Brief History of Atomic Theory

1
Brief History of Atomic Theory
2
1st atomic models

• In 400 BC, the model looked like a solid
  indivisible ball

3
Atomos

• Democritus theory Matter could not be divided
  into smaller and smaller pieces forever
• He named the smallest piece of matter atomos,
  an indivisible particle

4

• This theory was ignored and forgotten for
  more than 2000 years!

5
Why?
Aristotle Plato thought earth, fire, air and
water were the elements. Alchemy used this model
for about 2000 years.
6
Daltons Model

• In the early 1800s, the English chemist
• John Dalton performed experiments that
  confirmed the idea of atoms.

7
Daltons Atomic Theory

• All elements are made of indivisible atoms
• Atoms of the same element are identical, but
  differ from atoms of other elements
• Different elements atoms can combine to form
  compounds.
• Reactions occur when atoms are separated, joined,
  or rearranged.
• WHICH OF THESE ARE NO LONGER CONSIDERED TO BE
  TRUE ?

8
Thomsons Plum Pudding Model

• In 1897, J.J. Thomson discovered that atoms
  are made of even smaller particles.

9
Thomson Model

• Thomson used cathode ray tube
• The ray consisted of negatively charged
  electrons.

10
Thomson Model

• He proposed a model of the atom called the Plum
  Pudding model.
• Atoms were made from a positively charged
  substance with negatively charged electrons
  scattered about, like raisins in a pudding.
• Aka raisin pudding model

11
Millikan (1909)

• OIL DROP experiment
• Measures charge on electron

-
12

• Rutherfords gold foil experiment (1911) Involved
  firing a stream of tiny positively charged
  particles at a thin sheet of gold foil (2000
  atoms thick)
• Result most of space occupied by atom is empty
  space! Except for small, dense, positively
  charged NUCLEUS.
• Positive particles named PROTONS
• all protons are in the nucleus.

13
(No Transcript)
14
Rutherford Nuclear Model

• all of an atoms positively charged particles are
  contained in the nucleus. The negatively charged
  particles were scattered outside the nucleus.

15
Bohr Model

• In 1913, the Danish scientist Niels Bohr proposed
  that each electron is in a specific energy level.

16
Bohr Model

• According to Bohrs atomic model, electrons move
  in definite orbits around the nucleus, much like
  planets circle the sun.

17
Wave Model Louis DeBroglie (1924) es have
wavelike properties
18
Wave Model Erwin Schrodinger (1927) Quantum
mechanics model es location probability
19
Chadwick (1932)

• Discovers particle with same mass as proton but
  no charge the
• NEUTRON

20
(No Transcript)
21
Indivisible Electron Nucleus Orbit Electron Cloud
Greek X
Dalton X
Thomson X
Rutherford X X
Bohr X X X
Wave X X X
