Data Transmission

1

• Data Transmission

2
1. Terminology

• Transmitter
• Receiver
• Medium
• Guided medium
• e.g. twisted pair, optical fiber
• Unguided medium
• e.g. air, water, vacuum

3
Frequency, Spectrum and Bandwidth

• Time domain concepts
• Analog signal
• Varies in a smooth way over time
• Digital signal
• Maintains a constant level then changes to
  another constant level
• Periodic signal
• Pattern repeated over time
• Aperiodic signal
• Pattern not repeated over time

4
Analogue Digital Signals
5
PeriodicSignals
6
Sine Wave

• Peak Amplitude (A)
• maximum strength of signal
• volts
• Frequency (f)
• Rate of change of signal
• Hertz (Hz) or cycles per second
• Period time for one repetition (T)
• T 1/f
• Phase (f)
• Relative position in time

7
Varying Sine Wavess(t) A sin(2pft f)
8
Wavelength

• Distance occupied by one cycle
• Distance between two points of corresponding
  phase in two consecutive cycles
• ?wavelength
• Assuming signal velocity v
• ? vT
• ?f v
• c 2,98108 m/s (approximately 3108 m/s) speed
  of light in free space

9
Frequency Domain Concepts

• Signal usually made up of many frequencies
• Components are sine waves
• Can be shown (Fourier analysis) that any signal
  is made up of component sine waves
• Can plot frequency domain functions

10
Addition of FrequencyComponents(T1/f)
sin(2pft)
(1/3) sin(2p(3f)t)
(4/p) sin(2pft)(1/3)sin(2p(3f)t)
11
Spectrum Bandwidth

• Spectrum
• range of frequencies contained in signal
• Bandwidth (BW)
• Narrow band of frequencies containing most of the
  signal energy
• Absolute bandwidth Width of the spectrum
• Effective bandwidth (or bandwidth) energy of
  signal contained in a narrow band of frequencies
  (usually expressed as the 3 dB points)
• DC Component
• Component of zero frequency

12
FrequencyDomainRepresentations
Signal spectrum
Absolute bandwidth 3f-1f2f
Fundamental frequency (f)
(4/p) sin(2pft)(1/3)sin(2p(3f)t)
This signal has an infinite bandwidth. Its
effective bandwidth is limited in a relatively
narrow band of frequencies where the most energy
of the signal is contained
s(t)1, -X/2lttltX/2
13
Signal with DC Component
Time Domain
s(t) 1 (4/p) sin(2pft)(1/3)sin(2p(3f)t)
Frequency Domain
14
Square wave
Square wave signal consists of an infinite number
of odd harmonics
(4/p) sin(2pft)(1/3)sin(2p(3f)t)(1/5)sin(2p(5f)
t)
(4/p) sin(2pft)(1/3)sin(2p(3f)t)(1/5)sin(2p(5f)
t) (1/7)sin(2p(7f)t)
(4/p)Ssin(2pkft)/k for odd k
15
Data Rate and Bandwidth (1)

• Any transmission system has a limited band of
  frequencies
• This limits the data rate that can be carried

16
Data Rate and Bandwidth (2)

• Suppose a digital transmission system is capable
  of transmitting signals with a BW of 4MHz. Let us
  attempt to transmit a square wave signal (i.e. a
  sequence of alternating 0s and 1s. What is the
  achievable data rate?

17
Data Rate and Bandwidth (3)
Case 1 Assume that the square wave is
approximated to this signal.
(4/p) sin(2pft)(1/3)sin(2p(3f)t)(1/5)sin(2p(5f)
t)
BWfupper flower 5f f 4f If f1MHz, then
the BW4MHz. Since T1/f then signal period is
1/1MHz1µs Since one bit occurs every 0.5T then
Data rate1/0.5T2Mbps So, for this particular
example, for a BW of 4MHz, the Data Rate achieved
is 2Mbps
18
Data Rate and Bandwidth (4)
Case 2 Assume that the square wave is
approximated to this signal.
(4/p) sin(2pft)(1/3)sin(2p(3f)t)(1/5)sin(2p(5f)
t)
BWfupper flower 5f f 4f If f2MHz, then
the BW8MHz. Since T1/f then signal period is
1/2MHz0.5µs Since one bit occurs every 0.5T then
Data rate1/0.5T4Mbps So, for this particular
example, for a BW of 8MHz, the Data Rate achieved
is 4Mbps
19
Data Rate and Bandwidth (5)
Case 3 Assume that the square wave is
approximated to this signal.
(4/p) sin(2pft)(1/3)sin(2p(3f)t)
BWfupper flower 3f f 2f If f2MHz, then
the BW4MHz. Since T1/f then signal period is
1/2MHz0.5µs Since one bit occurs every 0.5T then
Data rate1/0.5T4Mbps So, for this particular
example, for a BW of 4MHz, the Data Rate achieved
is 4Mbps
20
Data Rate and Bandwidth (6)

• Conclusions
• In general, any digital waveform has infinite BW
• If a digital waveform is transmitted over any
  medium, the transmission system will limit the BW
  that can be transmitted
• For any given medium, the greater the BW
  transmitted, the greater the cost
• Limiting the BW creates distortions, which makes
  the task of interpreting the received signal more
  difficult
• The more limited the BW, the greater the
  distortion, and the greater the potential for
  error by the receiver

