Title: Workbook 10 Network Applications


1
Workbook 10Network Applications
Pace Center for Business and Technology
2
Chapter 1.  An Introduction to TCP/IP Networking
  • Key Concepts
  • Most Linux networking services are designed
    around a client-server relationship.
  • Network server applications are generally
    designed to be "always running", starting
    automatically as a system boots, and only
    shutting down when the system does. Generally,
    only the root user may manage server processes.
  • Network client applications are generally running
    only when in use, and may be started by any user.
  • Most Linux network servers and clients
    communicate using the TCP/IP protocol.
  • The TCP/IP address of both the client process and
    the server process consists of an IP address and
    a port.
  • Network servers usually use assigned, "well
    known" ports, as cataloged in the /etc/services
    file. Network clients generally use randomly
    assigned ports. Often, well know ports reside in
    the range of privileged ports, below port number
    1024.
  • The hostname command can be to examine a
    machine's current IP address, while the netstat
    -tuna command can be used to examine all open
    ports.

3
Clients, Servers, and the TCP/IP Protocol
  • Most networking applications today are designed
    around a client-server relationship. The
    networking client is usually an application
    acting on behalf of a person trying to accomplish
    a particular task, such as a web browser
    accessing a URL, or the rdate command asking a
    time server for the current time. The networking
    server is generally an application that is
    providing some service, such as supplying the
    content of web pages, or supplying the current
    time.
  • The design of (applications acting as) network
    clients and (applications acting as) network
    servers differs dramatically. In order to
    appreciate the differences, we will compare them
    to the agents in a more familiar client-server
    relationship, a customer buying a candybar from a
    salesperson.

4
The Server
  • Servers are Highly Available
  • Just as a salesperson must always be running the
    register, even when customers are not around,
    processes implementing networking services need
    to be running, ready to supply services upon
    request. Usually, processes implementing network
    services are started at boottime, and continue to
    run until the machine is shutdown. In Linux (and
    Unix), such processes are often referred to as
    daemons. Generally, only the root user may start
    or shutdown processes acting as network servers.
  • Servers have Well Known Locations
  • In addition to being available when a customer
    wants service, salespeople stay where they know
    customers can find them. Just as customers can
    look up the locations of unfamiliar candybar
    salesmen in telephone books and find them by
    street address, networking clients can look up
    the locations of unfamiliar network servers using
    a hostname, which is converted into the IP
    Address used to access the service.

5
The Server
  • The Client
  • In contrast, the candybar customer needs to be
    neither highly available nor well known. A
    customer doesn't hang around a store from dawn
    until dusk just in case he decides he wants a
    candybar. Likewise, clients generally do not need
    to to stay at well known locations. Our customer
    doesn't stay at home all day, just in case
    somebody wants to come by to sell him a candybar.
  • Processes that implement network clients are
    started by normal users, and generally are only
    running as long a necessary to complete a task.
    When someone breaks for lunch, he closes his web
    browser. Also, client applications do not need to
    have fixed addresses, but can move from place to
    place. More on this next.

6
The Server
  • TCP/IP Addresses
  • Every process which is participating in a TCP/IP
    conversation must have an IP Address, just as
    every participant in a phone conversation must
    have a phone number. Additionally, every process
    in a TCP/IP conversation must have port number,
    whose closest analogy might be a telephone
    extension associated with a phone number.
  • Computers on a network are identified by IP
    address. The IP address comes in the form of four
    integers, each ranging from 0 to 255 (not
    coincidentally, the amount of information that
    can be encoded in one byte of memory), and
    traditionally written separated by periods, such
    as 192.168.0.3. This representation is often
    informally referred to as a dotted quad.
  • Processes on computers are identified by a port
    number, which is an integer ranging from 1 to
    65535 (not coincidentally, the amount of
    information that can be encoded in two bytes of
    memory). Whenever a process wants to participate
    in a TCP/IP conversation with another process, it
    must first be assigned a port number by the
    kernel.
  • The TCP/IP protocol allows two processes, each
    identified by a combination of an IP address and
    port number, to locate one another. The IP
    address is used to locate the machine that the
    process is running on (this is the "IP" part of
    the protocol), and the port number is used to
    locate the correct process on the machine (this
    is the "TCP" part).

7
Sockets
  • In order to illustrate a typical TCP/IP
    transaction, we will examine the conversation
    between a fictitious student's mozilla web
    browser, running on the machine
    station3.example.com, which translates into an IP
    address of 123.45.67.89, and the httpd web server
    running at academy.redhat.com, which translates
    into an IP address of 66.187.232.51. The process
    usually resembles the following.
  • As the machine academy.redhat.com is booted, the
    httpd process is started. It first allocates a
    socket, binds it to the port 80, and begins
    listening for connections.
  • At some point later, perhaps measured in minutes,
    perhaps days, the mozilla process is started on
    the machine station3.example.com. It also
    allocates a socket, and requests to connect to
    port 80 of the machine 66.187.232.51. Because it
    did not request a particular port number, the
    kernel provides a random one, say 12345. As it
    requests the connection, it provides its own IP
    address and (randomly assigned) port number to
    the server.
  • The server chooses to accept the connection. The
    established socket is now identified by the
    combined IP address and port number of both the
    client and server.

8
Sockets
  • Once the socket is established, the mozilla
    process and the httpd process can read
    information from and write information to one
    another as easily as reading and writing from a
    file. (Remember... "everything is a file", even
    network connections! For most practical purposes,
    a socket is just another file descriptor.) The
    highlighted verbs in this section, bind, listen,
    connect, accept, and even read and write, are
    well defined terms in Linux (and Unix). They also
    are the names of the programming system calls
    that implement each step.

9
Sockets
  • In the TCP/IP protocol, a socket is defined by
    the combined IP address and port number of both
    the server and the client. For example, what if
    our student was running multiple versions of
    Mozilla, each making requests of
    academy.redhat.com, or what if multiple users
    were using the machine station3.example.com
    simultaneously, all accessing academy.redhat.com?
    How would the web server keep straight which
    conversation it was having with which client?
    Each client process would be assigned a distinct
    port number, and therefore converse with the
    httpd daemon using a distinct socket.

