Title: Impact of the Cardiac Heart Flow Alpha Project


1
Impact of the Cardiac Heart Flow Alpha Project
  • Kathy Yelick
  • EECS Department
  • U.C. Berkeley

2
Outline
  • Vision of a Digital Human
  • Applications of the IBM
  • The Heart Model
  • The Cochlea Model
  • Others
  • Overview of the Immersed Boundary Method
  • The Alpha project
  • Solvers
  • Automatic tuning (FFT vs. MG)
  • Heart model
  • Short term future directions

3
Simulation The Third Pillar of Science
  • Traditional scientific and engineering paradigm
  • Do theory or paper design.
  • Perform experiments or build system.
  • Limitations
  • Too difficult -- build large wind tunnels.
  • Too expensive -- build a throw-away passenger
    jet.
  • Too slow -- wait for climate or galactic
    evolution.
  • Too dangerous -- drug design.
  • Computational science paradigm
  • Use high performance computer systems to simulate
    the phenomenon.

4
Economics of Large Scale Simulation
  • Automotive design
  • Crash and aerodynamics simulation (500 CPUs).
  • Savings approx. 1 billion per company per year.
  • Semiconductor industry
  • Device simulation and logic validation (500
    CPUs).
  • Savings approx. 1 billion per company per year.
  • Airlines
  • Logistics optimization on parallel system.
  • Savings approx. 100 million per airline per
    year.
  • Securities industry
  • Home mortgage investment and risk analysis.
  • Savings approx. 15 billion per year.
  • What about health care, which is 20 of GNP?

Source David Bailey, LBNL
5
From Visible Human to Digital Human
Building 3D Models from images
Source John Sullivan et al, WPI
Source www.madsci.org
6
Heart Simulation Calculation
  • Developed by Peskin and McQueen at NYU
  • Done on a Cray C90 1 heart-beat in 100 hours
  • Used for evaluating artificial heart valves
  • Scalable parallel version done here
  • Implemented in a high performance Java dialect
  • Model also used for
  • Inner ear
  • Blood clotting
  • Embryo growth
  • Insect flight
  • Paper making

7
Simulation of a Heart
8
Simulation and Medicine
  • Imagine a digital body double
  • 3D image-based medical record
  • Includes diagnostic, pathologic, and other
    information
  • Used for
  • Diagnosis
  • Less invasive surgery-by-robot
  • Experimental treatments
  • Where are we today?

9
Digital Human Roadmap
1 organ 1 model
1 organ multiple models
multiple organs
organ system
improved programmability
3D model construction
better algorithms
coupled models
scalable implementations
100x effective performance
1995
2000
2005
2010
10
Last Year
11
Project Summary
  • Provide easy-to-use, high performance tool for
    simulation of fluid flow in biological systems.
  • Using the Immersed Boundary Method
  • Enable simulations on large-scale parallel
    machines.
  • Distributed memory machine including SMP clusters
  • Using Titanium, ADR, and KeLP with AMR
  • Specific demonstration problem Simulation of the
    heart model on Blue Horizon.

12
Outline
  • Short term goals and plans
  • Technical status of project
  • Immersed Boundary Method
  • Software Tools
  • Solvers
  • Next Steps

13
Short Term Goals for October 2001
  • IB Method written in Titanium (IBT)
  • IBT Simulation on distributed memory
  • Heart model input and visualization support in
    IBT
  • Titanium running on Blue Horizon
  • IBT users on BH and other SPs
  • Performance tuning of code to exceed T90
    performance
  • Replace solver with (adaptive) multigrid

14
IB Method Users
  • Peskin and McQueen at NYU
  • Heart model, including valve design
  • At Washington
  • Insect flight
  • Fauchy et al at Tulane
  • Small animal swimming
  • Peter Kramer at RPI
  • Brownian motion in the IBM
  • John Stocky at Simon Fraser
  • Paper making
  • Others
  • parachutes, flags, flagellates, robot insects

15
Building a User Community
  • Many users of the IB Method
  • Lots of concern over lack of distributed memory
    implementation
  • Once IBT is more robust and efficient (May 01),
    advertise to users
  • Identify 1 or 2 early adopters
  • Longer term workshop or short course

16
Long Term Software Release Model
  • Titanium
  • Working with UPC and possibly others on common
    runtime layer
  • Compiler is relatively stable but needs ongoing
    support
  • IB Method
  • Release Titanium source code
  • Parameterized black box for IB Method with
    possible cross-language support
  • Visualization software is tied to SGI

17
Immersed Boundary Method
  • Developed at NYU by Peskin McQueen to model
    biological systems where elastic fibers are
    immersed in an incompressible fluid.
  • Fibers (e.g., heart muscles) modeled by list of
    fiber points
  • Fluid space modeled by a regular lattice

