Confirmatory and differential diagnostic tests
after positive screening results

• Péter Monostori, PhD
• Neonatal Screening Laboratory, Department of
  Pediatrics, University of Szeged

2
Primary screening tests

• Routine primary screening methods are designed to
  identify as many abnormal infants as possible.
• Therefore, diagnostic sensitivity (low number of
  false-negative results) is more important than
  diagnostic specificity (to have few
  false-positive results)
• This approach exponentially increases the number
  of false-positive test results as more disorders
  are included in screening.

• Obtaining another blood sample to confirm/exclude
  the disorder is a valid choice but is not always
  necessary

3
The problem with repeated sampling

• The newly obtained samples require additional
  work.
• The cost of the screening program is increased.
• Repeated sampling causes stress and anxiety in
  the families
• infants with false-positive screening results are
  more often hospitalized than healthy children
  with normal screening results

• families subjected to false-positive newborn
  screening results are at higher risk of
  developing dysfunctional parent-child
  relationships

4
How to address this issue?

• The aim is therefore to improve diagnostic
  specificity (decrease the number of
  false-positive results) without reducing
  diagnostic sensitivity
• Inclusion of secondary criteria, such as ratios
• C3/C2 for propionic/methylmalonic acidemia etc.
• Good interpretation of the results in view of
  the clinical status (prematurity etc.), drugs,
  nutrition
• Second-tier tests

5
Second-tier tests What are these?

• More specific for the diagnostic compound than
  the primary screening method and/or
• Measure additional metabolites
• Use the same sample (e.g. dried blood spot, DBS)
• there is no need to obtain a new sample
• Utility

• support or exclude the diagnosis suggested by the
  primary test
• differentiate between disorders (differential
  diagnosis)

6
Second-tier tests

• Then why dont we use these as primary tests?
• Limitations
• lower sample throughput
• greater complexity
• longer analysis time
• higher cost

7
Second-tier tests

• Biochemical tests (mainly MS/MS)
• Enzyme activity measurements
• Molecular genetic tests

8
Second-tier tests Examples

1. Congenital adrenal hyperplasia (CAH)
2. Phenylketonuria (PKU)
3. Propionic acidemia (PA), methylmalonic acidemia
   (MMA) with/without homocystinuria (HCYS)
4. Tyrosinemia type I (Tyr I)
5. Galactosemia
6. Isovaleric acidemia (IVA)
7. Maple syrup urine disease (MSUD)

9
1. Congenital adrenal hyperplasia (CAH)
10
First-tier tests for CAH

• First-tier screening tests for CAH use
  immunoassays to measure 17-hydroxy-progesterone
  (17-OHP) levels in DBS
• Dissociation-enhanced, lanthanide fluorescence
  immunoassay (DELFIA) is almost exclusively used
• However, the positive predictive value for
  first-tier screening of CAH is generally about
  1.

11
Limitations of first-tier screening of CAH

• First, the antibodies used in the immunoassays
  cross-react with other steroids, particularly
  17-hydroxypregnenolone.
• Second, 17-OHP levels are normally high at birth
  and decrease rapidly during the first few days.
  By contrast, 17-OHP levels increase over time in
  newborn babies with CAH. Thus, diagnostic
  accuracy is poor in the first 2 days.
• Third, newborn girls have lower 17-OHP levels
  than newborn boys (sensitivity of screening for
  CAH in girls is lower).
• Fourth, premature, sick or stressed babies tend
  to have higher levels of 17-OHP.
• most laboratories use a series of (birth weight-
  or) gestational age-adjusted threshold values

• Fifth, antenatal corticosteroids administered to
  mothers at risk of preterm delivery might reduce
  17-OHP levels (false-negative test results ?).
• Finally, neonatal screening identifies only few
  babies with mild, nonclassic CAH.

