Title: Routing In Wireless Mesh Networks


1
  • Routing In Wireless Mesh Networks
  • CST593 Final Project
  • by
  • Dilshad Haleem
  • Division of Computing Studies, ASU Polytechnic

2
CST593 Committee
  • Chair Dr. Bruce R. Millard
  • Member Dr. Alan Skousen
  • Member Dr. Timothy E. Lindquist

3
Introduction
  • Wireless Mesh Networks are radio based self
    configuring networks, with minimal infrastructure
    requirements
  • Nodes operate as host and also as a router
  • Reliable, resilient and robust
  • Different than Mobile Ad Hoc Networks

4
Architecture
Reference http//www.primidi.com/2005/01/04.html
5
Difference between WMNs and MANETs
  • Mesh Routers are relatively static
  • No power constraints
  • Traffic concentration may be higher in certain
    paths (hot spots)
  • Number of users

6
Ad Hoc On Demand (AODV)
  • A protocol developed for MANETs
  • Reactive in operation
  • Route discovery and maintenance using control
    packets (RREQ, RREP, RERR and HELLO)
  • Uses minimum hop count as the performance metric

7
Problem Statement
  • Creating Wireless Mesh Network and Ad Hoc Network
    scenarios in OPNET Modeler
  • Simulating AODV in Wireless Mesh and Wireless Ad
    Hoc Networks
  • Performance comparison
  • Implementation of Expected Transmission Count
    (ETX) as a Process Model in OPNET

8
Wireless Ad Hoc Network VS WMN
9
AODV and WLAN Parameters
10
Simulation ResultsEnd to End Delay
  • High Delay is observed in WMN
  • Probable reason, nodes closer to the GW, are
    relaying theirs and other nodes traffic
  • MAC layer Fairness

11
Simulation ResultsRouting Traffic Received
  • More RREQ and RREP in Ad Hoc Network
  • Routes do not change frequently in WMN
  • Mostly in case of node failure or new node
    joining

12
Simulation ResultsRouting Traffic Sent
13
Simulation ResultsThroughput
  • Less throughput is observed in WMN
  • Throughput decreases as the number of hops
    increases

14
Simulation ResultsThroughput of node_7 node_9
  • Node_7 enjoys a higher throughput, than node_9
  • Node_9 is 3-hops away from the Gateway

15
Expected Number of Transmission (ETX)
  • Routing Protocol must be aware of the consequence
    of path selection
  • Routing protocol must be aware of the link
    condition
  • Link layer performance metric, ETX is the loss
    rate of broadcast packets between pair of nodes

16
Implementation of ETX
  • Nodes broadcast probe packets(134 bytes) once per
    second
  • Nodes keep track of the number of probes received
    in 10 seconds
  • Reverse delivery ratio pkt rcvd / pkt sent
  • Forward delivery ratio is obtained from the
    neighbors probe

17
Implementation of ETX in OPNETNode Model
  • Pkt_src processor generates probe packets
  • Calc_ETX module calculates ETX
  • Rcv and xmt modules rcv and tx the packets

18
Implementation of ETX in OPNETCalc_ETX Process
Model (FSM)
  • INIT state performs initialization of State
    variables
  • Time_out state reset the packet count every 10
    seconds and calculates ETX
  • Idle state waits until a packet needs to be sent
    or received

19
Implementation of ETX in OPNETCalc_ETX Network
Model
  • 2 nodes Network Model
  • Data rate is set to 11Mbps

20
Simulation Results of ETX Model
  • Reverse Delivery Ratio pkt rcvd / pkt sent
    10/10 1
  • Forward Delivery ratio, piggybacked
  • on neighbors probe 1

21
Simulation Results of ETX ModelLink ETX
  • Link ETX 1
  • This implied a perfect link
  • As link ETX increases link quality decrease
  • ETX quantify the link

22
Conclusion
  • MANETs routing protocols are not suitable for
    WMNs
  • Simulation confirmed that, throughput decreases ,
    when AODV is used in WMNs
  • Routing protocol should be aware of the link
    condition
  • Implementation of link quality metric (ETX) model
    in OPNET
