Title: Information%20Extraction:%20What%20It%20Is%20How%20to%20Do%20It%20Where%20It


1
Information ExtractionWhat It IsHow to Do
ItWhere Its Going
  • Douglas E. Appelt
  • Artificial Intelligence Center
  • SRI International

2
Some URLs to Visit
  • http//www.ai.sri.com/appelt/ie-tutorial/
  • ANLP-97 tutorial on information extraction
  • Many WWW links
  • Research sites and literature
  • Resources for building systems
  • http//www.ai.sri.com/appelt/TextPro/
  • An IE System for Power PC Macintoshes
  • Uses TIPSTER technology
  • TIPSTER architecture
  • Common Pattern Specification Language
  • Its free
  • Comes with a complete English name recognizer

3
Information ExtractionSituating IE
  • Text Manipulation grep
  • Information Retrieval
  • Information Extraction
  • Text Understanding

4
Text Understanding
  • No predetermined specification of semantic or
    communicative areas of interest
  • No clearly defined criteria of success
  • Representation of meaning must be sufficiently
    general to capture all of the meaning of the text
    and the authors intentions.

5
Information Extraction
  • Information of interest is delimited and
    pre-specified
  • Fixed, predefined representation of information
  • Clear criteria of success are at least possible
  • Corollary Features
  • Small portion of text is relevant
  • Often, only a portion of a relevant sentence is
    relevant
  • Targeted at relatively large corpora

6
Applications
  • Information Retrieval (routing queries)
  • Indexing for Information Retrieval
  • Filter for IR Output
  • Direct Presentation to the User highlighting
  • Summarization
  • Construction of data bases and knowledge bases

7
Evaluation Metrics
  • MUC Evaluations
  • Precision and Recall
  • Recall percentage possible found
  • Precision percentage provided that is correct
  • F-measure weighted, geometric mean of recall and
    precision
  • Is there a F-60 barrier?

8
A Bare BonesExtraction System
Tokenizer
Morphological and Lexical Processing
Parsing
Domain Semantics
9
Flesh for the Bones
Tokenizer
Text Sectionizing And Filtering
Morphological and Lexical Processing
Part of Speech and Word Sense Tagging
Parsing
Coreference
Domain Semantics
Merging Partial Results
10
The IE Approach - KISS
  • Keep it Simple, Stupid
  • Finite-state language models
  • Fragment processing
  • Simple semantics
  • Propositional
  • Small number of propositions
  • Often represented by templates
  • Use heuristics
  • Missing Information
  • Make favorable recall/precision tradeoffs

11
Two Approaches to Extraction Systems
  • Knowledge Engineering Approach
  • Grammars constructed by hand
  • Domain patterns discovered by introspection and
    corpus examination
  • Laborious tuning and hill-climbing
  • Learning and Statistical Approach
  • Apply statistical methods where possible
  • Learn rules from annotated corpora
  • Learn from interaction with user

12
Knowledge Engineering Approach
  • Advantages
  • Skilled computational linguists can build good
    systems quickly
  • Best performing practical systems have so far
    been handcrafted.
  • Disadvantages
  • Very laborious development process
  • Difficult to port systems to new domains
  • Requires expertise

13
Learning-Statistical Approach
  • Advantages
  • Domain portability is straightforward
  • Minimal expertise required for customization
  • Rule acquisition is data driven - complete
    coverage of examples
  • Disadvantages
  • Training data may not exist and may be difficult
    or expensive to obtain
  • Highest performing systems are still hand-crafted

14
A Combined Approach
  • Use statistical methods on modules where training
    data exists, and high accuracy can be achieved
  • Part-of-speech tagging
  • Name recognition
  • Coreference
  • Use knowledge engineering when training data is
    sparse and human ingenuity required
  • Domain Processing

15
Lexical ProcessingNamed Entity Recognition
  • Named Entities are targets of extraction in many
    domains
  • Companies
  • Other organizations
  • People
  • Locations
  • Dates, times, currency
  • Impossible or impractical to list all possible
    named entities in a lexicon

16
The List Fallacy
  • Comprehensive lexical resources do not
    necessarily result in improved extraction
    performance
  • Some entities are so new theyre not on any lists
  • Rare senses cause problems - has been as a noun
  • Names often overlap with other names and ordinary
    words
  • Dallas can be the name of a person
  • Dollar is the name of a town
  • Solutions
  • Part-of-speech tagging
  • Recognition from context

17
Knowledge Engineeringvs. Statistical Models
  • Knowledge Engineering
  • SRI, SRA, Isoquest
  • Performance
  • 1996 F 96.42
  • 1998 F 93.69
  • Statistical Models
  • BBN, NYU (1998)
  • Performance
  • 1997 F 93
  • 1998 F 90.44

Hand-coding reduces the error rate by 50.
18
Knowledge EngineeringName Recognition
  • Identify some names explicitly in lexicon
  • Identify parts of names with lexical features
  • Write rules that recognize names
  • Use capitalization in English
  • Recognize names based on internal structure
  • Mumble Mumble City Location
  • Mumble Mumble GmbH Company
  • Exceptions for common gotchas
  • Yesterday IBM announced
  • General Electric is a company, not a general
  • Many complex rules are the result

19
Statistical ModelName Recognition
Hidden Markov Models
Name
End
Start
Not-a-name
20
Statistical ModelName Recognition
  • Transitions are probabilistic
  • Training
  • Annotate a corpus
  • Estimate transition probabilities given words
    (and/or their features)
  • P(si si-1, wi)
  • Application
  • Compute the maximum-likelihood path through the
    network for the input text.
  • The Viterbi algorithm

21
Training Data
  • The amount of data needed is not onerous
    (diminishing returns at 100,000 words)
  • Annotation can be done by non-linguist native
    speakers
  • Training also works (with some degradation) for
    upper-case-only and punctuation-free texts.