10
More about Ports
  • Well Known Services and the /etc/services File
  • In our example, we mentioned that the httpd
    process requested to bind to port 80, and in turn
    the mozilla process requested to connect to port
    80 of the server. How did each agree that port 80
    was the appropriate port for the web server?
    Traditional Internet services, such as a web
    server, or ftp server, or SMTP (email) server,
    are referred to as well known services. On Linux
    (and Unix) machines, a catalog of well known
    services, and the ports assigned to them, is
    maintained in the file /etc/services.
  • Notice that both the client and server need to
    agree on the appropriate port number, so the
    /etc/services file is just as important on the
    client's machine as on the server's. Just because
    a service is listed in the /etc/services file
    does not mean that you are implementing (or even
    capable of implementing) that well known service.

11
Privileged Ports
  • Unlike clients, processes implementing network
    servers generally request which port they would
    like to bind to. Only one process may bind to a
    port at any given time (Why must this be?).
    Otherwise, how would a client distinguish which
    process it would like to connect to? Ports less
    than 1024 are referred to as privileged ports,
    and treated specially by the kernel. Only
    processes running as the root user may bind to
    privileged ports. (This helps ensure that, if
    elvis had an account on the machine
    academy.redhat.com, he couldn't start up a rogue
    version of a web server which might hand out
    false information.) Originally, the well known
    ports and the privileged ports were meant to
    coincide, but in practice there are more well
    known ports than privileged ones.

12
Determining Current TCP/IP Networking Services
  • Using hostname to Display the Current IP Address
  • The hostname command, without arguments, displays
    a machine's current hostname. With the -i command
    line switch, machine's IP address is displayed
    instead.
  • What if there are multiple IP addresses?
  • The design of the hostname command is a little
    misguided, because machines can easily have more
    than one IP address (one for each of multiple
    network interface cards, for instance.) In such
    situations, there is no reason why any one IP
    address should be privileged over the others. For
    historical reasons, however, the kernel keeps
    track of a parameter it refers to as its
    hostname, and the hostname -i command displays
    the IP address associated with it.

13
Using the netstat Command to Display Open Ports
  • When a port is used by a socket, it is referred
    to as an open port. The netstat command can be
    used to display a variety of networking
    information, including open ports.
  • Unfortunately, when called with no command line
    switches, the netstat command's output is
    overwhelmed by the least interesting information,
    local "Unix" sockets that are used to communicate
    between processes on the same machine. When
    called with the following command line switches,
    however, more interesting information is
    displayed.

14
Using the netstat Command to Display Open Ports
  • Many more switches are available, as a quick look
    at the netstat(8) man page will reveal. The above
    switches were chosen from the many, not only
    because when combined, they produce interesting
    output, but also because they are easy to
    remember just think "tuna".
  • When invoked with the above switches, netstat's
    output is akin to the following.

15
Using the netstat Command to Display Open Ports
  • Of the many lines, we may weed away those
    associated with the udp protocol, and focus
    instead on columns 4, 5, and 6 of the rows
    associated with tcp.

16
Special IP Addresses
17
Understanding IPv6 Addresses
  • The IP protocol which we discussed above, with
    friendly IP addresses such as "66.187.232.51", is
    known as Internet Protocol version 4, or "IPv4",
    and is by far the dominant IP protocol in use
    today. With the IPv4 protocol, you can have
    around 4 billion distinct IP addresses. When the
    IPv4 protocol was developed in the early 1970's,
    this was plenty of addresses, and the IPv4
    protocol has served us well. By learning a few
    tricks such as masquerading, where many machines
    can "hide behind" a single public IP address, we
    still manage to live with it well. As appliances
    become more intelligent, however, and networking
    (particularly wireless networking) becomes
    cheaper, we are approaching a day where every
    toaster is going to want its own IP address, and
    4 billion address wont' be enough. Changes are on
    the horizon.
  • These changes are coming in the form of Internet
    Protocol Version 6, or "IPv6". Among many other
    changes, the IPv6 protocol takes the obvious
    step, and makes IP addresses bigger. Four times
    bigger. An IPv6 address, in full form, looks like
    fe80000000000000021122fffe334411. Instead
    of writing addresses as familiar decimal numbers
    (like "127"), they are written in hexadecimal
    numbers (like "fe33").

18
Understanding IPv6 Addresses
  • Some merciful conventions in representing IPv6
    addresses help.
  • Once within an address, a series of zero
    segments, such as 000000000000, can be replaced
    with a double colon ().
  • For any segment which begins with leading zeros,
    such as 0211, the leading zeros can be dropped.
  • With these two shortcuts in mind, the above
    address could be written a little more friendly
    as fe8021122fffe334411.

19
Understanding IPv6 Addresses
  • Red Hat Enterprise Linux is getting ready for a
    future transition to IPv6, and many applications
    can already handle either IPv4 or IPv6
    connections. For our purposes, because it is not
    yet widely adopted, we're going to ignore IPv6 as
    much as possible. Fortunately, there's just a few
    forms of IPv6 addresses we need to be able to
    recognize, summarized in the table below.
  • Whenever these forms of IPv6 address are
    encountered ( ffff192.168.0.1, 1, and ),
    you can simply think of them as their IPv4
    equivalents ( 192.168.0.1, 127.0.0.1, and
    0.0.0.0, respectively).

20
Understanding IPv6 Addresses
  • Listening Sockets
  • Listening are sockets are sockets owned by a
    server, before any clients have come along. For
    example, at the end of step one of our sample
    TCP/IP connection above, the httpd process would
    have a socket open in the listening state. Notice
    in the above output that for listening sockets,
    only the local half of the address is defined.
  • Established Sockets
  • As the name implies, established sockets have
    both a client process and a server process with
    established communication.
  • Pulling it All Together

21
Understanding IPv6 Addresses
  • These two sockets are listening for connections,
    but only on the loopback address. They must
    belong to services expecting to receive
    connections from other processes on the local
    machine, but not from other machines. To
    determine what services these ports belong to, we
    do some greping from the /etc/services file.
  • Apparently, whatever process has claimed port 25
    is listening for email clients. This is probably
    the sendmail daemon. The process listening on
    port 631 is listening for print clients. This is
    probably the cupsd printing daemon. Both of these
    services are discussed in more detail in this
    Workbook.

