Climate Monitoring WEB Interface Using 1_Wire

1
Climate Monitoring WEB Interface Using 1_Wire
Sensors

• Imad Hoteit
• Hassan Wehbe

2
Outline

• Project Summary
• Functional Description
• Modes of Operation
• Database updates
• Flowcharts
• Testing
• Schedule of tasks

3
Project Summary

• The purpose of this project is to set up these
  sensors, create a user-friendly web based
  interface (applet) and a database that will hold
  previous data and provide query abilities to the
  applet.
• The objective of these sensors is mainly
  maintenance.

4
Functional Description

• Hardware Interface
• The sensors will be distributed along two wires
  that go through different rooms of Jobst hall
  these are connected to the HA5 adapter.

5
Functional Description

• Applet
• The applet is running on a web server .
• The applet displays a blueprint of Jobst
  hall,with the location of the sensors in each
  room.
• The applet shows the current readings of the
  sensors

6
Functional Description

• Once you press on the sensor a historical value
  chart appears,showing the previously recorded
  values

7
Functional Description
8
Applet Flowchart
Start
Initialize and Display
Lights
Humidity
Temperature
Room Sensor Is Located in, Value Read, Time of
Reading
Graph Displayed
Room where sensor is shown
9
CGI Script Flowchart
10
Modes of Operation

• Applet
• Display historical data
• Get immediate sensor update
• Sensor Query Daemon
• Discover sensors on network
• Request sensor readings
• Update database

11
Functional Description
12
Database updates

• The MySQL database has five tables
• Temperature
• timestamp, sensorid, temp_R, temp_V
• Light
• timestamp, sensorid, lite
• Humidity
• timestamp, sensorid, temp_R, temp_V, hmd_R, hmd_V
• Data
• sensorid, type, timestamp, value
• Map
• map, sensorid, X, Y

13
Sensor Query Daemon Flowchart
14
Sensor Query Daemon

• The server application uses two classes
• HA5
• Sensor_DB
• The reasons for object oriented programming are
• Anticipated growth
• Ease of debugging
• Clarity of code

15
HA5

• Open connection
• Close connection ? Destructor
• Search all, by family, by condition
• Select one sensor
• Read
• Light switch
• Temperature value
• Humidity ratio

16
Sensors_DB

• Open connection
• Close connection ? Destructor
• Search
• All tables
• By sensorid, by type
• Insert/Update a row
• Delete a rowused for troubleshooting

17
Climate Monitoring WEB Interface

• Questions
• Climwisr
