UK Link Industry Engagement Forum

1
UK Link Industry Engagement Forum

• 24th October

2
Gas Nominations Allocations End to End Process
Walkthrough

• 24th October

3
Call-outs
An information only call out.
Denotes a change in the process.
A BRD reference.
4
Calculate NDM Output Nominations
NDM Demand estimation formula the formula willl
no longer use the Scaling Factor and will apply a
Weather Correction Factor calculated from the
Forecast Weather data. Formula
(AQ/365)ALP(1DAFWCF)
UNC Ref H2.2- Formula C2.5 Principles of NDM
Nominations
Weather Correction Factor adjusts for the
difference between the Daily Composite Weather
Variable and the Daily Seasonal Normal Composite
Weather Variable per LDZ.
Settlement BRD Ref 5.1, 5.3
Note There are no file formats associated with
this Business Process.
5
Validate Output Nominations
Applicable to Class 1 2 Nominations
UNC Ref C2.2.6 D-7
Where a Gas Nomination for a Class 1 2 is not
submitted, a D-7 estimate will be generated and
applied. The estimate will be based on a D-7
Output Nomination.
The generation of an estimate will be visible in
Gemini and can be replaced within the Gas
Nomination timescales.
Settlement BRD Ref 5.1.2
Note There are no file formats associated with
this Business Process.
6
Calculate Forecast Unidentified Gas
UNC Ref H2.6 Unidentified Gas
The Forecast Unidentified Gas will be apportioned
to Shippers using the Allocation Adjustment
Factors. A Unidentified Gas Meter ID will be
created per Shipper per LDZ / Exit Zone.
3.4.4.2 Publish Forecast Unidentified Gas
Forecast Unidentified Gas Available
The LDZ Forecast Unidentified Gas is calculated
at D-1 for the Gas Flow Day. Calculation LDZ
Forecast Demand (LDZ shrinkage Total DM
Nominations Total NDM Nominations)
Settlement BRD Ref 5.4
7
Calculate Energy Allocations
UNC Ref E3
Unidentified Gas Available
3.5.3 Calculate LDZ unidentified gas
Unidentified Gas value feeds into imbalance
position and cash out charges.
New NDM demand calculation. The formula will no
longer include the Scaling Factor and will apply
a Weather Correction Factor calculated from
actual weather data.
Weather Correction Factor adjusts the difference
between the daily CWV and the daily seasonal
normal CWV per LDZ.
Settlement BRD Ref 5.3
8
Calculate Unidentified Gas Allocation
The Allocated Unidentified Gas will be
apportioned to Shippers using the Allocation
Adjustment Factors.
Allocated Unidentified Gas Available
3.5.3.2 Publish Allocated Unidentified Gas
UNC Ref E1.1.6 E1.1.7
The LDZ allocated Unidentified Gas is calculated
at D1 for the Gas Flow Day. Calculation LDZ
Demand (LDZ Shrinkage Total DM Allocations
Total NDM Allocations)
Settlement BRD Ref 5.4
9
Supply Point Transfer End to End Process
Walkthrough

• 24th October

10
Call-outs
An information only call out.
Denotes a change in the process.
A BRD reference.
11
Supply Point Enquiry
Enquire against all registered Supply Points via
the enquiry file (S47).
NMRS59,S70,S75,S98Q44 Q51
NMR S78,S68,S72
Response via (S59) Response will includeA
maximum 24 months worth of history or the maximum
available for the Supply Point. Volume will be
provided in kWhAMR Indicator Class
(prevailing)Batch Frequency (class 3)SMP and
Formula Year AQSOQ for Class 3 4 DNI
Indicator Withdrawal Status Seasonal
Indicator CYM
NOM S47,S68
New feature within the existing enquiry file
(S47) to submit a consumption request.
Supply Point Register BRD Ref 8.4
Note Files to be used for GT and iGT sites.
12
Supply Point Nomination
NMR S21, S69, S72 U70,U72
NOM S48, S69 U70,U72
NMR S21,S69
NRF S21,S69 S72, Q46
NMR,NRF - S64, S70, S75, K12,K14,S98,Q44,
U71,U73,U74,U75, Q46, K85

• Sites may be referred for
• Class 1 and 2 for capacity
• request for short haul
• New request for seasonal capacity (subject to mod
  approval). Note iGT sites referring for
  capacity will refer to the iGT GT.