22
Understanding IPv6 Addresses
  • These lines reflect both halves of an established
    connection between two processes, both on the
    local machine (notice the loopback IP address for
    both of them). The first is bound to port 59330
    (probably a randomly assigned client port), and
    the second to the port 631. Some process on the
    local machine must be communicating with the
    cupsd daemon.
  • Our final extracted lines represent established
    connections between clients on remote machines,
    and services on our local machine's external
    interface (192.168.122.156). The first is a
    connection to an IPv6 aware service on port 22.
    Again, we try a little grepping to look up the
    well known service associated with port 22.
  • Apparently, this line represents an active
    connection between a ssh client on a remote
    machine with IP address 192.168.122.1, and a sshd
    daemon on our local machine.
  • The latter is a connection to an IPv4 only
    service bound to port 653, probably an NFS
    related service.

23
Online Exercises Chapter 1.  An Introduction to
TCP/IP Networking
  • Online Exercises
  • Lab Exercise
  • Objective Gain familiarity with TCP/IP
    configuration and activity.
  • Estimated Time 10 mins.
  • Specification
  • Create the file /lab11.1/ipaddr, which contains
    your machine's IP address, as reported by the
    hostname command, as its single word.
  • Create the file /lab11.1/listening_ports, which
    contains a list of all ports less then 1024 on
    your current machine which are open in the
    listening state, one port per line.
  • Deliverables
  • The file /lab11.1/ipaddr, which contains your
    machine's current IP address (as reported by the
    hostname command) as its single word.
  • The file /lab11.1/listening_ports, which
    contains a list of all ports less then 1024 on
    your current machine which are open in the
    listening state, one port per line.

24
Using Email
  • The Simple Solution
  • The simplest solution is appropriate for people
    using computers which have permanent, well known
    Internet connections. At the time that many of
    the protocols defining how email delivery should
    be handled were developed, this was more of the
    standard instead of the exception. The solution
    involves two separate applications whose roles
    are identified by TLA's (Three Letter Acronyms).
    The first application is referred to as the MTA,
    or Mail Transport Agent the second is known as
    the MUA, or Mail User Agent.

25
The MTA (Mail Transport Agent)
  • The MTA generally operates in the background,
    performing the work of the local post office. The
    MTA receives email to be delivered from programs
    on the local machine, determines from the
    recipient's address the appropriate machine to
    contact, and attempts to connect to a
    complementary MTA running on the recipients
    machine, who should be listening to port 25. If
    the sender's MTA cannot contact the receiver's
    MTA, the mail is spooled on the sender's machine,
    and the sender's MTA tries again at a later time.
  • The MTA also binds to the local port 25, where it
    receives connections from other MTA's. When it
    receives mail from a remote MTA which is destined
    for a user on the local machine, it receives the
    mail, and stores it in a mail spool which is
    referred to the user's inbox. In Linux (and
    Unix), the default inbox for a user is
    /var/spool/mail/username, so that mail awaiting
    the user elvis would be stored in the file
    /var/spool/mail/elvis.
  • The default MTA in Red Hat Enterprise Linux is a
    daemon called sendmail.

26
The MUA (Mail User Agent)
  • The MUA is the application most user's think
    about when they think about email. The MUA
    retrieves delivered mail from a user's mail spool
    (inbox), and presents it to the user as "New
    Mail". The MUA allows users to compose responses
    or new mail messages, and passes these messages
    to the local MTA for delivery.
  • Red Hat Enterprise Linux ships with a wide
    selection of MUAs, several of which will be
    introduced in this and the next lesson.

27
Mailbox Servers
  • While simple, the previous solution requires
    that, first of all, users are receiving email on
    a machine that maintains a persistent Internet
    connection, and secondly, the machine has a well
    known host name and is accessible to others. Many
    users, such as people using a "dial up" or "High
    Speed" connection from an ISP (Internet Service
    Provider), or people using machines behind an
    institution's firewall, are not in this
    situation. Another solution has evolved to serve
    people in these situations Mailbox servers.

28
Mailbox Servers
  • In the diagram above, we assume that elvis is
    using a "high speed" Internet connection which he
    has subscribed to from the company "ISP.Net".
    When he connects to the Internet, his ISP issues
    his machine an IP address, but elvis cannot
    predict ahead of time which IP address he will
    receive. The hostname which the ISP has assigned
    to the IP address is probably unattractive, such
    as dhcp-191-93.isx.isp.net, so even if elvis were
    guaranteed to receive the same IP address each
    time, he would not want to advertise his
    machine's hostname as his email address.
  • Instead, elvis takes advantage of an "email
    account" which his ISP offers him. Very likely,
    this account exists on a Linux or Unix machine
    owned by the ISP, which has a permanent
    connection to the Internet, and is assigned a
    hostname such as pop.isp.net. The ISP has
    arranged all mail destined to addresses of the
    form user_at_isp.net to be delivered to the MTA
    running on this machine. When the MTA running on
    pop.isp.net receives mail for elvis, it stores
    the delivered mail into a mail spool dedicated to
    elvis (very likely in the file /var/spool/mail/elv
    is), and the email is considered delivered.
  • Because the ISP's machine pop.isp.net has a
    permanent, well known connection to the Internet,
    it is a much better candidate for receiving email
    than elvis's machine at home. Sitting at home,
    however, elvis still needs access to the email
    sitting in his "inbox" on pop.isp.net. Usually,
    this access is provided in the from of a POP
    (Post Office Protocol) or IMAP (Internet Mail
    Access Protocol) server.

