Title: Fair Cycle Detection: A New Algorithm and a Comparative Study


1
Fair Cycle Detection A New Algorithm and a
Comparative Study
  • Fabio Somenzi
  • University of Colorado at Boulder

2
Acknowledgement
  • This talk is the conflation of
  • Kavita Ravi, Roderick Bloem, and Fabio Somenzi,
    A comparative study of symbolic algorithms for
    the computation of fair cycles
  • Roderick Bloem, Hal Gabow, and Fabio Somenzi, An
    algorithm for strongly connected component
    analysis in n log n symbolic steps
  • Both presented at FMCAD00

3
Model Checking
  • Given
  • A finite state transition structure
  • A property (set of admissible behaviors) usually
    specified as
  • Temporal logic formula
  • ?-regular automaton
  • Decide whether initial states of structure
    satisfy property

4
Properties
  • Safety properties
  • violation described as finite path
  • Liveness properties
  • infinite path (cycles)
  • ?-regular automata acceptance, fairness
  • Büchi, Muller, Rabin, Streett, L-process

5
SCC Decomposition
  • Find all sets of nodes that can reach each other
    (Strongly Connected Components)
  • SCC is trivial if it contains no edges
  • Central graph problem
  • Tarjans algorithm is linear, but explicit
  • Find a good implicit algorithm

6
Motivation
  • Fair cycle detection algorithms
  • Symbolic vs. explicit state search
  • Many symbolic algorithms, no systematic
    comparisons
  • What really makes the difference?
  • Can we improve over O(n2) ?

7
Outline
  • Motivation
  • Introduction
  • Fair cycle algorithms
  • A general framework
  • Lockstep algorithm
  • How do the different algorithms fare?
  • Conclusions

8
Büchi Emptiness
  • A Büchi automaton accepts at least a word if it
    has a nontrivial SCC that contains an accepting
    state
  • Used in
  • LTL model checking (Spin, SMV)
  • Fair CTL model checking (VIS, SMV)
  • Language-containment checking (COSPAN)
  • If language not empty, produce witness

9
Notation
  • CTL
  • EX, EU, EG, EF (future tense, backward)
  • EY, ES, EH, EP (past tense, forward)
  • Fixpoint operators
  • ?, ?

10
Symbolic Algorithms
  • Sets are represented by their characteristic
    functions
  • No loops over the elements of sets
  • Instead
  • Union, intersection, complementation
  • Check for equality (emptiness)
  • (Choice of one element)
  • Image (EY), preimage (EX)

11
Symbolic Complexity
  • Number of variables is important
  • Sets of nodes have 1 set of variables
  • Transition relation has 2 sets
  • Number of variables sets for operations
  • Boolean operations 1 set
  • Image, preimage 2 sets
  • Transitive closure 3 sets
  • Our Measure is number of steps image and
    preimage
  • Keep transition relation constant!

12
Known Complexity
  • Measured in nodes (n)
  • Known results (symbolic)
  • SCC decomposition O(n2) Xie Beerel 99
  • Büchi emptiness O(n2) Emerson Lei 86
  • We also measure number of steps as function of
    number of nodes, but

13
Interesting Parameters
  • n number of states
  • d Diameter of the graph
  • Largest (finite) of the shortest distances
    between two nodes
  • h Height of the SCC quotient graph
  • How many SCCs we can have along a path
  • N Number of SCCs
  • N Number of nontrivial SCCs
  • C Number of fairness constraints

14
Outline
  • Motivation
  • Introduction
  • Fair cycle algorithms
  • A general framework
  • Lockstep algorithm
  • How do the different algorithms fare?
  • Conclusions

15
Symbolic Fair Cycle Computations
16
SCC Hull Algorithms
  • Generic SCC Hull algorithm (GSH)
  • Emerson-Lei
  • Hojati et al.
  • Kesten et al.
  • Hardin et al.