• Response will be via the offer (S64).
• Offer now includes
• Class
• CSEP Data
• GT Rates
• iGT Rates
• Short Haul Rates (where appropriate).
• CYM (current year minimum MOD445)
• DNI Indicator

• Nomination request (S48) will include
• Class type,
• If requesting Class 1 or 2, you have to nominate
  the SOQ SHQ, existing capacity validations will
  be applied
• If requesting Class 3 the batch period for
  submitting reads will need to be provided. This
  period can be either 7 days, 14 days or 1 month.

Supply Point Register BRD Ref 8.2, 8.3, 8.6
Note Files to be used for GT and iGT sites.
13
Supply Point Confirmation
CNF S38, S42,S66, S67,S83, S84,U70, U72, T05
CFR S72, S09, S16,S66,S67,S83,S84,U70,U72,T06
CFR S07,S70,S75,S66,S67,S83,S84,S98,K12,K14,
K85, Q44,Q45,U71,U73,U74, U75,S10,S77,T06,T07
WAO -S39,S40,S74,S41,S54,S73
TRF S15,S70, S75,S66, S67,S76,
S98,Q44,Q45,U71,U73,U74,U75,S88,S63,S08, S72,K12,K
13, K85
WOR S11,S12, S26,S13, S14,S30, S65,S72
DCF S08,S70, S76, S63,S72
MRI-U06,K15, S98,N90

• Transfer of Ownership D-7 (D-2 Faster Switching)
  to be provided
• Gas Nomination ID
• AMR
• SMSO ID
• CYM (if applicable)
• Last Read Read Date

• Confirmation only sites for SSPs
• Class
• SOQ/SHQ (as recorded at the time) for Class 2 and
  SMQ in ratio of previous 3 or 4
• Class 3 SSP sites will need to provide the batch
  read frequency.
• Confirmation response (S38 LSP / S42 SSP) will
  include
• Class
• iGT Rates
• iGT CSEP data
• AMR Indicator
• CYM (if applicable)

Supply Point Register BRD Ref 8.2, 8.11
Replacement reads to be sent via the U01 file for
the transfer date
Note Files to be used for GT and iGT sites.
14
Class Change End to End Process Walkthrough

• 24th October

15
Call-outs
An information only call out.
Denotes a change in the process.
A BRD reference.
16
Manage Class Change
SPC C38, C39
D-2 Process Gemini
Class Change (SPC) record C38 minimum 5 business
days (regardless of class) Provide class if
going from Class 2 (from 3 or 4) provide
prevailing SOQ SHQ in ratio. If Class 1 or
Class 2, the prevailing SOQ/SHQ must be used and
the effective date.
Class 3 Batch Frequency Class 4 MRF (can cancel
2.12) by D -3
Response Gas Nomination ID. SMP AQ/SOQ Class
1/2 SMP AQ/SOQ Formula Year AQ/SOQ Class 3/4
Supply Point Register BRD Ref 8.10
17
Class Changes24th October 2014
18
Introduction

• This presentation aims to provide an overview of
  the process for Class change specifically the
  reconciliation and Check Read processes.
• The presentation also covers scenarios where
  there is a Shipper Transfer and Class change
  combined.
• Where a combined change of Shipper and Class
  change is associated with DRE/AMR equipment the
  focus is around apportioning the drift following
  a Check Read.

