Information Systems Analysis and Design

1
Information Systems Analysis and Design
Information Systems
Section A
CHAPTER 9
PARSONS/OJA
Page 442
2
Information Systems Analysis and Design
Chapter 9
Chapter PREVIEW

• Information systems
• Types of information systems
• System development life cycle (SDLC)

Page 443
3
Information Systems
Section A
Chapter 9
What is an information system?

• An information system collects, stores, and
  processes data to provide useful, accurate, and
  timely information
• Information is used to make decisions

Page 444
4
Information Systems
Section A
Chapter 9
Who uses information systems?

• Top management makes decisions with long-range
  impact. Referred to as strategic planning
• Summarized information for entire company
• Mid-level managers set incremental goals that can
  be achieved in a year or lessa process referred
  to as tactical planning
• Information relevant to managers
  responsibilities
• Low-level managers are responsible for scheduling
  employees, ordering supplies, and other
  activities that make day-to-day operations run
  smoothlya process referred to as operational
  planning
• Detailed information

Page 445
5
Information Systems
Section A
Chapter 9
How do information systems help the people in
an organization?

• An information system can help the people in an
  organization perform their jobs more quickly and
  effectively by automating routine tasks
• Online banking
• One of the major functions of an information
  system is to help people make decisions in
  response to problems
• Price for flight from Dallas to Chicago on
  Southwest

Page 446
6
Information Systems
Section A
Chapter 9
Do organizations require different kinds of
information systems?

• Because organizations have different missions,
  face different threats, and encounter different
  opportunities, they require different kinds of
  information systems

Page 448
7
Information Systems
Section A
Chapter 9
Types of information systems

• Office automation systems
• Transaction processing systems
• Management information system
• Decision support system
• Expert systems
• Neural networks
• Data base mining

Page 448
8
Information Systems
Section A
Chapter 9
Office Automation Systems

• An office automation system automates, or
  computerizes, routine office tasks
• Reorder of inventory

Page 448
9
Information Systems
Section A
Chapter 9
Transaction Processing Systems Whats a
transaction?

• A transaction is an event that requires a manual
  or computer-based activity
• Order a cheeseburger at McDonalds
• Most modern transaction processing systems use
  online processing. Such systems are often
  referred to as OLTPS (online transaction
  processing systems)
• Adding/dropping classes at EIU

Page 449
10
Information Systems
Section A
Chapter 9
What are common examples of transaction
processing systems?

• A point-of-sale (POS) system records items
  purchased at each cash register, and calculates
  the total amount due for each sale
• An order-entry/invoice system provides a way to
  input, view, modify, and delete customer orders
• A general accounting system records the financial
  status of a business by keeping track of income,
  expenses, and assets
• An e-commerce system collects orders and
  processes credit card payments

Page 450
11
Information Systems
Section A
Chapter 9
Management Information Systems What is a
management information system?

• A management information system (MIS) refers to a
  type of information system that uses the data
  collected by a transaction processing system, but
  manipulates that data to create reports that
  managers can use to make routine business
  decisions in response to structured problems

Page 450
12
Information Systems
Section A
Chapter 9
What is a management information system?

• One of the major goals of an MIS is to increase
  the efficiency of managerial activity
• A summary report combines or groups data and
  often shows totals
• Top management
• An exception report contains information that is
  outside of normal or acceptable ranges
• Middle management regions where GM SUV sales
  below monthly forecast
• Scheduled reports follow a fixed format and are
  produced according to a preset timetable
• An ad hoc report is a customized report,
  generated to supply specific information not
  available in scheduled reports
• Impact of SARS on airlines at Torontos airport

Page 451
13
Information Systems
Section A
Chapter 9
How does an MIS differ from a TPS?

• Whereas a TPS simply records data, an MIS can
  consolidate data by grouping and summarizing it
• TPS provides raw material
• MIS is finished product

Page 451
14
Information Systems
Section A
Chapter 9
What are the limitations of a management
information system?