18
Immersed Boundary Method Structure
  • 4 steps in each timestep

Fiber activation force calculation
Fiber Points
Interpolate Velocity
Spread Force
Interaction
Navier-Stokes Solver
Fluid Lattice
19
Challenges to Parallelization
  • Irregular fiber lists need to interact with
    regular fluid lattice.
  • Trade-off between load balancing of fibers and
    minimizing communication
  • Efficient scatter-gather across processors
  • Need a scalable elliptic solver
  • Plan to uses multigrid
  • Eventually add Adaptive Mesh Refinement
  • New algorithms under development by Colellas
    group

20
Tools used for Implementation
  • Titanium supports
  • Classes, linked data structures, overloading
  • Distributed data structures (global address
    space)
  • Useful for planned adaptive hierarchical
    structures
  • ADR provides
  • Help with analysis and organization of output
  • Especially for hierarchical data
  • KeLP provides
  • Alternative programming model for solvers
  • ADR and KeLP are not critical for first-year

21
Titanium Status
  • Titanium runs on uniprocessors, SMPs, and
    distributed memory with a single programming
    model
  • It has run on Blue Horizon
  • Issues related to communication balance
  • Revamped backends are more organized, but BH
    backend not working right now
  • Need to replace personnel

22
Solver Status
  • Current solver is based on 3D FFT
  • Multigrid might be more scalable
  • Multigrid with adaptive meshes might be more so
  • Balls and Colella algorithm could also be used
  • KeLP implementations of solvers included
  • Note McQueen is looking into solver issues for
    numerical reasons unrelated to scaling
  • Not critical for first year goals

23
IB Titanium Status
  • IB (Generic) rewritten in Titanium.
  • Running since October
  • Contractile torus
  • runs on Berkeley NOW and SGI Origin
  • Needed for heart
  • Input file format
  • Performance tuning
  • Uniprocessor (C code used temporarily in 2
    kernels)
  • Communication

24
Immersed Boundary on Titanium
  • Performance Breakdown (torus simulation)

25
Immersed Boundary on Titanium
26
Next Steps
  • Improve performance of IBT
  • Generate heart input for IBT
  • Recover Titanium on BH
  • Identify early user(s) of IBT
  • Improve NS solver
  • Add functionality
  • Bending angles, anchorage points, source sinks)
    to the software package.

27
Adaptive Computations for Fluids in
Biological Systems
Immersed Boundary Method Applications
Human Heart (NYU)
Embryo Growth (UCB)
  • Yelick(UCB), Peskin (NYU), Colella (LBNL),
    Baden (UCSD), Saltz (Maryland)

Blood Clotting (Utah)
Robot Insect Flight (NYU)
Pulp Fibers (Waterloo)
Heart (Titanium)
Insect Wings
Flagellate Swimming

Application Models
Generic Immersed Boundary Method (Titanium)
Extensible Simulation
Spectral (Titanium)
Multigrid (KeLP)
AMR
Solvers
28
General Questions
  • - How has your project addressed the goals of the
    PACI program (providingaccess to tradition HPC,
    providing early access to experimental
    systems,fostering interdisciplinary research,
    contributing to intellectualdevelopment,
    broadening the base)?- What infrastructure
    products (e.g., software, algorithms, etc.) have
    you produced?- Where have you deployed them (on
    NPACI systems, other systems)?- What have you
    done to communicate the availability of
    thisinfrastructure?- What training have you
    done?- What kind/size of community is using your
    infrastructure?- How have you integrated your
    work with EOT activities?- What scientific
    accomplishments - or other measurable impacts
    notcovered by answers to previous questions -
    have resulted from its use?- What are the
    emerging trends/technologies that NPACI should
    buildon/leverage?- How can we increase the
    impact of NPACI development to date?- How can we
    increase the community that uses the
    infrastructure you'vedeveloped?

29
Gregs Slides
30
Scallop
  • A latency tolerant elliptical solver library
  • Implemented in KeLP, with a simple interface
  • Still under development

31
Elliptical solvers
  • A finite-difference based solvers
  • Good for regular, block-structured domains
  • Method of Local Corrections
  • Local solutions corrected by a coarse solution
  • Good accuracy, well-conditioned solutions
  • Limited communication
  • Once to generate coarse grid values
  • Once to correct local solutions

32
KeLP implementation
  • Advantages
  • abstractions available in C
  • built in domain calculus
  • communication management
  • numerical kernels written in Fortran
  • Simple interface
  • callable from other languages
  • no KeLP required in user code

33
A Finite Difference Domain Decomposition Method
Using Local Corrections for the Poisson Equation
  • Greg Balls
  • University of California, Berkeley

34
The Poisson Equation
  • We are interested in the solution to
  • A particular solution to this equation is

35
Infinite Domain Boundary Conditions
  • We can write our infinite domain boundary
    condition as
  • These boundary conditions specify a unique
    solution.

