Title: Experiments and Observational Studies

Chapter 13
  • Experiments and Observational Studies

  • Population Parameter
  • This is a numerical summary of a population
  • Proportion, mean, standard deviation
  • We dont know this number and usually never will.
  • Sample Statistic
  • This is a numerical summary computed from a
    subset of the population(a sample).
  • sample proportion, sample mean, sample standard
  • We know this number because we can compute it. We
    use this number to try and get an idea of what
    the population parameter(which we dont know)
    might be.

Observational Study
  • Observing data in the wild.
  • Researchers don't assign treatments to subjects
    they simply observe them.
  • Results show association, but do not prove
  • Also called an Investigative Study.
  • Sample surveys are observational studies.

Observational Studies
  • Two types
  • Retrospective Study
  • Subjects are selected
  • Previous behaviors or conditions are determined
  • Prospective Study
  • Subjects are selected
  • Subjects are followed to observe future outcomes

  • A way to prove a cause and effect relationship
    between two or more variables
  • Manipulate explanatory variable
  • Observe response
  • In an experiment you are applying a treatment to
    the subjects in an observational study you just
    observe them

Experiment Terminology
  • Experimental Units individuals on whom the
    experiment is performed
  • Factors explanatory variable(s)
  • Need at least one factor for every experiment

Experiment Terminology
  • Levels specific values that the experimenter
    chooses for a factor
  • Need at least two levels for each factor
  • Treatments different levels of a single factor
    or combinations of levels of two or more factors

Example OptiGro Fertilizer
  • An ad for OptiGro plant fertilizer claims that
    with this product we will grow juicier, tastier
    tomatoes. We'd like to test this claim and see
    if we can get by with a half-dose.
  • What are the experimental units in this example?
  • Tomato plants (the thing we apply the treatment
  • What is the response we are interested in?
  • Juiciness and Tastiness of the tomatoes

Example OptiGro Fertilizer
  • What is the factor?
  • Fertilizer
  • What are the levels of this factor?
  • No Fertilizer (to see if the fertilizer even
  • Full-Dose
  • Half-Dose (want to see if the half dose is as
    good as the full)
  • What are the treatments?
  • No Fertilizer, Full-Dose, Half-Dose

Example OptiGro Fertilizer
  • The makers of OptiGro want to ensure that their
    product will work under a wide variety of
    watering conditions. Let's include this as a
    second factor specifically lets look at daily
    watering and watering every other day.
  • How many factors are there now?
  • 2
  • What are the factor(s)?
  • Fertilizer and water
  • What are factor levels
  • Fertilizer
  • no fertilizer, half dose, full dose
  • Water
  • every day, every other day

Example OptiGro Fertilizer
  • What are the treatments in the new experiment?
  • Half-Dose of fertilizer, daily watering
  • Full-Dose, daily watering
  • No fertilizer, daily watering
  • Half-Dose, water every other day
  • Full-Dose, water every other day
  • No fertilizer, water every other day

Experiment Terminology
  • Control Group experimental units assigned to a
    baseline treatment level
  • Provides basis for comparison
  • Baseline either a gold standard or a placebo
  • Placebo a null treatment known to have no
  • Placebo Effect tendency of many human subjects
    to show response even when administered a placebo

Experiment Terminology
  • Blinding - the researcher disguises treatments
  • Single Blind - either the subject or the
    evaluator is unaware of the treatment
  • Double Blind - both the subject AND the evaluator
    are in the dark
  • Reduces personal bias

Experiment Terminology
  • Confounding - A condition where the effects of
    two variables on the response cant be
    distinguished from each other
  • Lurking Variable - A variable that effects the
    relationship between the response variable and
    the explanatory variable and is not included
    among the variables in a study.

Principles of Experimental Design
  • Control
  • Make all conditions as similar as possible for
    all treatment groups
  • The only difference between groups should be the
  • Controlling outside influences reduces
    variation in the responses, making it easier to
    detect differences among the groups due to the

Principles of Experimental Design
  • Randomization
  • Experimental units should be randomly assigned to
    treatment groups
  • Order of the trials should also be randomized
  • Some uncontrolled sources of variation will be
    controlled through randomization
  • Experiments without randomization may have biased

Principles of Experimental Design
  • Replication
  • In an experiment, each treatment is given to
    several different experimental units
  • Entire experiment should be repeated on a
    different group of experimental units

  • This can be considered another principle of
    experimental design, but not required in an
    experimental design
  • Group similar individuals together and then
    randomize within each of these blocks
  • Reduces the effects of identifiable attributes of
    the subjects that cannot be controlled

  • The leg muscles of men aged 60 to 75 were 50 to
    80 stronger after they participated in a
    16-week, high-intensity resistance-training
    program twice a week.
  • Experiment
  • Men aged 60 to 75 (experimental units)
  • Exercise (1 level) (factors)
  • 1 treatment 16-week resistance-training
  • Strength levels pre- and post-exercise program
  • Not blinded
  • Applies only to men 60 to 75 who participate in
    similar exercise programs. (Nature and scope of
  • Randomization?

