Title: Circadian Rhythms


1
Circadian Rhythms
  • ???
  • (????)

2
Index
  • Intro - What is the circadian rhythm?
  • Mechanism in reality
  • How can we understand it?
  • ? Nonlinear dynamics
  • Limit cycle
  • Linearization and stability
  • Stochastic resonance
  • Coupled nonlinear oscillators
  • Summary - What have we learned?

3
Circadian rhythm?
  • circa means round about
  • dies means a day
  • ? About-a-day-period behavioral rhythm
  • Sleep-wake cycle, Insect eclosion,
  • Circadian rhythm vs. cell cycle?(ref)

4
Is 24 hours a long time?
  • If we think that a day is long time
  • ? A trap!-Two short period oscillator model
  • ? long period is extremely sensitive to changes
    in the short period.
  • because long periods are inconvenient in the
    laboratory (Winfree)
  • ? aging, female endocrine cycle, replacement of
    membrane phospholipids

5
What we know about circadian rhythms I
  • Scale
  • In temporal scale ? About 24 hours(ref)
  • In spatial scale ? From a single cell to complex
    multicelluar organisms in synchrony
  • In the kingdom of life ? from bacteria to mammals
    (synechococcus, neurospora, drosophila, mouse,
    human,)

6
What we know about circadian rhythms II
  • Reliability
  • Period conservation under temperature variation
    (temperature compensation)
  • Immunity to many kinds of chemical perturbation
  • Sensitivity to visible light of an appropriate
    color
  • Slow entrainment to outside environment

7
Dunlaps viewpoint about circadian clock research
  • Mechanism - how does the clock work?
  • Input how does outer world entrain the clock?
  • Output how does the clock control the entire
    organism?

8
Viewpoint of this presentation(mech-specific)
  • First, How can we make a 24-hours clock in a
    single cell?
  • We get a clock, then how do cells in a tissue
    synchronize with each other?
  • We get tissues in synchrony, then how do tissues
    synchronize all over the body?

9
Discovered Mechanism in a cell
  • Positive element vs. negative element
  • Positive element enhance both
  • Negative element inhibit positive element
  • Negative element has slower dynamics
  • This mechanism is fundamental in the neuron
    interaction model(ref)
  • Simplest example which has a limit cycle

10
Mechanism in a diagram
11
How can we understand it?
  • Nonlinear dynamics!
  • Why nonlinear?
  • Nonlinear systems are ubiquitous
  • Zoology Metaphor
  • Linear systems can be broken down into parts
    (superposition principle. 224) nonlinear ?
    emergence, holism, stability
  • Noise tolerance

12
Basic concepts
  • ODE(ordinary differential equation)
  • Ex) pendulum

13
Basic concepts
  • Phase space

14
Geometric paradigm of dynamics
  • Classical method
  • Find analytical solution
  • Approximations (linearization)
  • With trajectory in phase space,
  • ? Find Geometry of phase space

15
Geometry of dynamics
16
Fixed point and stability analysis
  • Fixed point a point where
  • Give a small disturbance, then watch linear terms
  • Stable, unstable, saddle

17
Limit cycle ? clock
  • Isolated closed trajectory
  • Only in nonlinear system(linear systems wont be
    isolated)

18
Slaving principle(pseudo-steady state)
  • For fast variable and slow variable
  • Fast variable is a slave of slow variable
  • ? reduction of number of variables

19
Poincare-Bendixson theorem
  • If an annulus region in 2d
  • Has no stable fixed point
  • Has only trajectories which are confined in it
  • ? There exist limit cycles

20
noise-induced dynamics(Stochastic resonance)
  • Noise ? what is to be removed
  • Noise ? what is important in dynamics
  • Noise enhance signal (stochastic resonance,
    coherent resonance)
  • Climate change (Phys.Rev.Lett., 88,038501)
  • Sensory system(PRL, 88,218101)
  • Noise can do work
  • Molecular ratchet, Parrondos paradox(ref)