36
The Discretized Problem
  • We would like an approximate solution

37
Solving the Discretized Problem
  • We could calculate the convolution integral at
    each point
  • Multigrid provides a faster method

38
A Standard Finite Difference Discretization
  • With a discretization of the Laplacian, e.g.
  • We solve the discretized equation

39
A Finite Difference Approach for the Infinite
Domain Problem
  • A discrete solution can be found in three steps
  • Solve a multigrid problem with homogeneous
    Dirichlet boundary conditions.
  • Do a potential calculation to set accurate
    inhomogeneous Dirichlet boundary conditions.
  • Solve a second multigrid problem with these
    boundary conditions.

40
A Finite Difference Approach for the Infinite
Domain Problem
  • The first multigrid solution

41
A Finite Difference Approach for the Infinite
Domain Problem
  • The potential calculation

42
A Finite Difference Approach for the Infinite
Domain Problem
  • The second multigrid solution

43
Domain Decomposition
  • We would like to solve this problem in parallel,
    calculating f h such that
  • A basic domain decomposition strategy
  • Do until converged -
  • Break into pieces.
  • Solve on each piece.
  • Compute coupling.

44
Domain Decomposition Options
  • Point relaxation
  • Too much communication and too much computation.
  • Multigrid
  • Less computation, but still too much
    communication.
  • Finite element domain decomposition
  • Less communication, but still iterative.

45
The Importance of Communication
  • Current parallel machines can do many floating
    point operations in the time that it takes to
    send a message.
  • This imbalance will get worse.

46
Fast Particle Methods
  • Methods such as FMM and MLC need no iteration.
  • They take advantage of the fact that the local
    and far-field solutions are only weakly coupled.

47
A Method of Local Corrections for Finite
Difference Calculations
  • The basic strategy
  • Break into pieces.
  • Solve on each piece.
  • Compute coupling through a single coarse
    solution.
  • Compute the corrected solution on each piece.

48
The Initial Solution
  • An infinite domain solution is found on each
    piece, l
  • The effects of all other pieces are ignored.

49
A Coarse Grid Charge
  • A coarse grid charge is computed for each piece.

50
The Global Coarse Solution
  • All the individual coarse grid charges are
    combined on a global coarse grid.
  • A global coarse solution is found.

51
Setting Accurate Boundary Conditions
  • The interpolation stencil only interpolates
    far-field information.

52
Setting Accurate Boundary Conditions
  • The coarse stencil information is interpolated to
    a corresponding fine grid stencil to O(H4).
  • Local information is added from nearby fine grids.

53
The Corrected Solution
  • Once the boundary conditions have been set for
    each piece, we solve one last time with
    multigrid
  • The full solution is then

54
How Accuracy Is Maintained
  • Local error is only O(h2).
  • Error in the global coarse solution is O(H4).
  • The coarse solution is accurate to O(H4) because
    of the error of the L9 discretization.

55
Scaling for Accuracy and Performance
  • We can scale the coarse and fine grids as
  • The coarse grid solve represents much less work
    than the work done on the fine grids.

56
The Titanium Programming Language
  • Titanium is a new language designed for
    scientific computing on parallel architectures.
  • SPMD parallelism.
  • A dialect of Java, compiled to native code.
  • Language support for scientific computing.

57
The Benefits of Titanium
  • An object-oriented language with built-in support
    for fast, multi-dimensional arrays.
  • Language support for
  • Tuples (Points).
  • Rectangular regions (RectDomains).
  • Expressing array bounds as RectDomains and
    indexing arrays by Points.
  • A global address space

58
Accuracy of the Method
Grid Size Np Nr Max Error L2 Error Max Convergence L2 Convergence
257 2 4 8.61e-8 2.18e-8
257 2 8 8.51e-8 2.13e-8
257 4 8 8.25e-8 2.02e-8
257 4 16 7.23e-8 1.77e-8
513 2 4 2.02e-8 5.32e-9 2.22 2.06
513 2 8 2.01e-8 5.26e-9 2.23 2.06
513 4 8 1.96e-8 5.05e-9 2.32 2.18
513 4 16 1.67e-8 4.12e-9 2.42 2.30
59
Error on a Large, High-Wavenumber Problem
60
Scalability of the Method
  • Results from the SDSC IBM SP-2

61
Scalability of the Method
  • Results from the NERSC Cray T3E

62
Future Work
  • Extension to three dimensions.
  • Implementation of different boundary conditions.
  • Use in other solvers such as
  • Euler.
  • Navier-Stokes.

63
Conclusions
  • The method is second-order accurate.
  • The method does not iterate between the local
    fine representations and the global coarse grid.
  • The need for communication is kept to a minimum.
  • The method is scalable.

64
Comparison to the Serial Method
  • Extra computational costs
  • The time spent on the coarse grid solution can be
    kept to less than 10 of time spent on the local
    fine grids.
  • The final multigrid solution adds 40 more fine
    grid work.
  • Communication costs
  • Experimentally, less than 1 of the total time
Write a Comment
User Comments (0)
About PowerShow.com
