Title: NITROGEN%20CYCLE


1
NITROGEN CYCLE
  • Submitted by,
  • SREEJITH P
  • S4 EEE
  • ROLL NO- 54

2
CONTENTS
  • Introduction
  • Processes of the nitrogen cycle
  • Human influences on the nitrogen cycle
  • References

3
INTRODUCTION
  • Earth's atmosphere is about 78 nitrogen.
  • Nitrogen is essential for many biological
    processes and is crucial for any life on Earth.
  • It is in all amino acids, is incorporated into
    proteins, and is present in the bases that make
    up nucleic acids, such as DNA and RNA.

4
Nitrogen cycle
  • The nitrogen cycle is the biogeochemical cycle
    that describes the transformations of nitrogen
    and nitrogen-containing compounds in nature.
  • It is a gaseous cycle.

5
Processes of the nitrogen cycle
  • Conversion of N2
  • Assimilation
  • Ammonification
  • Nitrification
  • Denitrification
  • Anaerobic ammonium oxidation

6
CONVERSION OF N2
  • The conversion of nitrogen (N2) from the
    atmosphere into a form readily available to
    plants and hence to animals and humans is an
    important step in the nitrogen cycle, that
    determines the supply of this essential nutrient.
  • There are four ways to convert N2 (atmospheric
    nitrogen gas) into more chemically reactive
    forms
  • 1.Biological fixation
  • 2.Industrial N-fixation
  • 3.Combustion of fossil fuels
  • 4.Other processes

7
  • 1. Biological fixation some symbiotic bacteria
    (most often associated with leguminous plants)
    and some free-living bacteria are able to fix
    nitrogen and assimilate it as organic nitrogen.
    An example of nitrogen fixing bacteria is the
    Rhizobium bacteria, which live in legume root
    nodules. An example of the free-living bacteria
    is Azotobacter.
  • 2.Industrial N-fixation  in the Haber-Bosch
    process, N2 is converted together with hydrogen
    gas (H2) into ammonia (NH3) which is used to make
    fertilizer and explosives.

8
  • 3.Combustion of fossil fuels  automobile engines
    and thermal power plants, which release various
    nitrogen oxides (NOx).
  • 4.Other processes  Additionally, the formation
    of NO from N2 and O2 due to photons and
    especially lightning, are important for
    atmospheric chemistry, but not for terrestrial or
    aquatic nitrogen turnover.

9
Assimilation
  • Plants can absorb nitrate or ammonium ions from
    the soil via their root hairs.
  • If nitrate is absorbed, it is first reduced to
    nitrite ions and then ammonium ions for
    incorporation into amino acids, nucleic acids,
    and chlorophyll.
  • In plants which have a mutualistic relationship
    with rhizobia, some nitrogen is assimilated in
    the form of ammonium ions directly from the
    nodules.
  • Animals, fungi, and other heterotrophic organisms
    absorb nitrogen as amino acids, nucleotides and
    other small organic molecules.

10
Ammonification
  • When a plant or animal dies, or an animal
    excretes, the initial form of nitrogen is
    organic.
  • Bacteria, or in some cases, fungi, converts the
    organic nitrogen within the remains back into
    ammonia, a process called ammonification or
    mineralization.

11
Nitrification
  • The conversion of ammonia to nitrates is
    performed primarily by soil-living bacteria and
    other nitrifying bacteria.
  • The primary stage of nitrification, the oxidation
    of ammonia (NH3) is performed by bacteria such as
    the Nitrosomonas species, which converts ammonia
    to nitrites (NO2-).
  • Other bacterial species, such as the
    Nitrobacter, are responsible for the oxidation of
    the nitrites into nitrates (NO3-).

12
Denitrification
  • Denitrification is the reduction of nitrites back
    into the largely inert nitrogen gas (N2),
    completing the nitrogen cycle.
  • This process is performed by bacterial species
    such as Pseudomonas and Clostridium in anaerobic
    conditions.
  • They use the nitrate as an electron acceptor in
    the place of oxygen during respiration.
  • These facultatively anaerobic bacteria can also
    live in aerobic conditions.

13
Anaerobic ammonium oxidation
  • In this biological process, nitrite and ammonium
    are converted directly into dinitrogen gas.
  • This process makes up a major proportion of
    dinitrogen conversion in the oceans.

14
SCHEMATIC REPRESENTATION OF THE FLOW OF NITROGEN
THROUGH THE ENVIRONMENT.
15
Human influences on the nitrogen cycle
  • As a result of extensive cultivation of legumes
    (particularly soy, alfalfa, and clover), growing
    use of the Haber-Bosch process in the creation of
    chemical fertilizers, and pollution emitted by
    vehicles and industrial plants, human beings have
    more than doubled the annual transfer of nitrogen
    into biologically available forms.
  • In addition, humans have significantly
    contributed to the transfer of nitrogen trace
    gases from Earth to the atmosphere, and from the
    land to aquatic systems.
  • N2O has risen in the atmosphere as a result of
    agricultural fertilization, biomass burning,
    cattle and feedlots, and other industrial sources.

16
  • N2O has deleterious effects in the stratosphere,
    where it breaks down and acts as a catalyst in
    the destruction of atmospheric ozone.
  • Ammonia (NH3) in the atmosphere has tripled as
    the result of human activities.
  • It is a reactant in the atmosphere, where it acts
    as an aerosol, decreasing air quality and
    clinging on to water droplets, eventually
    resulting in acid rain.
  • Fossil fuel combustion has contributed to a 6 or
    7 fold increase in NOx flux to the atmosphere.

17
  • NOx actively alters atmospheric chemistry, and is
    a precursor of tropospheric (lower atmosphere)
    ozone production, which contributes to smog, acid
    rain, and increases nitrogen inputs to
    ecosystems.
  • Ecosystem processes can increase with nitrogen
    fertilization, but anthropogenic input can also
    result in nitrogen saturation, which weakens
    productivity and can kill plants.
  • Decreases in biodiversity can also result if
    higher nitrogen availability increases
    nitrogen-demanding grasses, causing a degradation
    of nitrogen-poor, species diverse heathlands.

18
Reference
  • http//en.wikipedia.org/wiki/nitrogen cycle
  • http//www.ucsusa.org/clean_energy/nitrogenbasics/
  • http//www.aquariumdomain.com/guideTheNitrogenCycl
    e.asp

19
THANK YOU