12
Second-tier tests for CAH Biochemical assays

• Direct analysis of steroid levels by LC-MS/MS
  from DBS is used as second-tier tests.
• This assay does not only determine 17-OHP as a
  direct substrate for 21-hydroxylase, but also
  cortisol (a downstream product of this enzymes
  reaction) and other steroids.
• The run times for individual samples in most
  LC-MS/MS assays are generally 6-12 min, which
  would be too long for a first-tier screen.

13
Second-tier tests for CAH Biochemical assays

• Appropriately selected ratios of the steroids can
  further improve the specificity of LC-MS/MS.
• The rationale for using ratios with cortisol
• newborns under stress have high cortisol levels
  with secondary accumulation of 17-OHP
• in CAH patients, cortisol levels are relatively
  low
• Ratio No. 1
• (17-OHPandrostenedione)/cortisol
• androstenedione is only secondarily increased in
  CAH (indirectly due to the deficiency of
  21-hydroxylase)
• Ratio No. 2
• (17-OHP21-deoxycortisol)/cortisol

• 21-deoxycortisol is highly specific for
  21-hydroxylase deficiency

14
Second-tier tests for CAH Molecular genetic
assays

• CYP21A2 mutations can be detected in DNA samples
  extracted from the same DBS used for primary
  screening.
• However, this approach is not comprehensive
• CAH is a genetically heterogenous disorder
• not all mutations can be reliably detected in a
  screening setting
• LC-MS/MS is less costly and time-consuming than
  genotyping

15
A novel biochemical assay as a first-tier test
for CAH

• As shown earlier, the run times for individual
  samples in most LC-MS/MS assays are generally
  6-12 min, which would be too long for a
  first-tier screen.
• Exception a US laboratory (Manitoba) developed
  an LC-MS/MS assay using a modified instrument for
  first-tier screening (turbo-?ow chromatography
  coupled to LC-MS/MS)
• rapid determination of 17-OHP, androstenedione
  and cortisol
• no false-positives so far

16
Improvement of the specificity for CAH screening
(Mayo Clinic, USA)
17
2. Phenylketonuria (PKU)
GTP cyclohydrolase (GTPCH)
6-Pyruvoyl-tetrahydrobiopterin synthase (PTPS)
Sepiapterin reductase (SR)
Dihydropteridine reductase (DHPR)
Phenylalanine hydroxylase (PAH)
q-Dihydrobiopterin
Pterin-4a-carbinolamine dehydratase (PCD)
18
First-tier tests for PKU

• First-tier screening tests for PKU determine
  phenylalanine (Phe) levels in DBS. With MS/MS,
  tyrosine levels and Phe/Tyr ratios are also
  obtained.
• A positive screening result is generally
  sufficient to conclude that some form of
  hyperphenylalaninemia (PKU, transient
  hyperphenylalaninemia or tetrahydrobiopterin
  (BH4) deficiency) is present.

• For differential diagnosis
• Phe and BH4 loading test,
• pterin profile analysis (from urine or DBS),
• dihydropteridine reductase (DHPR) activity
  measurement (from DBS) should be performed

19
Differential diagnosis of BH4 deficiencies

• BH4 loading test
• useful in all forms of BH4 deficiency
• a 24 h Phe loading test is recommended
  previously, especially if the basal Phe level is
  low (e.g. lt 360 µM)
• single Phe dose plus a single BH4 dose 3 h later
• blood sampling -3 0 4 8 12 16 24 h
• Pterin profile analysis (neopterin, biopterin and
  pterin)
• sample DBS or urine (random urine specimen dried
  on filter paper is better than liquid urine, as
  pterins are very unstable)
• HPLC plus fluorescent detection or MS/MS
• DHPR activity measurement from DBS
• spectrophotometry