17
Generic SCC Hull Algorithm (GSH)
  • SCC hull a set of states that contains all fair
    SCCs
  • Operators
  • TB EX(Z), E(Z U Z?c)
  • TF EY(Z), E(Z S Z?c)
  • Algorithm start with all states, at every
    iteration
  • choose and apply an operator from TB or TF
    (operator schedules)
  • converge when no change in state set under TB OR
    TF operators (weaker condition)

18
Instances of GSH Different operator schedules
19
SCC Quotient Graph
Trivial
Non-trivial
6
7
15
3
2
8
1
14
4
9
16
10
5
13
11
12
20
SCC Quotient Graph
Trivial
Non-trivial
Emerson-Lei, Hojati
6
7
15
3
2
8
1
14
4
9
16
10
5
13
11
12
21
SCC Quotient Graph
Trivial
Non-trivial
Hojati, Kesten
6
7
15
3
2
8
1
14
4
9
16
10
5
13
11
12
22
SCC Quotient Graph
Trivial
Non-trivial
Hojati, Hardin
6
7
15
3
2
8
1
14
4
9
16
10
5
13
11
12
23
SCC Quotient Graph
Trivial
Non-trivial
GSH (TF convergence)
6
7
15
3
2
8
1
14
4
9
16
10
5
13
11
12
GSH (TB convergence)
24
Generic SCC-Hull Algorithm
  • TB EX(Z), E(Z U Z?ci)
  • TF EY(Z), E(Z S Z?ci)

GSH (G, I, TB ,TF ) do Z Z ? PICK
(TB - ? , TF - ? ) Z ? (Z) until
(CONVERGED(Z, Z, TB ,TF , ?, ?))
25
Generic SCC-Hull Algorithm
CONVERGED (Z, Z, TB ,TF, ?, ?)) if (Z ?
Z) ? return FALSE
else ? ? ? ? return TB ? ?
? TF ? ?
26
Complexity in Steps
  • n number of states
  • C number of fairness constraints
  • d diameter of graph
  • N Number of SCCs (N non-trivial)
  • h height of the SCC quotient graph

O(Cn2) complexity
27
Symbolic SCC Enumeration Algorithms
  • Xie-Beerel
  • IXB
  • Bloem

28
Symbolic SCC Enumeration
  • Find an SCC
  • pick a state v
  • compute the SCC of v as (EP(v)?EF(v))
  • Check if SCC is fair
  • Recur on the partitions

29
Symbolic SCC enumeration
  • Xie-Beerel
  • v is randomly chosen
  • EF(v), EP(v) are SCC-closed sets
  • Partition the state space
  • EG(partition) applied to trim
  • Complexity O(dN)

6
7
15
3
2
8
14
1
4
9
16
10
5
13
11
12
30
Symbolic SCC enumeration
  • Improvements to Xie-Beerel
  • trim with EH(partition) in addition to
    EG(partition)
  • Improves complexity
  • v is chosen from a priority queue
  • Shortens prefix of counterexample

6
7
15
3
2
8
14
1
4
9
16
10
5
13
11
12
31
Outline
  • Motivation
  • Introduction
  • Fair cycle algorithms
  • A general framework
  • Lockstep algorithm
  • How do the different algorithms fare?
  • Conclusions

32
Lockstep Algorithm
  • Same basic approach as in Xie-Beerel
  • Choose node v
  • Search backward and forward, SCC of v is
    intersection
  • Perform two searches simultaneously for n log n
    performance

33
Lockstep by Example
Stage 1 Search forward and backward
until one converges Stage 2 Complete search
to find SCC Stage 3 Recursion
34
Lockstep by Example
Stage 1 Search forward and backward
until one converges Stage 2 Complete search
to find SCC Stage 3 Recursion
35
Lockstep by Example
Stage 1 Search forward and backward
until one converges Stage 2 Complete search
to find SCC Stage 3 Recursion
36
Lockstep by Example
Stage 1 Search forward and backward
until one converges Stage 2 Complete search
to find SCC Stage 3 Recursion
37
Lockstep by Example
Stage 1 Search forward and backward
until one converges Stage 2 Complete search
to find SCC Stage 3 Recursion
Backwards search converged!
38
Lockstep by Example
Stage 1 Search forward and backward
until one converges Stage 2 Complete search
to find SCC Stage 3 Recursion
39
Lockstep by Example
Stage 1 Search forward and backward
until one converges Stage 2 Complete search
to find SCC Stage 3 Recursion
40
Lockstep by Example
Stage 1 Search forward and backward
until one converges Stage 2 Complete search
to find SCC Stage 3 Recursion
41
Lockstep by Example
Stage 1 Search forward and backward
until one converges Stage 2 Complete search
to find SCC Stage 3 Recursion
42
Picture of Search Space
  • Recur on Black and Blue White both are
    SCC-closed
  • One of Black and Blue White has lt n/2 nodes.
    This is S

