COS 125

1
COS 125

• DAY 2

2
Agenda

• Questions from last Class??
• Review
• ISOC presentation on Internet History
• Todays topics
• Circuit versus Packet switching
• TCP/IP
• Software Structure of The Internet
• Internet Addresses and Names
• How IP Routers work
• As promised, Assignment 1 is posted to WebCt
• Due Monday, Jan 24

3
Circuit Switching

• This is how Phone Networks operate
• For Alice to talk to Bob there must a dedicated
  Connection (wire) from Alice to Bob
• If there is no connection path available than
  circuit is said to be busy
• Connection is dedicated for entire length of
  conversation
• Wasteful

4
Circuit Switching
5
Packet Switching

• TCP/IP (and the Internet) uses Packet Switched
  networks
• Large files are broken in smaller packets
• Each packets finds its way across Internet
• DEMO
• Allows for Multiplexing
• More efficient
• Causes problems for data that requires specific
  timing
• Audio, Video

6
Packet Switching
1. Break message into Smaller packets (also known
as frames)
Original Message
Packet Switch A
B
C
Computer X
Packet
Switching Decision
Computer Y
F
E
D
2. Route packets individually Packet switches
along the way Make decisions about the packet
7
TCP/IP

• Two protocols that are part of the Networking
  Stack
• Transmission Control Protocol
• Computer to Computer
• Breaks down Files into Packets and reassemble
• Internet Protocol
• Internet Device to Internet Device
• Ensures packets are delivered to right destination

8
TCP/IP Stack
9
Connecting to Internet

• Two ways
• LANS
• Direct connection
• Just like in this lab
• 24/7/365
• Modems
• Cable
• DSL
• Telephone
• Use two different protocols
• SLIP or PPP

10
Internet Software Structure

• Client/Server
• Clients (PCs) ask for stuff
• Servers (large computers) deliver stuff
• In case of WWW
• Uses HTTP
• Browsers (Internet explorer) is the client
• Web Server (www.umfk.maine.edu) is the server

11
Client/Server Architecture
Usually, Two Types of Stations Clients and Servers
Server
Client PC
Service
Network
Clients Receive Services
Servers Provide Services
12
Internet Address and Domains

• The Heart of the Internet is DNS
• Domain Name System
• Translate names to addresses
• Sort of an automatic phone book
• www.umfk.maine.edu -gt 130.111.185.92
• Use nslookup at the command prompt (2000, XP,
  Mac OSX, UNIX)
• The name (www.umfk.maine.edu) is a URL or Uniform
  Resource Locator
• 130.111.185.92 is an IP address (like a phone
  number)

13
Domain names

• www.umfk.maine.edu
• Computer.subdomain.minordomain.majordomain
• Major Domains
• edu, com, net, org mil
• Minor domains
• Maine, yahoo, nasa
• Sub domains (could have more than one)
• Umfk
• Computer names
• www, tgauvin, nb11

14
Domain name organization
15
Name servers

• DNS Names Server covert names to IP address
• No ONE name server could know all names and all
  addresses
• more than 4 billion possibilities
• Names ltgt ip address tables are distributed
• Each minor domain is responsible for running its
  own Name Server(s)
• 13 Root Servers (one per major domain) maintain
  lists of all the name servers responsible of the
  minor domains

16
Distributed Name Resolution
17
Root Servers
18
Static versus Dynamic IP Addresses

• Every computer connected to the Internet MUST
  have an IP address
• xxx.xxx.xxx.xxx
• 0.0.0.0 ltgt 255.255.255.255
• If the address for a computer never changes then
  it is static
• Else it is dynamic

19
Why use Dynamic Addressing

• There is not enough address to go around
• 4.2 billion possibilities
• Actually only about 3 billion due to allocation
  schemes
• Not all computer are connected 24/7
• If an ISP has only 24 modems that its customers
  connect to than why use more than 24 addresses
  even though it may have 200 or more customers
• Dynamic IPs became possible with DHCP around
  1995

20
DHCP
21
How routers work

• Traffic cops of the Internet
• Ensure all IP packets get to where the are
  supposed to go
• Look at destination IP address of any packet
  coming into the router on any of its ports
  (connections)
• Looks up ip address in routing table
• Decides where to send packet
• Another port

22
Routing Table for a router
network Next Hop
10.2.1.56 10.3.4.56
10.2.0.0 10.3.2.1
10.3.0.0 Deliver directly
10.1.0.0 10.3.1.1
10.5.0.0 Deliver directly
10.6.0.0 10.5.6.1
0.0.0.0 10.3.2.1
23
Routing
24
Routing
25
For next week

• Read HITW Chaps 7-13 (page 85)
• Assignment 1
• Due next Monday, January 24, 2004 at beginning of
  class