21
2. Analog and Digital Data Transmission

• Data
• Entities that convey information
• Signals
• Electric or electromagnetic representations of
  data
• Signaling is the physical propagation of the
  signal along a suitable medium
• Transmission
• Communication of data by propagation and
  processing of signals

22
Analog and Digital Data

• Analog
• Continuous values within some interval
• e.g. sound, video
• Digital
• Discrete values
• e.g. text, integers

23
Acoustic Spectrum (Analog)
(log scale)
24
Analog and Digital Signals

• Means by which data are propagated
• Analog
• Continuously variable
• Various media
• wire, fiber optic, space
• Speech bandwidth 100Hz to 7kHz
• Telephone bandwidth 300Hz to 3400Hz
• Video bandwidth 4MHz
• Digital
• Use two DC components (binary 0 and 1)

25
Advantages Disadvantages of Digital

• Cheaper
• Less susceptible to noise
• Greater attenuation
• Pulses become rounded and smaller
• Leads to loss of information

26
Attenuation of Digital Signals
27
Components of Speech

• Frequency range (of hearing) 20Hz-20kHz
• Speech 100Hz-7kHz
• Easily converted into electromagnetic signal for
  transmission
• Sound frequencies with varying volume converted
  into electromagnetic frequencies with varying
  voltage
• Limit frequency range for voice channel
• 300-3400Hz

28
Conversion of Voice Input into Analogue Signal
29
Advantages of Digital Transmission

• Digital technology
• Low cost large-scale and very-large scale
  integration technology
• Data integrity
• Longer distances over lower quality lines
• Capacity utilization
• High bandwidth links economical
• High degree of multiplexing easier with digital
  techniques
• Security Privacy
• Encryption
• Integration
• Can treat analog and digital data similarly
• Economies of scale and convenience can be
  achieved by integrating voice, video and digital
  data

30
3. Transmission Impairments

• Signal received may differ from signal
  transmitted
• For Analog signals - degradation of signal
  quality
• For Digital signals - bit errors may occur
• Most significant transmission impairments are
• Attenuation and attenuation distortion
• Delay distortion
• Noise

31
Attenuation

• Signal strength reduces with distance over any
  transmission medium
• Depends on medium
• Received signal strength
• must be enough to be detected
• must be sufficiently higher than noise to be
  received without error
• Attenuation is an increasing function of
  frequency, i.e. the higher the frequency, the
  more the attenuation attenuation

32
Delay Distortion (DD)

• Only in guided media
• It occurs because the propagation velocity of a
  signal through a guided medium varies with
  frequency
• Received signal is distorted due to varying
  delays experienced at its constituent frequencies
• DD is particularly critical for digital signals
• some of the signal components of one bit may
  spill over into other bit positions, causing
  intersymbol interference, which limits the
  maximum data rate over a transmission channel

33
Noise (1)

• Additional signals inserted between transmitter
  and receiver
• Noise is the major limiting factor in
  communication system performance
• Noise can be divided into 4 main categories
• Thermal
• Intermodulation
• Crosstalk
• Impulse noise

34
Noise (2)

• Thermal
• Due to thermal agitation of electrons in all
  electronic devices
• Uniformly distributed across the bandwidth
• Also referred to a white noise
• Intermodulation
• Signals that are the sum and difference of
  original frequencies sharing the same
  transmission medium
• Example mixing of signals at f1 and f2 may
  produce energy at f1f2, which could interfere
  with an intended signal at (f1f2) or (f1-f2)
• Crosstalk
• Unwanted coupling between signal paths
• Antennas or wires may pick up other unwanted
  signals, eg. phone line
• Impulse
• Non continuous, consisting of irregular pulses or
  noise spikes of short duration but of high
  amplitude
• e.g. External electromagnetic interference, such
  as lightning

35
4. Channel Capacity

• As we have seen so far, there is a variety of
  impairments that distort or corrupt a signal. To
  what extent do these impairments limit the
  maximum achievable data rate?
• Channel Capacity is the maximum rate at which
  data can be transmitted over a communication
  channel.
• Data rate
• In bits per second (bps)
• Rate at which data can be communicated
• Bandwidth
• In cycles per second, or Hertz
• Constrained by transmitter and medium

36
(No Transcript)
37
(No Transcript)
38
Nyquist Bandwidth

• Assume a noise-free channel
• If rate of signal transmission is 2B, then a
  signal with frequencies no greater than B is
  sufficient to carry signal rate
• or, given bandwidth B, highest signal rate is 2B
• Given a binary signal, the maximum data rate
  supported by a channel of bandwidth B Hz is 2B
  bps
• Maximum data rate, C, can be increased by using M
  signal levels
• Nyquist formula C 2 B log2M in bps
• However, receiver must be able to distinguish one
  of M possible signal elements. Noise and other
  transmission impairments limit the practical
  value of M.

39
Shannon Capacity Formula

• Nyquists formula indicates that doubling BW,
  doubles the data rate in a noise-free channel.
• In practice, noise is always present. So, let us
  consider the relationship between data rate,
  noise and error rate.
• Faster data rate shortens each bit duration so a
  burst of noise affects more bits
• So, at a given noise level, the higher the data
  rate, the higher the error rate
• Signal-to-Noise ratio (SNR or S/N) expressed in
  decibels
• SNRdB10 log10 (Signal power/Noise power)
• Max channel Capacity is CB log2(1SNR) in bps
• This formula is for error-free capacity and
  assumes white noise. In practice, data rate is
  lower than C.

40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