V
43
Analysis Charging
  • Amortized analysis charge to nodes and count
    total charge
  • In Stage 1 at most S C steps
  • Charge 1 to every node in S and C
  • In Stage 2 at most C steps
  • Charge 1 to every node in C

44
Analysis Total Charge
V1
  • Every node goes down only one branch
  • Stage 1 Every node is charged ? log n times
  • Stage 2 Every node is charged ? 1 time
  • Total charge n log n n O(n log n)

S1 lt V1/2
V2
S2 lt V2/2 lt V1/4
45
Sharper Analysis
  • For Emerson-Lei O(dh)
  • For Lockstep O(n log(dN/n))
  • N is number of SCCs
  • With optimization O(dNN) and O((dh)N)

46
Complexity Comparison
Symbolic SCC enumeration
SCC-Hull
O(Cn2) complexity
O(n log n)
O(n2)
N Number of non-trivial SCCs
47
Counterexamples
  • Symbolic SCC enumeration algorithms
  • Only one fair SCC
  • Shortest prefix can be generated with onion rings
  • SCC hull algorithms
  • counterexample procedure depends on the computed
    hull i.e., location of fair SCCs

48
Counterexamples
Length of counterexample depends on the SCC hull
49
Summary
  • SCC-hull algorithms
  • Symbolic SCC enumeration algorithms
  • Lockstep
  • Performance depends on
  • N, N, d, h, C
  • Number of fair SCCs, location of the fair SCCs
  • BDD factors?

50
Outline
  • Motivation
  • Introduction
  • Fair cycle algorithms
  • A general framework
  • Lockstep algorithm
  • How do the different algorithms fare?
  • Conclusions

51
Experiments
  • Implemented 5 algorithms in COSPAN
  • Emerson-Lei, Hojati/Kesten, Hojati/Hardin, IXB,
    Lockstep
  • Measured time, number of steps, length of
    counter-examples

52
Experiments No Fair Cycles
53
Experiments Fair Cycles
54
Experiments Length of Counterexamples
55
Experiments Summary
  • Emerson-Lei seems no worse than others
  • IXB, Lockstep designed to produce short
    counterexamples
  • BDDs play a large role in actual performance

56
On-The-Fly Lockstep
  • For example WV
  • Lockstep takes 5779 s
  • The fair path is very short (3,2)
  • One (large) SCC is examined
  • Stop as soon as B(v) ? F(v) intersects all fair
    sets
  • A fair cycle is guaranteed in B(v) ? F(v)

57
Outline
  • Motivation
  • Introduction
  • Fair cycle algorithms
  • A general framework
  • Lockstep algorithm
  • How do the different algorithms fare?
  • Conclusions

58
Conclusions
  • Compared various symbolic algorithms
  • provided a classification, generalized some
    algorithms
  • Studied performance with experiments
  • Future work
  • Forward vs. Backward, BDD effects
  • Streett acceptance
  • Hybrid algorithms?

59
Conclusions
  • n log n symbolic algorithm for
  • SCC decomposition,
  • Büchi emptiness,
  • Streett emptiness,
  • measured in images/preimages
  • Improves n 2 previously known bounds
  • When measured more sharply Lockstep incomparable
    with EL

60
Conclusions
  • Lockstep useful for counterexample generation
  • Future work parallelizing algorithms that change
    transition relation or even use extra variables
About PowerShow.com