22
Interesting Aside
  • NYU trained a statistical model using as word
    features whether various other name recognition
    systems tagged that word as part of a name.
  • Result Better than human performance!
  • System achieved F 97.12
  • Experienced humans F 96.95 97.60

23
Parsing in IE Systems
  • Some IE Systems have attempted full parsing
  • NYU Pre-1996 Proteus System
  • SRI Tacitus System
  • Attempts to adapt to the IE task
  • Fragment interpretation
  • Limitation of search
  • Statistical Parsing?
  • No real systems exist yet

24
Problems with Full Parsing
  • The search space becomes prohibitively large for
    long sentences.
  • The system is slow. Rapid development and testing
    of rules becomes impossible.
  • Full Parse heuristic
  • It is often possible with a comprehensive grammar
    to span the sentence with a highly improbable
    parse when the actual analysis is outside of the
    grammar, or lost in the search space.

25
The IE Approach to Parsing
  • Analyze sentences as simple constituents that can
    be described with a finite-state grammar
  • Noun Groups, Verb Groups, Particles
  • Ignore prepositional attachment
  • Ignore clause boundaries
  • Parser consists of one or more finite-state
    transducers mapping words into simple constituents

26
A Finite-State Fragment Parse
A. C. Nielson Co.NG saidVG George Garrick,NG
40 years old, presidentNG of Information
Resources, Inc.NG 's London-based European
Information Services operationNG will becomeVG
presidentNG and chief operating officerNG of
Nielson Marketing Research USANG a unitNG of Dun
Bradstreet.NG
27
Handling Difficult Cases
  • Relative Clauses
  • Use nondeterminism to connect single subject to
    multiple clauses
  • VP Conjunction
  • Use nondeterminism to connect single subject to
    multiple verb phrases
  • Appositives
  • Handle only domain-relevant cases
  • Prepositional Attachment
  • Handle only domain-relevant cases

28
An Application Domain
  • Identify domain-relevant objects
  • Identify properties of those objects
  • Identify relationships among domain-relevant
    objects
  • Identify relevant events involving domain objects

29
The Molecular Approach
  • Standard approach
  • High precision, low recall approach
  • Read texts
  • Identify common, domain relevant patterns
    signaling properties, events, and relationships
  • Build rules to cover those
  • Move to less frequent, less reliable patterns

30
The Atomic Approach
  • Aims for high recall, low precision
  • Determine features of application-relevant entity
    types
  • Determine features of application-relevant event
    and relation types
  • Every occurrence of a phrase with the relevant
    feature triggers a candidate event/relation
  • Merge candidate relations to obtain more fully
    instantiated event/relation descriptions
  • Filter using application-specific criteria

31
Appropriateness
  • Appropriate when
  • Relevant entities have easily determined types
  • Only one or a small number of relations can hold
    of an entity with a given type
  • Relevant events and relations are symmetrical.
  • Examples
  • Labor negotiations
  • MUC-5 Microelectronics
  • Heavy reliance on merging of partial information
    (even within sentence)

32
Is There a Barrier?
33
Where is the Upper Bound?
  • Experience suggests that, for a MUC-like task
    with MUC scoring, it is unrealistic to expect to
    achieve more than about F 65 on a blind test. (F
    70 on training data)
  • About 75 of human performance.

34
Reasons for the Limits
  • There is a long tail of increasingly rare
    domain-relevant expressions
  • A barrier of inherently hard linguistic phenomena
  • Complex coordination
  • Collective-distributive reference
  • Multiple interacting phenomena in the same
    sentence
  • Hard inferences required
  • Limits of heuristic tradeoffs are reached

35
Improve Information Retrieval
  • Routing task
  • Build a quick extraction system for a topic.
  • IR system picks 2000 texts
  • Rescore by using extraction system to evaluate
    the text for relevance
  • Return the 1000 top texts
  • Results 12 improve, 4 same, 5 worse
  • Best results when training data is sparse
  • More testing and evaluation needed.

36
Topic Oriented Summarization
  • Extract information of interest
  • Generate NL summary of extracted data
  • Generation can be in a different language,
    enabling cross-language access to key information.

37
Process Many Documents Quickly
  • Exploit redundancy in corpora to get higher
    recall from merging of multiple descriptions of
    the same event.
  • Analyze data from multiple news feeds
  • Annotating text for training language models
  • Need to identify names in speech (broadcast news)
  • Train class bigram on 100 million words of
    training data.
  • Because automatic name annotation is almost as
    good as human annotation, automatic annotation of
    training data is feasible.

38
Make Limits More Quickly Attainable
  • Automatic learning of rules from examples
  • Application of "open domain" extraction systems
  • Build general rules for a very broad domain, like
    "business and economic news"
  • Quickly customize rules from library for a
    specific application
  • Used a prototype to generate extraction systems
    for routing queries in a half-day.
Write a Comment
User Comments (0)
About PowerShow.com