• A traditional MIS is based on the data collected
  by a transaction processing system
• Employee morale
• The reports generated by an MIS are limited by
  the processing capabilities of the database
  software.
• The MIS cannot typically be used to create models
  or projections

Page 451
15
Information Systems
Section A
Chapter 9
Decision Support Systems Whats a decision
support system?

• A decision support system (DSS) helps people make
  decisions by directly manipulating data,
  analyzing data from external sources, generating
  statistical projections, and creating data models
  of various scenarios

Page 452
16
Information Systems
Section A
Chapter 9
Whats a decision support system?

• A DSS does not make decisions, however. That
  task remains the responsibility of the human
  decision maker
• A decision model is a numerical representation of
  a realistic situation
• A decision query is a question or set of
  instructions describing data that must be
  gathered to make a decision
• Pujols has hit .537 against left handed pitchers
• A DSS typically includes modeling tools so
  managers can create a numerical representation of
  a situation and explore what-if alternatives

Page 452
17
Information Systems
Section A
Chapter 9
What are the limitations of a DSS?

• A DSS helps people manipulate the data necessary
  to make a decision, but does not actually make a
  decision
• A DSS is appropriate in situations where it is
  used by trained professionals

Page 453
18
Information Systems
Section A
Chapter 9
Expert Systems What is an expert system?

• An expert system, sometimes referred to as a
  knowledge-based system, is a computer system
  designed to analyze data and produce a
  recommendation, diagnosis, or decision based on a
  set of facts and rules
• The facts and rules for an expert system are
  typically derived by interviewing one or more
  experts, and then incorporated into a knowledge
  base
• What percent of my portfolio should be invested
  in stocks?

Page 453
19
Information Systems
Section A
Chapter 9
Expert Systems What is an expert system?

• Use data base of knowledge to draw conclusions
• Data base is If, Then knowledge
• Rules of thumb provided by expert individuals
• Can handle routine situations with great
  accuracy leaves complex situations to humans
• Can explain why it reached conclusion loan
  denied because
• Each expert system is designed to make decisions
  in a particular area or domain
• Credit card fraud, HP printer support

Page 453
20
Information Systems
Section A
Chapter 9
Neural networks

• An expert system begins with a set of facts and
  rules. But if the rules are not known, a
  computer can learn how to make decisions based
  on hundreds or thousands of lightning-fast trial
  and error attempts
• A neural network uses computer circuitry to
  simulate the way a brain might process
  information, learn, and remember
• Looks for patterns that work
• May use genetic algorithms where only the best
  solutions survive

Page 455
21
Information Systems
Section A
Chapter 9
Neural networks are used when

• There are not hard and fast solutions such as
  pattern recognition and forecasting
• Neural nets are well suited to problems that
  people are good at solving, but for which
  computers are not.
• What are the characteristics of a terrorist?

Page 455
22
Information Systems
Section A
Chapter 9
Data base mining

• automated extraction of predictive information
  from large databases
• What customer will respond to a catalog of bird
  feed and houses?
• Deep Blue used data mining to calculate all
  possible moves and selected best move
• Confirming or discovering patterns in huge data
  bases

Page 455
23
Information Systems
Section A
Chapter 9
Data base mining

• Pattern validation
• Confirm existence of expected patterns.
• Visits to Health Service in November versus
  September
• Top down data mining
• May not ask about the right patterns.
• Pattern discovery
• 75 of the purchasers of low-fat ice cream buy
  bottled water

Page 455
24
Systems Analysis
Section B
Chapter 9
What is a system development life cycle?
Page 458
25
Systems Analysis
Section B
Chapter 9
Planning Phase How does an information system
project begin?

• An information system project begins with a
  planning phase
• The goal of these activities is to create a
  Project Development Plan
• This planning document includes
• A short description of the project, including its
  scope
• A justification for the project
• A list of project team participants
• A schedule for the project, including an outline
  of its phases

Page 456
26
Systems Analysis
Section B
Chapter 9
Justify Project Why are new information
systems developed?