19
Why have a Check Read

• Check Reads are required where equipment (AMR) is
  installed that derives the reads from the meter.
• The Check Read identifies where the meter and the
  equipment are not synchronised and will detect
  any drift between the meter and the equipment.
  Any drift is then apportioned across the relevant
  period.
• Class 1 and 2
• Class 3 and 4

Daily Reads
A
A
A
A
A
A
CR
CR
Reconciliation
Reconciliation
Reconciliation
A
A
A
CR
CR
20
Class Change
Process Description Process for initial Allocation Process for Energy Balancing close-out Read Submission Timescales Type of Read Submission AQ Calculation Reconciliation
Class 1 Daily Metered Time Critical Readings Uses daily read Uses daily read By 11am on GFD1 All reads daily on GFD1 Monthly using Optimum Read Meter Point level following a site visit or estimate
Class 2 - Daily Metered not Time Critical Readings Transporter estimate Uses daily read By end of GFD1 (05.59 am) All reads daily by end of GFD1 Monthly using Optimum Read Meter Point level following a site visit or estimate
Class 3 Batched Daily Readings Allocation Profiles Allocation Profiles Daily Reads in batches All daily reads in batches Monthly using Optimum Read Daily Rec at Meter Point level on receipt of a batch of reads
Class 4 Periodic Readings Allocation Profiles Allocation Profiles Periodic Periodic reads Monthly using Optimum Read Meter Point level at receipt of read
21
Terms Used

• DRE Daily Read Equipment
• AMR Automatic Read Equipment
• GFD Gas Flow Day
• CR Check Read
• A Actual Read
• N Cyclic Read
• E Estimate Read
• D Effective date of the Class Change

22
General Principles

• Where DRE/AMR is installed for Class 2, 3 4 the
  kit is not changed on a Class change only event.
• For a change in Class an Actual read is required
  to close out the outgoing Class.
• The Actual Read provided for the effective date
  of the Class change will not be subject to the
  read tolerance validations only standard asset
  validation (serial number, dials and units etc.)
• This is because the read may not follow on from
  the previous read due to the difference between
  the on-site reading and the derivable reads.
• On Class Change only event the Check Read will
  reconcile back to the previous Check Read or
  AMR/DRE Installation Read.
• When AMR/DRE equipment is installed the first
  Check Read received will reconcile back to the
  previous Check Read or Installation Read.

23
General Principles - Reconciliation

• There are 3 steps for energy allocation/reconcilia
  tion for Class 3 and 4 Supply Meter Points where
  AMR equipment is installed
• Daily Allocations are based on the Demand
  Estimation Formula.
• An Actual Read received will trigger
  reconciliations.
• Daily for Class 3
• Periodic for Class 4
• Following receipt of a Check Read reconciliation
  will be triggered back to the previous Check Read
• In the cases of a Shipper Transfer this will be
  the opening read.
• Where AMR/DRE is fitted on a Class 3 or 4
  Reconciliation will be processed first followed
  by the Check Read Reconciliation (apportion the
  drift across the period).
• For Class 1 and 2 any replaced meter readings
  received outside of
• close-out will trigger Reconciliation.

24
General Principles Shipper Transfer

• For Class 1 and 2, any reads received following a
  Shipper Transfer that fail validation will
  generate an Estimated Read. On receipt of a valid
  actual read the Estimated Reads will be
• re-calculated (better estimates) back to the
  Shipper Transfer/Class change day.
• If the Check Read is not provided for the Class
  change date for a Shipper Transfer within the UNC
  timescales then an Estimate Read will be
  calculated and treated as a Check Read.
• Class 2 within GFD5
• Class 3 4 within Month10
• For a Shipper Transfer where the outgoing Class
  is Class 1 or 2 the D-1 volume
• will be estimated for Allocation purposes, either
  using D-7 or AQ/365.
• This is to ensure that the drift is allocated to
  the correct period (previous Check Read) rather
  than the total drift allocated to the day before
  the Class change
• On Shipper Transfer where AMR/DRE equipment is
  fitted the Opening Read received will be treated
  as a Check Read and therefore will trigger
  Reconciliation back
• to the last Check Read. This will close out the
  position for the Outgoing
• Shipper.

