Comparison of Recalibration Techniques for Logistic Regression in Interventional Cardiology

1
Comparison of Recalibration Techniques for
Logistic Regression in Interventional Cardiology

• Michael E. Matheny, MD
• HST 951 Final Presentation

2
Background

• Risk Models are evaluated for accuracy in two
  categories
• Discrimination ability of a model to separate
  data with respect to values of an outcome
  variable
• Measured by the Area Under the Receiving
  Operating Characteristic Curve (ROC or AUC)
• Calibration ability of a model to accurately
  predict risk for individuals or small subgroups
  of the population
• Multiple measurements Hosmer-Lemeshow
  Goodness-of-Fit, Brier Score, Calibration Slope,
  etc.

3
Background

• Risk Modeling techniques are generally able to
  perform well in terms of discrimination and
  calibration on local development and test data
• Performance Depends on
• Data collection quality (data noise level)
• Identification of relevant risk factors for an
  outcome
• Time delay to realization of an outcome

4
Background

• A model is most useful when it can be
  successfully applied to all patients in that
  domain
• External validation of these models in multiple
  medical domains with various risk modeling
  techniques have produced consistent results
• Discrimination is preserved
• Calibration tends to fail

5
Background

• Multiple Reasons for Calibration Failure
• Problems related to location/medical center
• Different patient demographics / case-mix
• Different outcome event rates
• Possibly different data element definitions
• Problems related to time
• Changes in the standard of medical care

6
Background

• Various recalibration methods have been applied
  to adapt a risk model to local conditions
• Outcome Scaling
• Adjusting the model result by the outcome event
  ratio between the new and original models
• Model Refitting
• Applying a new model to the result of the
  original model
• Including the result of the original model as a
  covariate in the new model
• Remodeling
• Fitting a new model using the same covariates

7
Background

• These techniques have been variably successful in
  improving calibration for local populations
• Relative performance of these techniques has not
  been well-described in the literature
• Application of these techniques over multiple
  consecutive time periods of data for a population
  has not been reported

8
Background

• Logistic Regression is the most common risk
  modeling technique used in medicine
• Interventional Cardiology
• High Data Quality (National Data Element
  Standard)
• Many large published risk models
• Risk factors for outcome are well-known
• Access

9
Purpose

• The purpose of this study was to evaluate
  well-known recalibration methods for Logistic
  Regression over multiple periods of time to
  compare the relative performance of each method
  in the domain of Interventional Cardiology.

10
MethodsSource Data

• Brigham Womens Hospital
• 720 Bed Academic Teaching Hospital
• Interventional Cardiology Suites
• Electronic Data Collection
• Compliant with National Data Element Standard
• State mandated data collection for every case

11
MethodsSource Data

• All PCI cases performed from January 01, 2002 to
  December 31, 2004 were included
• The outcome of interest was post-procedural
  in-hospital mortality
• A separate data set was created each year of cases

12
MethodsSource Data
Year Cases Mortality ()
2002 1947 15 (0.8)
2003 1841 33 (1.8)
2004 1767 33 (1.9)
13
MethodsData Collection

• The most well-known LR risk models were utilized
  for the evaluation (event rate)
• American College of Cardiology (ACC)
• 707/50123 (1.4)
• Northern New England (NNE)
• 165/15331 (1.1)
• Cleveland Clinic (CCL)
• 169/12985 (1.3)
• University of Michigan (MIC)
• 169/10796 (1.6)

14
MethodsData Collection

• All statistical evaluations were performed by SAS
  9.1 (Cary, NC)
• Discrimination was measured by the Area Under the
  Receiving Operator Characteristic curve

15
MethodsStudy Data

• Three calibration evaluations
• Hosmer-Lemeshow Goodness-of-Fit
• Brier Score / Spiegelhalter Z Score
• Calibration Plot (Intercept/Slope)
• Graphical Only
• Based on risk deciles in HL GOF algorithm
• For each recalibration, the prior year was used
  to recalibrate (2002-gt2003, 2003-gt2004)