• The justification for a new information system
  usually emerges from a serious problem with the
  current system, or from an opportunity to improve
  an organizations products or services using
  technology
• Perhaps your network cant handle traffic trying
  to use the Internet at peak times

Page 457
27
Systems Analysis
Section B
Chapter 9
Analysis Phase What happens in the analysis
phase?

• The goal of the analysis phase is to produce a
  list of requirements for a new or revised
  information system

Page 460
28
Systems Analysis
Section B
Chapter 9
Is it really important to understand the
current system before planning a new system?

• Typically, a new information system is designed
  to replace a system or process that is already in
  place
• It is important to study the current system to
  understand its strengths and weaknesses before
  planning a new system

Page 460
29
Systems Analysis
Section B
Chapter 9
Determine System Requirements How does the
project team determine what the new system should
do?

• System requirements are the criteria for
  successfully solving the problem or problems
  identified in an information system
• They also serve as an evaluation checklist at the
  end of the development project, so they are
  sometimes called success factors

Page 461
30
Systems Analysis
Section B
Chapter 9
What marks the end of the analysis phase of the
SDLC?

• The analysis phase concludes when the project
  team produces a written report that documents its
  findings
• The System Requirements Report typically contains
  diagrams that illustrate what the new information
  system should do
• Should we do the same thing when we buy a
  personal computer?

Page 462
31
System Design
Section C
Chapter 9
Design Phase What happens in the design phase?

• In the design phase of the SDLC, the project team
  must figure out HOW the new system will fulfill
  the requirements specified in the System
  Requirements Report

Page 464
32
System Design
Section C
Chapter 9
Identify Potential Solutions How does the
project team come up with solutions?

• There might be more than one way to solve the
  problems and meet the requirements identified in
  the analysis phase of the SDLC
• The project team should identify several
  potential hardware and software solutions by
  brainstorming and researching case studies on
  Web sites and in computer magazines

Page 464
33
System Design
Section C
Chapter 9
What kinds of hardware alternatives are
available?

• A myriad of hardware options are available for
  information systems
• Mainframes, servers, and personal computers are
  the most commonly used components, but in some
  information systems, handhelds, or even
  supercomputers, play a role

Page 464
34
System Design
Section C
Chapter 9
What kinds of software alternatives are
available?

• The project team might consider software
  alternatives, such as whether to construct the
  system from scratch, use an application
  development tool, or commercial software
• Creating an information system from scratch
  using a programming language can take many months
  or years
• An application development tool is essentially a
  type of software construction kit containing
  building blocks that can be assembled into a
  software product

Page 466
35
System Design
Section C
Chapter 9
What kinds of software alternatives are
available?

• Commercial software for an information system is
  usually a series of pre-programmed software
  modules, supplied by a software developer,
  consulting company, or value-added reseller (VAR)
• A turnkey system is essentially an information
  system in a box which consists of hardware and
  commercial software designed to offer a complete
  information system solution
• A turnkey system must be extensively evaluated to
  determine whether it can satisfy system
  requirements

Page 466
36
System Design
Section C
Chapter 9
Evaluate Solutions and Select the Best How
does the team choose the best solution?

• To determine the best solution the project team
  devises a list of criteria for comparing each of
  the potential solutions
• Each criterion is assigned a weight to indicate
  its importance. The project team then evaluates
  the criteria for each solution and assigns raw
  scores
• Sound complicated? It isnt, especially if the
  project team uses a decision table

Page 467
37
System Design
Section C
Chapter 9
Select Hardware and Software How does the
project team find the right hardware and software
for the new information system?

• Once the project team selects a solution, the
  next task is to select the hardware and software
  needed to implement the solution
• The method for selecting the hardware, software,
  and vendor depends on the project teams
  understanding of what is required for the solution

Page 467
38
System Design
Section C
Chapter 9
Develop Application Specifications What
happens after the project team selects a solution?