20
Pterin levels and DHPR activity in variants of
BH4 deficiency
Phe (plasma) Biopterin (urine) Neopterin (urine) DHPR activity (blood) Homovanillic acid (HVA, liquor) 5-hydroxy-indoleacetic acid (5-HIAA, liquor)
GTPCH1 (recessive) ? ? ? N ? ?
GTPCH1 (dominant) N N (? in liquor) N (? in liquor) N ? N/?
PTPS ? ? ? N ? ?
PCD ? ? N/ ? primapterin N N N
DHPR ? ? N ? ? ?
SR N N (? in liquor) N (? liquor sepiapterin) N ? ?
21
3. Propionic acidemia (PA), methylmalonic
acidemia (MMA) with/without homocystinuria (HCYS)
22
First-tier tests for PA, MMA and MMAHCYS

• First-tier screening tests for PA and MMA measure
  propionylcarnitine (C3) levels and C3/C2 ratios
  in DBS with MS/MS (in MMA, C4DC may also be
  increased). For MMAHCYS (caused by defective
  cobalamine metabolism Cbl C, Cbl D), elevated C3
  and C3/C2, plus decreased methionine levels may
  be suggestive.
• C3 is frequently responsible for false-positive
  results in newborn screening

• dietary deficiency of vitamin B12 (newborn or
  mother), prematurity, jaundice (hyperbilirubinemia
  )
• ratios and/or second-tier tests are used

23
Second-tier tests for PA, MMA and MMAHCYS

• The simultaneous determination of methylmalonate,
  methylcitrate and homocysteine in DBS by means of
  LC-MS/MS allows confirmation and differential
  diagnosis of the disorders (in some laboratories,
  3-hydroxypropionate is assayed instead of
  methylcitrate)

Initial screening Initial screening Second-tier test Second-tier test Second-tier test
C3 Met methyl-malonate methyl-citrate homo-cysteine
PA ?? N N ?? N
MMA ?-?? N ?? ? N
MMAHCYS ? ? ? N ?
24
Testing algorithm for PA, MMA and MMAHCYS (Mayo
Clinic, USA)
25
4. Tyrosinemia type I (Tyr I)
26
First-tier tests for Tyr I

• First-tier screening tests for tyrosinemias
  detect tyrosine levels in DBS with MS/MS.
• Tyrosine elevation is not specific for Tyr I (in
  fact, tyrosine is generally higher in Tyr II and
  III).
• Tyrosine levels in babies with Tyr I can be
  relatively low during the first few days of life.
• Tyrosine elevation is most often associated with
  benign transient tyrosinemia or an increased
  protein uptake.

27
Second-tier test for Tyr I

• Succinylacetone (SA, SUAC) is a specific marker
  for Tyr I.
• Succinylacetone in DBS can be measured in a
  second-tier test or as a routine primary screen,
  both by means of MS/MS.

28
Testing algorithm for Tyr I (Mayo Clinic, USA)
29
5. Galactosemia
30
Galactosemia

• First-tier screening tests for galactosemia
  generally use assays to measure galactose plus
  galactose-1-phosphate levels in DBS (enzymatic
  test)
• the microbiological (Guthrie-)test measures
  galactose only.
• However, a positive screening result can also be
  caused by a portosystemic (liver) shunt or liver
  dysfunction.

• Therefore, newborns with abnormal screening
  results should be further tested with
  confirmatory assays.

31
Second-tier tests for galactosemia

• Beutler-test enzymatic assay for confirmation of
  galactose-1-phosphate uridyltransferase
  deficiency (GALT, classic galactosemia) in whole
  blood
• Multiplex enzyme assay using UPLC-MS/MS in DBS
  simultaneous determination of all three enzymes
  in galactose degradation

32
6. Isovaleric acidemia (IVA)
33
First-tier tests for IVA

• First-tier screening tests for IVA measure
  isovalerylcarnitine (C5) levels in DBS with
  MS/MS.
• However, a positive screening result may also be
  caused by increased 2-methylbutyrylcarnitine,
  valerylcarnitine and pivaloylcarnitine levels
  (these are not determined separately in routine
  MS/MS assays)
• 2-methylbutyrylcarnitine may be indicative for
  Short/branched-chain acyl-CoA dehydrogenase
  (SBCAD) deficiency 2-methylbutyryl-CoA
  dehydrogenase deficiency