25
Files Formats

• The reads will be provided on the following
  communication methods
• Incoming Methods

Class Type File
Class 2 UDR
Class 3 UBR
Class 4 UMR
Class 2 Site Visit Details Web Services
Class 3 4 Site Visit Details SFN
26
Same Shipper Class change, Class 2 to 3, DRE/AMR
fitted.
Scenario A Opening read provided
Class Change Day
Class 2
Class 3
D-2
D-1
D
A
A
A
A
A
A
Reconcile A?A
CR
27
Same Shipper Class change, Class 2 to 3, DRE/AMR
fitted.
Scenario A Opening read not provided
Class Change Day
Class 2
Class 3
D-2
D-1
D
D-7
A
A
A
A
A
E
Reconcile E?A
CR
28
Shipper Transfer with Class Change, Class 2 to 3,
DRE/AMR fitted, Opening Read provided by Incoming
Shipper.
Transfer/Class Change Day
Incoming Shipper (Class 3 )
Outgoing Shipper (Class 2)
D-2
D-1
D
A
A
A
A
A
A
CR
29
Shipper Transfer with Class Change, Class 2 to 3,
DRE/AMR fitted, No Opening Read provided by
Incoming Shipper.
Transfer/Class Change Day
Incoming Shipper (Class 3 )
Outgoing Shipper (Class 2)
D-2
D-1
D
A
A
A
A
CR (E)
30
Shipper Transfer with Class Change, Class 2 to 3,
No DRE/AMR fitted.
Transfer/Class Change Day
Outgoing Shipper (Class 2)
Incoming Shipper (Class 3)
A
A
A
A
A
A
31
Same Shipper Class Change, Class 4 to 2
Class Change Day
Class 4
Class 2
D
N
A
N
Reconciliation
32
Same Shipper Class Change, Class 4 to 2
Class Change Day
Class 4
Class 2
D
N
A
N
Reconciliation
33
Same Shipper Class Change, Class 4 to 2
Class Change Day
Class 4
Class 2
D
N
A
N
Reconciliation
34
Same Shipper Class Change, Class 4 to 2
Class Change Day
Class 4
Class 2
D
N
A
N
E
A
E
B
B
Reconciliation
If subsequent Actual reads following the Class
change date fail validation Estimated Reads will
be generated. When the next valid Actual is
received the estimated reads will be replace with
better estimates.
35
Shipper Transfer with Class Change, Class 4 to 2,
DRE/AMR fitted, Opening Read provided by Incoming
Shipper.
Transfer/Class Change Day
Incoming Shipper (Class 2)
Outgoing Shipper (Class 4)
N
A
CR
36
Shipper Transfer with Class Change, Class 4 to 2,
DRE/AMR fitted, No Opening Read provided by
Incoming Shipper.
Transfer/Class Change Day
Incoming Shipper (Class 2)
Outgoing Shipper (Class 4)
N
CR
CR(E)
37
Shipper Transfer with Class Change, Class 4 to 2,
No DRE/AMR fitted.
Transfer/Class Change Day
Outgoing Shipper (Class 4)
Incoming Shipper (Class 2)
N
N
38
Consumption Adjustments

• For Class 2, Consumption Adjustments can be
  provided for
• A day
• For a period - per day between two Check Reads
•
• Submission of a Consumption Adjustment for Class
  1 and 2 Supply Meter Points will be via
• Within Submission of GFD5 via Web Services
• Outside GFD5 through CMS
• Submission of Consumption Adjustments for Class 3
  and 4 Supply Meter Points will be submitted via
  CMS.
• The Consumption Adjustments are provided as a
  total between two read dates

39
Faulty Asset Equipment End to End Process
Walkthrough

• 24th October

40
Call-outs
An information only call out.
Denotes a change in the process.
A BRD reference.
40
41
Apply Asset Fault Status (Input)
Fault Notified via SFN File for Class 3 4.
Class 1 2 via web portal.
If fault flagged in error submit a further SFN
File (3 4) or portal update (1 2) to advise
the Fault Notification was raised in error
SFN
SFR
This process flow is repeated in this
presentation to demonstrate input and output.
Supply Point Register BRD Ref 8.8
41
42
Faulty Meter
If the fault has been applied in error the
suspended status is removed.
Read Validations are applied
Where a fault has been flagged the next read
submissions via the UMR/UDR or UBR read files
will be suspended.
Where a read is suspended a D -7 estimate for
Class 1 and 2 will be generated. If the Shipper
has raised the fault the DMSP will be notified.
UMR
UDR
Following a fault being flagged any read
suspended for Classes 2, 3 4 will be notified
via URS file. The notification will state Read
suspended due to fault flag.
Settlement BRD Ref 5.5, 5.6
UBR
42
43
Apply Asset Fault Status (Output)
Where a Meter Exchange has been updated the meter
will be considered to be faulty. To receive a
consumption adjustment an RFA contact should be
raised via CMS for fault period between two reads.
Where a Corrector Exchange has been updated the
meter readings and previous check read will be
used to automatically reconcile the fault period.