• Exactly what happens next in the system design
  phase depends on the type of solution selected
• If the project team selected a solution that
  requires custom programming, the teams systems
  analysts will create a set of application
  specifications

Page 469
39
System Design
Section C
Chapter 9
What happens to the completed specifications?

• Application specifications are similar to the
  pages of an architectural blueprint that show the
  detailed plan for electrical wiring or plumbing
• In a large information systems project, the
  specifications are given to a programming team or
  application developer who creates the software
• In a small information systems project, you as
  the user might develop your own specifications

Page 470
40
Implementation and Maintenance
Section D
Chapter 9
Implementation Phase What happens during the
implementation phase?

• During the implementation phase of the SDLC, the
  project team supervises the tasks necessary to
  construct the new information system

Page 471
41
Implementation and Maintenance
Section D
Chapter 9
Purchase and Install Hardware and Software Do
most new information systems require new hardware?

• Most new information systems require new
  hardware, which can either replace old equipment,
  or be connected to existing equipment

Page 471
42
Implementation and Maintenance
Section D
Chapter 9
How about new software?

• Many information systems require new software,
  such as a commercial application, a programming
  language, an application development tool, or an
  expert system shell

Page 471
43
Implementation and Maintenance
Section D
Chapter 9
Test Applications How can the team ensure that
a new information system works?

• A rigorous testing process is the only way to
  make sure that a new information system works

Page 472
44
Implementation and Maintenance
Section D
Chapter 9
What is application testing?

• Application testing is the process of trying out
  various sequences of input values and checking
  the results to verify that the application works
  correctly
• As each application module is completed, it
  undergoes unit testing to ensure that it operates
  reliably and correctly
• When all modules have been completed and tested,
  integration testing is performed to ensure that
  the modules operate together correctly

Page 472
45
Implementation and Maintenance
Section D
Chapter 9
Train Users How do employees learn how to use
the new information system?

• In preparation for using a new information
  system, users need extensive training, which
  might include hardware operation, data entry, and
  backup procedures
• Training sessions can be conducted by members of
  the team or professional trainers
• Resistance to change!!!

Page 473
46
Implementation and Maintenance
Section D
Chapter 9
Convert to New System How does a business
switch from the old system to the new system?

• System conversion refers to the process of
  deactivating an old information system and
  activating the new one
• A direct (crash) conversion means that the old
  system is completely deactivated and the new
  system is immediately activated
• A parallel conversion avoids some of the risk
  because the old system remains in service while
  some or all of the new system is activated
• In a phased conversion, the new system is
  activated one module at a time

Page 474
47
Implementation and Maintenance
Section D
Chapter 9
How does a business switch from the old system
to the new system?

• A pilot conversion works well in organizations
  with several branches that have independent
  information processing systems
• The new information system is activated at one
  branch
• If the system works correctly at one branch, it
  is activated at the next branch

Page 474
48
Implementation and Maintenance
Section D
Chapter 9
Maintenance Phase What happens during the
maintenance phase?

• The maintenance phase of the SDLC involves
  day-to-day operation of the system, making
  modifications to improve performance, and
  correcting problems
• The maintenance phase of the SDLC is the most
  expensive because it lasts until the system is
  retired

Page 475
49
Implementation and Maintenance
Section D
Chapter 9
Why do maintenance activities include user
support?

• Even after-in-depth training, employees sometimes
  forget procedures, or have difficulty when they
  encounter a new set of circumstances
• Many organizations establish a help desk to
  handle end-user problems

Page 476
50
Implementation and Maintenance
Section D
Chapter 9
Does an information system change during the
maintenance phase?

• The term maintenance phase is a bit misleading
• Changes during the maintenance phase typically
  include the following
• Upgrades to operating system and commercial
  software
• User interface revisions
• Application software revisions
• Hardware replacements
• Security upgrades

Page 477
51
Implementation and Maintenance
Section D
Chapter 9
When does the maintenance phase end?

• The maintenance phase continues until an
  information system is no longer cost effective,
  or until changes in the organization make the
  information system obsolete
• Then cycle begins again with the development of a
  replacement system

Page 477
