Scientific Measurements

1
Pflugerville Independent School
District Integrated Physics Chemistry
Measurement
2
Quantitative and Qualitative Observations

• What do YOU think
• the difference is?

3
1) What is a system of measurement ?

• 2) Metric system- AKA International system , and
  SI (Systeme International d'Unites)
• English system- AKA British system, customary
  system our system
• 3, 4, 5, 6) METRIC!!!!!!

4
7 Base Metric Units

• Meters measure length
• Kilograms measure mass
• Seconds measures time
• Kelvin measures temperature
• Ampere measures current
• Lumens measures light intensity
• Moles measures the amount of a substance

5
Metric Prefixes

• Kilo 1000
• Hecto 100
• Deka 10
• Deci 1/10
• Centi 1/100
• Milli 1/1000

6
Other Derived Metric Units (from basic 7)

• Volume is length x width x height measured in
  centimeters cubed or millilters
• Temperature is measured in degrees celsius or
  centigrade (oC)
• Heat is measured in calories (cal) or joules (J)
• Weight is measured in newtons (N)

7
How Big?

• A meter is about 39 inches
• A kilometer is 0.6 mile
• A centimeter is about the width of your little
  finger
• A gram is about the mass of a paper clip
• A kilogram is 2.2 pounds
• You drink 2 liters of pop
• See handout for other prefixes

8
Tools for Measurement

• Thermometer
• Multimeter
• Photometer

• Meterstick
• Balance (triple beam and digital)
• Graduated Cylinder
• Stopwatch

9
Graduated CylinderMeasurement

• Volume is measured using a graduated cylinder.
• When reading a graduated cylinder, read the
  bottom of the meniscus.

10
Insert Slides on Dimensional Analysis

• From Bill Anderson, HHS

11
K H D O D C M

• To change from one metric unit to another, we
  simply multiply by a conversion factor.
• For example
• 25.4 km _____________ cm?
• 25.4 km x 1000cm/1km 2,540,000 cm

12
Scientific Notation

• Rules
• 1 digit before the decimal point
• Multiply the number by a power of 10
• Example Write 34,000 in scientific notation.
• Solution 3.4 x 104

13
Write the following in scientific notation
4.1 x 106

• 4,100,000 _______________
• 345,600,000,000 _________
• 0.0456 ________________
• 0.00000012____________
• O.00305 ____________

3.456 x 1011
4.56 x 10-2
1.2 x 10-7
3.05 x 10-3
14
Write the following in standard form
4670

• 4.67 x 103 __________________
• 3.112 x 105 _________________
• 3.112 x 10-4 ________________
• 4 x 10-6 ___________________
• 1 x 1011 __________________

311200
0.0003112
0.000004
100,000,000,000
15
Density of Water

• One milliliter of water
• Has a mass of 1 gram
• Density Mass Volume
• Calculate the density of water

1g 1mL 1g/mL
16
Measuring Water

• If you wanted to measure 25 mL of water, what
  instrument would you use?

17
Measuring Water

• If you wanted to measure 25 grams of water, what
  2 instruments could you use?

18
Accuracy vs. Precision

• ACCURACY
• "capable of providing a correct reading or
  measurement.
• A measurement is accurate if it correctly
  reflects the size of the thing being measured.

• PRECISION
• "exact, as in performance, execution, or amount.
• It means repeatable, reliable, getting the same
  measurement each time.

19
Try This On-line Activity
http//www.learner.org/channel/courses/learningmat
h/measurement/session2/part_c/accuracy.html
20
Measuring volume of a solid by water displacement
21
One cubic centimeter One milliliter
Using water displacement, how many milliliters do
you expect the water to raise when the cube is
lowered?
This cubes sides are each 3 cm. What is the
volume of the cube?
27 cubic cm
27 mL
22
Thats all folks!

• Time to try some on your own!