The submission of RGMA ONJOB File to update a
Meter or Corrector Exchange will end date the
fault against the faulty asset. If the fault is
on the Daily Read Equipment, notification of the
site visit information will be required either
via the portal or the SFN file in order to end
the fault.
Where Daily Read Equipment is installed automatic
reconciliation will go back to the previous check
read using convertor reads or meter reads.
ONJOB
SFN
SFR
Note If a Meter or Converter Exchange is updated
for a day during the fault period it will be
treated as if the meter is faulty and a
consumption adjustment must be provided.
Note If you wish to correct the consumption
fault period within Exit Close out you can view
the portal for Class 1 2 sites.
Supply Point Register BRD Ref 8.8
43
43
44
UK Link Programme Dashboard Report UKLIEF 24th
October 2014
Executive summary

• RAG status for the Programme remains at amber.
• The File Format consultation process remains on
  track with final approvals targeted for 13/11.
• Functional fit currently remains positive at
  approximately c.80.
• Residual activities to complete Detailed Design
  are on track.
• The UK Link Shipper Engagement Day was held on
  02/10 the event was extremely well attended.

Recent Achievements
Future Priorities

• Phase 1 of the File Format Formal Consultation
  process commenced, as per plan, on 30/09. The
  File Format consultation process remains on track
  with final approvals targeted for 13/11.
• UK Link Shipper Engagement Day was successfully
  held on 02/10 with over 100 Industry colleagues
  attending. Feedback received from the event was
  positive all Industry questions have been
  responded to.
• The release plan for non-shipper file formats has
  been developed industry engagement approaches
  are being agreed.
• Two Transition mods (mod 514 and 515) have been
  raised and are being progressed through their
  respective working groups. Two further mods are
  being progressed through the required governance
  in order to raise to the Industry.

• Progress and close out the File Format
  consultation process through the UK Link
  Committee.
• Progress System Test investigate and conclude
  the assessment of whether Market Connectivity
  Testing and Market Trials can be decoupled.
• Ensure that suitable progress is made in data
  cleanse activities through the Data Cleanse
  Forum.
• Continue to progress the To Be Process Walk
  Throughs the current schedule will conclude in
  December 2014.
• Continue to work through the Market Trials
  approach, scheduled for Industry communication
  during Q1 2015.
• Continue to progress the formal raising of
  Transition mods through PNUNC.
• Finalise the approach and plan for Non-Shipper
  file format release.

2014 Q1
2015 Q1
2014 Q2
2014 Q3
2014 Q4
2015 Q2
2015 Q3
2015 Q4
Industry Engagement Comms
GO LIVE
Reporting Date
To-Be Processes
IDR Updates
31/3 Imp. Dates Outage Window
IE Comms.
02/10 Shipper Egt Day
30/11 Industry Go, No Go Straw Man
Programme Milestones
Key Milestone High Level Design Complete Detailed Design Complete Xoserve UAT Complete Industry Testing Start Cutover Implementation
Baseline Date 18/04/14 26/09/2014 28/05/15 01/06/15 01/10/15
Current Planned Date Complete 30/04/14 24/10/2014 28/06/15 01/06/15 01/10/2015
Aggregated Programme RAG

