2O light energy ?CH2O O2
• CH2O represents the general formula for a sugar.

10

• Clues to the mechanism of photosynthesis came
  from the discovery that the O2 given off by
  plants comes from H2O, not CO2.
• Before the 1930s, the prevailing hypothesis was
  that photosynthesis occurred in two steps
• Step 1 CO2 ? C O2
• Step 2 C H2O ? CH2O
• C.B. van Niel challenged this hypothesis.
• Studied sulfur bacteria that use H2S, not water,
  in photosynthesis.
• They produce yellow globules of sulfur as a
  waste.
• Van Niel proposed this reaction
• CO2 2H2S ?CH2O H2O 2S
• Applied this to plants proposed
• CO2 2H2O ?CH2O H2O O2

11
Tracking the atoms

• Other scientists confirmed van Niels hypothesis.
• Used 18O, a heavy isotope, as a tracer, labeled
  either CO2 or H2O.
• Found that the 18O label only appeared if water
  was the source of the tracer.
• Essentially, hydrogen extracted from water is
  incorporated into sugar and the oxygen released
  to the atmosphere (where it will be used in
  respiration).

12
ID. Nature of Sunlight

• Electromagnetic energy travels in waves but also
  behaves as discrete particles
• Visible ?spectrum of colors of diff wave lengths

13
Nature of Sunlight

• Absorption Spectrum
• Action Spectrum

14
Absorption Spectrum
15
Absorption Spectrum
16
Action Absorption Spectra? photosynthesis is
greatest in the blue and red end
17
Engelmanns Experiment
18
Pigments

• Absorb and reflect light resulting in the color
  of the leaves
• Green wave length of light is not absorbed, it is
  reflected back hence leaf appears green

19
Why leaves are green interaction of light with
chloroplasts
20
IE. Photosystems

• Light harvesting unit embedded in the thylakoid
  membrane
• Consists of several hundred chlorophyll
  molecules? energy funnel
• Array of pigment molecules that act as a light
  antenna

21
Light Harvesting Complex

• Mostly chlorophyll a, some carotenoids and other
  pigments
• Various molecules absorb at varying wavelenghts
  all direct energy to a single pigment
  molecule(P700 0r P680)
• Two photosystems PS II(P680) PS I(P700)? named
  in order of discovery, but PSII functions first
• See fig 10.12

22
IF. Overview

• Light Reaction
• Takes place in the thylakoid membrane
• Converts light energy to chemical energy
• Water is split, ATP NADPH is made, O2 evolved
• Calvin Cycle (Dark Reaction)
• Takes place in the stroma
• Carbon fixation
• Energy ? ATP NADPH of the light Rxn

23
Overview
24
II. Light Reactions

• NonCyclic Phosphorylation
• Oxygen is evolved
• Water is split
• NADPH produced
• Cyclic Phosphorylation
• No oxygen is released
• NADP not reduced

25
Non Cyclic Phosphorylation

• Light energy is used to generate ATP and NADPH
• Predominant route of electron flow

26
(No Transcript)
27
Cyclic Phosphorylation

• Takes place under certain conditions, uses PSI
• WHY??
• Calvin Cycle uses more ATP than NADPH
• Cyclic electron flow makes up the difference?
  produces ATP, no NADPH
• NADPH regulates the shift from noncyclic to cyclic

28
Cyclic Phosphorylation
29
How is ATP Sythesized
30
Chemiosmosis in Mitochondria Chloroplasts
31
III. Calvin Cycle

• Takes place in phases
• Phase 1? Carbon fixation
• Phase 2?Reduction
• Phase 3? regeneration of CO2 acceptor
• CO2 enters the cycle and leaves as sugar.
• The actual sugar product of the Calvin cycle is
  not glucose, but a three-carbon sugar,
  glyceraldehyde-3-phosphate (G3P).

32
Phase 1? Carbon Fixation

• Each CO2 molecule is attached to a five-carbon
  sugar, ribulose bisphosphate (RuBP).
• This is catalyzed by RuBP carboxylase or rubisco
  (most abundant enzyme on earth)
• The six-carbon intermediate splits in half to
  form two molecules of 3-phosphoglycerate per CO2.

33
Phase 1? Carbon Fixation
34
Phase 2?Reduction

• Each 3-phosphoglycerate receives another
  phosphate group from ATP to form 1,3
  bisphosphoglycerate.
• A pair of electrons from NADPH reduces each 1,3
  bisphosphoglycerate to G3P(6 molecules)
• One of these six G3P (3C) is a net gain of
  carbohydrate.
• One exits the cycle to be used by the plant cell
• The other five (15C) must remain in the cycle to
  regenerate three RuBP

35
Phase 2
36
Phase 3? regeneration of CO2 acceptor

• Five G3P molecules are rearranged to form 3 RuBP
  molecules
• It costs three ATP and two NADPH per CO2
• The G3P from the Calvin cycle is the starting
  material for metabolic pathways that synthesize
  other organic compounds, including glucose and
  other carbohydrates

37
(No Transcript)
38
Review of Photosynthesis
39
Alternate Mechanisms of Carbon Fixation

• Photorespiration
• C4 Plants
• CAM Plants

40
Photorespiration

• A metabolic pathway that consumes O2, releases
  CO2, generates no ATP
• Rubisco(RuBP carboxylase)? catalyzes both
  carboxylation and oxidation of RuBP
• Rubisco has alternate sites for O2 and CO2( both
  are substrates for the enzyme)
• This reverses carbon fixation undoes results of
  Calvin cycle

41
Photorespiration

• A metabolic process that is counter productive
• Under hot dry, bright condition
• An evolutionary quirk ?early atmosphere had very
  little oxygen
• Produces no ATP
• Decreases the photosynthetic output
• Certain species of plants have evolved
  alternate modes of carbon fixation to minimize
  photorespiration

42
C4 Plants

• Some plants preface the Calvin cycle with a Rxn
  that incorporate CO2 into 4C compounds
• Occurs in corn, sugar cane, crabgrass, at least
  19 plant families use this

43
C4 Leaf Anatomy

• Mesophyll cells ? light Rxns CO2 fixation
• Bundle Sheath? Calvin cycle

44
C4 Plants

• CO2 combines w/ PEP
• PEP Carboxylase has a greater affinity for CO2
  that rubisco
• Oxaloacetate (4C) or Malate(4C) ? bundle sheath
• Decarboxylate? pyruvate moves back to mesophyll
• CO2 picked up by RuBP(CO2 released w/in the
  bundle sheath, not lost)

45
CAM Plants

• Crassulaceae Acid Metabolism
• Aloe , Jade , Cacti
• Keep in as much water as possible by opening
  stomata only at night
• Store CO2 ? organic acids(in vacuoles)
• During the day these organic acids release CO2?
  Calvin cycle takes place

46
C4 and CAM Plants
47
Figure 10.20 A review of photosynthesis
