Anatomy

1

• Anatomy Radiographic and otherwise

Medical Environmental Research Learning INstitute
2
Lesson Goals

• Avian-specific anatomy
• Judge a radiograph for proper positioning and
  quality
• Identify boney structures
• Identify soft tissue structures
• Recognize common abnormalities

Medical Environmental Research Learning INstitute
3
Feathers

• Remiges wing feathers
• 10 primaries
• numbered 1 to 10 from the wrist
• originate from the metacarpal and digit bones
• 10 secondaries (variable)
• numbered 1 to 10 from the wrist
• originate from the dorsal ulna periosteum

Medical Environmental Research Learning INstitute
4
Feathers
lt- Primaries
Secondaries-gt
10
1
1
4
3
Medical Environmental Research Learning INstitute
5
Feathers

• Retrices tail feathers
• 6 pairs numbered from the center

Medical Environmental Research Learning INstitute
6
Feathers

• Development
• In blood very fragile
• Preening required for proper growth
• Bandages can inhibit growth

• Protect the feathers!

Medical Environmental Research Learning INstitute
7
Patagium

• pp propatagium
• lp ligamentum propatagialis
• h humerus
• u - ulna

1
2
3
4
Medical Environmental Research Learning INstitute
8
Talons

• Digits are numbered 1 to 4 starting from the
  hallux and going medially
• Digits 1 and 2 are the most important
• Talons are a thin layer of keratin over a boney
  core\phalange

1
2
3
4
Medical Environmental Research Learning INstitute
9
Beak

• Talons are a thin layer of keratin over a boney
  core\phalange
• Beak is a thin layer of keratin over a boney core

Medical Environmental Research Learning INstitute
10
GI tract

• Hawks have a crop. Owls do not
• Two-part stomach
• Proventriculus
• Ventriculus grinding stomach but not so much in
  raptors.

Medical Environmental Research Learning INstitute
11
Respiratory tract

• Trachea
• Complete rings do not use cuffed ET tube.
• No diaphragm
• Must move keel to breath. Do not hold to tightly.
• Syrinx
• Common place for obstructions
• Source of voice

Medical Environmental Research Learning INstitute
12
Respiratory tract

• Air sacs
• Cervicocephalic
• infraorbital sinus under eye
• Cranial
• cervical, clavicular, cranial thoracic
• Caudal
• caudal thoracic, abdominal
• Extend into femur, humerus, vertebrae
• They allow for easy endoscopic examination

Medical Environmental Research Learning INstitute
13
Respiratory tract

• Birds exchange O2 much more efficient.
• Two cycles required for air to enter and leave.
• Fresh air is always entering the lungs (on
  inspiration and exhalation)

Medical Environmental Research Learning INstitute
14
Eyes

• Shape
• AP flattened parrots, pigeons
• Conical hawks
• Tubular owls
• Scleral ossicles
• No extra-occular muscles
• Lower lid is more mobile

Medical Environmental Research Learning INstitute
15
Eyes

• Iris contains striated muscle
• Complete deccussation of nerve fibers
• Retina
• Avascular
• No tapeturm lucidum
• Pectin

Medical Environmental Research Learning INstitute
16
Proper positioning - VD

• Keel should overlay the spine
• Legs should be pulled downward so that the elbows
  and stifles do not overlap
• Wings pulled out symmetrically

Medical Environmental Research Learning INstitute
17
Proper positioning - lateral

• Acetabullae should overlap
• Coracoids should overlap
• Wings pulled back ( requires anesthesia)

Medical Environmental Research Learning INstitute
18
Positioning
Medical Environmental Research Learning INstitute
19
Positioning
Medical Environmental Research Learning INstitute
20
Positioning
Medical Environmental Research Learning INstitute
21
Shoulder joint

• Complex joint with many bones
• Humerus
• Pectoral crest
• Ventral tubercle
• Head of humerus
• Coracoid
• Scapula
• Clavicle

Medical Environmental Research Learning INstitute
22
Proximal wing

• Humerus
• Distal condyles
• Ulna
• Olecranon
• Secondary feather attachements
• Notice the curve
• Radius

Medical Environmental Research Learning INstitute
23
Distal wing

• Ulna
• Radius
• Radial carpal bone
• Ulnar carpal bone
• Alula (D1)
• Major metacarpal
• Minor metacarpal
• Phalanges of D2

Medical Environmental Research Learning INstitute
24
Pelvis

• Synsacrum
• Pelvis
• Illium
• Ischium
• Pubis
• Acetabullum
• Femur
• Head and neck
• Pygostyle

Medical Environmental Research Learning INstitute
25
Proximal leg

• Femoral condyles
• Patella and groove
• Tibiotarsus (not tibia)
• Fibula
• Tibiotarsal condyles

Medical Environmental Research Learning INstitute
26
Distal leg

• Tibiotarsal condyles
• Tarsometatasus
• Hallux (1)
• Metatarsal 1
• Digits 2-4
• Phalanges

Medical Environmental Research Learning INstitute
27
Soft tissue structures - VD

• Heart
• Liver
• Hour-glass
• Lungs
• Air sacs
• Intestines
• Ventriculus

Medical Environmental Research Learning INstitute
28
Heart-liver Hour glass
Medical Environmental Research Learning INstitute
29
Soft tissue structures - lateral

• Lung
• Heart
• Liver
• Spleen
• Proventriculus
• Ventriculus
• Kidney

• Acetabullae should overlap
• Coracoids should overlap
• Wings pulled back ( requires anesthesia)

Medical Environmental Research Learning INstitute
30
What do you see?
Medical Environmental Research Learning INstitute
31
What do you see?
Medical Environmental Research Learning INstitute
32
Compared these two
33
What do you see?
Medical Environmental Research Learning INstitute
34
What do you see?
Medical Environmental Research Learning INstitute
35
What do you see?
Pre-op
2 weeks later
Medical Environmental Research Learning INstitute
36
Fracture healing
6 weeks later
Medical Environmental Research Learning INstitute
37
What do you see?
Medical Environmental Research Learning INstitute
38
What do you see?
Medical Environmental Research Learning INstitute
39
What do you see?
Medical Environmental Research Learning INstitute
40
What do you see?
Medical Environmental Research Learning INstitute
41
What do you see?
Medical Environmental Research Learning INstitute
42
What do you see?
Medical Environmental Research Learning INstitute
43
What do you see?
Medical Environmental Research Learning INstitute
44
What do you see?
Medical Environmental Research Learning INstitute
45
What do you see?
Medical Environmental Research Learning INstitute
46
And finally
Medical Environmental Research Learning INstitute
47
References
Medical Environmental Research Learning INstitute
48
Questions?

• Dave Scott, DVM
• Carolina Raptor Center
• P.O. Box 16443
• Charlotte, NC 28297
• 704-875-6521