29
Mail Servers
  • POP servers
  • POP servers perform a very simple service. They
    allow users to access the user's single mail
    spool, and transfer its contents to their local
    MUA. POP servers generally bind to port 110, and
    require that any POP client authenticate itself
    using a username/password pair. Most modern MUA's
    act as POP clients, and can be configured to
    retrieve mail from a specified POP server.
  • If a mailbox server is implementing the POP
    service, it usually implies that the mailbox
    server is not intending to provide permanent
    storage for a user's email, but instead just
    cache it temporarily until the user can "pop" it
    down to a local machine.
  • IMAP servers
  • IMAP servers generally provide clients with more
    sophisticated mailbox management. IMAP users may
    maintain several folders on the mailbox server,
    not just their individual inbox. In general, an
    IMAP server implies that a user's email is
    intended to be permanently stored on the mailbox
    server, and users will occasionally connect with
    a MUA from a remote machine to "browse" their
    mail. Generally, IMAP servers are found in
    institutional and corporate environments. IMAP
    daemons bind to port 143.

30
Mail Servers
  • Sending Mail
  • Because elvis's machine maintains an almost
    continuous connection to the Internet, he is
    willing to still use his local MUA to deliver
    mail. If his local MUA is temporarily unable to
    connect to the recipient's machine, the MUA will
    spool the mail locally and try again later.
  • Red Hat Enterprise Linux Default Configuration
  • By default, Red Hat Enterprise Linux is
    configured appropriately for this scenario. The
    local MTA is started, but it will not accept
    connections over port 25 (except for from the
    loopback address, 127.0.0.1). It serves merely to
    deliver outgoing email. Users are assumed to be
    accessing their email from a POP or IMAP server.
  • The default configuration can be changed, but the
    necessary configuration is beyond the scope of
    this course.

31
Outgoing Mail Servers
  • For machines that have only transient connections
    to the Internet, attempting to deliver email
    using the local MTA may not be appropriate.
    Instead, users of "dial up" connections and the
    like often use what is referred to as an SMTP
    (Simple Mail Transfer Protocol) Server, or
    outgoing mail server. Many ISPs and institutions
    provide outgoing SMTP servers, often with names
    like smtp.isp.net.
  • The MTA on the SMTP server is willing to accept
    mail from "local" machines, even though it is not
    the final recipient for the email. Instead, the
    SMTP server relays the mail, forwarding it on to
    its destination. If any temporary problems occur,
    the spooling and redelivery attempts of the
    pending mail is now the responsibility of the
    SMTP server.
  • Many MUA's allow users the option of specifying a
    remote host to act as the user's SMTP server (as
    opposed to forwarding mail to the local MTA for
    delivery). 1

32
Local Delivery
  • All of the above scenarios assume that a user is
    sending email from his machine to a recipient on
    a remote machine. Linux (and Unix) also allows
    users on a local machine to deliver email to one
    another, where email is addressed simply to a
    username, such as blondie.
  • For local delivery, no POP servers or SMTP
    servers are required, as the email is instantly
    delivered by the local MTA.

33
Local Delivery
  • Sending Email with mail
  • The mail command can be used to deliver mail to
    recipients who are specified as arguments on the
    command line. The body of the message is read
    from standard in (which may be read from a pipe,
    a redirected file, or from the keyboard directly,
    where CTRLD ("EOF") is used to indicate the end
    of the message).
  • The command line switches in the following table
    can be used to specify a subject line, recipients
    to "Cc", etc.
  • As an example, in the following, elvis mails to
    blondie the contents of the file lyrics.txt.

34
Using mail to Read Mail
  • The mail command can also be used to read mail
    from a user's local mail spool. The interface is
    primitive, however, and usually other MUA's are
    used instead. Details can be found in the mail
    man page. These days, the most common use of the
    mail command is as a quick and easy way to send
    mail.
  • In the following example, blondie is using the
    mail command, without arguments, to view the mail
    in her inbox, and then delete the message and
    quit.

35
Chapter 6.  Network Diagnostic Applications
  • Key Concepts
  • /sbin/ifconfig displays local IP configuration.
  • ping confirms low level network connectivity
    between hosts.
  • host makes direct DNS queries.
  • The netstat -tuna command lists currently active
    network services and connections.
  • /sbin/traceroute can diagnose routing problems.

36
Required Configuration for the Internet Protocol
  • IP Address
  • Linux (and Unix) represents every networking
    device attached to a machine (such as an Ethernet
    card, a Token Ring card, a modem used for dialup
    connections, etc...) as a network interface.
    Before an interface can be used to send or
    receive traffic, it must be configured with an IP
    address which serves as the interface's identity.
  • Default Gateway
  • The mechanics of the IP protocol organizes
    machines into sub networks, or subnets. All
    machines on a given subnet may exchange
    information directly. IP subnets are in turn
    linked to other subnets by machines acting as
    routers. A router has multiple network
    interfaces, usually each participating in a
    distinct subnet. In order to communicate with a
    host on another subnet, the data must be passed
    to a router, which (with the help of other
    routers) routes the information to the
    appropriate subnet, and from there to the
    appropriate host.
  • In order to communicate with machines outside of
    your local subnet, your machine must know the
    identity of a nearby router. The router used to
    route packets outside of your local subnet is
    commonly referred to as a default gateway.

37
Required Configuration for the Internet Protocol
  • Nameserver
  • Other machines on the Internet are in turn
    identified by their IP address. People tend to
    prefer to think in terms of names instead of
    numbers, however, so a protocol has been
    developed to assign names to IP addresses. The
    protocol is called Domain Name Service, or more
    commonly DNS.
  • The DNS protocol requires that every machine have
    available one or more DNS servers (commonly
    called nameservers), which can serve as both a
    database for assigning name to local IP
    addresses, and also a starting point for
    determining IP addresses for domain names for
    which the server does not have direct knowledge.

38
Determining Your IP Address(es) /sbin/ifconfig
  • A previous Lesson introduced the hostname -i
    command, which displays the IP address of your
    local machine. In reality, a "machine" does not
    have an IP address, a machine's network
    interfaces do. This Lesson discusses the topic of
    IP addresses and network interfaces in more
    detail.
  • In Linux (and Unix), every network device is
    represented as a network interface. (For once, we
    encounter something that is not a file!) Linux
    names interfaces according to the type of device
    it represents. The following table lists some of
    the more commonly encountered interface names
    used in Linux.
  • In each case, n is replaced with a distinct
    integer for each instance of a given device
    attached to a machine.

