An Unobtrusive Debugging Methodology for Actel AX and RTAX-S FPGAs

1
An Unobtrusive Debugging Methodology for Actel AX
and RTAX-S FPGAs

• Jonathan Alexander
• Applications Consulting Manager
• Actel Corporation
• MAPLD 2004

2
Logic Design Challenges

• Designs often dont work the way they were
  intended to the first time

• Device Issues
• Timing Problems
• External setup/hold
• Clock skew
• Cross-clock domain paths
• Software/Timing model bug
• Device speed (faster or slower than expected)
• Device Problems
• Damage due to electrical overstress (EOS)
• Defect
• Packaging

• Non-Device Issues
• Signal Integrity
• VIH/VIL
• Ground/Vcc Bounce
• Cross Talk
• Termination
• Edge rates
• Power supply noise
• Assembly
• Solder shorts
• Component orientation
• Component alignment
• PCB Design or PCB Manufacturing
• Spacing rules
• Shorts/Opens

3
Debugging Challenges

• Non-Device Issues
• Signals can be directly probed on a PCB
• Power supplies can be probed
• Resistance can be measured
• Components can be replaced
• JTAG tests for continuity
• Must have test points and test headers for access
  to signals
• Device Issues ASIC
• Custom test vectors offer high coverage for the
  specific design implemented
• Test points and test blocks built into device
• Limited access to internal nodes
• Long and expensive re-spins

4
Debugging Challenges (Contd)

• Device Issues Reprogrammable FPGAs
• Device can be reprogrammed to access internal
  node activity
• Debuggers are available for pre-determined node
  access
• Manufacturers have very high test coverage and
  can retest devices
• Re-place and route required to view different
  nodes
• Timing issues very difficult to detect due to
  requirement of a new place and route
• Device Issues Axcelerator FPGAs
• Manufacturer has very high test coverage for
  production screen
• Built-in probe circuitry gives access to
  virtually every net in the design without
  additional programming or redesign
• Design-specific test vectors are needed for
  manufacturer failure analysis

5
Axcelerator Design and Debug Flow
6
Probe Setup

• Silicon Explorer 2
• Serial port connection between PC and Probe
  header on board
• 100MHz asynchronous sampling
• Multilevel triggering
• Four internal probe channels
• 18 total logic analyzer channels (4 may be used
  for internal probing)
• Requires 5V or 3.3V power. Power can be taken
  from the PCB (1 Amp required) or from supplied
  power converter.
• 18 X 64K sample buffer

7
Axcelerator Probing Setup
8
Axcelerator Probe Circuitry

• JTAG Test Access Port (TAP) used for control
  interface
• Silicon Explorer connects to JTAG TAP to
  designate XY coordinate of cell to observe.
• Cell output is transmitted to one of four
  available probe output pins.
• Dynamic Internal Node Access
• Nodes can be selected and changed while device is
  in full system operation
• Selecting a node has no impact on design
  performance

Registers
Control
Registers
9
Axcelerator Cell Probe Selection Example
10
Silicon Explorer Logic Analyzer
4
1
3
2
11
Silicon Explorer Logic Analyzer

• 1. Probe Control
• This section shows what signal each probe is
  assigned to
• This section will also shows what the Checksum of
  the device is, allowing the user to verify that
  the device has been programmed with the correct
  design
• 2. Node Listing
• This section shows all the nets/nodes that can be
  probed
• 3. Waveform Viewer
• This is the window where all waveforms captured
  by the Silicon Explorer II are displayed.
• 4. Menu
• This is where all the controls are located
• It allows manipulation of the waveforms

12
Probe Performance

• Maximum observable signal speed
• Worst case RTAX-S simulations show 100MHz signals
  can be observed without distortion
• Typical case RTAX-S simulations show that up to
  150MHz signals can be observed without distortion

13
Probe Guidelines

• The Silicon Explorer gives access to internal
  nodes through XY coordinates
• Built in logic analyzer can be used to view
  signals at 100MHz sample rate
• Oscilloscope or other logic analyzer can connect
  to probe outputs to view signals with higher
  resolution
• Measuring delays
• The probe circuit is not designed to accurately
  reflect internal delays. Only logic states and
  timing approximations should be considered
• Errors due to timing can be observed such as hold
  and setup violations on a flip flop.

14
Probe Guidelines

• Design Tips
• Reserve the probe pins in Actels Designer
  software. This will prevent the probe pins from
  being used as IOs
• Avoid assigning probe pins as inputs or
  bi-directionals. If the pins are needed for IO,
  use them only as non-critical outputs
• Avoid assigning JTAG pins as inputs or
  bi-directionals. If the pins are needed for IO,
  use them only as non-critical outputs
• Do not program the security fuse in the FPGA.
  This will disable the probe circuitry in the
  device.
• The probe circuitry allows four simultaneous
  internal signals to be monitored with a maximum
  of two signals per tile.
• 70 Ohm series resistors are recommended on every
  probe connection

15
Conclusion

• Real-time observation of internal nodes allows
  you to Find
• Timing violations
• Logic errors
• Large glitches
• Un-obtrusive probe circuitry means
• No need to re-place and route design
• No additional delay added to design when probing
• No FPGA logic gates needed
