Fourier Optics

1
Lecture 5
Fourier Optics
2
Class Test I Mark Distribution

• Mean 40
• Standard deviation 23

3
Marks for Class Test I will be available from
your tutors from Wednesday.
4
Class Test I

• and you were given on the front sheet

5
Class Test I

• and you were given on the front sheet

You know from PC2 and the lecture notes handout
that FTtop-hat
and
6
Class Test I
7
Class Test I
8
Common errors I

• Inability to multiply complex exponential
  expressions for sine and cosine.
• Inability to integrate exponential functions in
  Fourier analysis this is a major concern.
• Arbitrarily interchanging x, k, t, w, k0 and w0
  (and other symbols)
• Not realising that a series of sine functions is
  a Fourier series (particularly worrisome)
• Not being able to write down correct expressions
  for complex exponential form of sine and/or
  cosine.

9
Common errors II

• Not being able to sketch simple filter response
  diagrams.
• Inability to write down correct form of Fourier
  integral even though it was an open book test.

10
Recap.

• Diffraction and convolution double slit
  experiment

Outline of Lecture 5

• 2D Fourier transforms
• Diffraction gratings
• Fourier filtering

11
Reciprocal space and spatial frequencies
Just as we can build up a complex waveform from a
variety of sinusoids of different amplitudes and
phases, so too can we generate an image from a
Fourier integral.
12
2D Images and 2D Fourier Transforms
Consider an aperture
?
f(x,y) in this case can be broken down into two
functions f(x) and f(y). Sketch those functions.
13
2D Images and 2D Fourier Transforms
So, for a square aperture we have two sinc
functions, one along kx and one along ky
Figures taken from Optics, Hecht (Addison-Wesley,
2nd Ed. 1987)
14
2D Images and 2D Fourier Transforms
?
Which area of the diffraction pattern is
associated with low spatial frequencies? With
high spatial frequencies?
15
2D Images and 2D Fourier Transforms
Aperture function (2 slits)
2 slit pattern
?
What is the effect on the image if we only pass
the spatial frequencies within the circle shown?
16
2D Images and 2D Fourier Transforms
?
What is the effect on the image if we block the
spatial frequencies within the circle shown?
17
Complex images Fourier transforming and spatial
filtering
Niamhs Fourier transform (modulus2)
Niamh
18
Complex images Fourier transforming and spatial
filtering
19
Complex images Fourier transforming and spatial
filtering
Optical computer
20
The diffraction grating

• An (infinite) diffraction grating has a
  transmission function which
• looks like

• We saw earlier how the double slit transmission
  function could be represented as a convolution of
  two functions. The grating transmission function
  can be treated similarly.

?
The transmission function above can be
represented as the convolution of two functions.
Sketch them.
21
The diffraction grating

• The train of delta functions is known as a
  Dirac comb (or a Shah function).

whose Fourier transform is another Dirac comb
where
22
The diffraction grating
has Fourier transform
?
At what value of k is the first zero in G(k)
located?
?
Sketch the Fourier transform (i.e. the
diffraction pattern) of the transmission function
for the infinite diffraction grating.
23
The diffraction grating

• Now, what happens if we want to consider a real
  diffraction grating (i.e. one that is not
  infinite in extent)?

?
The slits in the infinite grating above are
spaced by an amount L. Imagine that we want to
determine the Fourier transform of a grating
which is 50L wide. How do we convert the
transmission function for the infinite grating
into that for a real grating which is 50L wide?
24
The diffraction grating
