The Working Cell: Energy from Sunlight

1
The Working CellEnergy from Sunlight

• Chapter 8 Notes

2
Ch. 8 The Working Cell Energy from Light

• 8.1 Photosynthesis uses light energy to
  make food.
• 8.2 The light reactions convert light
  energy to chemical energy.
• 8.3 The Calvin cycle makes sugar from carbon
  dioxide.
• 8.4 Photosynthesis has a global impact.

3
8.1 Photosynthesis uses light energy to
make food.

• Objectives
• Describe the structure of a chloroplast.
• Identify the overall reactants and products of
  photosynthesis.

4
8.1 Photosynthesis uses light energy to
make food.

• Key Terms
• Chloroplast
• Chlorophyll
• Stroma
• Thylakoid
• Light reactions
• Calvin cycle

5
8.1 Photosynthesis uses light energy to
make food.

• Photosynthesis is the process by which plants
  other producers convert energy of sunlight to
  energy stored in organic molecules.
• Chloroplast organelle where photosynthesis
  takes place
• Chlorophyll chemical that gives a green color
  to chloroplasts.

6
8.1 Photosynthesis uses light energy to
make food.

• Chloroplasts structure is key to its function
• Has an inner outer membrane
• Inner membrane encloses a thick fluid called the
  stroma
• Suspended in the stroma are thylakoids
  disk-shaped sacs

7
8.1 Photosynthesis uses light energy to
make food.

• Cellular respiration fall of electrons form
  glucose to oxygen gives off energy, which is then
  used to make ATP.
• Photosynthesis is the opposite electrons from
  water are boosted uphill by the energy from
  sunlight.

8
8.1 Photosynthesis uses light energy to
make food.

• Excited electrons along with carbon dioxide
  water are used by chloroplasts to produce glucose
  oxygen.

9
8.1 Photosynthesis uses light energy to
make food.

• Photosynthesis occurs in 2 main stages.
• Light reactions convert sunlight to chemical
  energy
• Stored in NADPH ATP
• Calvin cycle makes sugar from carbon dioxide
  and H ions from the splitting of water.

10
8.1 Concept check (QUIZ)

• Draw label a simple diagram of a chloroplast
  that includes the following structures outer
  inner membranes, stroma, thylakoids.
• What are the reactants of photosynthesis, what
  are the products?
• Name the 2 main stages of photosynthesis. How
  are they related?

11
8.2 The light reactions convert light energy
to chemical energy

• Objectives
• Explain how light interacts with pigments.
• Describe how photosystems help harvest light
  energy.
• Identify the chemical products of the light
  reactions.

12
8.2 The light reactions convert light energy
to chemical energy

• Key Terms
• Wavelength
• Electromagnetic spectrum
• Pigment
• Paper chromatography
• photosystem

13
8.2 The light reactions convert light energy
to chemical energy

• Light energy is a form of electromagnetic energy
• Travels in waves (similar to ocean waves)
• Measured by wavelength distance between 2
  adjacent waves.

14
8.2 The light reactions convert light energy
to chemical energy

• Different forms of electromagnetic energy have
  characteristic wavelengths
• Electromagnetic spectrum the range of types of
  electromagnetic energy

15
8.2 The light reactions convert light energy
to chemical energy

• Pigments chemical compounds that give a
  substance its color.
• Cause different wavelengths to be
• Absorbed
• Transmitted
• Reflected

16
8.2 The light reactions convert light energy
to chemical energy

• Paper chromatography lab technique used to
  observe different pigments in substances.

17
8.2 The light reactions convert light energy
to chemical energy

• Harvesting light energy
• Photosystems clusters of pigment molecules
• Chlorophyll a
• Chlorophyll b
• Carotenoids

18
8.2 The light reactions convert light energy
to chemical energy

• Harvesting light energy
• 1)Pigments absorb light energy
• 2)transfer energy to electrons
• 3)transfer energy to electronacceptor.
• 4)converts to ATP or NADPH.

19
8.2 The light reactions convert light energy
to chemical energy

• Chemical products of the light reactions
• Oxygen, released as a waste product of the 1st
  photosystem.
• ATP produced by the release of energy by the
  electron transport chain between photosystems.
• NADPH produced by the second photosystem

20
8.2 Concept check

• Explain why a leaf appears green.
• Describe what happens when a molecule of
  chlorophyll a absorbs light.
• Besides oxygen, what 2 molecules are produced by
  the light reactions?
• Where in the chloroplast do the light reactions
  take place?

21
8.3 The Calvin cycle makes sugar from
carbon dioxide

• Objectives
• Explain how the Calvin cycle makes sugar.
• Summarize the overall process of photosynthesis.

22
8.3 The Calvin cycle makes sugar from
carbon dioxide

• The Calvin cycle
• Called a cycle because the starting material RuBP
  is regenerated each time the process occurs
• RuBP is a 5 carbon sugar

23
8.3 The Calvin cycle makes sugar from
carbon dioxide

• Into the Calvin cycle
• Carbon dioxide
• ATP
• NADPH

24
8.3 The Calvin cycle makes sugar from
carbon dioxide

• Outputs of Calvin cycle
• G3P (an energy rich sugar)
• Not yet glucose
• Used by plant to make glucose
• ADP P
• NADP

25
8.3 The Calvin cycle makes sugar from
carbon dioxide

• Summary of photosynthesis
• Light reactions
• Convert light energy to chemical energy
• Occurs in thylakoids
• Uses water (reactant) releases oxygen (product)

26
8.3 The Calvin cycle makes sugar from
carbon dioxide

• Calvin cycle
• Occurs in stroma
• Uses ATP NADPH
• Converts carbon dioxide (reactant) to sugar
  (product)

27
8.3 Concept check

• What are the inputs outputs of the Calvin
  cycle?
• Which stage of photosynthesis uses each reactant
  from the overall photosynthesis equation? Which
  stage generates each product from the overall
  photosynthesis equation?

28
8.3 Concept check

• Why is the Calvin cycle called a cycle?
• What molecule is the direct product of
  photosynthesis? How is that molecule then used
  by the plant cell?

29
8.4 Photosynthesis has a global impact.

• Objectives
• Describe the path of carbon in the carbon cycle.
• Explain how photosynthesis is related to climate.

30
8.4 Photosynthesis has a global impact.

• Key Terms
• Carbon cycle
• Greenhouse effect

31
8.4 Photosynthesis has a global impact.

• Processes that occur on a global scale depend on
  chloroplasts mitochondrion
• Carbon cycle process by which carbon moves from
  inorganic to organic back to inorganic.

32
8.4 Photosynthesis has a global impact.

• Path of carbon in the carbon cycle
• Producers convert inorganic carbon to organic
  carbon through photosynthesis.
• Consumers eat the producers, may be eaten by
  other consumers.
• Cellular respiration by both producers
  consumers eventually carbon dioxide to the
  atmosphere

33
8.4 Photosynthesis has a global impact.

• Plants other photosynthetic organisms make
  about 160 billion metric tons of organic
  material.
• 80 trillion copies of book
• 25 stacks reaching to the sun.

34
8.4 Photosynthesis has a global impact.

• Carbon dioxide in the atmosphere traps in heat
  greenhouse effect
• Keeps world climate warm enough for living
  things.
• Average 10C warmer than it would be.
• Amount of carbon dioxide in atmosphere is rising.

35
Photosynthesis
36
Stages of Photosynthesis
37
Electromagnetic spectrum
38
Pigments Color
39
Harvesting Light Energy
40
Chemical products of light reactions
41
Calvin cycle
42
Photosynthesis
43
Greenhouse effect
44
Light Waves