16
MethodsPost-Score Scaling (PSY)

• At the case level, model results are scaled by
  the following equation

• P(PSY) can exceed 1 for some values of
  ObservedEventRate gt ModelEventRate and these
  values are truncated to 1

17
MethodsLR Intercept Scaling (IntY)

• In the general LR equation

• B0 is the intercept of the equation
• This variable represents the outcome probability
  in the absence of all other risk factors
  (baseline risk)

18
MethodsLR Intercept Scaling (IntY)

• The proportion of risk contributed by the
  intercept (baseline) can be calculated for a data
  set by

19
MethodsLR Intercept Scaling (IntY)

• The proportion of risk (RiskInt()) is multiplied
  by the observed event rate, and converted back to
  a Beta Coefficient from a probability

• If ObsEventRate(New) gt ObsEventRate(Old) then the
  probability can exceed 1, and is truncated to 1.

20
MethodsRecalibration Methods

• LR Model Refitting (SigY)
• In this method, the output probability of the
  original LR equation is used to model a new LR
  equation with that output as the only covariate

21
ResultsROC with 95 Confidence Intervals
22
ResultsNo Recalibration
Model Obs Exp HLChi2 Spieg Z
2003
ACC 33 414 634 -11.4
NNE 33 39.0 24.3 0.08
MIC 33 27.2 6.6 1.51
CCL 33 56.3 14.0 -3.49
2004
ACC 33 418 641 -11.8
NNE 33 36.6 51.0 0.41
MIC 33 23.3 22.9 1.99
CCL 33 60.3 21.2 -3.78
23
ResultsPost-Scale (PSY) Recalibration
Model Obs Exp HLChi2 Spieg Z
2003
ACC 33 226 210 -13.6
NNE 33 27.9 32.8 1.43
MIC 33 13.4 40.4 5.63
CCL 33 33.3 5.8 -0.74
2004
ACC 33 524 1233 -4.91
NNE 33 58.9 44.7 -1.14
MIC 33 26.7 18.0 1.26
CCL 33 82.9 41.0 -4.79
24
Results2003 PSY vs None
25
Results2004 PSY vs None
26
ResultsLR Intercept Scaling (IntY) Recalibration
Model Obs Exp HLChi2 Spieg Z
2003
ACC 33 45.1 10.0 -2.20
NNE 33 26.0 43.6 2.52
MIC 33 22.1 12.7 2.78
CCL 33 24.8 10.5 1.25
2004
ACC 33 34.1 14.6 -0.90
NNE 33 28.9 69.8 1.82
MIC 33 26.5 17.6 1.22
CCL 33 33.5 14.2 -0.50
27
Results2003 IntY vs None
28
Results2004 IntY vs None
29
ResultsLR Refitting (SigY) Recalibration
Model Obs Exp HLChi2 Spieg Z
2003
ACC 33 24.0 12.7 1.16
NNE 33 18.6 32.9 4.14
MIC 33 20.1 24.0 4.56
CCL 33 25.5 15.2 2.18
2004
ACC 33 32.0 35.7 -0.47
NNE 33 31.2 21.7 1.00
MIC 33 31.0 23.6 0.27
CCL 33 31.6 13.2 0.84
30
Results2003 SigY vs None
31
Results2004 SigY vs None
32
Conclusions

• All 4 Models failed to maintain calibration on
  the data without recalibration
• Two utilized measures of calibration (HL Brier)
  commonly disagreed
• If a model was considered to be recalibrated only
  if both methods showed calibration, then
• Best was Intercept adjustment (IntY) 3 / 8
• 2nd was LR Refitting (SigY) 2 / 8

33
Limitations

• Low Event Rate makes attaining statistical
  significance for results more difficult
• Variation between 2002 and 2003/2004 Event Rates
  make recalibration less likely in 2003 compared
  to 2004.

34
Future Directions

• Analyze 2005 data after conclusion of the year
• Include locally derived model (from 2002 data)
• Include Support Vector Machine evaluation

35
Michael Matheny, MD mmatheny_at_dsg.harvard.edu
Brigham Womens HospitalThorn 30975 Francis
StreetBoston, MA 02115
The End