39
Confirming Network Interface Configuration
  • The ifconfig command displays the configuration
    of all active network interfaces. Because the
    command is generally used by root to configure
    interfaces, it lives within the /sbin directory,
    which is outside of the default PATH for standard
    users. Standard users can use the command to view
    interface configuration information, however, by
    using an absolute reference, as in the following
    example.

40
Confirming Network Interface Configuration
  • The ifconfig command displays a stanza of IP
    configuration information and usage statistics
    for each active network interface. In most
    situations, users should expect to see two
    stanzas reported. One stanza contains the
    configuration for an attached Ethernet card,
    while the other shows the configuration for the
    virtual loopback device. The important line is
    the second line, which displays the IP address
    assigned to the interface. If the line containing
    the IP address is missing, or if the IP address
    does not look reasonable for your local network
    configuration, you can expect to have trouble
    accessing the network.

41
Determining Your Default Gateway /sbin/route
  • As mentioned in this Lesson's introduction,
    communicating with hosts on your local subnet
    uses different procedures than communicating with
    hosts on a separate subnet. The Linux kernel,
    like all Unix kernels, maintains an internal
    table which defines which machines should be
    considered local, and what gateway should be used
    to help communicate with those machines which are
    not. This table is called the routing table.
  • If you are a standard user, the route command can
    be used to display the system's routing table. If
    you are the root user, the command can be used to
    manipulate the table as well. Like the ifconfig
    command, the route command lives in the /sbin
    directory, so standard users should invoke it
    using an absolute reference.

42
Determining Your Default Gateway /sbin/route
  • A standard routing table displays two types
    entries. The first type defines which subnets
    should be considered local subnets. In general,
    there should be one line specifying a subnet for
    each active interface. In the output above, the
    first line defines the subnet associated with the
    Ethernet interface (with an IP address of
    192.168.0.51), and the second line defines the
    subnet associated with the loopback interface
    (with an IP address of 127.0.0.1).
  • The second type of entry, which is used to define
    gateways, is more relevant to our discussion.
    Gateway entries can be distinguished because a
    host is defined in the second column ("Gateway"),
    and the fourth column ("Flags") contains a "G".
    Every routing table should contain an entry for a
    "default" gateway, an the second column should
    contain the gateway's hostname.

43
Determining Your Default Gateway /sbin/route
  • The same information can be displayed using IP
    addresses instead of hostnames using /sbin/route
    -n.

44
Determining Your Nameserver(s)
  • Domain Name Service allows users to refer to
    networked computers using hostnames instead of IP
    addresses. Unlike the other two aspects of
    network configuration, a nameserver is to some
    extent optional. In order to communicate with
    other machines at all, your host must have an IP
    address. In order to communicate with machines
    outside of your subnet, you must have a default
    gateway. If users are willing to refer to every
    machine by IP address instead of hostname,
    however, your machine can communicate using the
    IP protocol without ever consulting a nameserver.
  • In practice, however, nameservers seem more of a
    necessity. (Do you have an easier time
    remembering academy.redhat.com, or
    66.187.232.51?) Converting a hostname into an IP
    address is often referred to as resolving an
    address, and the library which implements
    nameservice is called the resolv library. When
    the library attempts to resolves an address,
    there are generally two resources available.

45
Static DNS Configuration /etc/hosts
  • The first resource is a simple text file called
    the /etc/hosts file. While only root can edit the
    file, any user can observe it.
  • The format of the file is as simple as it looks.
    The first token on a line should be an IP
    address, and subsequent tokens are hostnames
    which should resolve to the IP address. The
    standard Unix comment character () is also
    supported.
  • If a machine is only communicating with a few
    machines, or if an administrator wants to create
    shortcut hostnames (such as s), or if she would
    like to override the local nameserver, entries
    can be added to the /etc/hosts file using a
    simple text editor.
  • Obviously, this technique does not scale well.
    You cannot expect the local /etc/hosts file to
    provide every answer.

46
Dynamic DNS Configuration /etc/resolv.conf
  • When the local /etc/hosts cannot provide the
    answer, the resolv library consults a nameserver.
    In order to determine which machine running a
    nameserver to consult, it examines the resolv
    library's configuration file, /etc/resolv.conf.
  • The /etc/resolv.conf configuration file uses
    lines which begin with the keyword nameserver to
    specify the IP addresses of machines that are
    running nameservers. If multiple nameservers are
    specified, the first one will be used by default.
    If it is unavailable, the second will be used,
    and so on. Accordingly, the first listed
    nameserver is sometimes called the primary
    nameserver, the second listed server the
    secondary nameserver, and so on.
  • Notice that a nameserver does not need to be a
    nearby machine. Any machine which is implementing
    nameservice and allows you to query it can be
    used as a nameserver. In practice, using a local
    nameserver leads to better performance.

47
Network Diagnostic Utilities
  • Diagnostic utilities that can be used to ensure
    that the configurations are working appropriately
    with your local network environment.
  • Confirming IP Connectivity ping
  • The ping command can be used to confirm IP
    connectivity between two hosts. The first
    argument to ping can be either the hostname or
    the IP address of the machine you would like to
    contact.
  • The ping command will continue to run until
    canceled with the CTRLC control sequence.
  • If no response is returned from the ping command,
    you cannot expect any higher level networking
    communication to occur. One common culprit is an
    Ethernet cable which has become physically
    disconnected from the machine or from the wall.
  • Inconsistencies in the rate at which lines are
    displayed or discontinuities in the sequence
    numbers are generally indicative of a congested
    network, or a noisy connection, and you can
    generally expect poor network performance of
    higher level protocols.

48
Examining Routing /usr/sbin/traceroute
  • When connecting to a machine outside of your
    subnet, your packet is passed from router to
    router as it traverses various subnets, until
    finally the packet is delivered to the subnet
    which contains the destination machine. The path
    of the packet, as it is passed from router to
    router, can be traced with the /usr/sbin/tracerout
    e command.
  • The traceroute command is generally called with a
    single argument, the hostname or IP address of
    the destination machine.

