PROGRAMMING GRAPHICAL OBJECTS AND DATABASE IN DESIGN

1
PROGRAMMING GRAPHICAL OBJECTS AND DATABASE IN
DESIGN
Algirdas Sokas Department of Engineering Graphics
Vilnius Gediminas Technical University
2
Faculty of Fundamental Sciences bachelor study
programs

• Bioengineering
• Engineering Informatics
• Technomathematics

3
Master study programs

• Bioengineering
• Engineering Informatics
• Applied Informatic,
• Computerising of Physical and Technical
  Investigations,
• Information Systems.
• Information Technology
• Data Mining Technology,
• Engineering and Computer Graphics,
• Spatial Information Systems.
• Applied Statistics
• Ecology of Technosphere

4
Students
5
Scientist of mathematic Edgar Frank Codd from IBM
created first relational database model in 1969.
6
First version of AutoCAD was created by John
Walker and Dan Drake in 1982. They founded
,,AUTODESK.
7
Formulation of problem

• Prepare methods, algorithms and procedures for
  solving these design problems
• Attach information from database to a graphical
  object being drawn
• Read information from certain graphical objects
  of a drawing and collect, store and present this
  information in database.

8
(No Transcript)
9
Data exchange technology
Open database connectivity (ODBC) technology
(1991). Object linking and embedding
database (OLE DB) technology (1996). Modern
technology is ActiveX (1996).
10
Algorithms
Form an algorithm to attach database record
information to graphical object 1.  Select
one graphical object record in the database
2.  Create extended data of new graphical
object 3. Draw programming graphical object
depending on extended data and scale in the
drawing. Form algorithm to read the information
from graphical objects and to collect extended
data in the database records 1.  Select k
graphical objects in the drawing 2.  Take first
object from beginning 3.  Verify whether object
has extended data If does not have, go to
position 2 if has, go to position 4       4.
Collect extended data in the database record.
11
Programming with objects from database
We have to create an instance of the application
and to declare a variables that will represent
the other application Dim cc As
ADODB.Connection (1) Dim rr As
ADODB.Recordset (2) Second, we have to create a
set of statements with declared variables
  Set cc New ADODB.Connection (3) With cc
(4) .Provider "Microsoft.Jet.OLEDB.4.0"
(5) .Open "C\My Documents\ dbac2.mdb"
(6) End With (7) Set rr New
ADODB.Recordset (8)
12
Database table and drawing information
13
We can select one graphical object record in the
database of graphical object parameters
14
Procedure fragment to select one graphical object
record in the database
rr.Open "Lentele1", cc, adOpenKeyset,
adLockBatchOptimistic (9) ListBox1.Clear
(10) Do Until rr.EOF (11) ListBox1
.AddItem rr(0) " " rr(1) " " rr(2) _ "
" rr(3) " " rr(4) (12) rr.MoveNext
(13) Loop (14)
15
The next procedure selecting one graphical object
record with 5 fields in the database of graphical
object parameters and creating extended data of
new graphical objects
Dim DataType(0 To 1) As Integer (15) Dim
Data(0 To 1) As Variant (16) FunkcijaLangas
TextBox2, TextBox3, oLangas (17) If
oLangas.ObjectName "AcDbPolyline"
Then (18) DataType(0) 1001 Data(0)
"LangoData" (19) DataType(1)
1000 (20) Data(1) TextBox1 ""
CStr(TextBox2) _ "" CStr(TextBox3) ""
TextBox4 (21) oLangas.SetXData DataType,
Data (22) End If (23)
16
Collect Drawing Information In The Database
For j 1 To maxrecord (24)
rr2.AddNew (25) rr2.Fields("Code").Value
L j (26) rr2.Fields("Name").Value
MM(j, 1) (27) rr2.Fields("Count").Value
MM(j, 2) (28) rr2.Update (29) Next
j (30)
17
Analysis of procedures
PC Pentium III, 600 MHz, RAM 200 MB
18
Example. The house windows
19
Conclusions
  Prepare methods, algorithms and procedures for
solving these design problems attach information
from database to a graphical object being drawn,
reading information from certain graphical
objects of a drawing and collecting, storing,
presenting this information in database formats,
fulfilling mathematical operations with read
information. Form an algorithm to attach
database record information to graphical object.
Form algorithm to read the information from
graphical objects and to collect extended data in
the database records. The following are
presented procedure fragments and results
dependent on selected record in the database of
graphical object parameters creation of extended
data for new graphical object and information
transfer to another database. How the prepared
procedures work that collect drawing information
in the database with different number of
graphical objects and with and without sorting
procedure. Prepare example house facade drawing
and database with windows information with
program written in VBA language.