  • In 2001 a report in the Journal of the American
    Cancer Institute indicated that women who work
    nights have a 60 chance of developing breast
    cancer. Researchers based these findings on the
    work histories of 763 women with breast cancer
    and 741 women without the disease.
  • Observational Study
  • Retrospective
  • Women unknown selection process with in
    formation taken from work histories
  • (subjects studied and how they were selected)
  • Risk of breast cancer
  • parameter of interest
  • Observational study, no way to know that working
    nights causes breast cancer.
  • Nature and scope of the conclusion.

  • Some gardeners prefer to use non-chemical methods
    to control insect pests in their gardens. Two
    kinds of traps have been designed and Researchers
    want to know which one is more effective. They
    randomly choose 10 locations in a large garden
    and place one of each kind of trap at each
    location. After a week they count the number of
    bugs in each trap.
  • Experiment.
  • Locations in a garden. (experimental units)
  • 1 factor traps(2 levels). (factors)
  • 2 treatments. ( of treatments)
  • Number of bugs in trap. (response variable
  • Blocked by locations. (type of design)
  • Not blind.
  • One type of trap is more effective than the other
    (Nature and scope of conclusion)

  • One way to portray an experiment is through a

Group 1
Treatment 1
Random Assignment
Compare response
Group 2
Treatment 2
Example Shingles
  • A research doctor believes a new ointment will be
    more effective than the current medication in
    treating shingles (a painful skin rash). Eight
    patients have volunteered for our study. We will
    design an experiment to help the doctor verify
    her claim.

Example Shingles
  • Experimental Unit Person (we have 8)
  • Response Severity of shingles
  • Factor ointment
  • Levels current ointment and new ointment
  • Why do we not want a placebo here?
  • Treatments current ointment and new ointment
  • Treatments are the same as levels here because we
    only have one factor

Example - Shingles
  • Control
  • Ointment taken every day for both groups
  • All other care is similar
  • Replication
  • 4 patients in each treatment group
  • Randomization
  • Randomly assign 4 patients to each treatment
  • How do we do this?

Example - Shingles
  • Patients Alex, Bethany, Carl, Denise, Evelyn,
    Fred, George, Hannah
  • Number the patients 1 through 8
  • Use random numbers to assign treatments 41098
    18329 78458 31685 55259
  • First 4 patients we select get new treatment, the
    rest get the current treatment

Example - Shingles
  • By ones4 1 0 9 8 1 8 3 2 9 7 8 4 5 8 3 1 6 8 5
    5 5 2 5 9
  • Throw out 0 and 9 (they dont correspond to
  • Throw out repeats
  • New ointment 4, 1, 8, 3
  • Denise, Hannah, Alex, Carl
  • Current ointment 2, 5, 6, 7 (everyone else)
  • Bethany, Evelyn, Fred, George

Example - Shingles
Group 1 4 patients
Treatment 1 New Ointment
Randomly Assign the 8 patients to groups
Compare severity of shingles
Group 2 4 patients
Treatment 2 Current Ointment
Example - Shingles
  • Could we make this experiment double-blind?
  • Double-blind means that neither the patient nor
    the person evaluating the results knows who is
    receiving each treatment. To make this
    double-blind we would have to assume that the two
    ointments look alike same color, unmarked tubes,
    similar texture, similar odors, etc.
  • If one ointment had a distinctive odor, it would
    probably not be possible to make the experiment

Example Blocking
  • Cancer treatment (3 treatments)
  • We suspect that men and women respond differently
    so divide subjects into men and women
  • Randomly assign each block to three groups
  • The three groups in each block receive only one
  • Compare survival rates

Examples Blocking
Group 1
Treatment 1
Compare survival rates
Random Assign.
Group 2
Treatment 2
Group 3
Treatment 3
Group 1
Treatment 1
Compare survival rates
Random Assign.
Group 2
Treatment 2
Group 3
Treatment 3
Statistical Significance
  • If the differences between the treatment groups
    are big enough, we will attribute the differences
    to the treatments
  • How big is big enough?
  • Answer more precisely later
  • Looking for differences large enough to be due to
    something other than random variation