49
Examining Routing /usr/sbin/traceroute
  • Often, you will find that packets take surprising
    paths to get from one place to another. The
    number of routers that your packet passes through
    is generally referred to as the number of hops
    the packet has made. The packet above took 17
    hops to reach its destination.
  • If your packet cannot complete the first hop,
    your machine's default gateway has probably not
    been correctly defined. If your traceroute
    terminates within the first couple of hops
    (without reaching the final destination), the
    problem is a misconfigured local router, and your
    local network administrator can probably help
    solve the problem. If the traceroute peters out
    more than four or five hops away, the problem is
    probably outside of your local network
    administrator's control.

50
Performing DNS Queries Manually host
  • The host command can be used to perform DNS
    queries directly. With a single argument, the
    host command will simply report the requested DNS
    resolution.
  • If the -a command line switch is included, the
    host command displays detailed information about
    the query performed, and the response received,
    in "resource record" format. Additionally, the
    final line identifies the nameserver who resolved
    the request, and the amount of time the
    resolution required.

51
Chapter 7  Terminal Based Web and FTP Clients
  • Key Concepts
  • The Elinks terminal HTTP client, invoked as the
    command links, can be used to browse web pages
    from a non graphical environment.
  • The curl application is a non-interactive
    multi-protocol client (including HTTP, HTTPS, and
    FTP) which can be used to transfer files in batch
    mode.
  • The wget application is a non-interactive
    multi-protocol client (including HTTP, HTTPS, and
    FTP) which can be used to recursively transfer
    web pages, recursing through all pages the web
    page references.

52
Chapter 7  Terminal Based Web and FTP Clients
  • Why Terminal Based Clients?
  • Users are probably familiar with sophisticated
    graphical applications such a mozilla for
    browsing the web, or nautilus for accessing FTP
    servers. In addition to these applications, Linux
    provides a collection of robust command line base
    clients as well. Why would someone be tempted to
    use command line based clients instead of point
    and click applications?
  • The obvious reason If you are not running an X
    graphical environment, they are the only
    utilities available.
  • Command line utilities are scriptable. If you are
    repeatedly pulling information from the same
    location, you might consider writing a script to
    do the repetitive work for you.
  • Command line utilities require less resources. If
    you are trying to perform a long download on an
    otherwise busy machines, a curl process which
    consumes 4 megabytes of memory is much more
    attractive than a mozilla process which consumes
    40 megabytes of memory.
  • Simplicity tends to encourage stability. When
    downloading large files, such as 700 Megabyte ISO
    images, many of the large graphical applications
    can become unstable. (The list of culprits
    includes Internet Explorer). Command line clients
    such as curl tend to produce more stable results.

53
Starting Elinks
  • The Elinks text HTTP client (web browser) is
    designed to render web pages in a terminal,
    emulating the layout of a graphical web browser.
    As much as possible, tables and forms are
    rendered to scale. Note that in the following
    display of a web page associated with Red Hat
    Network, frames and tables are rendered
    appropriately.
  • Elinks is started as the links command,
    specifying a URL to load as an argument, as in
    the following.

54
Browsing Web Pages with Elinks
  • When using links, the screen is active, and
    links may be navigated using arrow keys or the
    mouse. By using the ESC key, a menu is created
    which allows a user to access bookmarks, history,
    and customization dialogs.
  • Although the -dump command line switch can be
    used to non-interactively render a page to
    standard out, and the -source command line switch
    will do the same to the "RAW" content of the URL
    (often dumping HTML), the support for scripted
    interactions is fairly unsophisticated when
    compared to other utilities such as curl. The
    links browser's strength is its ability to
    provide a comfortable web browsing experience in
    a text environment.

55
Configuring Elinks to use a Proxy Server
  • If the HTTP_PROXY environment variable is set,
    Elinks will use the specified proxy server, where
    (like the Elinks browser) the proxy server can be
    specified using the following syntax.
  • Fetching Web Resources with curl
  • In contrast the the links command, the curl
    command line web client makes no effort to render
    or interactively browse web pages. Instead, the
    development of curl has focused on a robust
    collection of command line switches that makes it
    well suited for the automated retrieval of files
    which are published using a web or ftp server.
    This text would have a hard time describing curl
    any more effectively or succinctly than the first
    two paragraphs of the curl(1) man page

56
Starting curl
  • When called with a URL as its argument, the curl
    command retrieves the URL, and dumps its contents
    to standard out. Additionally, some timing
    information is written to standard error, which
    is discarded in the following example.

57
Command Line Switches for the curl Command
  • The following table lists a few of the command
    line switches which can be used to modify curl's
    behavior. Consult the curl(1) man page for a
    complete list.

58
Command Line Switches for the curl Command
  • As an example, the following command line could
    be used to download the ISO images for the Fedora
    Core 1 release
  • The following details should be noted about the
    curl command line.
  • Notice the use of "brace expansion syntax" in the
    referenced URL. The curl command will attempt to
    download three files, yarrow-i386-disc1.iso,
    yarrow-i386-disc2.iso, and yarrow-i386-disc3.iso.
  • Because of the -O command line switch, the files
    will be downloaded to the local directory with
    the same names.
  • Notice the time left at the current throughput
    13 hours! If the command needs to be aborted and
    later restarted, the -C - switch tells curl to
    examine any already existing partial downloads,
    and pick up the transfer where it left off.
  • The -L command line switch tells curl to follow
    any redirects issued by the web server. (Although
    not evident from the output, curl was redirected
    to a FTP server.)

59
Configuring curl to use a Proxy Server
  • If the http_proxy environment variable is set,
    curl will use the specified proxy server, where
    the proxy server can be specified using the
    following syntax.
  • Recursively Downloading Web Resources with wget
  • The wget command line web client is designed to
    non-interactively use the HTTP, HTTPS, and FTP
    protocols to download resources, possibly
    recursing to pages referenced from downloaded
    pages.
  • Starting wget
  • When called with a URL as its argument, the wget
    command retrieves the contents of the URL and
    stores it in a local file in the current working
    directory of the same name (or index.html if the
    URL specified a directory).
  • The following table lists a few of the command
    line switches which can be used to modify wget's
    behavior. Consult the wget(1) man page for a
    complete list.

60
Command Line Switches for the wget Command
  • wget

61
Command Line Switches for the wget Command
  • As an example, the following command line could
    be used to mirror the content of the
    http//www.redhat.com/training site.