Key Dependencies
Risks
Risk Summary Impact Date Mitigation
Industry readiness Risk that there is a varied understanding within stakeholder organisations of Nexus requirements due to lack of or inconsistent attendance at industry forums. June 2015 Xoserves programme of industry engagement at all levels aims to level-set understanding. Terms of Reference in UKLIEF will avoid re-working topics agreed through PNUNC.
File Formats There is a risk that any changes to file formats as a result of the UKLC approval process (formal consultation and reps) may impact on the ability of the industry to deliver by Oct 2015 due to design re-work Nov 2014 Draft file formats released in August to give early sight and UKLP Engagement Day set up to focus on file formats in the context of business processes.
Market Testing Risk that Market Trials is insufficient in length, too late within the programme, and participants may not be ready in time to take part. June 2015 Xoserve are investigating the feasibility of de-coupling Market Connectivity Testing and Market Trials.
Dependency Date Required Impact if missed Status
Industry participants to cleanse Settlement data by December 2014 Dec 2014 Output from the Testing phase may produce unexpected results due to uncleansed data.
Industry (Shipper) agreement on Shipper file formats through UKLC Nov 2014 The programme will continue build and testing activities at risk.
Industry Stakeholders to complete their internal system builds Jun 2014 Industry may not be able to fully participate in the Market Trials phase
45
iGT Single Service Provision non-effective days
to support cutover

• A presentation to
• iGT Shipper Workgroup 3rd November 2014
• UNC Nexus Workgroup 4th November 2014
• See also the iGT single service provision data
  preparation and migration overview report
  published on the Joint Office website

46
iGT Single Service Provision non-effective days
to support cutover

• To move to the iGT Single Service provision
  arrangements a number of activities are required
• At some point the iGT systems must close
• There are then a number of activities to prepare
  arrangements for the UK Link system
  particularly around finalising the data for
  migration.
• The UK Link system will then open
• A period of time is required to prepare the UK
  Link system. During this time supply point
  register updates and supply point administration
  communications cannot be made.
• This does not mean that events cannot occur on
  these days or that updates cannot be made that
  are effective on these days.

47
iGT Single Service Provision non-effective days
to support cutover

• Six non-effective days for the purpose of supply
  point register (SPR) and supply point
  administration (SPA) communications
• This means that SPR and SPA communications cannot
  be sent to an iGT on these days
• The six days are September 25,26,27,28,29,30
• The last day a Shipper can send a SPR or SPA
  communication to the iGT is Thursday 24th
  September
• From 1st October Shippers will send SPR and SPA
  communications to the UK Link system

48
iGT Single Service Provision non-effective days
to support cutover

• Why six days are needed
• Working back from 1st October 0500 hrs
• The data to support Gemini processes (balancing
  etc) needs to be in Gemini for the start of day
  D-2. D is 1st October, D-2 is 29th September
  0600
• This means the data is loaded to Gemini on 28th
  September
• The source of the Gemini data is the Data
  Preparation Database
• The Data Preparation Database must have a final
  position on 28th September circa 1300hrs
• On 27th the data will be subject to check and
  re-check, no new data will be added to the Data
  Preparation Database on this day. (The final
  shipper portfolio will be issued from this
  closed-out position)
• The last processing of data on the Data
  Preparation Database is the 26th September
• The last date iGTs can submit data is 25th
  September
• Therefore the last day the iGT can accept files
  for processing for them prepare the final data
  for submission to Xoserve is 24th September

49
iGT Single Service Provision non-effective days
to support cutover

• What are the implications of this?
• The faster switching timescales, which create
  the minimum period for a transfer (14 calendar
  days starting from the day after the confirmation
  file is received), will not apply for the six
  days
• To effect a change of shipper event on 9, 10, 11,
  12, 13, 14 October the confirmation file must be
  submitted to the iGT by 24 September
• Any updates to the SPR e.g. asset update, meter
  reading etc that would ordinarily be submitted
  between 25 and 30 September will need to be
  submitted to Xoserve from 1st October using the
  new file formats.
• There is no opportunity to back-date files. All
  files processed from 1st October will be
  processed and validated against the receipt date
  of the file

50
iGT Single Service Provision non-effective days
to support cutover

• Confirmation of SPA and SPR files processed pre
  and post cut-over
• SPA events that start in the iGT system and end
  in UK Link will be migrated with no impact to the
  event. However, Shippers need to be aware that
  apparent unsolicited files will be received.
• The effective date of any SPR updates processed
  after 1st October will be maintained e.g. a meter
  exchange on 25th September will be recorded as
  having happened on the 25th September

51
Illustration of cutover time period
52
iGT Single Service Provision non-effective days
to support cutover

• Email address for questions
• externalrequests.spa_at_xoserve.com