• pivaloylcarnitine may be derived from
  pivalate-generating antibiotics (pivampicillin,
  pivmecillinam, cefditoren pivoxil, cefcapene
  pivoxil, cefteram pivoxil etc.) (pivalate
  esterification is used to improve absorption and
  oral bioavailability)

34
Second-tier tests for IVA

• LC-MS/MS-based assay for the quantitative
  analysis of isovalerylglycine in DBS
• the number of false-positive results is reduced

35
7. Maple syrup urine disease (MSUD)
36
First-tier tests for MSUD

• Deficiency of the Branched-chain alfa-ketoacid
  dehydrogenase complex results in elevated levels
  of isoleucine (Ile), leucine (Leu), valine (Val),
  and allo-isoleucine (allo-Ile, a characteristic
  biomarker for MSUD).
• However, first-tier screening tests with MS/MS
  cannot differentiate between the isomers of Leu,
  Ile, allo-Ile and hydroxyproline (OH-Pro).

• Elevated levels may also be caused by parenteral
  nutrition.

37
Second-tier tests for MSUD

• LC-MS/MS-based assay for the quantitative
  analysis of Val, Leu, Ile, allo-Ile and OH-Pro
• the number of false-positive results is reduced

38
Testing algorithm for MSUD (Mayo Clinic, USA)
39
Summary

• Second-tier tests support or exclude the
  diagnosis suggested by the primary screening
  test, and can help to differentiate between
  disorders.
• They offer higher specificity than the primary
  test without the need to obtain a new sample,
  which
• lowers the overall cost of the screening program
  and
• decreases stress and anxiety caused by repeated
  sampling.

• Second-tier tests are expected to become an
  essential part of the routine screening
  procedure.

40
Thank you for your attention!
41
References

1. Matern D, Tortorelli S, Oglesbee D, Gavrilov D,
   Rinaldo P. Reduction of the false-positive rate
   in newborn screening by implementation of
   MS/MS-based second-tier tests the Mayo Clinic
   experience (2004-2007). J Inherit Metab Dis.
   2007 30 585-592.
2. Lehotay DC, Hall P, Lepage J, Eichhorst JC, Etter
   ML, Greenberg CR. LC-MS/MS progress in newborn
   screening. Clin Biochem. 2011 44 21-31.
3. Chace DH, Hannon WH. Impact of second-tier
   testing on the effectiveness of newborn
   screening. Clin Chem. 2010 56 1653-1655.
4. Ko DH, Jun SH, Park KU, Song SH, Kim JQ, Song J.
   Newborn screening for galactosemia by a
   second-tier multiplex enzyme assay using
   UPLC-MS/MS in dried blood spots. J Inherit Metab
   Dis. 2011 34 409-414.
5. Turgeon CT, Magera MJ, Cuthbert CD, Loken PR,
   Gavrilov DK, Tortorelli S, Raymond KM, Oglesbee
   D, Rinaldo P, Matern D. Determination of total
   homocysteine, methylmalonic acid, and
   2-methylcitric acid in dried blood spots by
   tandem mass spectrometry. Clin Chem. 2010 56
   1686-1695.
6. Oglesbee D, Sanders KA, Lacey JM, Magera MJ,
   Casetta B, Strauss KA, Tortorelli S, Rinaldo P,
   Matern D. Second-tier test for quantification of
   alloisoleucine and branched-chain amino acids in
   dried blood spots to improve newborn screening
   for maple syrup urine disease (MSUD). Clin Chem.
   2008 54 542-549.

1. Shigematsu Y, Hata I, Tajima G. Useful
   second-tier tests in expanded newborn screening
   of isovaleric acidemia and methylmalonic
   aciduria. J Inherit Metab Dis. 2010 33 (Suppl
   2) S283-288.