62
Command Line Switches for the wget Command
  • And off it goes. After a little observation, it
    should become obvious that when called
    recursively, the wget command often recurses
    beyond expectations. After canceling the previous
    command with a CTRLC, the following directories
    demonstrate that wget strayed beyond the bounds
    of the www.redhat.com/training website.

63
Configuring wget to use a Proxy Server
  • Like the curl command, wget uses the http_proxy
    environment variable to specify a proxy server,
    again using the following syntax.

64
Chapter 8.  Remote Shell Commands
  • Key Concepts
  • Remote shell applications allow users to execute
    arbitrary commands on remote machines, and have
    standard out returned locally. Alternately, an
    interactive shell can be started.
  • The Secure Shell application provides a remote
    shell, where all transactions are encrypted, and
    users can be authenticated by traditional
    passwords or using a public key authentication
    scheme.
  • In order to use the public key authentication
    scheme, a public- private key pair must be
    generated with the ssh-keygen command.
  • Because Secure shell servers have their own
    public-private key pairs, servers can be
    authenticated to clients as well as clients
    authenticated to servers.

65
The Original Remote Shell rsh and Rhosts
Authentication
  • Remote Shells with rsh
  • Linux (and Unix) shells are intentionally
    designed with simple interfaces they read input
    from the standard in stream, and deliver output
    to the standard out stream. As a result, the
    interfaces are easily implemented over network
    connections. By simply substituting a TCP socket
    for a terminal device, a shell can operate on a
    remote machine as easily as the local machine. In
    Linux (and Unix), applications which provide this
    functionality are referred to as remote shells.
  • The first commonly used Unix remote shell was the
    simple rsh application. If a remote machine is
    properly configured (i.e., it is running the RSH
    server), users can use a rsh command line akin to
    the following to invoke a remote shell.

66
The Original Remote Shell rsh and Rhosts
Authentication
  • Translating, this command says "as the user elvis
    on the host server1, run the command ls /tmp".
    The command executes on the remote machine
    (server1), but standard out is delivered to the
    local machine (station). When the command
    completes, elvis's prompt implies that he is
    still on the host station.
  • If elvis does not specify a command to run, the
    rsh utility would opens an interactive shell on
    the remote host server1. By paying close
    attention to the bash prompt in the following
    excerpt, note which commands execute on which
    machine.

67
Rhosts Authentication /.rhosts
  • In each case, elvis did not need issue a
    password. Before he could access his remote
    account using rsh, however, elvis needed to
    configure the account to allow him access from
    his local machine. For rsh, access control
    configuration is as trivial as adding a line to a
    file. On the remote account, elvis created the
    file /.rhosts, and added one line containing the
    hostname and username for each external account
    which he wanted to grant access. Additionally,
    the RSH server requires that the file's
    permissions prohibit anyone but the user owner
    from reading the file. As the following commands
    illustrate, elvis has already configured his
    .rhosts file on the remote machine.
  • Authentication which relies on a properly
    configured /.rhosts configuration file is
    commonly called rhosts authentication.

68
The Secure Shell
  • The rhosts authentication method is pitiful. At
    its essence, it relies on DNS (Domain Name
    Service) to authenticate a user. In order to
    exploit elvis's /.rhosts configuration, all
    someone would have to do is detach the real host
    station from the network, and bring up another
    machine configured with station's IP address. The
    fault is not elvis's, but the design of the rhost
    authentication protocol.
  • Additionally, rsh is a plaintext protocol.
    Exchanging data over a network in plaintext is
    essentially the equivalent to sending mail on
    postcards anyone handling the data between here
    and there is privy to its contents.
  • The Secure Shell was developed to address both of
    these shortcomings of the rsh command, and add
    significant new capabilities, while still
    providing all of rsh's convenience. Assuming the
    remote machine is running the ssh service (i.e.,
    the sshd daemon), elvis could invoke a shell on
    the remote machine with the following.

69
The Secure Shell
  • The ssh command's new syntax for specifying the
    username of the remote account is slightly easier
    than is rsh's, although the -l command line
    switch is also implemented (in order to be fully
    backwards compatible).
  • In the above example, elvis is authenticated by
    providing a password instead of configuring a
    /.rhosts file. In the next section, we find that
    the Secure Shell can use a more mature public key
    technique to grant users "password free" access
    to an account. When public key authentication is
    not implemented, however, ssh falls back to
    traditional password authentication. 2

70
Secure Shell Public Key Authentication
  • In addition to traditional password
    authentication, the Secure Shell application can
    use public key cryptography to authenticate
    users. Public key encryption algorithms relate
    two large numbers, referred to as "keys", so that
    information encrypted with one key can only be
    decrypted with the other. Anyone who wants to use
    public key cryptography must first generate a
    pair of keys. Most public key protocols call one
    key a public key, and the complementary key a
    private key. Your public key you treat like your
    phone number you share it with anyone with whom
    you are willing to communicate, and may choose to
    list it in public directories. Your private key,
    on the other hand, you share with no one. All of
    the security provided by public key protocols
    relies on the fact that only you know the
    contents of your private key.

71
Generating a Public-Private Key Pair ssh-keygen
  • When using ssh, a user's public-private key pair
    can be generated with the ssh-keygen command. In
    the following example, elvis uses ssh-keygen to
    generate a ssh public-private key pair.
  • The user elvis was first prompted for the new
    (private) key's filename, to which elvis simply
    hit RETURN to accept the default filename
    /.ssh/id_rsa. Next, elvis was given the
    opportunity to attach a passphrase to his private
    key. By hitting RETURN again (twice), elvis chose
    not to. (We will discuss passphrases in more
    detail later.)

72
Generating a Public-Private Key Pair ssh-keygen
  • When the command returns, elvis has two new files
    in his (perhaps newly created) /.ssh directory.
    The first is his private key, which he shares
    with no one. (He certainly doesn't publish it in
    an online text).
  • He is free to share his second key (the public
    key) with anyone whom asks.