21
Stochastic resonance
22
The clock
23
The clocks state
C
R
24
Analysis of the clock
  • The Clock has so many variable.
  • ? pick up two slowest variable R, C
  • Can the reduced system exhibit clock limit
    cycle behavior?
  • ? stability analysis of fixed point and
    application of poincare-bendixon theorem

25
Analysis of the clock
Null cline
Fixed point
26
Stochastic resonance in the clock
27
Synchronization of the clocks
  • Clock ? Limit cycle or oscillator
  • Interacting clocks ? coupled oscillators

28
Synchronization of nonlinear oscillators
Huygens - pendulum clock
29
Sync in nonlinear oscillators
  • Winfree model
  • Modified general model(Kuramoto)

30
SCN The master clock
  • In the hypothalamus of the brain
  • Recept light signal from retina
  • About 20000 neuron
  • Negative elements Period(Per),
    Cryptochrome(Cry)
  • Positive elements Clock, Bmal1

31
Synchronization in SCN
  • SCN ? coupled oscillators
  • If f(-x) -f(x), and if K s are all symmetric,
  • Then collective frequency is mean of all.
  • Cell, 91,855 hamster SCNs period determination

32
Organization of Circadian Clock
33
What have we learned?
  • Study PHYSICS!
  • Abundant Nonlinearity in biology
  • Nonlinear dynamics is important for dynamical
    systems (ex. circadian clock)
  • Noise effects are important in life
  • Organisms actively use noise. (muscle, circadian
    clock)

34
References
  • About nonlinear science and mathematical tools
  • A.T.Winfree, The Geometry of Biological Time
    (1990)
  • ? 2nd edition published in 2001
  • S.H.Strogatz, Nonlinear dynamics and chaos
    (1994)
  • J.D.Murray, Mathematical Biology (1993)
  • H.R.Wilson, Spikes, decisions, and actions
    (1999)
  • About coupled oscillators
  • A.T.Winfree, The geometry of biological time
    (1990)
  • S.H.Strogatz, Sync published in 2003
  • S.H.Strogatz et al., Coupled oscillators and
    biological synchronization, Scientific american
    vol 269, No. 6 (1993)
  • S.H.Strogatz, From Kuramoto to Crawford, Physica
    D, 143, 1 (2000)
  • C.L et al. and S.H.Strogatz, Cell, 91,855 (1997)

35
References
  • About single cell level circadian rhythm
  • J.C.Dunlap, Molecular bases for Circadian
    Clocks, Cell, vol 96, 271 (1999) (Review)
  • N.Barkai and S.Leibler, Nature, 403, 268 (1999)
  • J.M.G.Vilar et al., PNAS, 99, 5988 (2002)
  • N.R.J.Glossop et al., Science, 286, 766 (1999)
    (mechanism of drosophila clock genes)
  • S.Panda et al., Circadian rhythm from flies to
    human, Nature, 417,329 (2002)
  • Why circadian, circannual rhythms are not
    precisely one day or one year?
  • H.Daido, Phys. Rev. Lett. 87, 048101 (2001)
  • The circadian oscillator can be synchronized by
    light without input from eyes
  • U.Schibler, Nature, 404, 25 (2000)

36
References
  • About synchronization between tissues or
    organisms
  • U.Schibler, et al., A web of circadian
    pacemaker, Cell, 111,919 (2002)
  • S.M.Reppert et al., Coordination of circadian
    timing in mammals, Nature, 418,935 (2002)
  • M.H.Hastings, nature, 417,391 (2002)
  • K.Stokkan et al., Science, 291,490 (2001)
  • J.D.Levine et al., Science, 298,2010 (2002)
  • Cancer connection
  • M.Rosbash et al., Nature, 420,373 (2002)

37
References
  • Stochastic resonance
  • L.Gammaitoni et al., Rev. Mod. Phys. 70, 223
    (1998)
  • Molecular ratchet Parrondos paradox
  • R.D.Astumian et al., Phys.Rev.Lett.,72,1766
    (1994)
  • G.P.Harmer et al., Nature, 402,864(1999)
  • J.M.R.Parrondo et al., Phys.Rev.Lett., 85, 5226
    (2000)
  • R.Toral et al., cond-mat/0302324 (2003)