73
Allowing Account Access /.ssh/authorized_keys
  • SSH access to an account is granted by obtaining
    a copy of the public key of the person who is to
    be granted access, and storing it in the
    account's /.ssh/authorized_keys file. Like the
    /.rhosts file, the /.ssh/authorized_keys file,
    and the whole /.ssh directory, must only be
    readable by the user. How the copy of the public
    key is obtained does not matter. It could be
    emailed, scped (as discussed in a moment), or
    transferred from one terminal to another using
    the mouse's cut and paste buffer.

74
Allowing Account Access /.ssh/authorized_keys
  • When handling public keys, however, care must be
    taken to ensure that the key is placed in the
    file with no embedded whitespace, including
    newlines. Although too long to be displayed as
    such, SSH public keys are always stored as a
    single line of text. More people can be granted
    access to an account by simply appending their
    public keys to the /.ssh/authorized_keys files,
    one public key per line.

75
Allowing Account Access /.ssh/authorized_keys
  • In the following example, elvis uses ssh,
    redirection, and some carefully placed quotes to
    append his public key (on the host station) to
    the authorized_keys file in his account on the
    host serer1.
  • Okay, so we need to make the .ssh directory
    first.
  • Why the quotes? With no quotes, the output of the
    cat command would have been appended to the file
    .ssh/authorized_keys on the local machine. The
    quotes serve to pass the redirection syntax
    "into" the remote shell.

76
Allowing Account Access /.ssh/authorized_keys
  • Having placed his public key in the
    /.ssh/authorized_keys file on the remote
    machine, elvis now expects to be able to examine
    the contents of the file without having to issue
    a password.
  • Something is amiss, because elvis was again
    prompted for his password. Recalling that only
    the user should be able to access the /.ssh
    directory and read the /.ssh/authorized_keys
    file, elvis implements the appropriate chmod
    command on the remote machine. Afterwords, he is
    able to observe the new permissions without
    having to issue a password.
  • Success.

77
Public Key Authentication Details
  • In order to develop an appreciation for the
    robustness of public key authentication, we will
    spend a few moments discussing the protocol. When
    the secure shell application implements public
    key authentication, it uses a procedure similar
    to the following. In our discussion, the
    following symbols will be used.

78
Public Key Authentication Details
  • First, the ssh client on the host station
    requests a connection to the sshd daemon on the
    host server1. Upon receiving the connection
    request, the sshd daemon looks for a registered
    public key in the destination account's
    /.ssh/authorized_keys file.
  • If a relevant public key is discovered, the sshd
    daemon initiates public key authentication by
    generating a random string R. It then encrypts
    the random string with elvis's public key P
    (which it obtains from the /.ssh/authorized_keys
    file), and delivers the encrypted random string
    P(R) over the network to the ssh client.

79
Public Key Authentication Details
  • Upon receiving the encrypted random string P(R),
    the ssh client uses elvis's private key S to
    decrypt it. Once the original random string R is
    recovered, the ssh client returns it to the sshd
    daemon.

80
Public Key Authentication Details
  • If the sshd daemon receives from the ssh client
    the same random string with which it started, the
    client is authenticated, and the connection is
    allowed to continue.

81
Public Key Authentication Details
  • A couple of aspects of this algorithm deserve
    mentioning.
  • The ssh client is authenticated not by a hostname
    or IP address, and not by a password, but solely
    by the possession of the private key. (If the
    client could not access the appropriate private
    key, it would not have been able to decrypt the
    encrypted random string passed to it.)
  • The only information passed over the network is
    an encrypted random string, and a random string
    (the symbols colored red in the accompanying
    figures). Anyone eavesdropping on the
    conversation would not learn anything useful.
  • In practice, the actual algorithm used is more
    complicated. But the protocol outlined above
    illustrates the most important features of the
    public key authentication protocol

82
Transferring Files Securely and Easily scp
  • As the previous discussion illustrates, files can
    be transferred from one machine to another using
    ssh with the cat command and careful redirection.
    Fortunately, there is an easier and less error
    prone way scp.
  • The scp command uses a syntax almost identical to
    the cp command, but either the source file(s) or
    the destination file can be on a remote machine,
    accessed through a specified account. 3 When
    referring to a file on a remote machine, the
    following syntax is used.
  • The user and host are simply enough the host
    where the file resides, and the user whose
    account is used to access the file. If the file's
    path begins with a /, it is considered an
    absolute reference. If not, it is considered
    relative to the user's home directory. If no path
    is supplied, the user's home directory is
    assumed.
  • As an example, the following command line would
    transfer the /etc/services file from server1 into
    the /cfg/server1/etc/ directory in elvis's home
    directory.

83
Transferring Files Securely and Easily scp
  • Because elvis has a properly configured public
    key authentication with his account on server1,
    he is able to transfer the file without issuing a
    password. What happens if he tries to transfer
    the file /etc/shadow?
  • The user elvis on the host server1 does not have
    permissions to read the file /etc/shadow, so the
    file can naturally not be transferred. If the
    user elvis knows the password to the root account
    on the remote machine, however, the file could be
    accessed through it.
  • Because elvis does not have public key
    authenticated access to the root account on
    server1, ssh used traditional password
    authentication.

84
Transferring Files Securely and Easily scp
  • The -r command line switch (for "recursive") must
    be specified when copying an entire directory
    (and its subdirectories). In the following, elvis
    recursively copies the /etc/sysconfig directory
    from his local machine (station) to the machine
    server1's /tmp directory.
  • As the scp command performs the transfer, it
    displays transfer timing information for each
    file.

85
Secure Shell Host Authentication
  • The first time the ssh (or scp) client is used to
    connect to a sshd Secure Shell server, a message
    similar to the following is displayed.
  • If the user answers yes (the only answer which
    will allow the connection to continue), the
    connection proceeds, with the following warning.
  • On subsequent connections, the message is no
    longer seen.

86
Secure Shell Host Authentication
  • The Secure Shell not only authenticates clients
    to servers, but also servers to clients, using
    public key authentication. Just as users can
    create public-private key pairs with the
    ssh-keygen command, the sshd daemon maintains its
    own public-private key pair, known as its host
    key. The first time a ssh client connects to a
    sshd daemon, it appends a copy of the remote
    daemon's public host key to the local file
    /.ssh/known_hosts.
  • As the client is used to connect to various
    machines, the /.ssh/known_
About PowerShow.com
